BC Acoustique EX001-EU Configuration guide

BC ACOUSTIQUE
BP 306 - 94709 Maisons-Alfort Cedex France
AC Power Condioner
ENGLISH FRANCAIS SPANISH DEUTSCH
OWNER’S MANUEL
MODE D’EMPLOI
MANUEL DEL USUARIO
BEDIENUNGSANLEITUNG

2
Safety Instrucons ……..…………………………………………………..02
Glossary..…………………………………………………………………..…….02
Recommandaons ..………………………………………………………..02
Recycling product ..…………..…………………………………………....03
Locaon and precauons ……….…………………..………………03
Power Sources …………….………………………………………………….03
Warranty .……..………………………………………………………………..03
Basic Instrucons: QUICK START ………..…………...……………..04
Top view ……………………………………………..……..…….…………….04
Front view …………………………………………………………....……....05
Rear view ………….………………………………………………....……....05
Specicaons .………………………..……………………………………….05
Troubleshoong ………..…………………………………………………...05
More about .…...……………………………………………………..……….06
Notes .………..…………………..…………………………………..………….06
We invite you to read the instrucons on the proper use of
your product carefully. They will ensure the proper
funconing of the laer and it safely.
- Do not use this device in a wet area or near water.
- Clean only with a dry cloth. As a precauon it is best to
unplug the unit before handling.
- Do not install near heat sources.
- Take great care of the power cord and plugs electrical
connecon. In parcular, do not walk, or press the power
cord, specically at plugs, power plant and the output of
the power supply.
- Use only parts and accessories recommended by BC
Acousque.
- A grounding safety must be present for your EX001 to
work properly. Any use of the device without grounding
safety will be considered irregular and may invalidate the
warranty.
- Do not aempt to repair your EX001 beyond what is it
explained in this guide. All other servicing should be
referred to a qualied technician.
The CE mark indicates that this product
complies with European direcves called "low
voltage" (2006/95/EC), Electromagnec
Compability (2004/108/EC) and apply eco-design
requirements for energy products (2009/125/EC) when the
appliance is installed and used in accordance with the user
manual. For connued compliance only BC Acousque
accessories must be used with this product and servicing
must be performed by specialized and qualied sta.
The WEEE symbol is that of the European
Union regarding the recycling of electrical and
electronic equipment. It indicates that this
product contains electrical and electronic
components that can be reused, recycled or
recovered. Therefore this product should not
be disposed of in your regular trash. Thank you to return
the unit or contact your authorized dealer for more
informaon.
This symbol alerts the user to the presence
of "dangerous voltage" uninsulated which may
pose a risk of electric shock to the user.
This symbol alerts the user that the
documentaon that comes with the device
contains important instrucons for
maintenance and proper use of the product.
Do not use the EX001 outdoors. This product is intended for
use exclusively indoors, in rooms where the temperature
varies between 5 and 35 ° C.
To avoid electric shock, it is strictly forbidden to aempt to
open the product for any reason whatsoever. Please
contact the aer sales service of BC Acousque if you think
that the product is defecve.
Recommendaons
Safety instrucons
Summary Glossary
Dear Customer,
Thank you for choosing a BC Acousque product. Its implementaon has been our know-how, both in terms of design to the
manufacturing. Electronic components and mechanical parts correspond to the selecon criteria of very high quality.
Operaon and nish of each product have been checked before delivery. To obtain best results, please read the advice
contained in this document.
Introducon

3
ENGLISH
At the end of its useful life, this product should not be
disposed of with regular garbage, but returned to a
collecon point for the recycling of electrical and electronic
components. This point is emphasized by the symbol on the
product, the instrucon manual and on the packaging.
The materials can be reused in accordance with their
markings. Through reuse and recycling of raw materials or
any other form of recycling, you make an important
contribuon to environmental protecon. Your municipality
can tell you where is the point of the nearest collecon site.
Avoid placing it in direct sunlight or near a heat source. No
source of light shall be placed on the apparatus. Also avoid
all sources that could cause vibraon, dust, cold or
moisture. The recommended ambient temperature range is
5-35 ° C.
The device must be installed on a stable, level surface. Do
not place the unit on an unstable surface or shelf. The unit
may fall, causing serious injury to a child or adult as well as
serious damage to the product. Do not place other
equipment on top of the unit.
Due to stray, turntables or CRT TVs magnec elds should
not be located near the unit to avoid possible interference.
The unit should be operated only from the type of power
source indicated on the label. If you are unsure of the type
of power available to you, thank you to contact your dealer
or the company responsible for the power supply in your
area.
Turn o device if you do not intend to use this unit for a
long me.
In case of prolonged absence from home, it is
recommended to unplug from the electrical outlet.
Make sure each cable is correctly inserted. To prevent hum
or background noise, do not mix dierent other antenna
cable with the power cord or speaker wires.
BC Acouscs warrants this product parts and labor (under
the condions specied below).
BC Acouscs will repair or replace (at its discreon) this
product or any defecve parts. The warranty period may
vary by country. If in doubt, contact your dealer. Always
retain proof of purchase of this product.
For warranty service, please contact the BC Acousque
authorized reseller from which you purchased this product.
If your dealer is not itself repair the product, it can be sent
to BC Acousque authorized aer-sales service. If
necessary, you will need to ship this product in its original
packaging or packaging aording an equal degree of
protecon.
Proof of purchase such as an invoice stang that the
product is covered by the Guarantee must be presented for
any warranty claims.
This warranty is void if:
- The factory serial number has been altered or removed.
- This product was not purchased from an authorized
reseller BC Acousque. To conrm that the serial number
has been altered or that the product was purchased from
an authorized reseller BC Acousque, you can call BC
Acousque BC Acousque or distributor in your country.
- If the power supply cord or plug is damaged.
- If liquid has been spilled or if objects have fallen inside.
- If the unit has been exposed to rain or water.
- If the unit is dropped or damaged in any way.
- This warranty does not cover cosmec damage or damage
caused by or due to force majeure, an accident, mis use,
abuse, negligence, commercial use or modicaon of part
any product.
- This warranty does not cover damage caused by or
resulng from misuse, a maintenance or improper
installaon or repairs made or aempted by anyone other
in BC Acousque or not BC Acouscs dealer or technician
approved, authorized to carry out maintenance and repair
under warranty for BC Acousque. Any unauthorized
repairs will void this warranty. This warranty does not cover
products sold "AS IS".
- REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
- BC Acousque NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
Locaon and precauons
Product recycling Warranty
Power sources

4
- Some countries do not allow the exclusion or limitaon of
incidental or consequenal damages or exclusions of
implied warranes. Therefore, the limitaons or exclusions
herein may not apply. This warranty gives you specic legal
rights, in addion to other rights which vary from state to
state or country to country.
1 - Connect up to 6 devices .
Connect the power cords from your devices (devices with 2
wires included) to the EX001 AC outlets.
The 4 ltered plugs ① are parcularly suitable for digital
audio sources and other products that do not require a lot
of power.
The 2 unltered plugs ② are intended primarily for
products with high power consumpon.
2 - Connect your EX001 mains power cord to the wall plug.
Plug the power cord of the EX001 line power condioner to
the outlet ③ standard 3 wires grounded 230V AC, 50 Hz
IEC detachable power cable is supplied with the module.
3 - Move the POWER switch to the "ON" posion .
Press the switch ④ located on the front of the EX001 unl
it illuminates, indicang that power is supplied to 6 outlets.
About the direcon of connecon of power outlets: .
The EX-001 is equipped with females sockets sectors to
choose the direcon of connecng cables males. It is
welknown that the direcon of connecon may have an
eect in some cases on the quality of audio playback
devices.
To idenfy the "best" sense of connecons,
you must proceed as follows: .
1 - Disconnect your device from all other (RCA cables, HP,
etc ...) . .
2 - Turn on the device (thus opng for one of the two
possible direcons of connecons). .
3 - Measure with a voltmeter (the "alternang voltage"
posion) the tension between "your hand" and " the chassis
of the device." .
4 - Unplug the unit and plug it into the "other way".
5 - Repeat the measurement in these new condions.
The best "posion" is the one which produces the lowest
voltage.
① POWER OUTLETS - 10A FILTERED
These 4 ltered outlets are adapted to medium power
levels can supply up to 10 Amps (for a total power of
2.200W) for your digital audio sources and other products
that do not require very large power supply.
② POWER OUTLETS - 16A
These 2 unltered power outlets with their high power can
supply up to 16 Amps, are designed for high-power blocks.
Notes: .
DO NOT OVERLOAD the power outlets of the EX001 power
condioner.
The power condioner EX001 can accept a total load of
material up to 16 A (in a stand alone plug or spread amongs
severals plugs).
Basic instrucons
Quick starng guide
Warranty Top view

5
ENGLISH
③ POWER OUTLET
Connect the power cable to the EX001 and then plug the
power cable into an outlet to the wall. .
You can now turn the unit on.
Number of plugs in the European Format:
4x Filtered plugs (up to 10A)
2x Unltered plugs (up to 16A)
Maximum output power: 2.200 W
Mains voltage: AC 110-230V
Standard IEC mains input
With detachable power cable
PRODUCT
Dimensions (WxHxD): 163 x 120 x 347 mm
Weight: 4.6 Kg
BOX
Dimensions (WxHxD): 219 x 175 x 396 mm
Weight: 5.2 Kg
Volume: 0.02 m3
EAN CODE: 0628586586406
④ POWER BUTTON
This switch allows shutdown or operaon of the power
condioner. Zero is OFF, and One is ON.
Here you will nd a number of fault descripon and
possible soluons we invite you to read in order to ensure
the possibility of an actual breakdown of your device.
The unit does not turn on .
- Make sure the power cord is properly connected.
- Make sure the plug is fully inserted into the wall outlet
and there is power.
- Make sure the camera is turned on.
- Check the fuse in the mains plug or adapter if necessary.
In case the above soluons do not remedy your problem,
check our FAQ secon (Frequently Asked Quesons) on our
website: www.bc-acousque.com
For repair, during or aer the warranty, please contact your
dealer.
Front view Rear View
Specicaons
④
Troubleshoong
③

6
The BC Acousque mains lter gives your hi- or home
cinema eecve protecon against voltage surges and
electrical disturbances. These are indeed likely to aect the
performance of your equipment. The mains lter protects
you by removing voltage spikes during lightning storms or
accidental overvoltage.
This lter also helps regulate the ow of electricity
connuously suering the eects of electromagnec
interference and radio frequencies that are oen generated
by your other equipment, more and more in our home
environment , such as your mobile phone , computers,
power supplies halogen lamps …
Once puried , the power delivered to your audio and video
equipment ensures a quality picture and sound ideal ,
without disturbing . This results in a purest, clearest ,
without distoron. Similarly , the images from your screen
or beamer enjoy a beauful clarity, no noise or image jump.
A beer quality of current also helps extend the life of your
electronics and your projector lamp.
To know more... Notes

7

8
To obtain warranty service and technical support, thank you kindly register your product online
by registering on the website www.bc-acousque.com the « Product registraon » secon.
BC ACOUSTIQUE
BP 306
94709 Maisons-Alfort Cedex - France
www.bc-acousque.com
