Beavertail Flip Top Blind User manual

Flip Top Blind Instructions
PARTS LIST
Item # Qty Description
1. 1 Canvas Blind
2. 2 Large elbows
3. 2 Hinge Brackets with pin and bolt
4. 2 Small Elbows
. 2 Main cross members with pins and hinges
6. 3 or 2 Large center section bars (1800 has 3, 1400/1600 has 2)
7. 3 or 2 Small center section bars (1800 has 3, 1400/1600 has 2)
8. 2 Straps
9. Bungee cords
Tools required
Drill/Driver
7/16 wrench and ratchet with 7/16 socket
Phillips bit for drill
Cross
members
Large
elbows
Hinge
Brackets
Bungee
cords
Fabric
Blind
Small
elbows Straps
Large center
sections
Small center
sections

2. Attach the hinge bracket to the main support pole as shown below using the ¼ x 1 ½
bolts and nylock nuts. Do this on both support poles.
3. Attach large elbow to the hinge bracket. The support hinge should be on the inside
and the elbow should point in the same direction.
Attach bracket
here with the
two bolts and
nylock nuts.
Support hinge should be
on the inside.
Hinge bracket
Main support bar

4. Assemble the three large center bars. The longer piece with the two flared ends will
be in the middle and the other two pieces will slide into place, one from each end. Use
two self tapping screws at each joint to reduce the amount of movement in the pole. If
you need to be able to disassemble the poles so the blind is a more compact size then do
not install the self tapping screws.
. Repeat process for the three small center bars.
Slide poles together
Secure with self tapping
screws. (Optional)
Slide poles together Secure with self tapping
screws (optional)

6. Attach the small elbow to the small center bar as shown. Attach an elbow on each
end.
7. Attach the assembled small support bar to the main support pole using the provided
pins as shown below. Repeat on other end.
Attach small
support pole
here.
Small support pole
attached and in place

8. Slide the assembled large support pole into the sleeve on the front edge of the blind.
9. Position blind as shown below and then attach the large support bar to the large
support elbows.
Pole inserted
into sleeve.
Attach here. Attach here.
Insert here

10. Slide blind over large elbows and attach the blind to the small support bar with the
Velcro straps.
11. Install completed Flip Top Blind onto the top of the Beavertail Boat Blind. The
plastic c-clips will fit over the boat blind tubing as shown below. Install one clip from
the top and one from the bottom to prevent the blind from coming off. If both clips are
installed from the top then the strap must be used to hold the Flip Top blind to the boat
blind. The two clips in back will both clip on from the top.
Completed blind.
Clip on top
Clip on
bottom

12. Attach bungee cords to the vegetation straps and hook onto either the blind frame or
boat.
13. Completed blind installed on the top of the boat blind.
Attach bungee cords

14. The front opening or height of the blind may be adjusted by changing the position of
the pin in the hinge bracket. There are three holes to adjust the blind from low to high.
1 . To lock the blind in one position so it cannot be flipped open first determine the
proper height for your situation. Next drill a hole through the main support pole so the
pin will fit through it. The pole should be lined up with one of the three holes in the
hinge bracket when the hole is drilled.
Tips:
- Use mud to reduce any shine of the fabric. A light mist of brown camo paint will work
as well. Most of the outfitters and guides routinely use these methods.
- Utilize the vegetation straps to make the boat nearly invisible to the birds.
- Do not store the blind wet. Allow it to dry out before storing.
Adjust blind height
by moving pin.
Line pole up with one of
the bracket holes and
drill through.
