Baxi Single Channel Digital Programmer Assembly instructions

en
United Kingdom
These instructions should be read in conjunction with the Boiler Installation and Service Instructions.
Please leave with the user when completed.
Instruction manual for Installers and Users
Single Channel Digital Programmer
Override
Extra Hour
Mode
DAY/ PROG RUN
TIME
OK
Holidays
OFF
am
Thu
AUTO
ONCE
CONT
EXT HOUR
+1
+2
+3
ON1
Select

2 EcoBlue Accessories 7212551

Contents
3EcoBlue Accessories
7212551
ection Page
1. Introduction
1.1 General energy information 4
1.2 Description of the device 4
1.3 Designated use 5
1.4 Technical data 5
2. itting the Controller
2.1 Installation and mounting 6
2.2 General siting information 6
2.3 Wiring and wall mounting 6
3. Operation & Configuration
3.1 Quick start guide 7
3.2 Guide to button functions 7
3.3 Commissioning 8
3.4 To alter the time and date 9
3.5 To show a digital time display and change
AM/PM time display to 24 hour clock 10
4. Setting the Heating Programmes
4.1 Running a default programme 11
4.2 Selecting a programme type and
a default programme 12
4.3 Weekly programming days or blocks 13
4.4 5-2 programming 13
4.5 Daily programming 13
4.6 Setting time periods 14
5. Operating Mode
5.1 Using the mode button 15
5.2 Override mode 15
5.3 Extra hour mode 15
5.4 Holiday mode 16
6. Installer Information
6.1 Installer menu 17
6.2 Disposal 19

4 EcoBlue Accessories
1. Introduction
7212551
Warning
Danger! Risk of electric shock! Installation must be carried out by a person competent to do so!
Before removal from backplate, the device must be disconnected from the power supply!
Interferences and changes to the device will invalidate the warranty and guarantee rights.
Maximum diameter of the cable for the terminals is 2 x 2.5 mm2.
Read and observe these instructions fully to ensure the correct operation of the device and a safe
operation.
1.1 General energy information
What is a programmer?...an Explanation for Householders
(as recommended by the Energy Savings Trust)
Programmers allow you to set ‘ON’ and ‘O ’ time periods. Some models switch the central
heating and domestic hot water on and off at the same time, while others allow the domestic hot
water and heating to come on and go off at different times. Set the ‘ON’ and ‘O ’ time periods to
suit your own lifestyle. On some programmers you must also set whether you want the heating and
hot water to run continuously, run under the chosen ‘ON’ and ‘O ’ heating periods, or be
permanently off.
The time on the programmer must be correct. Some types have to be adjusted in spring and
autumn at the changes between Greenwich Mean Time and British Summer Time. You may be
able to temporarily adjust the heating programme, for example, ‘Override’, ‘Advance’, or ‘Boost’.
These are explained in the manufacturer’s instructions. The heating will not work if the room
thermostat has switched the heating off. And, if you have a hot-water cylinder, the water heating
will not work if the cylinder thermostat detects that the hot water has reached the correct
temperature.
1.2 Description of the device
Your single channel programmer provides timing control for your central heating, letting you set ON
and O periods to suit your own lifestyle.
Backlit LCD Display
Real Time Clock
Up to 3 ON/O per day
Automatic summertime / wintertime changeover
Daily, weekly and week-weekend programming possibility
Different running modes: O , AUTO, ONCE, CONTINUOUS and HOLIDAYS
Manual override function
Manual extra hour function
3 different pre-programmed profiles, customisable by user

1. Introduction
5EcoBlue Accessories
7212551
1.3 Designated use
The programmer is used to control central heating zone systems or combi boilers.
Suitable for use in dry rooms only!
Do not install in the vicinity of devices which generate inductive discharges (motors, transformers,
etc.)
1.4 Technical data
Dimensions H x W x D (mm) 95 x 148 x 36
Weight g (approx.) 285
Power supply 230 V AC / 50-60 Hz
Power consumption < 3 W
Power reserve >2h
Switching capacity 3 A 250 V ~ resistive, cos φ = 1
3 A 250 V ~ inductive, cos φ = 0.6
Time display 24 h or 12 h AM/PM format
Time setting resolution:
- Time of day 1 min.
- Programmes / min. switching 1 min.
Programmes Selectable (daily , weekly, or week-weekend)
Number of switchings per day 3 ON/O pairs
(2 ON/O pairs selectable)
Operating temperature range 0°C ... + 45°C
Ambient temperature -20°C ... + 55°C
Humidity range 10 to 90% RH, non condensing
Accuracy Type ± 1 sec./day at +20°C
Terminal capacity 2 x 2,5 mm2
Protection type IP 30
European standards EN60730-2-7
Compliant with building regulations
(Part L UK) (Part J Scotland)

6 EcoBlue Accessories
2. itting the Controller
7212551
2.1 Installation and mounting
Warning
Danger! Risk of electric shock! Installation must
be carried out by a person competent to do so!
2.2 General siting information
Identify a suitable site to locate the unit. ig. 1
gives guidance on optimum positioning and siting
restrictions.
Do not place behind curtains.
Do not place above or below sources of heat.
2.3 Wiring and wall mounting
Undo the retaining screw underneath the
programmer. ig. 2(a). Insert a screwdriver as
shown and carefully prise the programmer loose
and lift away from backplate.
Wiring can be routed from behind or if surface
mounted, through the breakout tab to the left of
the retaining screw at the bottom of the back
plate.
ix the backplate to the wall using the screws
provided.
Connect the wiring into the backplate connectors
as shown in ig. 3.
The input to terminal 1 may be supplied from the
mains supply or from the boiler wiring
connections as appropriate to the appliance
used.
Please consult the relevant boiler instructions for
further guidance.
Replace the programmer on the backplate and
press firmly down to fully engage the contact pins
and tighten the screw underneath the
programmer.
1.5 m
NL1234
N
INPUT
OFF
ON
OUTPUT TO ROOM
THERMOSTAT / BOILER
timeswitch /
programmer
wallplate
L
Fig. 3. Wiring diagram
Fig. 2. Mounting the controller
Fig. 1. Siting
a
d
e
c
b

3. Operation & Configuration
7EcoBlue Accessories
7212551
3.1 Quick start guide
1. Connect mains power.
2. Press OK three times.
The default Standard programme runs.
You can control the unit with the Override, Extra
Hour or Mode buttons.
Please read the full instructions if you want to
know more.
3.2 Guide to button functions
A Day of the week indicator
B Current day, month, year
C Central heating operating mode indicator
D Central heating override button
E Central heating extra hour button
Central heating operating mode button
G Central heating indicator lamp
H Central heating extra hour indication
I Central heating programming period indication
J Select indicator lamps
K Select
L OK button
M “-” and “+” button
N1Holiday button
O1Holiday icon
P Information text line
Q Analogue clock / current time
R Warning icon
Override
Extra Hour
Mode
DAY/ PROG RUN
TIME
OK
Holidays
OFF
am
Thu
AUTO
ONCE
CONT
EXT HOUR
+1
+2
+3
ON1
Select
A
D
R
Q
P
O1
N1
M
E
F
G
H
I
J
LK
BC
Override
Extra Hour
Mode
OK

Select day with + and -
buttons and confirm with OK.
DAILY The same ON/O time schedule is used every day.
WEEKLY A different time schedule can be programmed for
each day.
5-2 One time schedule is used for Mon- ri and a different
one can be used for Sat & Sun.
OK
2
Select your program type with +
and - buttons and confirm with OK.
OK
1
Select month with + and -
buttons and confirm with OK.
OK
3
Select year with + and -
buttons and confirm with OK.
OK
4
Select hour with + and -
buttons and confirm with OK.
OK
5
Select minutes with + and -
buttons and confirm with OK.
OK
6
The date and time are saved.
The programmer goes to
RUN mode
OK
7
8 EcoBlue Accessories
3. Operation & Configuration
3.3 Commissioning
Connect the programmer to the power. The product name and version are displayed briefly.
7212551

3. Operation & Configuration
3.4 To alter the time and date
9EcoBlue Accessories
7212551
Press the SELECT buttons until DAY/TIME light is lit.
DAY/ PRG RUN
Select
TIME
1
Select day with + and -
buttons and confirm with OK.
OK
2
Select month with + and -
buttons and confirm with OK.
OK
3
Select year with + and -
buttons and confirm with OK.
OK
4
Select hour with + and -
buttons and confirm with OK.
OK
5
Select minutes with + and -
buttons and confirm with OK.
OK
6The date and time
are saved.
Press the right hand
SELECT button to
select RUN mode.
OK
7
DAY/ PRG RUN
Select
TIME

10 EcoBlue Accessories
3. Operation & Configuration
3.5 To show a digital time display and change AM/PM time display to 24 hour clock
7212551
DAY/ PRG RUN
Select
TIME
OK
1
OK
2
OK
3
Press the SELECT
buttons until
RUN light is lit.
Press and hold + & - buttons
together for 10 seconds. Press OK
Press OK
OK
4
Press -
OK
5
Press OK
OK
6
Press OK
OK
7
Press + or -
OK
8
Press OK
Press + seven times
to exit menu.

4. Setting the Heating Programmes
4.1 Running a default programme
11EcoBlue Accessories
7212551
The default programmes can be selected in the INSTALLER MENU. To access the installer’s
menu, the device must be working in RUN mode.
Default programme TD (DEFAULT)
Daily ON1: 06:30 am ON2: 12:00pm* ON3: 04:30 pm
O 1: 08:30 am O 2: 12:00pm* O 3: 10:30 pm
Weekly ON1: 06:30 am ON2: 12:00pm ON3: 04:30 pm
O 1: 08:30 am O 2: 01:00pm O 3: 10:30 pm
5-2 ON1: 06:30 am ON2: 12:00pm ON3: 04:30 pm Mon - ri
O 1: 08:30 am O 2: 01:00pm O 3: 10:30 pm
ON1: 06:30 am ON2: 12:00pm ON3: 04:00 pm Sat - Sun
O 1: 09:30 am O 2: 01:00pm O 3: 10:30 pm
Default programme HOME
Daily ON1: 06:30 am ON2: 12:00pm* ON3: 04:00 pm
O 1: 09:30 am O 2: 12:00pm* O 3: 11:00 pm
Weekly ON1: 06:30 am ON2: 12:00pm ON3: 04:00 pm
O 1: 09:30 am O 2: 01:00pm O 3: 11:00 pm
5-2 ON1: 06:30 am ON2: 12:00pm ON3: 04:30 pm Mon - ri
O 1: 09:30 am O 2: 01:00pm O 3: 11:00 pm
ON1: 06:30 am ON2: 12:00pm ON3: 04:00 pm Sat - Sun
O 1: 09:30 am O 2: 01:00pm O 3: 11:30 pm
Default programme ECO
Daily ON1: 06:30 am ON2: 12:00pm* ON3: 05:30 pm
O 1: 07:30 am O 2: 12:00pm* O 3: 10:00 pm
Weekly ON1: 08:30 am ON2: 12:00pm ON3: 05:30 pm
O 1: 09:30 am O 2: 01:00pm O 3: 10:00 pm
5-2 ON1: 06:30 am ON2: 12:00pm ON3: 05:30 pm Mon - ri
O 1: 07:30 am O 2: 12:00pm O 3: 10:00 pm
ON1: 08:30 am ON2: 12:00pm ON3: 05:30 pm Sat - Sun
O 1: 09:30 am O 2: 01:00pm O 3: 10:30 pm
Press OK
Press -
Three programme types are possible on the programmer
DAILY The same ON/O time schedule is used every day.
WEEKLY A different time schedule can be programmed for each day.
5-2 One time schedule is used for Mon- ri and a different one can be used for Sat & Sun.
or each programme type, three default programmes are provided. These have been designed to
provide heating at typical times throughout the day. The default programmes give you a starting
point that you can personalise to your own requirements, please see the section 4.3 - 4.5.
You can choose the desired programme in the INSTALLER MENU as shown overleaf.
Every programme has three pairs of ON/O switching times per day.
Each time can be set between 3.00 am and 2.50 am (on the next day).
*On/off periods with the same time cancel out - no switching will occur.

12 EcoBlue Accessories
4. Setting the Heating Programmes
4.2 electing a programme type and a default programme
7212551
DAY/ PRG RUN
Select
TIME
OK
1
OK
2
OK
3
OK
4
Press OK.
Press + four times until
program type is displayed.
Press OK.
With the + & - buttons, scroll
through and select
programme type.
Press OK to select.
OK
5
OK
6
Press +.
OK
7
With the + & - buttons, scroll through and
select setting (STD,HOME or ECO).
Press OK to select.
Press + twice to leave menu.
Press OK to select.
Press the SELECT
buttons until
RUN light is lit.
Press and hold + & -
buttons together for
10 seconds.

4. Setting the Heating Programmes
4.3 Weekly programming days or blocks
13EcoBlue Accessories
7212551
DAY/ PRG RUN
Select
TIME
OK
Thu Fri Sat SunWedTueMon
ON1
am
On DAILY programme, all days are automatically
selected and the setting for the first ON period is
displayed.
Go to Section 4.6.
OK
Mon
Days
DAY/ PRG RUN
Select
TIME
1Press the SELECT
buttons until PRG
light is lit.
Use +/- to choose a
day to set the
programme for.
Press OK.
OK
Mon Tue Wed Thu Fri
Days
Press the SELECT buttons until the PRG light is lit.
On 5-2 programme, Monday - riday can be selected
and Saturday - Sunday selected as separate blocks.
Use +/- to choose the required block of days.
Press OK. Go to Section 4.6.
OK
Mon
2
To set the programmer
for more than one day,
press OK.
OK
Mon
4
OK
Mon Tue
Days
3
Use +/- to choose
additional days.
Press OK.
Repeat this process
until all the desired days
have been selected. On the last day selected,
choose NO for ADD
DAYS and press OK.
Go to Section 4.6
You have the option to edit each day individually or you can create dayblocks, e.g. Tue, Wed, ri
and Sat, where you can set the same ON and O sequence.
Days you do not select will keep the preset values.
4.4 5-2 programming
4.5 Daily programming

14 EcoBlue Accessories
4. Setting the Heating Programmes
4.6 etting time periods
7212551
DAY/ PRG RUN
Select
TIME
OK
Thu Fri Sat SunWedTueMon
ON1
am
1Once the required
days have been
selected, the first ON
time is displayed.
Press + & - to
adjust ON1 time.
Press OK.
OK
Thu Fri Sat SunWedTueMon
OFF1
am
2
Press + & - to
adjust O 1 time.
Press OK.
OK
Thu Fri Sat SunWedTueMon
ON2
pm
3
OK
Thu Fri Sat SunWedTueMon
OFF2
pm
4
Press + & - to
adjust O 2 time.
Press OK.
Press + & - to
adjust ON2 time.
Press OK.
OK
Thu Fri Sat SunWedTueMon
ON3
pm
DAY/ PRG RUN
Select
TIME
5
OK
Thu Fri Sat SunWedTueMon
OFF3
pm
6
7
Press + & - to
adjust O 3 time.
Press OK.
The screen returns to SELECT
DAYS (or to ON1 for DAILY
programmes).
Press the SELECT buttons until
RUN light is lit.
The programme is now saved.
Press + & - to
adjust ON3 time.
Press OK.
If you make any changes, you must
press OK to confirm ALL ON/O pairs
before pressing the SELECT button to
return to the RUN mode otherwise your
changes will be lost.

5. Operating Mode
15EcoBlue Accessories
7212551
5.1 Using the mode button
The operating mode may only be changed when RUN mode is
activated (green indicator lamp RUN must be ON). Pressing
the MODE button cycles through the following options:
OFF The system will remain OFF.
AUTO The system will be switched ON and OFF according
to the set programme.
ONCE The heating will come on at the first programmed
ON time and go OFF at the last programmed OFF
time.
CONT The system will remain ON continuously.
5.2 Override mode
The Override function (temporary programme override) allows
the user to end the current running programme prematurely or
start a programme running before its scheduled start. This
depends on the current channel status. The Override function
applies only to the current program and remains active until
the next programme change. After that, the programmer
returns to AUTO mode.
The Override function is only available when the device is
running in AUTO and ONCE operating mode.
Press OVERRIDE once to activate.
Press OVERRIDE again to cancel.
5.3 Extra hour mode
The extra hour button allows you to switch the system ON for
up to 3 extra hours without altering the programme. When the
blue central heating indicator lamp is O , pressing the
EXTRA HOUR button switches the heating ON for just one
hour. When the blue central heating indicator lamp is ON,
pressing an EXTRA HOUR button extends the programmed
ON period by one hour. urther presses of the EXTRA HOUR
button will increase the extra hour period by one hour for each
button press, up to a maximum of 3 hours. To cancel the extra
hours, press the EXTRA HOUR button until the message EXT
HOUR disappears from the display. The system returns to
previous status.
OFF OFFOFF ONON
OFF
OFF
Example 1
Example
AUTO mode
OFF
Back to AUTO
ONON
ON OFF
OFF
Example 2
OFF
Back to AUTO
ON
OVERRIDE
OVERRIDE
DAY/ PRG RUN
Select
TIME
OK
Override
Extra Hour
Mode
OFF
AUTO
ONCE
CONT
+1
+2
+3
ON1
OFF OFFOFF ONON
ON ON
OFF OFFOFF
(1 to 3 hours)
(1 to 3 hours)
Example 1
OFF
ON
ON OFFOFF
Example 2
OFFON
Extra Hour
Extra Hour
Example
AUTO mode

16 EcoBlue Accessories
5. Operating Mode
7212551
5.4 Holiday mode
The Holiday function allows you to switch O
your heating system when you are away from
home, but resumes normal operation on the day
of your return.
1. Make sure the device is working in RUN
mode.
2. Press the HOLIDAY button.
3. Select desired numbers of days, + or - and
confirm with OK.
Holiday mode is activated.
To cancel the Holiday function, just press the
HOLIDAY button again. If you use the holiday
function during winter you should ensure that you
have a secondary frost protection device in your
system to prevent frost damage.
DAY/ PRG RUN
Select
TIME
OK
OFF
AUTO
ONCE
CONT
+1
+2
+3
ON1
Holidays

6. Installer Information
17EcoBlue Accessories
7212551
6.1 Installer menu
The programmer has a special installer’s menu
where some features can be adjusted to suit your
lifestyle or preferences. To access to installers
menu (INST MENU) the device must be working
RUN mode (green indicator lamp RUN must be
ON).
To save your settings, continue scrolling through
the menu options with + key, until you once again
see INST MENU / – OK + and leave the
installer’s menu with the + key.
To cancel the installer’s menu, press the select
button.
The following settings are possible:
DAY/ PRG RUN
Select
TIME
OK
1
OK
2
OK
3
Press the SELECT
buttons until
RUN light is lit.
Press and hold + & - buttons
together for 10 seconds. Press OK
Press + or - to scroll
through installer menu

18 EcoBlue Accessories
6. Installer Information
7212551
6.1 Installer menu
DIGI CLOCK: Shows the current time (hours/minutes) in a digital and analogue clock format
Setting possibilities:
NO: Digital clock not shown (Default value).
YES: Digital clock shown. If digital clock is set YES, you can choose between 12 HRS (AM-PM) or
24 HRS format.
BACKLIGHT: Setting possibilities:
PERMANENT ON: Backlight always ON.
PERMANENT O : Backlight always O .
BUTTON PRESSED: Backlight ON when any pushbutton is pressed. Backlight goes O 20
seconds after the last button press (Default value).
/W CHANGE: Automatic Summer/Winter time change. Summer time starts on the last Sunday of
March (1:00 am to 2:00 am) and ends on last Sunday of October (2:00am to 1:00am), then Winter
time starts.
Setting possibilities:
ON: S/W time change will be done automatically (Default).
OFF: S/W time change must be done manually.
PROG TYPE: Menu to select daily, week-weekend, weekly programming. This value will be
applied by central heating programming method.
Setting possibilities:
Daily: All days (Monday - Sunday) are programmed with the same ON/O time schedule.
Weekly: You can program each day (Monday, Tuesday, ...) with a different ON/O time schedule
5-2: You can program Monday - riday with a ON/O time schedule and Saturday - Sunday with
a different one.
NR PERIOD : The number of adjustable time periods defined by ON-O pairs to control the time
programmes.
Setting possibilities:
3 ON-O : adjust maximum 3 ON-O time periods (Default value).
2 ON-O : adjust maximum of 2 ON-O time periods.
DEFAULT PRG : Time programme that will appear by default when running in AUTO mode or as
base point to customize according to users lifestyle.
Setting possibilities:
STD
HOME
ECO
or detailed explanation of the profiles, see Section 4.1 “Running a default programme”
RE ET: Reset all parameters of installation menu to factory default.
To leave the installer’s menu press the + key.

6. Installer Information
19EcoBlue Accessories
7212551
6.2 Disposal
Dispose of the packaging materials correctly
according to legal requirements and regulations.
Please recycle where possible.
Do not throw electrical and electronic
components in the bin. These should be taken to
a recycling centre.

All descriptions and illustrations provided in this leaflet have been
carefully prepared but we reserve the right to make changes and
improvements in our products which may affect the accuracy of the
information contained in this leaflet. All goods are sold subject to our
standard Conditions of Sale which are available on request.
7212551 - 1 (03/14)
BAXI
A Trading Divi s i o n of Baxi H ating UK Ltd ( 3879156)
Brooks Hous , Cov ntry Road, Warwick. CV34 4LL
W bsit www.baxi.co.uk
&o
