Baumr-ag E-force 400 ii User manual

Cordless Pole Chainsaw - E-FORCE

400 II

User Manual

[Revision 1.0 July 2017]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY

DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by

this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

Cordless Pole Chainsaw - E-FORCE 400 II

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you

do not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you

do not follow instructions.

You CAN be INJURED if you

do not follow instructions or

equipment damage may occur.

It is important that you read and

understand the instruction manual before

use and keep the manual in a safe place

for future reference. Safety information

presented here is generic in nature – some

advice may not be applicable to every

piece of equipment.

All safety precautions must be observed to

reduce the risk of personal injury when

operating the equipment.

The term “equipment" refers to your

product, be it electrical mains, battery or

petrol engine powered.

IMPORTANT – Handle the equipment

safely and carefully.

BEFORE USE - If you are not familiar with

the safe operation/handling of this

equipment, or are in any way unsure of any

aspect of suitability or correct use it for

your application, you should complete

training conducted by a person or

organization qualified in safe use and

operation of this equipment, including

fuel/electrical handling and safety.

WARNINGS

•Read all safety warnings and all

instructions. Failure to follow warnings

and instructions may result in electric

shock, fire and/or serious injury.

•Do not operate the equipment in

flammable or explosive environments,

such as in the presence of flammable

liquids, gases or dust. Engine and

equipment may create sparks or heat

that may ignite vapours, dust etc

•Keep clear of moving parts.

•Equipment may be a potential source of

electric shock if misused.

•Do not operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

•Do not allow others to use the

equipment unless they have read this

manual and are adequately trained.

•When using the equipment, basic safety

precautions detailed here must always

be followed to reduce the risk of fire,

electric shock, personal injury and

material damage.

•When wiring electrically powered

equipment, follow all electrical and

safety codes.

•Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting

equipment.

General Work Area Safety

Work areas should be clean and well it.

Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

Personal Safety

Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

Prevent unintentional starting of the

equipment - ensure equipment and power

source switches are in the OFF position

before connecting or moving the

equipment. Do not carry equipment with

hands/fingers touching any controls.

Remove any tools or other items that are

not a part of the equipment from it before

starting or switching on.

Stay alert and use common sense when

operating equipment. Do not overreach.

Keep proper footing and balance at all

times. Do not use equipment when tired or

under the influence of drugs, alcohol or

medication. This equipment is not intended

for use by persons with reduced physical,

sensory or mental capabilities.

You must wear appropriate protective

equipment when operating, servicing, or

when in the operating area of the

equipment to help protect from serious

injury, including eye injury, inhalation of

toxic fumes, burns, and hearing loss.

Always wear eye protection. Protective

equipment such as respirators, non-skid

safety shoes, hard hat, hearing protection

etc should be used for appropriate

conditions. Other people nearby should

also wear appropriate personal protective

equipment. Do not wear loose clothing or

jewellery, which can be caught in moving

parts. Keep hair and clothing away from

the equipment.

If devices are provided for the connection

of dust extraction and collection facilities,

ensure these are connected and properly

used. Use of dust collection can reduce

dust-related hazards.

General Equipment Use and Care

Do not force the equipment. Use the

correct equipment for your application. The

correct equipment will perform better and

be safer within its design parameters. Do

not use the equipment if the ON/OFF

switch malfunctions – any equipment that

cannot be controlled with the ON/OFF

switch is dangerous and must be repaired.

Use the equipment and accessories etc.

in accordance with these instructions,

considering working conditions and the

work to be performed. Using the

equipment for operations different from

those intended could result in

hazardous situations.

Before use, inspect the equipment for

misalignment or binding of moving

parts, loose components, damage or

any other condition that may affect its

operation. If damaged, have the

equipment repaired by an authorized

service centre or technician before use.

Always keep the equipment and

accessories (cutting tools, nozzles, bits

etc) properly maintained. Keep the

equipment, controls and handles dry

and free from dirt, oil and grease.

Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place the equipment in

places where there are flammable

materials, combustible gases or

combustible liquids etc.

The equipment is not weather-proof,

and should not be stored in direct

sunlight, at high ambient temperatures

or locations that are damp or very

humid.

Pole Chainsaw Use and Care

•Never stand directly under the branch

you are trimming. Always position

yourself out of the path of falling

debris.

•Never stand on a ladder or other type

of unstable support while using the

equipment.

•Always use both hands to operate the

equipment. Keep a firm, steady

pressure while cutting.

•Do not use the equipment to cut

branches larger in diameter than the

length of the guide bar.

•Keep other persons away from

cutting end of equipment and at a

safe distance from the work area.

•Do not use the equipment near

electrical power or telephone lines.

Maintain a minimum clearance of 5m

(15') from any power lines.

Cordless Pole Chainsaw - E-FORCE 400 II

General battery and Charging Safety

•Use only with the batteries and battery

charger specified by the manufacturer.

•When battery is charged, disconnect the

charger from the power supply and

remove the battery from the charger.

•Batteries can explode in the presence of

an ignition source, such as a pilot light.

To reduce the risk of serious personal

injury, never use any cordless product in

the presence of open ﬂame. Exploding

batteries can propel debris and

chemicals.

•Do not use the charger in wet areas or

expose it to rain or water.

•Do not open the battery – danger of

short-circuiting and/or explosion.

•Do not attempt to destroy or

disassemble the battery pack or remove

any of its components.

•Do not touch the battery terminals with

metal objects and/or body parts as

short-circuit and/or personal injury may

result.

•Explosion hazard – protect the battery

against heat; for example, direct sunlight

and fire. Do not store batteries in

vehicles or locations subject to heat.

•Explosion hazard – do not open and/or

short-circuit the battery.

•Poison hazard – battery leakage (liquid

ejection). Under extreme conditions,

liquid may be ejected from the battery –

avoid contact. If contact accidentally

occurs, immediately seek medical

attention, and flush with water. If liquid

contacts eyes, immediately seek medical

attention, flush with clean water for at

least 10 minutes. Liquid ejected from the

battery may cause irritation or burns.

•Ensure that the battery charger electrical

cord is not subjected to damage or

stress. Do not operate the battery

charger if it has a damaged electrical

cord or plug.

•For best results, charge batteries in

temperatures between 7°C (45°F) and

40°C (104°F).

•Dispose of non-serviceable batteries in

an environmentally responsible manner

and according to local regulations

General Electrical Safety

•Inspect electrical equipment, extension

cords, power bars, and electrical fittings

for damage or wear before each use.

Repair or replace damaged equipment

immediately.

•Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

•When wiring electrically powered

equipment, follow all electrical and

safety codes.

•Wherever possible, use a residual

current device (RCD).

•Electrically grounded equipment must

have an approved cord and plug and be

connected to a grounded outlet.

•Do not bypass the on/off switch and

operate equipment by connecting and

disconnecting the power cord.

•Do not use equipment that has exposed

wiring, damaged switches, covers or

guards.

•Do not use electrical equipment in wet

conditions or damp locations.

•Do not use electrical cords to lift, move

or carry equipment.

•Do not tie electrical cords in tight knots

and ensure electrical cords do not

present trip hazards.

General Service Information

•Have the equipment serviced or

repaired at authorized service centres

by qualified personnel only.

•Replacement parts must be original

equipment manufacturer (OEM) to

help ensure that equipment safety is

maintained.

•Do not attempt any maintenance or

repair work not described in this

instruction manual.

•After use, the equipment and

components may still be hot – allow

the equipment to cool and disconnect

spark plugs and/or electrical power

sources and/or batteries from it

before making adjustments, changing

accessories or performing repair or

maintenance.

•Do not make adjustments while the

equipment is running.

•Perform all service related activities

under suitable conditions, such as a

workshop etc.

•Replace worn, damaged or missing

warning/safety labels immediately.

•Do not clean equipment with

solvents, flammable liquids or harsh

abrasives.

Cordless Pole Chainsaw - E-FORCE 400 II

Table of Contents

Safety...................................................................................................................................................2

Parts Identification.............................................................................................................................5

Batteries and Battery Charging........................................................................................................6

Charging ....................................................................................................................................................6

Assembly ............................................................................................................................................7

Saw Chain Tension and Adjustment ........................................................................................................10

Adjusting Chain Tension.................................................................................................................... 10

Operation ..........................................................................................................................................11

Maintenance .....................................................................................................................................13

Cleaning...................................................................................................................................................13

Guide Bar Care ........................................................................................................................................13

Saw Chain Sharpening ............................................................................................................................13

Filing Cutter Depth Gauges......................................................................................................................14

Replacing the Saw Chain.........................................................................................................................15

Storage..............................................................................................................................................16

Troubleshooting...............................................................................................................................17

Specifications...................................................................................................................................18

Cordless Pole Chainsaw - E-FORCE 400 II

Parts Identification

No. Name No. Name

1 Chainsaw Blade 11 Pole Locking Collar

2 Guide Bar 12 Telescopic Pole Clamp

3 Saw Sheath 13 Grip

4 Chain Lubricant Tank Cap 14 Strap

5

Chain Tensioner Lock Nut

15

Trigger Safety Lockout

6

Chain Tensioner

16

Trigger

7 Sprocket Cover 17 Handle

8 Angle Adjustment Button 18 Battery Release Button

9 Pole Connector 19 Battery Pack

10 Extension Pole

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Batteries and Battery Charging

Batteries may come supplied in a low-charge condition for shipping reasons – charge before

use. • A battery that is new or has not been used for a long period does not charge to full

capacity until after approximately 5 charge/discharge cycles. • Do not recharge batteries after using them if

they are not to be used for an extended period. • Recharge batteries only as and when required. • If the

battery is warm after use, allow it to cool before charging, otherwise it may not fully charge. • Use only with

the batteries and battery charger specified by the manufacturer. • Batteries can explode in the presence of

an ignition source, such as a pilot light. Never use any cordless product in the presence of open ﬂame.

Exploding batteries can propel debris and chemicals. • Do not use the charger in wet areas or expose it to

rain or water. • Ensure that the battery charger electrical cord is not subjected to damage or stress. Do not

operate the battery charger if it has a damaged electrical cord or plug. • Do not open the battery – danger of

short-circuiting and/or explosion. • Do not touch the battery terminals with metal objects and/or body parts as

short-circuit and/or personal injury may result. • For best results, charge batteries in temperatures between

7°C (45°F) and 40°C (104°F). • Dispose of non-serviceable batteries in an environmentally responsible

manner and according to local regulations. Charging time varies for different battery types depending on

battery capacity and charger output etc. • To prolong battery life, avoid leaving the battery pack on charge for

extended periods (over 30 days without use). • During charging, the battery may become warm and some

noise may be emitted – this is normal.

Charging

Generally, if the equipment stops during use, the cutting power reduces, or the motor slows considerably, it

indicates that the battery needs charging.

The battery pack has indicators that shows current charge status. To use the

function, press the button (A) on the battery – indicators for 25/50/75/100% charge

illuminate as applicable for a brief period

The battery charger has charge status LED indicators that illuminate and flash in

various combinations:

•Red – Charger ready.

•Red Flash - Battery is currently too hot and cannot be charged. The battery pack should be allowed to

cool.

•Green Flash – Charging.

•Green – Battery charged.

•Red Flash / Green Flash - Battery

fault detected.

1. Plug the charger (B) into an electrical

outlet and switch on.

2. Slide the charging dock (C) fully into

the battery (D). The battery charger

indicator LEDs will indicate battery

charge status. Charging takes

approximately 4 hours from fully

discharged.

3. When the battery is fully charged,

unplug the charger from power supply and remove the battery pack.

A

C

B

D

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Assembly

Cutting edges on the saw chain are sharp. Use protective gloves when handling the saw chain.

1. Remove the battery from the machine.

2. Attach the telescopic pole (A) and extension pole (B) together – align the poles so the "key" (AA) in the

telescopic pole aligns with the notch (BB) in the end of the extension pole, then push the two parts fully

together.

3. Slide the locking collar (C) over the end of the extension pole, then rotate it right (clockwise) to screw the

parts together. Firmly tighten the collar by hand.

BB AA

B

A

C

BB

AA

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

4. To adjust the length of the telescopic tube, if necessary (this can also be performed out before

connecting the extension pole), unlock the clamp (D).

5. Slide the telescopic section (CC) to the desired position, then place the clamp in the locked position.

Note that you can adjust the tightness of the clamp using the adjustment nut (E), if required – tighten the

nut to increase clamping pressure.

6. Position the strap clamp (F) as required, then tighten the screw to secure it. Clip the strap buckle (G) to

the strap clamp.

D

E

CC

F

G

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

7. Fill the chain lubricant tank with suitable oil, then securely tighten the tank cap (DD).

8. Insert the battery pack (H) – align the slots and grooves in the battery / tool and slide the battery pack

into the cavity at the back of the tool handle. Press and hold down the battery release button (EE) when

inserting and release the button when the battery is fully inserted. To remove the battery pack, press and

hold down the battery release button, then withdraw the battery from the tool.

Fully charge the battery before using it for the first time.

G

DD

EE

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Saw Chain Tension and Adjustment

Remove the battery from the tool before servicing. Severe injury or death could

occur from contact with a moving chain. • Cutting edges on the chain are sharp. Use

protective gloves when handling chain. • The saw chain tension is set at the factory; however, a new chain

will stretch. Check chain tension frequently during the first 2 hours of operation. • Before checking chain

tension, allow the saw chain to cool. • Do not over-tension chain. Over-tensioning will cause excessive wear

and will reduce the life of the guide bar and chain. Over-tensioning also reduces the number of cuts per

battery charge.

1. Remove the battery from the tool.

2. Place the tool on a firm, level surface to check chain tension.

3. Pull the chain with light force approximately 3mm (1/8") from the bottom of the guide bar, then release it

– if the chain lightly snaps back into place, tension is correct. A "sag" between the chain and guide bar of

up to 1.5mm is acceptable.

Adjusting Chain Tension

1. Loosen the chain tensioner lock nut (H). Do not remove the nut, just loosen it so the tensioner (I) can be

rotated.

2. Rotate the tensioner to the right (clockwise) until the chain is correctly tensioned.

3. Double-check the chain tension.

4. Firmly tighten the chain tensioner lock nut by hand.

H

I

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Operation

Never stand directly under the branch you are trimming. Always position yourself

out of the path of falling debris. • Never stand on a ladder or other type of unstable

support while using the equipment. • Always use both hands to operate the equipment. Keep a firm, steady

pressure while cutting. • Do not use the equipment to cut branches larger in diameter than the length of the

guide bar. • Keep other persons away from cutting end of equipment and at a safe distance from the work

area. • Do not use the equipment near electrical power or telephone lines. Maintain a minimum clearance of

5m (15') from any power lines.

1. Ensure that the chain lubricant tank is filled.

2. Insert a charged battery.

3. Use both hands to firmly grip the tool at the designated grip areas, and use the strap when operating the

tool. Thumbs and fingers must wrap around the handle and pole.

4. Make sure your footing is firm. Keep your feet apart, and spread your weight evenly on both feet.

5. When ready to make a cut, press in trigger lockout button and squeeze the trigger to switch the motor

ON. Releasing trigger will switch the motor OFF. Make sure saw is running before starting a cut.

6. When starting a cut, place the moving chain against the wood. Hold the tool firmly against the wood to

avoid possible bouncing or skating (sideways movement) of the saw.

7. Remove the saw from the cut with the saw running at full speed.

8. Release the trigger to switch the tool OFF. Make sure the chain has stopped completely before setting

the tool down.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Maintenance

Remove the battery from the tool before servicing. Severe injury or death could

occur from contact with a moving chain. • Cutting edges on the chain are sharp. Use

protective gloves when handling chain. • Harsh operating environments such as extreme temperatures, dust

etc may necessitate more frequent maintenance. • Maintenance frequencies are based on general factors

including a maximum use of approximately 300 hours per year. Apply common-sense when following the

maintenance schedule based on your actual use of the product. • Keep reasonable records of maintenance

activities for reference. Failure to follow the maintenance schedule, using incorrect or non-compatible

accessories or replacements parts, or general negligence may result in making the product warranty

void.

Cleaning

•Use a brush to remove wood particles and saw dust from the tool.

•Clean the saw body using a soft cloth dampened with a mild detergent

mixture. Do NOT use ammonia, abrasives, solvents or flammable liquids

to clean the tool. Do NOT submerge the tool in any liquids.

Guide Bar Care

Uneven wear causes most guide bar problems. Incorrect sharpening of the chain cutters and depth gauge

settings often cause this. When the guide bar wears unevenly, the chain bar groove tends to widen. This

causes chain clatter and rivet popping and makes it difficult to cut straight. A worn or damaged guide bar is

unsafe. Replace the guide bar if this occurs.

Inspect the guide bar before sharpening the chain and regularly maintain the guide bar, as follows:

1. Remove the saw chain and guide bar from the tool.

2. Remove any sawdust from the guide bar groove using a putty knife

or similar to get to the bottom of the groove.

3. Clean the chain oil slots after each day of use.

4. Remove any burrs from sides of guide bar, using a file. Ensure that

the edges are square.

Replace guide bar if the:

•Bar is bent or cracked.

•Inside groove of the bar is badly worn.

Saw Chain Sharpening

Keep the chain sharp to maintain tool efficiency and safety. A dull chain will cause undue sprocket, guide

bar, chain, and motor wear. If you must force the chain into the wood and cutting creates only sawdust with

few large chips, the chain is dull. To sharpen the chain, you will need.

•4mm (5/32") round file.

•Depth gauge tool.

•File guide.

•Vice.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

•Medium sized flat file.

•30° filing guide.

Sharpening Cutters

1. Tension the chain.

2. Clamp the guide bar in a vice to hold it steady. Be careful NOT to

clamp the chain.

3. Press a 4mm (5/32") round file (attached to a 30° file guide) into the

groove between top plate and depth gauge on chain. The file guide

should rest on both the top plate and depth gauge (see figure at the

right).

File at the midpoint of guide bar. The illustration shows the file

guide placement and filing direction for sharpening the cutters

on the left-side of the chain.

4. Hold the file guide level. Ensure the 30° mark on the file guide is

parallel to centre of the guide bar. This will ensure that you file

cutters are sharpened at a 30° angle to the guide bar.

5. File from inside towards outside of the cutter until it is sharp. File in

this one direction only.

Two or three strokes with the file should sharpen each cutter.

Filing Cutter Depth Gauges

The cutter depth gauge clearance reduces as cutters are

sharpened. After every second or third sharpening, reset the cutter

depth gauges.

1. Place depth gauge tool (.025") firmly across top of two cutters.

Make sure depth gauge enters the slot in the depth gauge tool.

2. Using a medium flat file, file the depth gauge level with the

depth gauge tool.

3. Remove the depth gauge tool. Using a flat file, round off the

front corner of the cutter depth gauge. After several hand filings,

have authorized service centre or sharpening service machine

sharpen the chain. This will insure even filing.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Replacing the Saw Chain

Do NOT clamp the chainsaw in a vice to replace the saw chain or guide bar. • Ensure that the chain

cutters are facing the correct direction. If the chain is installed backwards, the tool will vibrate badly

and will not cut.

Replace the saw chain when the cutters are too worn to sharpen further or if the chain breaks. Only use

replacement chains of the correct type. It is recommended to replace the drive sprocket when replacing the

chain. This will maintain proper driving of chain.

1. Loosen the chain tensioner lock nut, then rotate

the tensioning wheel to the left (anti-clockwise) to

remove all tension form the chain.

2. Continue loosening the chain tensioner lock nut

until the sprocket cover assembly can be

removed.

3. Remove the saw chain from the guide bar.

4. Place the new chain around the drive sprocket,

and along the top groove of the guide bar, and

around the guide bar nose. Position the chain so

the cutting edges on top of the guide bar face

toward the guide bar nose (see images and

indicator on the tool side cover).

5. Holding the guide bar and chain, re-install the

sprocket cover into position.

6. Rotate the chain tensioner lock nut right (clockwise) to

secure the sprocket cover, however, do NOT fully

tighten.

7. Set the chain tension.

8. Firmly tighten the chain tensioner lock nut by hand.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Storage

Cutting edges on the saw chain are sharp. Use protective gloves when handling the saw chain.

If the tool is to be stored for more than 30 days, follow steps below:

1. Remove the battery from the tool.

2. Charge the battery.

3. Remove and clean the guide bar and chain. Clean the guide bar and chain by soaking in petroleum

based solvent or mild soap and water mixture.

4. Dry the guide bar and chain.

5. Place the chain in container filled with oil to prevent corrosion.

6. Wipe a thin coating of oil over the surface of the guide bar.

7. Clean the saw body.

8. Store the tool and battery with the chain sheath over the guide bar in a secure, dry location out of the

reach of children.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Troubleshooting

Do not have the motor running during inspection and maintenance unless specifically

required. • The machine should be cool enough to touch before performing

maintenance activities. • Some maintenance activities may be beyond the scope of some users. Do NOT

attempt procedures that you are not comfortable with, or do not have the necessary tools, experience or

knowledge for – take the unit to an authorised service centre or qualified technician for servicing.

The following information may assist in identifying a problem and rectifying it.

Difficulty starting the tool.

Possible Fault Action

Incorrect procedure Press the trigger lockout switch and hold in this position, then pull the trigger.

No voltage Ensure the battery is charged and is correctly inserted.

Chain obstructed Remove the battery and remove any obstructions to the chain.

Battery or control switch faulty Have battery and / or machine tested and repaired at an authorised service centre.

Cutting is poor.

Possible Fault Action

Saw chain dull or damaged Sharpen or replace saw chain.

Cutting too much in one pass Adjust the cutting height and rate of mowing to reduce load on the engine. For tall or very

thick grass, cut in several passes. Do not attempt to cut beyond the capacity of the

machine.

Cutting height not suitable Adjust cutting height as required.

Excessive vibration.

Possible Fault Action

Saw chain dull or damaged / guide

bar worn

Sharpen or replace saw chain. Maintain or replace guide bar.

Fasteners loose Check all accessible fasteners for tightness.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Specifications

Battery 40V 4.0Ah Lithium-Ion

Saw Chain 10" Oregon® Double Guard Low Kickback

Chain Speed 4m/s

Bar & Chain Lubrication Automatic

Chain Lubricant Tank Capacity 100ml

Shaft Aluminium

Length 2.2m to 2.7m

Charger 240V SAA approved

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Cordless Pole Chainsaw - E-FORCE 400 II

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety

Consult all documentation, packaging

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.

Before each use, check the product for

loose/broken/damaged/missing parts,

wear or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear or leaks.

Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.

Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.

The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.

This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business

or employee, or financially affect the user, business or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement or service by a technician

may cause financial loss, loss of employee time or an

inconvenience requiring compensation.

If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.
