Bearon Aquatics F500F User manual

☐ F500F - .5HP Aerating Fountains
☐ F1000F - 1HP Aerating Fountains
AERATION
BEARON AQUATICS
POWER
HOUSE
AERATING FOUNTAINS
PLEASE READ ENTIRELY BEFORE OPERATING

2
Safety Instructions page 3
 SpecicationSheet        page4
Installation & Operation page 5
 Maintenance&Troubleshooting     page6
Parts & Accessories page 7
Warranty Information page 8
CONTENTS
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects,
or other reproductive harm.
Service Center
Paperwork
www.bearonaquatics.
com/service
Product
Registration
www.bearonaquatics.
com/resources/warranty-
registration/
Search for
Distributor or
Service Center
www.bearonaquatics.
com/search-for-a-
distributor/

3
CAUTION SHOULD BE USED WHEN DEALING WITH ANY ELECTRICAL EQUIPMENT WITH
MOVING PARTS.
NEVER LIFT OR DRAG THE UNIT BY THE POWER CORD. USE PROVIDED MOORING LINE TO MOVE
THE UNIT AS NECESSARY.
THIS MOTOR IS PROVIDED WITH A GROUND WIRE OR GROUNDING TYPE PLUG FOR
YOUR PROTECTION.
THE GROUND WIRE MUST BE SECURELY ATTACHED TO PROPER ELECTRICAL GROUND OR THE
GROUNDING TYPE PLUG MUST BE USED ONLY WITH A PROPERLY GROUNDED RECEPTACLE. IN
ADDITION, YOU SHALL USE GROUND FAULT INTERRUPTER PROTECTION IN ACCORDANCE WITH
THE NATIONAL ELECTRIC CODE.
DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE GROUND PRONG FROM A
GROUNDING TYPE PLUG.
ANY REWORK OR DAMAGE TO THIS CORD MAY CREATE SHOCK HAZARD AND WILL VOID
THE WARRANTY.
A QUALIFIED ELECTRICAN MUST BE CONSULTED TO INSURE A SAFE INSTALLATION.
UNDER NO CIRCUMSTANCES SHOULD ANYONE ENTER THE WATER WITH THE ELECTRICAL
EQUIPMENT CONNECTED AND/OR IN OPERATION. IT IS NEVER RECOMMENDED TO ENTER THE
WATER WITH THE EQUIPMENT IN OPERATION.
ALWAYS DISCONNECT THE ICE EATER FROM THE POWER SOURCE BEFORE ANY SERVICING OR
CLEANING OR MOVING OF THE UNIT BY UNPLUGGING OR BY REMOVING FUSE OR DEACTIVATING
CIRCUIT BREAKER.
WHEN USING OUR ICE EATER AND OUR THERMOSTAT TOGETHER, UNIT WILL START
AUTOMATICALLY BY AIR TEMPERATURE.
ALWAYS DISCONNECT THE ICE EATER FROM POWER SOURCE BEFORE ANY SERVICING OR
CLEANING OR MOVING OF THE UNIT BY UNPLUGGING OR BY MOVING FUSE OR DEACTIVATING
CIRCUIT BREAKER.
DO NOT REMOVE END COVER PLATE. REMOVAL OF PLATE WILL VOID WARRANTY. ALL REPAIRS
MUST BE MADE AT FACTORY OR AN AUTHORIZED SERVICE STATION.
RECOMMENDED COMMERCIAL GRADE BREAKER. USE DEDICATED CIRCUIT PER UNIT.
WARNING WARNING WARNING WARNING WARNING WARNING WARNING WARNING
WARNING WARNING WARNING WARNING WARNING WARNING WARNING WARNING
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS

4
COMPLETE PACKAGE
• (1) Assembled Motor (with shroud) .
• (1) UV Resistant Float .
• (2) 25’ Long 3/8” thick Hollow Braided
Polypropylene Mooring Lines.
• (1) SJTOW Rated 3-Wire, 14 Gauge
Power Cable with Potted Quick
Disconnect.
QUICK FACTS
• Able to Operate in water as shallow
as 14” for the F500F and 18” for
the F1000F.
• Total Component Listed to meet UL,
CE, & CSA Standards for Safety in
Water.
ULListingNo.E481181
MetListingNo.E112360
• Energyecientwithexcellent
Gallons per Minute (GPM)/kW Rates.
• HighOxygenTransferatan
aordableprice.
• SacricialAluminumAnodeand
Electrolysis Kit are available for
corrosion protection and use in
salt-water applications.
• Industrial Strength Design.
• 3-Year Warranty.
WARNING
Discontinue use and remove
fromwaterwhenwaterisbelow
freezing tempteratures (32F/0C).
 Donotruntheunitoutofwater.
Ground Fault Circuit Interrupter
(GFCI) or Residual Current Device
(RCD) protected circuit required.
MOTOR ASSEMBLY
• F500F - .5Hp; 106GPM; 5amps (115V).
• F1000F - 1Hp; 130GPM; 7.5Amps
(115V).
• Single Phase motors; 3-Phase on
1Hp motors available upon request.
• Units available in 115V or 230V.
• 50/60 Hz.
• 1,650 Rotations per Minute (RPM).
• Oil Cooled, Continuous Duty Rated.
• Two Long Life Bearings.
• Thermal Overload Protection.
• Fully Utilized Heavy Duty Carbon
Ceramic Mechanical Seal.
• Series 300 Austenitic Stainless
Housing with Magnesium Bronze
End-Bell.
POWER CABLE
• SJTOW UL & CSA Approved,
Underwater Rated Cable, 3 Wire.
• 115V available in 50’, 100’, and 150’
with Quick Disconnect Power Cord.
• 230V available in 50’, 100,’ 150’,
200’, 250’, 300’, 350’, 400’ with Quick
Disconnect Power Cord.
• Other cord lengths are available
through special order but will not
have a Quick Disconnect Power
Cord.
• Potted Quick Disconnect on 14
Gauge Cord.
FLOAT
• U.V. Resistant High Density
Thermoplastic.
• Single Piece Float with Closed Cell
Foam Filling.
• Series 300 Stainless Steel Hardware
• (2) 25’ long 3/8” thick hollow braided
polypropylene ropes.
• Available with a Float Cage
Accessory.
POPULAR ACCESSORIES
115V TIMER
• Portable Outdoor 24 Hour Timer
available for both 115V and 230V.
• Outdoor grade plastic.
• Timer: 24-hour with 23-1/2 hour
maximumontime.(2)“ON”&(2)
“OFF”trippers–standard.
• Dial will accept up to 12 sets of
trippers.
• Electrical Rating: 15 A (1800 W),
Resistive or Tungsten.
• Agency Approval: CSA/C-US.
• Outdoor grade cord with ground
plug, 3 wire, 22 inches.
• 1 Year Manufacturer’s Warranty.
230V TIMER
• Electromechanical Time Switch.
• Type 3R Plastic Enclosure.
• Provides direct 24-Hour control of
most loads.
• Control electrical loads up to 40
Amps.
• 1to12ON/OFFoperationseachday.
• MinimumON/OFFtimesof1hour.
• Manual override.
• Equippedwith(1)ONand(1)OFF
tripper.
• 1 Year Manufacturer’s Warranty.
FLOAT CAGE
• 24”Wx24”Lx16”H.
Fits F500, F750DP, F1000DP &
F1500TP.
• Protect your investment by
preventing foreign objects from
entering the shroud.
• Choiceof1/2”or1″gridplastic
coated, hot rolled metal screen that
covers the bottom 5 sides of the
oat.
AERATING FOUNTAINS

5
INSTALLATION
1. Immediately after delivery, inspect the aerating fountain
shipment for any visible damages. Report any damage to
your dealer.
2. The aerating fountain is completely assembled within the
housing. You will not need additional hardware.
3. Installtheaeratorintheoatbyfollowingthesesimple
instructions:
• Turn the aerator upside down with the propeller end
  facingdownwardandplaceonaatsurface.
 • Passpowercordthroughthetopsideoftheoat
  (sidewith“PowerHouse”printedonit).
 • Slideoat,PowerHousenamesidedown,over
the shroud. Twist to align slots in the throat of the
  oatwiththepowercordandmountingbolts.
• Make sure cord is free and does not loop above the
level of the propeller hub.
• If you are installing optional large screen - connect
  thescreentothebottomlipoftheoatusingthe
(16) small white clamps. The sides of the screen will
need to be connected by using pliers to close the
metal rings.
4. Turn unit to an upright position with the propeller facing
up.
5. Fasten one mooring line to a secure place such as a fence
post or large cinder block.
6. Drop unit into water and secure the other rope directly
acrossfromtherst.Adjustyourfasteningpointsto
position the unit where desired.
7. Make certain that there is adequate water depth
(atlowestwaterlevel)sothattheunitoatsfreely.
Keep unit away from heavy grass or debris.
8. Make sure all hands, feet, cords, lines, etc. are clear of the
unit before connecting to power supply.
OPERATION
1. Once your Power House Aerating Fountain unit is properly
installed and secured, the aerating fountain is ready for
immediate use.
2. Your aerating fountain is designed for continuous
operation. It can be cycled by the use of a timer, photocell
ordissolvedoxygenmeter.Thiscanhelptogreatlyreduce
the amount of energy consumed by the aerator, while still
circulating the water.
Contact your local electrician for assistance.
3. Operating equipment should be observed on a regular
basis for any reduction or variation in the aerator’s
performance.
4. Plug the electrical cord into properly grounded GFCI
(Ground Fault Circuit Interrupter) or RCD (Residual
Current Device) protected circuit.
Plug the electrical cord into a receptacle that matches the
unit operating voltage or connect to an appropriate power
source. GFI required for each unit.
(Recommended that an electrician verify your power
supply.)
WARNING:Whenanextensioncordisused,itmustbe
sized as follows:
Up to 100ft. - Use #12/3 wire cord
Up to 200ft. - Use #10/3 wire cord
5. Unit will start immediately and can twist slightly upon
starting. Make certain that all lines are clear and secure.
Water should be forced well above the top lip of the white
shroud and should look thick.
WARNING: Do not run out of water. Unit must be
submerged.Keephandsclear.
6. Routinely inspect the propeller and shaft for any damage
from foreign objects.
7. Ifusinginsaltwater,routinelyinspectthesacrical
anode. Replace parts as necessary.
8. Whentheunitisusedforowgenerationinacircular
tank or pond, the water will gradually circulate and will
continueforsometimeaftertheunitisturnedo.
9. Smallshcanbesuckedthroughtheunitundercertain
operating conditions. Make sure that you have reviewed
your stock and any possible damage before you start the
unit.
10. FreezingTemperaturescancauseoattocrackorsplit.
WARNING: Discontinue use and remove from water
whenwaterisbelowfreezingtemperatures(32°F/0°C)
INSTALLATION & OPERATION INSTRUCTIONS
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS
SideViewofAeratingFountainshown
withMooringLinesata45°angle

6
TROUBLESHOOTING TIPS
1. If the aerating fountain does not start when plugged in or
turned on:
• Check power source to make sure that appropriate
voltage is available.
• Make sure the power cord connections are fully
made. Check tightness at both the source end and at
the unit.
• Have an electrician check your installation if the
ground-fault circuit interrupter (GFCI) or circuit
breaker has tripped or blown a fuse.
• If the aerating fountain requires a push/spin to start
then there is a problem with the Start/Run Capacitor.
Discontinue use and have it looked at by an
Authorized Service Center.
2. Iftheaeratorstartsslowlyordoesnothavefullow:
• This can be a symptom of several possible problems.
There could be a problem with the electrical or a
problem with the aerator’s motor.
• Check power source for voltage drop or undersized
service. If several pieces of equipment are operating
on the same circuit, restart each piece of
equipment individually.
• Unplug the unit and make sure the propeller turns
freely. Turn propeller through several full revolutions
Try to start the unit again.
• Unplug the unit and make sure there is no debris
around the propeller or shaft.
• Check screen to make sure it is clean. You must
remove any accumulation of algae or grass.
• If you’re still unable to diagnose the issue,
discontinue use and have it looked at by an
Authorized Service Center.
WARNING: Discontinue use immediately if you are
noticingthesesymptoms.
3. Iftheaeratingfountainshutsitselfointermittently
without tripping the GFCI or Breaker:
• Unplug the aerator from the power source and
remove the unit from water.
• The unit may be overheating due to low voltage.
Check power source for voltage drop or
undersized service.
• The unit may be overheating due to overload.
Inspect the aerator to make sure there aren’t any
foreign objects around the propeller, shaft, or
canister. Each aerating fountain has a thermal
  overloadbuiltinwhichwillturntheunitowhenit
overheats. Once the unit has cooled down, it will start
back up on its own.
MAINTENANCE
• Bearonaeratingfountainmotorsarelledandsealedwith
aspecialnon-toxicdielectriclubricatinguidanddoesnot
require additional lubrication.
• When storing your unit, clean it thoroughly and place it
propellersidedowninaat,coolplace.Storingpropeller
side down will keep the seals lubricated.
• Units placed in heavy weed or plant locations may need
to have the screen and prop cleaned occasionally. Before
removing or cleaning the unit, unplug or disconnect the
unitfromthepowersource.Scrubwithasti,nylon
bristle brush. Cleaners will not damage the unit; however,
these products could leave a residue that may damage
plants and animals when the unit is put back in service.
Whenusingcleaners,thoroughlyushandrinsetheunit
with fresh, clean water.
• Routinely inspect the propeller, internal brackets, and
shaft for the accumulation of weeds, vines or string.
Foreign objects can damage the seals, prop and shaft.
Keep the shaft and propeller clear of debris. Inspect the
brackets and propeller for chips and cracks. Broken or
damaged brackets or propeller can be replaced easily in
theeldwithfactoryparts.
• Inspect the power cord for breaks, nicks, and abrasion.
Under normal conditions, the cord will be usable for many
years. However, physical abuse and rodent, animal or
equipment damage can result in safety hazards such as
electrical shock. Replace the cord if there are deep enough
cuts in the outer jacket to see the inner conductors. A
severe shock could result if the copper wire is showing.
Immediately remove the unit from service and replace
the cord.
• Units operated in brackish or salt water must have a
sacricialanodeattachedtotheshaft.Theanodemust
be inspected periodically for deterioration. Operation
without the anode could result in metal deterioration and
contamination and may void the warranty.
WARNING:Donotopenthesealedmotorunitfor
any reason.
• The motor can only be opened and assembled under
special conditions at the factory or authorized
service center. Do not attempt to repair the motor. Any
tampering or attempted repairs may void the warranty
and could result in equipment failure or bodily injury.
• For optimum operation, send the unit to the manufacturer
orauthorizedservicecentereveryfourtoveyearsfor
standard service. Commercial duty operations may wish
to service units more frequently.
MAINTENANCE & TROUBLESHOOTING

7
Prop & Disc-Impellerthatts
the F500F & F1000F units
Large Brackets - (set of 4)
tsF500F&F1000F
Connects Motor Canister to
Shroud
AlMag Brackets - Fresh Water
Only
Shackles - (set of 2)
OneSize-tsF500F&F1000F
units. 1/4” stainless steel
shackles with a 9/64” short arm
hexkey
Black Mooring Lines - (set of 2)
25’Longx3/8”thickhollow
braided polypropylene ropes
Square Black Float
tsF500F&F1000F
U.V. Resistant High Density
Thermoplastic Float with Closed
Cell Foam Filling
P1101 Timer - for 115V Aerator
This grounded plug-in timer
utilizes an outdoor rated
raintightip-openenclosure.
(2)Onand(2)Osettingsmake
this a perfect timer to control
your unit and keep your
costs low.
T104PTimer - for 230V units
This heavy-duty timer stands
the test of time while providing
the highest horsepower ratings
in the industry for industrial,
commercial, and
residential applications.
Float Cage
24”Wx24”Lx16”H
Standard-tsF500F&F1000F
1″gridplasticcoated,hotrolled
metal screen that covers the
bottom5sidesoftheoat.
Minnow-tsF500F&F1000F
1/2″gridplasticcoated,hotrolled
metal screen that covers the
bottom5sidesoftheoat.
SacricialAnode
Aluminium-tsallmodel.1
anodeand1hexkeyincluded.
protects against corrosion and
electrolysis in salt water, high
electrical current and/or
warm water.
Electroylsis Kit
One Size-tsbothAerating
Fountain models Additional
protection against corrosion
and electrolysis in areas of high
salinity, high electrical current
and/or warm waters.
AeratingFountainShroud -
Patented heavy-duty PVC Venturi
housing designed for superior
waterowandmotor/propeller
protection.
12”x73/8”,tsF500F&F1000F
LightingAccent - (Float not
included)
tsF500F,&F1000F
115V-NoTransformer
(2) 18W Bright White LED Lights
Various cord lengths available.
Colored Lenses & Clips for additional wow factor!
PARTS & ACCESSORIES
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS
Replacement power cords, critter
sleeving, and motor assemblies are
available for Aerating Fountains.

8
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS
BearonAquatics,adivisionofBearonManufacturingLLC(hereincalled“Bearon”),warrantsproductstobefreefromdefects
inmaterialandworkmanshipforthewarrantyperiodspeciedbelowfromthedateofmanufacturebyBearon,undernormal
use and service. This limited warranty does not include defects or failures due to mishandling, misuse, improper installation, or
improper electrical supply.
Bearon will replace any defective parts covered by its warranty without charge for parts or labor, provided that the full unit is
returned to Bearon (or an Authorized Service Center) within thirty (30) days after discovering the defect.
Thiswarrantyisinlieuofanyotherwarranty,expressorimplied,includingbutnotlimitedto,anyimpliedwarranty
ofmerchantabilityortnessforaparticularpurposeandanyotherobligationorliabilitywhatsoeveronthepartof
Bearon.innoeventshallBearonbeliableforincidentalorconsequentialdamages.
Inadditiontotheproduct-speciclimitationsbelow,thewarrantywillbevoidedifanyofthefollowingoccurs:
• Use of parts or products not manufactured by Bearon;
• The unit is damaged or altered by unauthorized tampering and/or repairs;
• The unit was subjected to abuse, negligence, accident, or misapplication;
  •Example:chips/nicksanddeteriorationinpropellersize
• The unit is not stored properly;
• The unit was run out of water; or
  •Animpropersizedextensioncordorcircuit.
  IMPORTANT:oneunitperdedicatedoutlet
Standard maintenance services and the replacement of service items connected with such services are covered
by warranty.
StandardServiceitemsincludeseals,bearings,dielectricuid,boot&capacitor.StandardServiceisonlyavailableforIceEater,
Power House Aeration, & Weeds Away products.
All units must be shipped complete prepaid/brought to the attention of:
Bearon Aquatics
Attn: Service Center
10233S.DoleldRd.
OwingsMills,MD21117
OR can be shipped complete prepaid/brought to an authorized service center of Bearon Aquatics.
There are no warranties beyond those contained herein, and no person is authorized to give any other warranties or assume
liabilitiesonbehalfofBearon.Anevaluationfee(seespecicproductfordetails),plusreturnshipping,willbechargedwhena
unit is returned for repair and found to be in good working condition. The evaluation fee also applies for units customers decide
not to repair but wish to reclaim certain parts. The evaluation fee is waived if the unit is scrapped (at Bearon) or the unit is
repaired. After the original warranty period described below has ended, there is a thirty (30) day warranty period for a standard
repair by Bearon. A new, full warranty is only reissued if a customer purchases a brand new motor with service.
• Warranty Period: Three (3) years from the date of manufacture by Bearon. For non-standard use, the warranty period
is one (1) year from the date of manufacture by Bearon.
 •Inareasofhighsalinity,brackish,highelectricalcurrent,and/orwarmtemperatures,asacricialanodeshouldbeused
 ontheshaftorformoreextremeconditions;anelectrolysiskitmustalsobemountedtothestainlesssteelcan.
• In addition to the limitations above, this limited warranty does not include any defects or failures of the ropes, power
cord, propeller, or brackets.
 •Thewarrantywillbevoidediftheshaftand/orstainlesssteelcanshowssignicantdeterioration.Failuretokeepthe
shaft and can clear of debris (including string, bags, calcium buildup, barnacles, etc.); or if the propeller/impeller shows
 signsofexcessiveorunusualwearandtear.
• Failure to inspect and clean units constitutes misuse. Recommended frequency for cleaning the unit is once a month.
 •Completeunitsmustbeshippedforevaluation;however,wedonotrequireoatstobesentinforwarranty
 inspectionsunlesstheoatisdefective.
• The evaluation fee is $65.
**All units sent to Bearon or authorized repair center are considered abandoned,
ifnotclaimed,aftersix(6)months.Bearonisnolongerresponsibleforsuchunits,
and units will be scrapped.**
WARRANTY
