The Elevated Listening (EL) two and three way
satellites offer phenomenal performance. All
speakers in this series feature injection-woven
woofer cones with .75 inch Mylar tweeters (plus a
2" poly-cone mid on the ELC 6903). These speakers
all have built in crossovers handle the frequency
division, so you don't have to. The 5.25, 6.5, and
6x9 inch EL Satellites also come equipped with a
hot looking grille that looks great on or off-the
decision is yours!
The company that revolutionized the Amplfied Subwoofer nearly 20 years ago is changing the way people
party in their car again! With the new EL Party Packs, there's simply no easier way to get tons of bass in
your trunk. Featuring hand selected components, specifically built enclosures, custom amplifier endplates,
and custom stitching make these monsters a perfect solution for those who want all the performance and
custom look of a high end system, but would rather spend their time partying in the car instead of working
on it. With Party Packs that range in size from the single 10 inch woofer with a 190 watt amplifier, to the
MASSIVE dual 15 inch party pack with 500 watt amplifier, there's a Party Pack that's just right for you.
The Bazooka satellite speakers offer a
stunning combination of looks and
performance. With their “injection woven”
woofer cones and aluminum dome tweeters,
these speakers are designed to recreate an
audio soundstage unlike any other. Add to that
the striking black and aluminum cosmetic and
you've got the best looking, best sounding
satellite speakers available at any price.
We've been building and designing subwoofers for
over 20 years. That history shows in the all-new
Bazooka branded subwoofers. From their custom
designed basket and motor structure, to the
outrageous cone design, these subwoofers are built
for one purpose - to make all of your friends jealous
with their inferior woofers. After all, no company
can design a woofer better than the one who
revolutionized the subwoofer market 21 years ago
with the invention of the original Bazooka subwoofer!
This year, Bazooka Mobile Audio is taking it to the
next level. To once again raise the bar, we are
introducing an entire new line of audio products
that will give our customers the flexibility to
design a first class system from mild to wild and
within any budget category all from a single family
of products.
Ranging from a mild mannered 60 watt per
channel stereo amp to a whopping 925 watt class
D mono block, the Bazooka amplifiers live up to
their reputation of offering the best dollar to
watt ratio in the industry. The extruded aluminum
heatsink, metal end plates, and new Bazooka logo
badge show that we mean business when it comes
to amplifier design. Audition one of these amps
and hear for yourself what the reviews have
already said - Bazooka offers more bang for the
buck than anyone!
Worried about installation and interface issues?
You don’t have to be. With Bazooka’s F.A.S.T.
system, installation is a breeze! Ideal for leased
vehicles, or vehicles with difficult to interface
with audio systems, the F.A.S.T. harness allows you
to add bass to your system with a quick, plug in
installation--No cutting or splicing of factory
wiring is necessary! Once you’ve connected the
interface cable and the extension cable, simply
plug in your Amplified Bass Tube Subwoofer. It’s
really that simple-and you’ll know it’s done right
the first time, every time!
(See bazooka.com for compatible models)
Models:
BW1014, BW1024,
BW1214, BW1224
Models:
ELTVB10190PP
Models:
EL10190PP, EL12300PP,
EL15500PP
Models:
ELW1014P, ELW1214P,
ELW1514P
Component Woofer
Grill Compatible
GR-S10B/S10C,
GR-S12B/S12C
Component Woofer
Grill Compatible
GR-S10B/S10C,
GR-S12B/S12C
BC COAXIALS EL PARTY PACKS
EL COAXIALS EL COAXIALS
EL WOOFERS
EL AMPLIFIERS
BW WOOFERS
BA AMPLIFIERS
CHIL ACCESSORIES
F.A.S.T ACCESSORIES
ELC5702
ELC4002
ELC5252
ELC6502
ELC6903
ELC3502
ELC4602
BC5702
BC4002
BC5252
BA260, BA1150
BA1300, BA2100
BA1900D
Models:
ELA1190, ELA265
Models:
ELA465, ELA1300.
ELA1500, ELA1800
BA2150HC FAST-1771
BA1500, BA460
BC6502
BC6903
BC3502
BC4602
ELC5702P
ELC4002P
ELC5252P
ELC6502P
ELC6903P
ELC3502P
ELC4602P
For 2006, we've refined the already spectacular lineup
of EL woofers. With PP reinforced paper cones, huge
voice coils, rubber surrounds, foam edge gaskets,
custom baskets and a large magnet with bumped
backplate and rear venting. Like all other Bazooka
woofers, the EL woofers are designed to utilize the
optional Bazooka liquid cooling C.H.I.L. System, a quick
way to get over 50% more RMS power handling
capability. All new for 06 is the 15 inch ELW1514P, the
BIG brother to the EL1214P, the woofer that proved to
audiophiles around the world that a woofer doesn't
have to have a big price tag to deliver big performance.
All new for 2006 is a lineup of EL Coaxials that are
designed to deliver the absolute best value for
upgrading those factory speakers. Available in all the
common OEM replacement sizes, and sharing the
heritage of the Legendary EL Coaxials, these speakers
were designed for easy drop-in installation. All EL P
Coaxials feature poly coated paper cones, mylar
tweeters, and built in crossovers. With shallow
mounting depths, and tweeters that will actually fit
behind the stock grilles in your car, EL Coaxials are the
PERFECT choice for upgrading your sound without
drawing unnecessary attention to your audio system.
In the past 4 years, no other amplifier lineup
has presented more value, more power, and a
better dollar-to-watt ratio than the EL Series
Amplifiers. For 2006, we've taken that a step
further with an all new heatsink that allows
for better cooling, and new circuitry that
makes even more power in the same small,
user-friendly footprint. Available as 2 x 65
watts, 4 x 65, 1 x 190, 1 x 375, 1 x 500, and
1 x 800 watts, there's enough amplification
here to get any system you can dream up!
When cooling more
than one woofer,
this kit helps get the
job done. Includes 2
woofer C.H.I.L. plugs
and hose.
This kit comes
complete with pump,
reservoir, hoses, and
fittings to effective
cool one amp. One
kit can cool up to 4
C.H.I.L. compatible
products. Additional
accessories required
for multiple unit
applications.
For adding additional amps to your
C.H.I.L. system, you need these fitting
kits. 4 fittings per unit – enough for
one amp install.
These individually packaged units
are needed when adding multiple
woofers to a C.H.I.L. system.
Two get the C.H.I.L. hose through
your speaker enclosure; this 2 pack
of through-box fittings will get the
job done.
Another camouflage
innovation from
Bazooka®is the new
stiffening capacitor
hidden within a fire
extinguisher cover.
CP-Kit
CP-Kit-W
RX-FECAPCVR
CHIL-AMPFTG
CHIL-PLUG
CHIL-FTG
Bazooka2006_Foldout.qxp 12/21/2005 11:56 AM Page 1

AMPLIF IERS
ELA265 2 x 65 watts @ 4ohm stereo, 2ohm mono capable 300 watts N/A 25Hz-22kHz
ELA465 4 x 65 watts @ 4ohm stereo, 2ohm mono capable 600 watts N/A 25Hz-22kHz
ELA1190 1 x 190 watts @ 2ohm mono (subwoofer amplifier only) 300 watts N/A 25Hz-250Hz
ELA1300 1 x 370 watts @ 2ohm mono (subwoofer amplifier only) 500 watts N/A 25Hz-250Hz
ELA1500 1 x 500 watts @ 2ohm (subwoofer amplifier only) 750 watts N/A 25Hz-250Hz
ELA1800 1 x 800 watts @ 2ohm (subwoofer amplifier only) 1000 watts N/A 25Hz-250Hz
BA260 2 x 60 watts @ 4ohm stereo, 2ohm mono capable 300 watts N/A 20Hz-20kHz
BA460 4 x 60 watts @ 4ohm stereo, 2ohm mono capable 300 watts N/A 20Hz-20kHz
BA2100 2 x 100 watts @ 4ohm stereo, 2ohm mono capable 500 watts N/A 20Hz-20kHz
BA1150 1 x 150 watts @ 2ohm mono (subwoofer amplifier only) 500 watts N/A 20Hz-250Hz
BA1300 1 x 300 watts @ 2ohm mono (subwoofer amplifier only) 750 watts N/A 20Hz-250Hz
BA1500 1 x 500 watts @ 2ohm (subwoofer amplifier only) 600 watts N/A 20Hz-250Hz
BA2150HC 2 X 300 watts @ 1 ohm stereo, 1 ohm stable, 700 x 1 @ 2 ohm mono 1000 watts N/A 20Hz-20kHz
BA1900D 1 x 900 watts @ 2 ohm mono, 1 ohm stable (subwoofer amplifier only) 1200 watts N/A 20Hz-250Hz
SUBWOOFERS
ELW1014P 10” 4 ohm w/ Paper cone, rubber surround, 1.5” VC, CHIL compatible 300 watts 90 dB 20Hz-250Hz
ELW1214P 12” 4 ohm w/ Paper cone, rubber surround, 2” VC, CHIL compatible 400 watts 93 dB 20Hz-250Hz
ELW1514P 15” 4 ohm w/ Paper cone, rubber surround, 2.5” VC, CHIL compatible 500 watts 87 dB 20Hz-250Hz
BW1014 1014-SVC 1024-DVC 4 ohm w/ Poly-paper cone, foam surround, 2î VC, CHIL compatible 450 watts 87 dB 20Hz-250Hz
BW1214 1214-SVC 1224-DVC 4 ohm w/ Poly-paper cone, foam surround, 2î VC, CHIL compatible 500 watts 89 dB 20Hz-250Hz
RXT114/126 Big triangle, SVC 4 ohm OR DVC 6 ohm w/ P&P cone, rubber surround, 2" VC, CHIL compatible 450 watts 87 dB 20Hz-250Hz
RXT2 Bigger triangle, SVC 4 ohm OR DVC 6 ohm w/ P&P cone, rubber surround, 2" VC, CHIL compatible 450 watts 87 dB 20Hz-250Hz
SATELL ITES
ELC3502P EL 2-way - 3.5” w/ Poly-paper woofer, mylar tweeter 50 watts 89 dB 85Hz-20kHz
ELC4002P EL 2-way - 4” w/ Poly-paper woofer, mylar tweeter 50 watts 88 dB 85Hz-20kHz
ELC4602P EL 2-way - 4”X6” w/ Poly-paper woofer, mylar tweeter 50 watts 88 dB 75Hz-20kHz
ELC5252P EL 2-way - 5.25” w/ Poly-paper woofer, mylar tweeter 75 watts 89 dB 5Hz-20kHz
ELC5702P EL 2-way - 5”X7” w/ Poly-paper woofer, mylar tweeter 75 watts 90 dB 65Hz-20kHz
ELC6502P EL 2-way - 6.5” w/ Poly-paper woofer, mylar tweeter 100 watts 90 dB 65Hz-20kHz
ELC6903P EL 3-way - 6” x 9” w/ Poly-paper woofer, mylar tweeter 100 watts 92 dB 55Hz-20kHz
ELC3502 EL 2-way - 3.5” w/ Poly woofer, mylar tweeter 50 watts 89 dB 85Hz-20kHz
ELC4002 EL 2-way - 4” w/ Poly woofer, mylar tweeter 80 watts 90 dB 85Hz-20kHz
ELC4602 EL 2-way - 4”X6” w/ Poly woofer, mylar tweeter 80 watts 90 dB 75Hz-20kHz
ELC5252 EL 2-way - 5.25” w/ Poly woofer, mylar tweeter 100 watts 92 dB 75Hz-20kHz
ELC5702 EL 2-way - 5”X7” w/ Poly woofer, mylar tweeter 100 watts 93 dB 65Hz-20kHz
ELC6502 EL 2-way - 6.5” w/ Poly woofer, mylar tweeter 120 watts 93 dB 65Hz-20kHz
ELC6903 EL 3-way - 6” x 9” w/ Poly woofer, mylar mid & tweeter 150 watts 94 dB 55Hz-20kHz
BC3502 BC 2-way - 3.5” w/ Poly woofer, aluminum tweeter 50 watts 89 dB 85Hz-20kHz
BC4002 BC 2-way - 4” w/ Poly woofer, aluminum tweeter 80 watts 90 dB 85Hz-20kHz
BC4602 BC 2-way - 4”X6” w/ Poly woofer, aluminum tweeter 80 watts 90 dB 75Hz-20kHz
BC5252 BC 2-way - 5.25” w/ Poly woofer, aluminum tweeter 100 watts 92 dB 75Hz-20kHz
BC5702 BC 2-way - 5”X7” w/ Poly woofer, aluminum tweete 100 watts 93 dB 65Hz-20kHz
BC6502 BC 2-way - 6.5” w/ Poly woofer, aluminum tweeter 120 watts 93 dB 65Hz-20kHz
BC6903 BC 3-way - 6” x 9” w/ Poly woofer, mylar mid & aluminum tweeter 150 watts 94 dB 55Hz-20kHz
RX-55 RX 2 way - 5.25” aluminum woofer w/separate aluminum tweeters, 18db crossover 150 watts 92 dB 65Hz-20kHz
RX-6S RX 2 way - 6.5” aluminum woofer w/separate aluminum tweeters, 18db crossover 150 watts 93 dB 55Hz-20kHz
TUBE SUB S
BT6014 6.5” BAZOOKA tube subwoofer (8 OHM avail.) 100 Watts 100 dB 35Hz-250Hz
BT8014 8” BAZOOKA tube subwoofer (8 OHM avail.) 150 Watts 102 dB 35Hz-250Hz
BT1014 10” BAZOOKA tube subwoofer (8 OHM avail.) 200 Watts 104 dB 35Hz-250Hz
BTA6100, 8100, 10100 6.5”, 8” or 10” dual BTL amplified BAZOOKA tube subwoofer - 100 watt RMS 100 watts N/A 35Hz-85Hz
BT6024DVC 6.5” BAZOOKA DVC tube subwoofer (8 OHM avail.)
BT8024DVC 8” BAZOOKA DVC tube subwoofer (8 OHM avail.) 300 wats 102 dB 30Hz-250Hz
BT1024DVC 10” BAZOOKA DVC tube subwoofer (8 OHM avail.) 400watts 104 dB 30Hz-250Hz
BTA6200, 8200, 10200 6.5”, 8” or 10” MOSFET amplified BAZOOKA tube subwoofer - 150 watts RMS 150 watts N/A 35Hz-250Hz
NOS6 6” RS Bazooka subwoofer with Nitrous Bottle cosmetic finish 200 watts 100 dB 35Hz-250Hz
NOS8 (NOS8P, NOS8W) 8” RS Bazooka subwoofer with Nitrous Bottle cosmetic finish (available Purple, White, or Blue) 300 watts 102 dB 35Hz-250Hz
NOS8A 8” RS Amplified Bazooka subwoofer with Nitrous Bottle cosmetic finish 150 watts N/A 35Hz-250Hz
BOX SUB S/PART Y PACKS
ELTVB10190PP Tri-vent enclosure, 1-ELW1012P 2 OHM woofer, 1-ELA1190 amplifier 300 watts N/A 20Hz-250Hz
EL10190PP Custom slot vented enclosure, 2-ELW1014P woofers, 1-ELA1190 amplifier 300 watts N/A 20Hz-250Hz
EL12300PP Custom slot vented enclosure, 2-ELW1214P woofers, 1-ELA1300 amplifier 500 watts N/A 20Hz-250Hz
EL15500PP Custom slot vented enclosure, 2-ELW1514P woofers, 1-ELA1500 amplifier 750 watts N/A 20Hz-250Hz
TVB-141 Tri-vent MDF enclosure with Rx-T1 subwoofer 450 watts 104 dB 30Hz-250Hz
BL -WA1-2xRXT114 Dual woofer MDF enclosure with 2 - RXT114 900 watts 102dB 25Hz-250Hz
BL -WC1-3xRXT126 Triple woofer MDF enclosure with 3 - RXT126 1300 watts 104 dB 25Hz-250Hz
BL -WB1-2xRXT2 Dual woofer MDF enclosure with 2 - RXT2 1000 watts 104dB 25Hz-250Hz
NOS8P
NOS8A
NOS8, NOS6
Without question, the wildest and most original
subwoofer enclosure design in the history of car
audio. Use it alone, in pairs, or even mount it
next to your existing Nitrous Oxide system. This
8" subwoofer is simply a Bazooka®subwoofer
with the patented Bass Tubes®enclosure
camouflaged to look like a Nitrous bottle.
Available in White, Purple, and Classic Blue to
match the most popular Nitrous Oxide systems
available. This unit comes complete with tank,
cosmetic nozzle, braided line speaker wire, and
a mounting kit. For the completely stealth
installation, the NOS8 is now available as the
NOS8A, equipped right out of the
shipping carton with 150 watt
amplifier with built in crossover
ready to rock!
The company that created the worlds best
automotive tube subwoofer, with it’s innovative
Bass Tubes®enclosure, is setting new standards for
product development with the latest offering of
superior products from a company known and
recognized for innovations.
Several of our products offer features that can only
be found in Bazooka®Mobile Audio products. These
features are part of what differentiates us from the
competition. No other car audio product
manufacturer in the world offers products with
features like:
Simulated Nitrous Oxide bottle Bazooka®subwoofer
(patented)
Liquid cooled woofer motor structures (patented)
Triangular shaped subwoofers (patented)
Tri-Vent enclosure design (patented)
Amplifiers with tuner based cosmetic
upgrades available
Amplifiers with auxiliary amplified
subwoofer interface
Bass Tubes enclosure design (patented)
Cast Aluminum infinitely configurable tube subwoofer
mounting brackets
Amplified tube subwoofers with remote controls
8” 2-way Marine satellite speakers
In 2005 Bazooka®is unveiling the most aggressive
mix of car audio speakers, subwoofers, and amps in
the company’s history. Bazooka, one of the most
widely recognized names in car audio, now offers a
full compliment of products to make your car (or
boat) the hottest ride in town! Check out the new
tube subwoofers, and the revised CHIL system for
liquid cooling the most outrageous gear on the planet.
Bazooka®Mobile Audio
1-800-THE-TUBE
www.bazooka.com
2006
PRODUCT
GUIDE
, SAS, BAZOOKA, BASS TUBES, and LISTEN TO YOUR EARS are registered trademarks of Southern Audio Services, Inc. BAZOOKA subwoofer speaker systems exclusively
incorporate the revolutionary BASS TUBES patented subwoofer enclosure design available only from SAS. PAT. NO. 4,567,959 • PAT. NO. 5,097,513. ©Southern Audio Services, Inc. All rights reserved.
NOS8W
NOS TUBES
Model Number Basic Product Description Speaker Power Handling/
Amp Max power 1W Sensitivity Freq. Resp. +/-3dB
Please go to www.bazooka.com or refer to the specific products owner’s manual fo detailed specifications
Following the success of the TVB-141,
Bazooka®makes it easier than ever to put
the world's best triangular subwoofers in
your car. These hot new enclosures are
available in dual T1, dual T2, and the
awesome Triple T1 configurations. With gold
plated binding posts for easy connections,
solid Medium Density Fiberboard (MDF)
construction, carpeted to match your trunk,
the new enclosures are ready to rock, just
add an amp!
TVB-141
BL-WC1-3XRXT126
Models: UMS6A,
UMS8A, UMS10A
Models:
RXT114/126DVC,
RXT214/226DVC
The new amplified Bazooka®subwoofers
feature the legendary patented Bass Tubes
enclosure design, but with a twist. These units
are completely self-contained bass monsters!
Available in 100 watt BTL or 200 watt MOSFET
amplifier configurations, the new amplified
Bazooka subwoofers are the true solution to
the common automobile interior problem of
“not enough space for bass.”
The non-amplified Bazooka®subwoofers feature
the legendary patented Bass Tubes®enclosure
design and now incorporate the most advanced
woofer design ever used in a Bazooka tube sub.
The legend lives on in this latest revision of
the most award-winning subwoofer in car
audio history.
BTA6200
BTA6100
BT6024DVC/6028DVC
BT6014/6018
BTA8200
BTA8100
RBCM-100
RBCM-RS
RBCM-100
RBCM-RS
RBCM-100
RBCM-RS
BT8024DVC/8028DVC
BT8014/8018
BTA10200
BTA10100
BT1024DVC/1028DVC
BT1014/1018
BT BASS TUBES
REFERENCE SERIES
REFERENCE SERIES
Corner loading is
recommended
for all Bazooka®subwoofers
Optional tube mounting system
BL-WA1-2XRXT114,
BL-WB1-2XRXT2
BL-WC1-3XRXT126
The Rx-T woofers were a 4-year R&D experiment that
culminated in the production of the world’s first (and
only) triangular subwoofer. This patented design offers
installation opportunities never before possible while at
the same time not compromising bass performance.
With features taken from the EL and RS line of woofers,
the proven motor structure and C.H.I.L. compatibility
insure max output with the wildest cosmetic design
ever given to a subwoofer cone.
The pinnacle of satellite speaker performance is the
Bazooka®Reference X separates. In fact, Tim Kelly of
Car Audio magazine said of the Rx6s - “They were so
smooth and so neutral that I could have listened
forever…”. These Aluminum woofer and tweeter sets
come with a crossover that features Mylar capacitors
and allows for tweeter level setting. The tweeter for
the RS separates can be surface, flush, or angle
mounted. These speakers are an obvious choice for
the discerning listener.
RX-5S
RX-6S
