Bazooka CS8A5 User manual

PLACE
STAMP
HERE
SOUTHERN AUDIO SERVICES, INC.
15049 FLORIDA BLVD.
BATON ROUGE, LA 70819
cut along dotted line
For: CS8A, EL8A, TA850
1008120401

Dear Friend,
Thank you for selecting Bazooka®subwoofer speaker systems for your
car stereo system. Today, the Bazooka represents Bazooka Mobile
Audio’s continued commitment to efficiency and design. An innovative
manufacturing process developed by SAS for the Bazooka provides
consumers with state-of-the-art speaker system design. At SAS, we take
pride in manufacturing the most revolutionary bass speaker systems ever
created, featuring our patented Bass Tubes®enclosure design, and we
hope you will take pride in owning them.
Several years ago, we realized that efficiency was the wave of the
future in autosound, so we made a commitment to design, manufac-
ture, and deliver the most efficient speaker systems possible.
Today we market our patented speaker systems worldwide and the
high quality of the Bazooka brand is well respected by consumers and
dealers of all nationalities.
When properly installed, Bazooka subwoofer speaker systems will
give you years of clean uninterrupted sound reproduction. Therefore,
I urge you to take a few minutes of your time to review this instruc-
tion booklet. It was designed to give you a better understanding of
our products and to explain how to apply them properly.
Thank you again for choosing Bazooka. Our early commitment to
quality has made them the product of choice, and I am sure you will
agree that you have made the right one! Enjoy!
Sincerely,
JON C. JORDAN
President
SAS/BAZOOKA
CONGRATULATIONS
1
CONTENTS
System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 3
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 4
Mounting The Bazooka . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 5, 6, 7, 8
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 9
Power Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 10
Ground Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 11
Remote Turn On Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 11,12
Input Signal Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 13,14
Setting The Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 14
Practice Safe Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pg 16,17,18
2
If you have any questions contact the SAS
Technical Support Department at:
Phone - [phone] • Fax - [phone]
In Canada: [phone]
Email - [email protected] • Website - www.bazooka.com
14763 Florida Blvd., Baton Rouge, LA. 70819

8” SUBWOOFER
PATENTED BASS TUBES®ENCLOSURE WITH BASS REFLEX/DUCTED PORT ALIGNMENT*
HIGH EFFICIENCY OUTPUT
OPTIMIZED FOR SPACE EFFICIENCY
DESIGNED FOR CORNER LOADING
MOISTURE RESISTANT ENCLOSURE
BUILT IN 50 WATT MAX AMPLIFIER POWER
18dB ELECTRONIC CROSSOVER FIXED @ 85 Hz.
NOISE REJECTING BALANCED INPUT CIRCUITRY
INPUTS ARE SUMMED MONO INTERNALLY
SELECTABLE AUTOMATIC TURN ON FEATURE
12dB PER OCTAVE SUBSONIC FILTER @ 35 Hz.
* The efficiency levels of all Bazooka subwoofer speaker systems are measured in the typical
environment: In the low bass region with one watt of power.
SYSTEM FEATURES
SPECIFICATIONS
3
BASS TUBES® nclosur - pat nt d Bass R fl x/duct d port alignm nt
TA850
Woof r Siz 8
Voic Coil Siz 1 high pow r /high t mp
Magn t Siz 15 oz.
Fr qu ncy r spons 39-85 hz.
Effici ncy 105 dB*
Dim nsions 18.125x8.5x10
W ight 15.5 lbs.
Imp danc 2 ohms
*BAZOOKA®subwoofer speaker systems exclusively incorporate the revolutionary Bass Tubes®
patented subwoofer enclosure design available only from SAS.
®
4
INSTALLATION
Figure 1
Figure 2
Figure 3

5
Please take time to read through this manual and
plan out your installation before you begin!
Locate an area in the rear of the vehicle where you would like to place
the Bazooka speaker system. The location you have selected must meet
the following requirements in order for the Bazooka to be properly
installed in the vehicle:
Be sure that your application meets all of these require-
ments before you continue the installation procedure!
INSTALLATION
1) The woofer (grill end) should
be facing into a corner. (See fig-
ures 1, 2 and 3)
2) Ideally, there should be 2 to 4
inches between the woofer and
the corner it is pointing into.
3) The mounting area should be
carefully checked to be sure that
the mounting screws will not
damage the gas tank, electrical
wiring, fuel lines, or the spare
tire during the mounting of the
strap bases.
4) The strap mounting bases
should be screwed securely to a
rigid surface that is part of, or
anchored to, the structure of the
vehicle.
6
1. With the top side
of the buckle facing
up (see figure 4), lace
the strap through the
mounting base as
illustrated in figure 5.
2. After the strap is
completely laced
through the mount-
ing base, make a
loop with the strap,
where it runs across
the middle of the
base as illustrated in
figure 6. This loop
is necessary to
access the two
mounting holes in
the base.
MOUNTING THE BAZOOKA
Figure 4
Figure 5
Figure 6
To p
Logo
should
fac up

3. Place each
mounting base
under the Bazooka
so that the apex at
the bottom of the
tube sits inside the
mounting base as
in figure7.
4. Move the bases
so that they are
spaced approxi-
mately 3” from
each end of the
enclosure as illus-
trated in figure 8.
5. Remove the
Bazooka without
moving the mount-
ing bases and set it
aside.
6. Screw each
mounting base
securely in place
with screws provid-
ed as illustrated in
figure 6.
MOUNTING THE BAZOOKA
7
Figure 7
Figure 8
3,,
3,,
Figure 10
Figure 9
MOUNTING THE BAZOOKA
8
7. Adjust buckle end
of strap so that it
extends out of the
mounting base 22”
(see figure 9) the
proper length for
the model size of
Bazooka you are
installing.
8. Remove any slack
in the strap by feed-
ing it out of the
mounting base on
the loose end of the
strap opposite the
buckle.
9. Place Bazooka on
the mounting bases
and fasten the buck-
les as illustrated in
figure 10. The strap
should loop through
the buckle and be
tightened securely
by holding the strap
in place with one
hand and pulling
the loose end away
from the buckle, but
against the cabinet.
Technical Note
Due to the jarring and shifting that can occur in a vehicle, the mount-
ing straps may stretch or loosen. We recommend that you check the
straps regularly to assure that your Bazooka is mounted securely in
place.
22”

LEVEL
GRAY/TRACE
HI-LEV
INPUT (-) GN/TRACE
HI-LEV
INPUT (-)
ORANGE
REMOTE
QUICK
DISCONNECT
YELLOW ON/OFF
JUMPER LOOP
GRAY
HI-LEV
INPUT (+)
GREEN
HI-LEV
INPUT (+)
RCA
PHONO PLUGS
Right & Left Low
Level Inputs
1 GAUGE
BLACK CHASS
I
GROUND
1 GAUGE RED
BATTERY (12v+)
NOTE: REMOVE AUTO TURN-ON LOOP TO USE ORANGE
REMOTE IRE FOR NORMAL REMOTE TURN-ON
WIRING DIAGRAM
9
When using high level inputs, take the time after you make all wiring
connections to run through the AM I IN PHASE procedure of this
manual to confirm that your inputs are in correct electrical phase and
the proper bass response is being produced.
DO NOT substitute the 7.5 amp fuse included with the Amplified
Bazooka with anything other than the same fast blow current rated
fuse. Substitution or deletion will void the product's warranty and may
cause damage to your car or the amplifier.
The 16 gauge red wire on the 14-pin Molex Mini-fit Jr. connector
is the 12 Volt positive power wire. It must be fused and connected
directly to the positive terminal of the battery to provide a power
source with a low voltage drop and low noise. Do not make the
power connection at the fuse block or any point other than the
battery. Improper power sources can reduce output and cause dis-
tortion.
The fuse holder should be connected to the battery's positive termi-
nal. The fuse is designed to prevent fire or damage to your car,
should the battery wire short to ground. Wait to insert the fuse into
its holder until all wire connections have been made.
If it is necessary to lengthen the battery wire, add the required
length between the amplifier and the fuse holder, not the fuse
holder and the battery. Use 16 gauge or larger to extend the bat-
tery wire. It is best to use as short a wire as possible.
Be sure you DO NOT run the power wire next to the input cables of
the amplifier, this will induce noise.
Avoid running the power wire near the radio's antenna or power
leads, or near sensitive equipment or harnesses. The power wire car-
ries substantial currents and could induce noise.
POWER WIRE
CAUTION
10

Option Two:
If the source does not have an Auto-Antenna lead (or if the Auto-
Antenna goes down during tape operation),you can connect the
Amplified Bazookas' Remote Turn On Wire to an accessory or igni-
tion point at the vehicle fuse block. In this configuration, the
Amplified Bazooka will be on whenever the ignition is on. This
method may allow noise or turn-on-and-off transients to become
amplified when the source unit is not in use. When you are using
this Option, the Quick Disconnect YELLOW On/Off Jumper Loop
MUST be disconnected from the wiring harness.
Option Three:
The Amplified Bazooka has a built -in Auto Turn-On Feature. If
you choose to use this feature, the Amplified Bazooka will turn on
automatically whenever there is music present at the inputs (high
level or low level input). Please take notice of the Quick Disconnect
Yellow On/Off Jumper Loop located on the Amplified Bazooka
wiring harness. SAS ships the Amplified Bazooka with this Jumper
Loop plugged into the wiring harness. When the JUMPER LOOP
plugged in, the Auto Turn-On Option is in the ON position and the
Amplified Bazooka will turn on automatically when it senses any
music at the inputs. The ORANGE wire should not be connected
to anything if this feature is being used. Be sure to insulate the
end of the ORANGE wire so that it will not short to ground, as this
may damage the Amplified Bazooka.
TURN ON OPTIONS CONT.
12
The 16 gauge black wire on the 14-pin Molex Mini-fit Jr. connector is
the negative ground wire. It must be connected directly to the vehi-
cle chassis near the amplifier. We do not recommend extending the
ground wire in any installation, as this can cause unwanted ground
loops.
The ground point in the car should be a piece of chassis metal that is
part of or welded to the main body of the vehicle. Painted surfaces
should be scraped or sanded clean to expose the bare metal before
the ground lug is bolted down. (Cover the bare metal area with paint
or grease after you finish mounting the ground wire to prevent rust.)
GROUND WIRE
REMOTE TURN ON OPTIONS
11
The ORANGE wire on the Amplified Bazookas' 14-pin Molex Mini-fit
Jr. connector is the Remote Turn On Wire. You have several options
in connecting the Remote Turn On Wire. These options are listed in
the order of preference recommended by SAS. Select the option best
suited for your application.
Option One:
For the most versatility the Remote Turn On Wire should be connect-
ed to the source unit's "Accessory", "Auto-Antenna" or "Remote"
lead -- any of which will supply 12 Volts positive when the source is
turned on. When you are using this configuration, the Quick
Disconnect YELLOW On/Off Jumper Loop MUST be disconnected
from the wiring harness.

Should I Use High or Low Level Inputs?
If the source unit has only speaker outputs, use the high-level inputs of
the Amplified Bazooka. If the source unit has both high and low level
outputs, we recommend using the high level inputs over the low level
inputs, due to the configuration of the Amplified Bazooka's balanced
input circuit. PLEASE NOTE THAT THE WIRING IN A FACTORY STEREO
MAY NOT BE ELECTRICALLY IN PHASE EVEN WHEN YOU HAVE MADE
THE PROPER CONNECTIONS. Take the time after you make your wire
connections to run through the quick phase check procedure in the AM
I IN PHASE? Section of this manual. NEVER USE BOTH high and low-
level inputs at the same time!
High-Level Inputs:
If the source unit has both front and rear speaker outputs, use only one set
of speaker outputs for the high-level input of the Amplified Bazooka.
Connect the GREEN wire from the 14-pin Molex plug of the Amplified
Bazooka to the source units left (+) positive speaker output. Connect the
GREEN W/BLACK stripe wire of the plug to the source units left (-) negative
speaker output. Connect the GRAY wire of the plug to the source units right
(+) positive speaker output. Connect the GRAY W/BLACK stripe wire of the
plug to the source units right (-) negative speaker output.
INPUT SIGNAL CONNECTIONS
PHASE ALERT
13
Am I In Phase?
If your inputs are out of phase and you turn the balance control of
your radio all the way to one side, right or left, the bass output from
the Bazooka will increase. When you bring the balance control back
to the center position the bass level will drop. This confirms that one
of your input channels is wired out of phase with the other. To correct
When one of the Amplified Bazooka's High-level Input channels is out
of phase electrically with the other High-level Input channel, your
Bazooka will sound as if it has little or no output and any output that
is produced may sound distorted. If you suspect that your Bazooka is
out of phase, use the AM I IN PHASE procedure to diagnose and cor-
rect the Bazookas' output, and proper bass response will be produced.
this situation, simply reverse the connections on ONE of the two input
channels. When the wiring is in correct electrical phase, the level of
bass output will be greatest when the balance control of the radio is
set to the center position.
LOW-LEVEL INPUT:
If your source unit only has low-level RCA phono jack output, use only
the low-level inputs of the Amplified Bazooka.
Connect the low-level RCA phono jack inputs of the Amplified Bazooka to
the source with a shielded RCA patch cord. To avoid possible noise prob-
lems, be sure to run the patch cord away from all power wires and facto-
ry wire harnesses.
When using the low-level inputs DO NOT make any connections to
the Green and Gray high-level input wires of the Amplified Bazooka
and make sure these wires are insulated to avoid the possibility of a
short circuit.
SIGNAL CONNECTIONS CONT.
SETTING THE LEVEL
14
To set the level of the Amplified Bazooka, start with the control all the
way to the left. The bass should be off or very low at this point. Turn
up the head unit until the sound from the existing speakers starts to
clip or distort. This should be the max volume point of the system. Now
bring up the level of the Amplified Bazooka so that the bass volume
blends well with the other speakers in the system. This should be the
proper setting for the level control.

LIMITED WARRANTY (UNITED STATES)
Southern Audio Services, Inc , warrants all products to b fr from d f cts
in mat rial and workmanship for a p riod of on (1) y ar from th dat of purchas ;
In the event the product is not as warranted, SAS sole obligation shall
be to repair or replace the defective product at SAS option: SAS limits
its obligation under any implied warranties under state laws to a period
not to exceed the limited warranty period SAS and its authorized
BAZOOKA® dealers specifically disclaim liability for any incidental or
consequential damages Some states to not allow limitations on how
long an implied warranty lasts, and some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above
limitation or exclusions may not apply to you This warranty gives you
specific legal rights, and you may have other rights, which vary from
state to state
What is covered:
This warranty cov rs all d f cts in mat rials or workmanship (parts and labor) in
th product.
What is not covered:
This warranty do s not cov r th following:
1. Damag s occurring during shipm nt of th product to SAS for r pair (claims
must b pr s nt d to th carri r).
2. Damag s caus d by accid nt, abus , n glig nc , misus or improp r op ration
or installation.
3. Damag s caus d by an act of God, including without limitation, fir , flood,
storms, or oth r acts of natur .
4. Any product, which has a s rial numb r, d fac d, alt r d, modifi d, or r mov d.
5. Any product that has b n alt r d or modifi d without SAS cons nt.
How to obtain warranty services:
1. You ar r sponsibl for d liv ry of th product to an authoriz d BAZOOKA®
d al r or contact SAS at 1-800-THE TUBE for a R turn Authorization numb r.
Th R turn Authorization numb r must b cl arly writt n on th outsid of th
box. Fr ight must b pr paid to SAS. Warranty r plac m nt parts will b
r turn d fr ight pr paid. Th ntir nclosur may b r turn d for warranty
s rvic , but r turn will b fr ight coll ct.
2. You must provid proof of th dat of purchas of th product. If proof of
purchas is not provid d, original dat of manufactur will b us d to d t rmin
warranty p riod.
3. You must packag th product s cur ly to avoid damag during shipm nt.
4. Aft r acquiring a R turn Authorization numb r, ship to th addr ss b low.
PRACTICE SAFE LISTENING
BASS TUBES®ENCLOSURE
Continuous exposure to high volumes of sound may cause permanent
hearing loss. High powered auto sound systems are capable of pro-
ducing sounds well over 130 dB. Even short periods of play at high
volume levels can impair your ability to hear necessary traffic sounds
and may constitute a hazard. Please use common sense and practice
SAFE LISTENING!
BAZOOKA®subwoofer speaker systems exclusively incorporate the
revolutionary Bass Tubes® patented subwoofer enclosure design
available only from SAS.®
SAS, Bazooka, Bass Tubes and “Listen to Your Ears” are registered trademarks of Southern
Audio Services, Inc. © Southern Audio Services, Inc. all rights reserved
15 16

IN MEXICO:
COIBA IMPORT S.A. DE C.V
Torr cillas # 2060
Guadalajara Jalisco Col. El Rosario
México C.P. 44890
Mod lo: CS8A, EL8A, TA850
RFC CIM-000901-1k0 Producto: Bocinas
POLIZA DE GARANTIA CONDICIONES
El producto qu ust d ha adquirido Cu nta con una garantía d 90 días Por
d f ctos d fabricación y 90 días D s rvicio a partir d la f cha d Adquisición
otorgada por:
COIBA IMPORT S.A. DE C.V
1.- Para hac r f ctiva sta garantía, ust d d b pr s ntar la factura d compra o
póliza d bidam nt ll nada por la ti nda o unidad v nd dora junto con l
producto.
2.- La mpr sa comprom t a r parar al producto, sin costo alguno al consumidor;
si la falla s atribuibl a d f cto d fabricación.
3.- El ti mpo d r paración n ningún caso s rá mayor d 30 días, transcurrido st
término COIBA IMPORT S.A. DE C.V. proc d rá a Ef ctuar l cambio por un
producto quival nt .
4.- C ntro d S rvicio:Torr cillas #2060 Guadalajara Jal. Col. El Rosario C.P. 44890
Esta garantía no es valida en los siguientes casos
1.- Cuando l producto no ha sido utilizado d acu rdo al instructivo.
2.- Si no s ha obs rvado las adv rt ncias s ñaladas
3.- Si ha sido xpu sto a cambios bruscos d voltaj
4.- Si ha sufrido d t rioro sc ncial irr parabl atribuido al consumidor
5.- Cuando l producto ha sido alt rado o r parado por p rsonas j nas a nosotros
6.- Esta póliza s nula si no cu nta abajo con los datos r qu ridos y s llos d la
ti nda dond s r alizó la compra.
GARANTIA VALIDA EN TU TIENDA DE SERVICIO
DATOS DEL DISTRIBUIDOR
Nombre:________________________________________________________________________
Calle y #________________________________________________________________________
Colonia ________________________________________________________________________
Producto:______________________________________________________________________
Fecha de compra:_____________________________________________________________
Sello y firma
De la tienda
____________________________________________ MODEL# ____________________________________________ SERIAL# ____________________________________________ PURCHASE DATE ____________________________________________ DEALER PURCHASED FROM ____________________________________________ DEALER ADDRESS ____________________________________________ TELEPHONE
____________________________________________ PURCHASERS NAME ____________________________________________ STREET ADDRESS ____________________________________________ CITY ____________________________________________ STATE ZIP ____________________________________________ TELEPHONE ____________________________________________ E-MAIL
PLEASE RETURN THIS PORTION IMMEDIATELY
17 18
