Becker TRAFFIC ASSIST 7977 User manual

Instructions for Use

2
>>> SAFETY MESSAGE HIERARCHY
> EN
Safety message hierarchy
This manual uses the following types of
safety messages to draw your attention to
important safety and other information
for use of the Traffic Assist.
Please review the symbols and content of
the boxes below. The information in the
DANGER, WARNING, CAUTION
and NOTICE boxes describes the poten-
tial consequence associated with disre-
garding the messages throughout the
manual. The information in the NOTE
boxes relates to use of the Traffic Assist.
DANGER
The warnings contain safety information
regarding hazardous situations, which if
not avoided, will result in death or seri-
ous injury.
WARNING
These warnings contain safety informa-
tion regarding hazardous situations
which, if not avoided, could result in
death or serious injury.
CAUTION
These warnings contain safety informa-
tion regarding hazardous situations
which, if not avoided, could result in mi-
nor or moderate injury.
NOTICE
These warnings contain information re-
garding items or situations which may
cause damage to the unit or vehicle if dis-
regarded, information regarding unit
warranties and/or information pertinent
to traffic laws.
Note:
This provides information regarding use
of the unit.

3
> EN
INDEX >>>
Safety message hierarchy 2
Index 3
Safety information 7
The Traffic Assist 9
Contents of the Instructions for Use 9
Use 9
Navigation 9
Music 10
Pictures 10
Video 10
Telephone* 10
Unpacking the Traffic Assist 10
Checking the delivery 10
Delivery contents 10
Complaints procedure 11
Handling the packaging 11
Description of the Unit 11
Traffic Assist - basic unit 11
Cable for power supply from
cigarette lighter 12
Battery 12
SD memory card 12
USB connection cable 13
Unit bracket 13
Accessories 13
Grid power supply unit 13
External microphone* 13
External GPS antenna 13
Docking station 13
Headset 14
Information About
Documentation 14
Instructions for Use 14
Registration 14
Repairs 14
Emissions and disposal 14
Overview Traffic Assist 15
Gerneral operation 20
Maintenance and care 20
Battery quality declaration 21
Display quality declaration 21
Start-up 21
Memory card 21
Inserting the memory card 22
Ejecting the memory card 22
Power supply 23
Using the battery 23
Connecting to the socket 23
Connecting up to power supply 23
Removing the power supply 24
Connecting to the cigarette lighter 24
GPS antenna 24
Unit antenna 24
Connecting up external
antenna 25
Connecting USB storage media 25
Docking station (optional) 25
Switching the Traffic Assist On/Off 26
Switching On 26
Switching Off 27
Unit bracket 27
Fitting the unit bracket 28
On the windshield 28
Adjusting the unit bracket 29
Vertical movements 29
Horizontal movements 29
Adding the Traffic Assist 29
Removing the Traffic Assist 29
Basic information about the
touchscreen 30
Operation 30
Calibration 30
Basic information about the menus 30
The main menu 30
Entries made with the entry menu 31
Entering characters 31
Adopting suggestions 31
Scrolling through the lists 32
Special characters 32
Entering numbers 32
Switching between upper and
lower case 33
Deleting characters 33
Inserting spaces 33
The Becker key 33
Volume control 34
Map data 34
Installation program 34
Index
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

4
>>> INDEX
> EN
Transferring files 34
Transferring using the SD card reader 34
Transferring using the USB port 35
Transferring maps 35
Transmitting music tracks, pictures
and videos 35
Faults 36
Navigational mode 37
What is navigation? 37
Selecting navigation 38
Aids for navigation 38
Rapid access 38
Navigation menu 38
Map display 38
Rapid access 38
Structure of rapid access 38
Navigation menu and map display 38
The list of destinations 39
Icons used 39
Operating rapid access 39
Starting using an existing destination 39
Scrolling in the destinations memory 39
Displaying or editing destinations 40
Change to the map display 41
Displaying current position 41
Calling up the Navigation menu 41
The Navigation menu 41
Structure of the navigation menu 42
Address 42
Point of interest 42
Select on map 42
Enter coordinates 42
Route planning 42
Settings 42
Navigation menu: Address 42
Selecting a state/territory 43
Select address 43
Set options and start navigation 46
Canceling navigation 48
Navigation menu: Point of interest 49
Point of interest: Near GPS position 49
Point of interest: nationwide 50
Navigation menu: Select on map 51
Navigation menu: Route planning 52
Route list 53
Using a route 53
The New key 54
The Edit key 54
The Calculate key 55
The Start key 55
Navigation menu: Enter coordinates 55
Navigation menu: Settings 56
The Routing options key 57
The Auto mode key 58
The Format key 58
The Map info key 59
The Route info key 59
The Speed key 60
The TMC key 61
The Time Zone key 61
The Smart Speller key 62
The Junction Info key 62
The Home address key 63
The Volume key 63
The GPS key 64
The Load map key 64
The Offroad key 64
Offroad navigation 65
Destination in offroad area 65
Start point in offroad area 65
Map display 66
Map layout 66
Map display without driving guidance 66
Map display with driving guidance 66
Map display with toolbar 67
Using the map display 68
Repeat the last voice prompt 68
Changing the announcement volume 68
Additional information 69
Position information 69
Zooming and the map (toolbar) 69
Display route (toolbar) 69
Daytime - Night-time design (toolbar) 70
Change display (toolbar) 70
Point northwards (toolbar) 70
Available POIs along the route
(toolbar) 70
Move map (toolbar) 72
Calling up the options menu (toolbar) 72
Playback of MP3 files during an
active navigation 73
Calling up the telephone function
(toolbar)* 73
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

5
> EN
INDEX >>>
Telephone mode* 74
Calling up telephone mode 74
Telephone fast access mode 74
Configuration of fast access mode 74
Number list 75
Icons used 75
Operating in fast access mode 75
Dialling an existing number 75
Scrolling through the number list 75
Displaying or editing entries 76
Telephone menu 76
Dialling a number 77
Telephone book 77
Connecting a mobile phone 78
Opening the device list 78
Connecting automatically 79
Searching for a mobile phone 80
Connecting from the device list 80
Disconnecting a mobile phone 81
Telephone/Bluetooth settings 81
Switching Bluetooth on/off 81
Visibility of the Traffic Assist 81
Activating/deactivating automatic
connection 82
Refreshing the phonebook 82
Setting the telephone volume 82
Device name 82
Telephone calls 83
Establishing a call 83
Answering a call 83
Ending a call 84
When route guidance is active 84
Without route guidance 84
Music operations 85
Selecting music playback 85
The MP3 player 85
Operating the MP3 Players 86
Track skip 86
Play 86
Pause 86
Canceling playback 86
Folder overview 87
Track repeat/random play function 87
Setting volume 88
Navigation during MP3 player
operation 88
Shutting down the MP3 Player 88
Pictures mode 89
Selecting pictures display 89
The Picture Viewer 89
Operating the Picture Viewers 90
Scrolling 90
Slideshow 90
Full screen 90
Shutting down the Picture Viewer 90
Folder viewing mode 91
Operating folder viewing mode 91
Subfolders 91
Scrolling 91
Selecting a picture 91
Changing folder levels 91
Closing folder viewing mode 91
Video mode 92
Selecting video playback 92
The video player 92
Operating the video player 92
Opening and playing videos 92
Showing the button bar while
video is playing 93
Pausing and resuming playback 93
Fast forward/reverse 93
Setting the volume 94
Settings 95
Selecting the settings 95
The setting menu 95
Operation 95
Selection possibilities 95
Closing the setting menu 95
The individual menu points 95
Energy 95
Displaying the energy supply 95
Ending the status display 96
Day/night display 96
Calibration 96
Starting calibration 96
Language 97
Calling up language selection 97
Turn the page 97
Selecting the language 97
Canceling the language selection 97
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

6
>>> INDEX
> EN
Moodlight 97
Tones 98
Automatic on/off 98
Switching the function on / off 98
Information 98
Factory settings 99
Car integration* 99
Specialist Words 100
Keywords 102
Technical Data 105
NOTICE 106
FCC Information 106
C-Tick mark 106
EU Declaration of Conformity 107
Disposal 107
*Applies only to the Bluetooth®-enabled Traffic Assist 7977
The information and data contained in
these documents are subject to change
without prior notice.
No part of these documents may be repro-
duced or transmitted for any purpose
without express written permission from
HARMAN/BECKER Automotive
Systems GmbH . All technical informa-
tion, drawings etc. are subject to copyright
law.
© Copyright 2008, HARMAN/BECKER
Automotive Systems GmbH
All rights reserved.

7
> EN
SAFETY INFORMATION >>>
Safety information
WARNING
• The unit may only be operated if the traffic situation permits and if you are absolutely certain that you, your fellow
passengers or other road users will not be put at risk, encumbered or distracted by it. This unit should not be used as a
substitute for the personal judgment of the driver.
• Applicable traffic regulations must be observed at all times. Destinations may only be input when the vehicle is stationary.
• The unit may only be used for its intended purpose. The volume of the navigational unit should be set so that noises
outside the vehicle can still be heard.
• The SD memory card can be removed. Small children could swallow it.
• Ensure the unit is installed outside the deployment zone of the airbags. Airbag deployment could dislodge the unit and
propel it toward an occupant or impair the function of the airbags, resulting in personal injury or death. See your
vehicle's owner's manual or contact the manufacturer of your vehicle for more information.
• Insufficient attention to the road, traffic controls or traffic conditions may result in traffic accidents. Accordingly, the
driver should not operate the unit while he/she is driving.

8
>>> SAFETY INFORMATION
> EN NOTICE
• The navigational system is only an aid. The data/details provided may in some cases be incorrect. The driver must always
decide whether or not to follow the directions given. We accept no liability for incorrect details issued by the navigational
system. As a result of traffic routing changes and deviating data, inaccurate or incorrect instructions may be given. Drivers
should always pay attention to the actual road signs and traffic conditions. In particular, the navigational system cannot
be used as a means of orientation in cases of poor visibility.
• The unit should be switched off immediately if faults occur (e.g. development of smoke or smells).
• For safety reasons, the unit may only be opened by a specialist. Please contact your local dealer if you require repairs.
• Please check local and state traffic laws prior to installation of the unit. For example, there may be regulations in your
state which forbid mounting the unit on the windshield. HARMAN/BECKER assumes no liability for driver errors or
the non-observance of applicable laws.
• In order to prevent theft of the unit, please take the unit with you when leaving the vehicle unattended.
• The grid voltages (V) indicated on the home charger, the car charger adapter and the unit must not be exceeded. Failure
to observe this can result in destruction of the unit and the charger as well as explosion of the rechargeable battery.
• Never open the unit or the rechargeable battery. Modifications to the unit are impermissible and may void the warranty.
• Use only genuine HARMAN/BECKER original accessories. This will ensure that all the relevant regulations are complied
with and damage to health and property is avoided. Dispose of defective units and the rechargeable battery according to
the applicable legal requirements.
• No warranty is granted in the case of improper use. These safety instructions also apply to genuine HARMAN/BECKER
original accessories.

9
> EN
THE TRAFFIC ASSIST >>>
The Traffic Assist
Contents of the Instructions
for Use
This Instructions for Use describes the
two devices Traffic Assist 7827 and Traf-
fic Assist 7977. The difference between
the two devices lies in the additional Blue-
tooth enablement of the Traffic Assist
7977.
All descriptions, except for those marked
with an asterisk (*), apply to both devices.
The sections of the Instructions for Use
marked with an asterisk (*) apply specifi-
cally to the Traffic Assist 7977.
Use
The Traffic Assist is a powerful PND
(Personal Navigation Device) for use in
vehicles and closed spaces. The unit
should be protected from dampness and
dirt.
The Traffic Assist can be used as a:
• navigational unit
• MP3 (device for playing music)
• Picture viewer
•Videoplayer
• Can be used as a very convenient hands-
free unit via Bluetooth®*
Navigation
Thanks to the GPS = Global Positioning
System, you no longer need to spend
hours searching through road atlases.
Once outside buildings, the receiver an-
tenna integrated in the unit gives you con-
tinuous access to navigational possibili-
ties. Depending on reception, you may
not be able to use the navigational func-
tion inside buildings. When used in vehi-
cles, you may not be able to adequately re-
ceive GPS data depending on how the
Traffic Assist is installed. In such cases,
you will have to connect up to an external
antenna (does not fall within the scope of
supply).
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

10
>>> THE TRAFFIC ASSIST
> EN
Music
Thanks to the integrated MP3 Player, you
can listen to your favorite tracks when on
the go.
Pictures
The Traffic Assist has a Picture Viewer of-
fering many functions for viewing pic-
tures.
Video
Traffic Assist features a video player for
playing videos.
Telephone*
Your Traffic Assist is equipped with Blue-
tooth® wireless technology. You can con-
nect a mobile phone equipped with Blue-
tooth® wireless technology to it via
Bluetooth. Your Traffic Assist serves as a
very convenient hands-free unit. In addi-
tion, you also have the option of reading
out the mobile phone's address book or
phonebook.
Unpacking the Traffic Assist
Checking the delivery
Before the Traffic Assist is started up, the
delivery should be checked to ensure that
it is complete, and in the correct condi-
tion (see also page 15).
>Carefully unpack the content of the
package, and check it.
Delivery contents
1Traffic Assist, the mobile navigation
system with integrated MP3 player,
video player, picture viewer and ex-
tremely convenient Bluetooth®
hands-free unit*
2Unit holder
312 V car power adapter for cigarette
lighter socket
4Memory card (SD memory card) with
pre-installed map data
5USB cable
6DVD with installer for map data, ac-
tual map data and operating instruc-
tions (not illustrated).
Note:
Your Traffic Assist is supplied in rugged
packaging. Do not unpack the unit en-
tirely if you discover any serious damage
to the packaging or its content. If this
happens, please contact your local dealer.
1
2
3
4
5
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

11
> EN
THE TRAFFIC ASSIST >>>
Complaints procedure
Please contact your local dealer if you have
any complaints. The unit can also be sent
directly to Harman/Becker in its original
packaging.
Handling the packaging
Keep the original packaging in a dry place,
at least for the warranty period.
Description of the Unit
The Traffic Assist consists of the basic
Traffic Assist unit, and the accessories in-
cluded in the delivery.
You will find photos of the individual
parts under:
• "Overview Traffic Assist" on page 15
Traffic Assist - basic unit
The basic unit contains all the electronics:
• an integrated antenna,
• a touchscreen,
• an integrated loudspeaker for the out-
put of messages during navigation and
for MP3 files and phone calls*,
• a microphone*.
On the sides of the unit, there are also
light bars as well as various connections
and ports.
You will find more details of the unit
under:
• See “Technical Data” on page 105.
Note:
The packaging should be disposed of cor-
rectly in accordance with national dispos-
al guidelines. The packaging must not be
burnt. Depending on the country to
which the unit is supplied, it may be pos-
sible for local dealers to accept packaging.
NOTICE
The basic unit and accessories must not
be opened or modified in any way.
Modifications to the unit and/or accesso-
ries may void the warranty
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

12
>>> THE TRAFFIC ASSIST
> EN
Cable for power supply from
cigarette lighter
This cable allows the unit to be connected
up to the car's cigarette lighter.
The power supply must satisfy the follow-
ing requirements:
• DC current 12 Volts
0.5 amps
Battery
When depleted, the integrated rechargea-
ble battery can be recharged by connect-
ing the Traffic Assist to the power supply.
For this purpose, connect the unit via a car
power adapter to a 12 V plug socket in a
vehicle or via the optional grid power
supply unit to the110 - 230 V grid.
SD memory card
A memory card is used as a storage medi-
um for road maps, music tracks and imag-
es.
The map data is preinstalled on the card
supplied with the unit. If you intend to
listen to music or view images using the
Traffic Assist, you can save these to the
free space on the memory card. If you re-
quire more memory space, you must save
further images or music tracks to a sepa-
rate card (not included). The separate card
must be formatted with the FAT 16 file
system.
When not in the unit, the memory card
must be stored in a protected dry place
away from direct sunlight in the packag-
ing supplied. Avoid touching or dirtying
the contact strip.
You will find more details about the mem-
ory card under:
• "Technical Data" on page 105
Note:
You can charge the Traffic Assist via the
car charger cable included in the scope of
delivery or via the optionally-available
grid power supply unit.
When the Traffic Assist is connected to a
PC, it is supplied with power via the PC
and does not consume battery power.
Notes:
If you wish to listen to music using the
Traffic Assist while navigation is
underway, it must be stored on the
supplied memory card or a USB storage
medium. The Traffic Assist does not
support the changing of memory cards
during navigation.
CAUTION
The SD memory card is removable.
Keep away from small children as it could
be swallowed.

13
> EN
THE TRAFFIC ASSIST >>>
USB connection cable
The USB connection cable can be used to
connect the unit to a standard personal
computer by means of the USB port.
However, to use the data on the PC, you
will first have to install the free "Active
Sync" software from Microsoft®.
Unit bracket
The Traffic Assist can be mounted in the
vehicle using the unit bracket.
Accessories
Grid power supply unit
This power supply allows connection of
the Traffic Assist to a grid outlet.
Requirements for the power supply:
Alternating current
• 100-240 V
0.2 Amps
50-60 cps
External microphone*
The internal microphone of the Traffic
Assist may not be able to achieve satisfac-
tory voice quality if the Traffic Assist is
placed unfavourably in the vehicle.
In these cases, please use the optionally
available external microphone. Please con-
sult your local specialist dealer.
Details of the connection can be found
under "Docking station (optional)" on
page 25.
External GPS antenna
You can use an external antenna to im-
prove reception in vehicles where only
limited GPS reception is available (not in-
cluded in the scope of supply). Please con-
tact your local dealer for more informa-
tion.
Details of the connection can be found
under "Connecting up external antenna"
on page 25.
Docking station
The optionally available docking station
replaces the carrier plate of the Traffic As-
sist included in the scope of delivery.
There are various connections on the
docking station. These connections can be
used to connect the Traffic Assist to an au-
dio system already installed in the vehicle.
Details of the connections on the docking
station can be found under "Docking sta-
tion (optional)" on page 25.
NOTICE
Please observe all regulations/laws in
your state as they may limit or specify
mounting locations of the unit.
Note:
Connection is only possible using the op-
tionally available docking station.
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

14
>>> THE TRAFFIC ASSIST
> EN
Headset
When using the Traffic Assist as an MP3
player, commercially available head-
phones with a 3.5 mm jack or adapter can
be connected (not included).
Information About
Documentation
Instructions for Use
A comprehensive explanation of the Traf-
fic Assist functionalities is contained in
these operating instructions.
Registration
You can register your product using our
software service; we will then inform you
of any new updates and other news.
You can register online on the Becker
homepage www.mybecker.com.
The “Software update” menu item is lo-
cated under “SERVICE/SUPPORT“.
Repairs
The unit must not be opened if it is dam-
aged. Please contact your local dealer.
Emissions and disposal
Information on emissions, electromagnet-
ic compatibility and disposal can be found
in the "NOTICE" on page 106.
WARNING
The use of headsets or ear-
phones at high volumes over
an extended period can cause
permanent hearing damage.
The use of headphones while driving is
illegal in many states and could interfere
with your ability to hear noises outside
the vehicle. Use headphones only when
the vehicle is safely parked.
NOTICE
It is forbidden to use headsets during
driving in many states. Please observe the
applicable laws and regulations in this re-
gard.

15
> EN
OVERVIEW TRAFFIC ASSIST >>>
Overview Traffic Assist
Scope of supply
1Traffic Assist - PND (Personal Navigation Device)
2Memory card (containing navigational data)
3USB connection cable
4Cable for power supply from car's cigarette lighter (12 Volts)
5Unit bracket
12
3
45

16
>>> OVERVIEW TRAFFIC ASSIST
> EN
Front of unit with controls and displays
1Touchscreen showing the main menu selected
2Touchscreen key
Press = activates the corresponding key command
3Microphone with flashing activity indicator for Bluetooth*
4Becker key ( )
Press = returns to numerous applications
Press for longer = switches the Traffic Assist on and off
5Mood light
2
4
5
1
3
*Applies only to the Bluetooth®-enabled Traffic Assist 7977

17
> EN
OVERVIEW TRAFFIC ASSIST >>>
Rear of unit
1Point for connecting up an external antenna
(external antenna not included in the scope of supply)
2Interface for docking station (docking station not included in
the scope of supply)
2
1

18
>>> OVERVIEW TRAFFIC ASSIST
> EN
Left side of unit
1SD memory card slot
2Reset button
3ON/OFF switch
Right side of unit
4Volume control
Move upward = increase volume
Move downward = decrease volume
Press = mute
53.5 mm connection for headset (headset not included in the
scope of supply)
6USB port for data carrier containing MP3 or image files
7Mini USB connection
1
2
4
5
3
6
7

19
> EN
OVERVIEW TRAFFIC ASSIST >>>
Left docking station
1Connection for telephone mute cable (accessory)
2Connection for audio signal cable (accessory)/external micro-
phone (accessory)
Right docking station
3Connection for TMC antenna (TMC is not supported in
Australia)
4Connection for external power supply
4
3
2
1

20
>>> GERNERAL OPERATION
> EN
Gerneral operation
Maintenance and care
The unit is maintenance-free.
For proper care, a commercially available
cleansing fluid for electrical devices may
be applied using a soft damp cloth.
Your mobile navigation system was de-
signed and manufactured with great care
and should be treated with equal care. You
will enjoy your mobile navigation system
for a long time to come if you observe the
recommendations listed in the following:
• "Protect your mobile navigation system
from water and moisture. If your unit is
exposed to moisture, switch it off im-
mediately and disconnect the power
supply. Allow the unit to dry at room
temperature.
• Do not operate your mobile navigation
system in a dusty or dirty environment,
and do not store it in such an environ-
ment.
• Do not store your mobile navigation
system in hot environments. High tem-
peratures can shorten the service life of
electronic components in your unit,
damage the rechargeable batteries, and
cause certain plastics to warp or melt.
• Do not store your mobile navigation
system in cold environments. During
operation, when the unit warms up to
operating temperature, moisture may
form internally, causing damage to elec-
tronic components.
• Do not drop your mobile navigation
system unit, protect it from shocks and
do not shake it. Improper handling can
damage components within the unit.
• Never use corrosive or aggressive chem-
icals, cleaning solutions or aggressive
detergents for cleaning.
All of the above information applies
equally to the mobile navigation system,
the rechargeable battery, the grid charg-
ing, and car power adapters as well as all
accessories. Should one of these parts not
work properly, please contact your au-
thorized dealer.
DANGER
Danger to life by electrocution. Always
switch off the unit and disconnect the
grid power supply unit before cleaning
the unit, supplied components, or acces-
sories.
Note:
Do not use any aggressive or abrasive
substances or cloths which may damage
the surface.
The unit must not be exposed to water.
