The Beckhoff bus terminal system
Up to 64 bus terminals
each with 2 I/O channels
for any form of signal
Decentralized wiring of the
I/O level
IPC as control unit
Bus couplers for all current
bus systems
Standard C rail assembly
Modularity
Display of channel status
The bus terminal system is the universal connecting link between a field-
bus system and the sensor/actor level. A unit consists of a bus coupler,
which is the interface to the fieldbus, and up to 64 electronic terminals, of
which the last is an end terminal. Terminals, each with two I/O channels,
are available for any form of technical signal and can be combined as de-
sired. The various types of terminal are all constructed in the same way, so
that the planning costs are kept extremely low. The height and depth of the
construction are calculated for compact terminal cabinets.
Fieldbus technology makes it possible to use compact control architec-
tures. The I/O level does not need to be taken right up to the control unit.
Sensors and actors can be connected decentrally with minimal lengths of
cable. You can position the control unit at any convenient location in the
installation. Using an industrial PC as control unit makes it possible to im-
plement the operating and monitoring element as part of the control hard-
ware, so the control unit can be located on an operating desk, control point
or similar. The bus terminals constitute the decentralized input/output level
of the control unit in the switch cabinet and its subordinate terminal cabi-
nets. As well as the sensor/actor level, the power unit of the equipment is
also controlled via the bus system. The bus terminal replaces a conven-
tional terminal as the cabling level in the switch cabinet; the switch cabinet
can be made smaller.
The Beckhoff bus terminal system combines the advantages of a bus sys-
tem with the functionality of compact terminals. Bus terminals can be used
on all current bus systems and serve to reduce the diversity of parts in the
control unit, while behaving like the conventional standard units for the
relevant bus system and supporting the entire range of functionality of the
bus system.
The simple and compact assembly on a standard C rail, and the direct
cabling of actors and sensors without cross connections between the ter-
minals, serve to standardize the installation, as does the uniformly de-
signed labeling.
The small size and great flexibility of the bus terminal system mean that
you can use it anywhere that you could use a terminal and use any type of
connection – analog, digital, serial or direct sensors.
The modular construction of the terminal row, using bus terminals with
various functions, limits the number of unused channels to at most one per
function. Two channels to a terminal is the optimum solution for the number
of unused channels and the cost per channel. The possibility of using
power input terminals to provide separate power supplies also helps to
minimize the number of unused channels.
The integrated light-emitting diodes close to the sensor/actor indicate the
status of each channel.
The K-bus
End terminal
The K-bus is the path taken by data within the terminal row. The bus cou-
pler carries the K bus through all the terminals by means of six contacts on
the side walls of the terminals, and the end terminal terminates the K bus.
The user does not need to know anything about the function of the K bus
or the internal operation of terminals and bus couplers. There are numer-
ous software tools available which provide for convenient planning, con-
figuration and operation.

Basic information
5 BK 7000
Power input terminals
for
separately powered groups
Three power contacts pass the operating power to the following terminals.
You can use power input terminals to subdivide the terminal row as desired
into groups, each with a separate power supply. These power input termi-
nals are not taken into account for addressing the terminals, you can insert
them at any position along the terminal row.
You can install up to 64 terminals on a terminal row, including power input
terminals and the end terminal.
The principle of the bus
terminal
isolation
contacts
bus coupler for the input Bus end
BK7000 bus coupler terminal
Terminal bus
PotentialPower
terminal
ControlNet
Powersupply
Potential
+ +
00X0
PE PE
BECKHOFF
4V
0V
BK7000
ControlNet
0
9
8
7
6
5
4
3
1
0
9
8
7
6
5
4
3
1
x10
x1
A
B
Bus couplers for various
fieldbus systems
You can use a variety of bus couplers to attach the electronic terminal row
quickly and easily to the various fieldbus systems, and you can also sub-
sequently convert to a different fieldbus system. The bus coupler deals with
all the necessary monitoring and control tasks for operating the attached
bus terminals, indeed all the operation and configuration of the bus termi-
nals is carried out via the bus coupler. The fieldbus, K bus and I/O level are
electrically isolated.
If the exchange of data across the fieldbus is temporarily interrupted, logic
states are preserved, digital outputs are cleared and analog outputs revert
to a reset value which can be individually configured for each output when
the equipment is set up.

Basic information
BK 7000 6
The interfaces
There are six ways of making a connection to a ControlNet bus coupler.
These interfaces are designed as plug connections and spring terminals.
The ControlNet coupler
BK7000
Power LEDs
Bus coupler / power contacts
Terminal bus
Power supply bus coupler
4 V DC / GND
Input
power contacts
power contacts
+
+
00X0
PE
PE
BECKHOFF
4V
0V
BK7000
ControlNet
Configuration
Interface
Network Access
Port (NAP)
Field Bus
Connector B
Field Bus
Connector A
0
9
8
7
6
5
4
3
1
0
9
8
7
6
5
4
3
1
Address
Selector
x10
x1
A
B
Power supply
24 V DC on the topmost
terminals
The bus couplers need an operating power of 24 V DC which is connected
via the topmost spring terminals, labeled "24 V” and "0 V”. This power sup-
ply serves not only the electronic components of the bus coupler but (via
the K bus) also the bus terminals. The power supply of the bus coupler
circuitry and that of the K-bus (Terminal bus) are electrically isolated from
the voltage of the field level.
Power supply to the power contacts
Lower 3 terminal pairs for
power input
maximum 24 V
maximum 10 A
The six lower connections with spring terminals can be used to supply
power to the peripherals. The spring terminals are connected in pairs to the
power contacts. The power supply to the power contacts has no connec-
tion to the power supply of the bus couplers. The power input is designed
to permit voltages up to 24 V. The pair-wise arrangement and the electrical
connection between the feed terminal contacts makes it possible to loop
through the wires connecting to different terminal points. The load on the
power contact may not continuously exceed 10 A. The current capacity
between two spring terminals is the same as the capacity of the connecting
wires.
Power contacts
Spring contacts at the side
On the right-hand side face of the bus coupler are three spring contacts
which are the power connections. The spring contacts are recessed in slots
to prevent them from being touched. When a bus terminal is connected,
the blade contacts on the left-hand side of the bus terminal are connected
to the spring contacts. The slot and key guides at the top and bottom of the
bus couplers and bus terminals ensure reliable location of the power con-
tacts.
Fieldbus connection
Control-Net connectors
On the left-hand side there are two ControlNet connectors A and B and a
NAP-Port. You will find a detailed description of the fieldbus interfaces in
another part of this manual (In the chapter "The transfer medium: plugs
and cables”).

Basic information
7 BK 7000
Configuration interface
Serial interface under the
front flap
On the lower part of the front face you will find the standard bus couplers
which are fitted with an RS232 interface. The miniature plug can be at-
tached to a PC by means of a connection cable and the configuration soft-
ware KS2000. This interface enables you to configure the analog channels.
You can also access the functionality of the configuration interface via the
fieldbus by means of the PLC interface communications.
K-bus contacts
6 contacts at the side
The connections between the bus coupler and the bus terminals are ef-
fected by gold contacts at the right-hand side of the bus coupler. When the
bus terminals are plugged together, these gold contacts automatically
complete the connection to the bus terminals. The K bus is responsible for
the power supply to the electronic components of the K bus in the bus ter-
minals, and for the exchange of data between the bus coupler and the bus
terminals. Part of the data exchange takes place via a ring structure within
the K bus. Disengaging the K bus, for example by pulling on one the bus
terminals, will break this circuit so that data can no longer be exchanged.
However, there are mechanisms in place which enable the bus coupler to
locate the interruption and report it.
Supply isolation
3 supply groups:
fieldbus
K-bus
peripheral level
The bus couplers operate with three independent supplies. The input
power supplies the electrically isolated K-bus circuitry in the bus coupler
and the K-bus itself. The power supply is also used to generate the operat-
ing power for the fieldbus.
Note: All the bus terminals are electrically isolated from the K bus, so that
the K-bus is completely electrically isolated.
Setting up the power levels
in the bus terminal system
Periphery level
Bus terminals
Bus coupler
Field bus
4 V DC
Terminal bus

Basic information
BK 7000 8
The operating modes
When it is first switched on the bus coupler carries out a self-test to check
the functions of its components and the communications of the K bus, and
while this is going on the red I/O LED will flash. When the self-test has
been completed successfully, the bus coupler will begin to test the at-
tached bus terminals (the "bus terminal test”) and read in the configuration
from which it constructs an internal structure list, which is not accessible
from outside. If an error occurs the bus coupler will enter the operating
mode "STOP”. If the start-up sequence is completed without errors the bus
coupler will enter the mode "fieldbus start”.
Start-up behavior of the bus
coupler
The bus coupler reports the error by means of the IO-ERR-LED. Clearing
the error returns the bus coupler to its normal operating mode.

Basic information
9 BK 7000
Mechanical design
The Beckhoff bus terminal system is remarkable for its compact construc-
tion and high degree of modularity. When you design the installation you
will need to plan for one bus coupler and some number of bus terminals.
The dimensions of the bus couplers do not depend on the fieldbus system.
If you use large plugs, for example like some of the bus plugs used for the
Profibus, they may protrude above the overall height of the cabinet.
Dimensions of a
bus coupler
+
+
00X0
PE
PE
BECKHOFF
4V
0V
BK7000
ControlNet
0
9
8
7
6
5
4
3
1
0
9
8
7
6
5
4
3
1
x10
x1
A
B
1
0
0
94
49
1
E0
.0
+ +
00
.1
PE
PE
The overall width of the construction is the width of the bus coupler, includ-
ing the bus end terminal, plus the width of the installed bus terminals. The
bus terminals are 12 mm or 24 mm wide, depending on their function. De-
pending on the gauge of cables used the overall height of 68 mm may be
overstepped by about 5 mm to 10 mm by the cables at the front.
Assembly and connections
It takes only a slight pressure to latch the bus coupler and the various bus
terminals onto a supporting 35mm C rail and a locking mechanism then
prevents the individual housings from being removed. You can remove
them without effort if you first release the latching mechanism by pulling the
orange tab. You should carry out work on the bus terminals and the bus
coupler only while they are switched off: if you plug or unplug components
while the power is on you may briefly provoke some undefined state (and,
for instance, reset the bus coupler).
You can attach up to 64 bus terminals in series on the right-hand side of
the bus coupler. When you assemble the components, make sure that you
mount the housings so that each slot comes together with the correspond-
ing key. You cannot make any functional connections merely by pushing
the housings together along the supporting track. When they are correctly
mounted there should be no appreciable gap between the adjacent hous-
ings.
The right-hand side of a bus coupler is mechanically similar to a bus termi-
nal. There are eight connections on the top which can be used to connect
to thick-wire or thin-wire lines. The connection terminals are spring loaded.
You open a spring terminal by applying a slight pressure with a screwdriver
or other pointed tool in the opening above the terminal and you can then
insert the wire into the terminal without any obstruction. When you release
the pressure the terminal will automatically close and hold the wire se-
curely and permanently.

Basic information
BK 7000 10
Insulation test
PE power contacts
The connection between bus couplers and bus terminals is automatically
effected by latching the components together. The K bus is responsible for
passing data and power to the electronic components of the bus terminals.
In the case of digital bus terminals, the field logic receives power via the
power contacts. Latching the components together has the effect that the
series of power contacts constitutes a continuous power track. Please refer
to the circuit diagrams of the bus terminals: some bus terminals do not loop
these power contacts through, or not completely (e.g. analog bus terminals
or 4-channel digital bus terminals). Each power input terminal interrupts the
series of power contacts and constitutes the beginning of a new track. The
bus coupler can also be used to supply power to the power contacts.
The power contact labeled "PE” can be used as protective earth or ground.
This contact stands proud for safety reasons and can carry short-circuit
currents of up to 125A. Note that in the interests of electromagnetic com-
patibility the PE contacts are capacitively connected to the supporting
track. This may lead to spurious results and even damage to the terminal
when you test the insulation (e.g. insulation test for breakdown using a
230V mains supply to the PE line). You should therefore disconnect the PE
line on the bus coupler while you carry out insulation tests. You can dis-
connect other power supply points for the duration of the test by drawing
the power supply terminals out from the remaining row of terminals by at
least 10mm. If you do this, there will be no need to disconnect the PE con-
nections.
The protective earth power contact ("PE”) may not be used for any other
connections.

Basic information
11 BK 7000
Electrical data
The electrical data specific to the fieldbus is given in this chapter. The fol-
lowing table lists an overview of all data:
Technical data BK7000
Voltage supply 24 V DC (20 V...29 V DC)
Input current 70 mA + (total K-Bus current)/4
500 mA max.
Starting current 2.5 x continuos current
Output current K bus 1750 mA max.
Configuration possibility by KS2000 or the controller
Number of bus terminals 64
Digital peripheral signals 256 inputs/outputs
Analog peripheral signals 256 inputs/outputs
Peripheral bytes 512 bytes I and 512 bytes O
Bus connection Two BNC-connectors (ControlNet A and B) and 1 NAP-Port
Baud rates 5 MBaud (ControlNet V1.5)
Voltage power contact 24V DC / AC max.
Current load power con. 10 A max.
Max. voltage capacity 500 Veff (power contact / supply voltage/field bus)
Weight approx. 170g
Operating temperature 0°C ... +55°C
Storage temperature -20°C ... +85°C
Relative humidity 95% non-condensing
Vibration /shock resistance conforms to IEC 68-2-6 / IEC 68-2-27
EMC resistance burst / ESD conforms to EN 50082 (ESD,Burst) / EN50081
Orientation for mounting Any
Type of fuse IP20
Current consumption on the
K-Bus
For operation of the K-bus electronics, the bus terminals require energy
from the K-bus that is supplied by the bus coupler. Refer to the catalog or
the corresponding data sheets of the bus terminals for details of the K-bus
current consumption. In doing so, pay attention to the maximum output
current of the bus coupler that is available for powering the bus terminals.
Using a special power supply terminal (KL9400), power can be fed back
into the K-bus at any chosen point. If you wish to use a power supply ter-
minal, please contact Beckhoff’s technical support. .

Basic information
BK 7000 12
The peripheral data in the process image
When the bus coupler is first switched on it determines the configuration of
the attached input/output terminals and automatically assigns the physical
slots of the input/output channels to the addresses in the process image.
The bus coupler sets up an internal list of assignments in which each of the
input and output channels has a specific position in the process image. A
distinction is made here between input and output and between bit-oriented
(digital) and byte-oriented (analog, or complex) signal processing.
It also forms two groups, whereby one contains only inputs and the other
only outputs. In each group, the byte-oriented channels take the lowest
addresses, in ascending order, and these are then followed by the bit-
oriented channels.
Digital signals
(bit-oriented)
Digital signals are bit-oriented. This means that one bit of the process im-
age is assigned to each digital channel. The bus coupler sets up a block of
memory containing the current input bits and arranges to immediately write
out the bits from a second block of memory which belongs to the output
channels.
The precise assignment of the input and output channels to the process
image of the control unit is explained in detail in the Appendix by means of
an example.
Analog signals
(byte-oriented)
The processing of analog signals is always byte-oriented and analog input
and output values are stored in memory in a two-byte representation. The
values are held as "SIGNED INTEGER” or "twos-complement”. The digit
"0” represents the input/output value "0V”, "0mA” or "4mA”. When you use
the default settings, the maximum value of the input/output value is given
by "7FFF” hex. Negative input/output values, such as -10V, are repre-
sented as "8000” hex and intermediate values are correspondingly propor-
tional to one another. The full range of 15-bit resolution is not realized at
every input/output level. If you have an actual resolution of 12 bits, the
remaining three bits have no effect on output and are read as "0” on input.
Each channel also possesses a control and status byte in the lowest value
byte. If the control/status byte is mapped in the control unit has to be con-
figured in the master configuration software. An analog channel is repre-
sented by 2 bytes user data in the process image.
Special signals and
interface
A bus coupler supports bus terminals with additional interfaces, such as
RS232, RS485, incremental encoder, etc.. These signals can be regarded
in the same way as the analog signals described above. A 16-bit data
width may not be sufficient for all such special signals; the bus coupler can
support any data width.
Default assignment of
inputs and outputs to the
process image
When the bus coupler is first switched on it determines the number of at-
tached bus terminals and sets up a list of assignments. This list distin-
guishes between analog channels and digital channels and between input
and output; which are grouped separately. The assignments begin imme-
diately to the left of the bus coupler. The software in the bus coupler cre-
ates the assignment list by collecting the entries for the individual channels
one at a time, counting from left to right. These assignments distinguish
four groups:
Function type of the channel Assignment level
1. Analog outputs byte-wise assignment
2. Digital outputs bit-wise assignment
3. Analog inputs byte-wise assignment
4 Digital inputs bit-wise assignment

Basic information
13 BK 7000
Analog inputs/ouputs are representative of other complex multi-byte signal
bus terminals (RS232, SSI sensor interface, ...)
Overview of the subdivision of the process image in the bus coupler:
Output data in the
bus coupler
O0
...
byte-oriented data
...
Ox
Ox+1
bit-oriented data
Ox+y
Input data in the
bus coupler
I0
...
byte-oriented data
...
Ix
Ix+1
...
bit-oriented data
...
Ix+y
Data consistency Data which contains no contradictions is said to be consistent. The follow-
ing consistency is required here: 1. The high byte and low byte of an ana-
log value (word consistency), 2. The control/status byte and the corre-
sponding parameter word for accessing the register. The interaction of the
peripherals with the control unit means that data can initially be guaranteed
consistent only within an individual byte: the bits which make up a byte are
read in together, or written out together. Byte-wise consistency is quite
adequate for processing digital signals but is not sufficient for transferring
values longer than eight bits, such as analog values. The various bus sys-
tems guarantee consistency to the required length. It is important to use
the appropriate procedure for importing this consistent data from the mas-
ter bus system to the control unit. You will find a detailed description of the
correct procedure in the User Guide of the appropriate bus system, in par-
ticular in the description of the standard master units that are installed. The
chapters of this manual which deal with the fieldbus refer to the most
common of these standard units.
Processing complex signals
All byte-oriented signal channels such as RS232, RS485 and incremental
encoder, can use byte lengths greater than two. Apart from the actual dif-
ference in length, the procedure is always comparable with that for analog
signals. In the configuration software for the bus masters of the second
generation (from around 09.96), the corresponding channel can be selec-
ted directly from the "GSD file". The configuration software automatically
ensures the settings for maintaining data consistency.

Basic information
BK 7000 14
Starting operation and diagnostics
When the bus coupler is first switched on it at once checks the attached
configuration. A correct start-up procedure is indicated by the red LED "I/O
ERR” going out. If this LED flashes, this indicates a fault somewhere in the
terminals. You can determine the actual error code by observing the speed
of flashing and number of flashes. This will enable you to clear the fault
quickly. You will find a detailed description in the chapter "The diagnostic
LEDs”.
The diagnostic LEDs The bus coupler has a status display consisting of two groups of LEDs.
The upper group has four LEDs which indicate the mode of the installed
fieldbus. The significance of these "fieldbus status LEDs” is explained in
the appropriate chapters of this manual; they correspond to the usual dis-
plays for fieldbuses.
There are two more green LEDs at the top right-hand side of the bus cou-
pler to indicate the supply voltage. The left-hand LED shows the 24V sup-
ply of the bus coupler. The left-hand LED shows the supply to the power
contacts.
Local errors Two LEDs, the "I/O LEDs”, which are situated below the fieldbus status
LEDs described above, are used to display the operating mode of the bus
terminals and the connection to these bus terminals. The green LED lights
up to indicate error-free operation, where "error-free” implies that commu-
nication with the fieldbus system is also operating correctly. The red LED
flashes at two different rates to indicate a fault, whereby the specific error
is encoded in the pattern of flashes, as follows.
Code of flashes
Rapid flashing Start of the error code
First slow sequence Type of error
Second slow sequence Location of error
Error
Error co-
de
Error argument Description
1 pulse 0
1
2
EEPROM checksum error
I/0 line buffer overflow
Unknown data type
2 pulses
0
n (n > 0)
Programmed configuration
Invalid table entry/bus coupler
Invalid table comparison (terminal n)
3 pulses 0 Terminal bus command error
4 pulses 0
n
Terminal bus data error
Rupture point after terminal n (0: coupler)
5 pulses N Terminal bus error during register commu-
nication with terminal n
>= 6 pulses ControlNet specific, will be described later
in this document
Location of error The number of flashes corresponds to the position of the last bus terminal
before the error, not counting passive bus terminals such as power input
terminals.
The bus coupler will carry on flashing the error code even when you have
cleared the fault and its operating mode will remain at "Stop”. The only way
to restart the bus coupler is by switching the power supply off and on
again.
You should not plug or unplug bus terminals from the series without first
turning off the power. The circuitry of the bus terminals and the bus coupler
is largely protected against damage, but if you modify the assembly while it
is under power, malfunctions and damage cannot be ruled out.

Basic information
15 BK 7000
If a fault occurs during normal operation, the error code will not be output
on the LEDs until the bus coupler has been requested to diagnose the bus
terminals. This diagnostic request is generated after the equipment is
switched on.
Fieldbus errors The fieldbus status LEDs A and B indicate the current ControlNet bus
status of the corresponding channel. The other two LEDs are reserved for
the future.
Priority indicator state how to view cause
Highest
(1)
both steady off viewed together reset or no power
2
both steady red viewed together failed link interface
3
alternating red /
green
viewed together self test
4
alternating red /
off
viewed together bad node configuration (such as duplicate MAC ID)
5
steady off viewed independently channel disabled or channel not supported
6
flashing red /
green
viewed independently invalid link configuration
7
flashing red / off viewed independently link fault or no MAC frames received
8
flashing green /
off
viewed independently temporary channel error, or listen-only
Lowest
(9)
steady green viewed independently normal operation
Please note that there is an association between the green I/O LED and
the fieldbus. The I/O LED lights up when access is made to the internal K
bus. The green I/O LED is not lit until data begins to be exchanged via the
fieldbus.
The bus coupler does, however, interrogate the configuration of the bus
terminals after power on and does not exchange any data with the termi-
nals. That is to say, the red I/O LED goes off after an error-free start up
without the green I/O LED having to light up. Then, the green I/O LED does
not light up until data transfer is begun via the field bus.
If a terminal bus error occurs during operation, the procedure followed con-
forms to the reaction to the terminal bus errors parameterisation. If the
terminal bus error already occurs during start up, the slave does not assu-
me ControlNet data transfer.

Basic information
BK 7000 16
Run times and reaction times
Transfer of the signals from the input to the controller and from the control-
ler to the outputs requires a run time. This is composed of various compo-
nents. Transfer from the controller to the scanner, transfer through the
ControlNet and transfer from the bus coupler to the outputs. This applies
analogously to the return distance.
Controller / Scanner
Please refer to the data provided by the scanner manufacturer for details of
the reaction time from the controller to the master. These times are compa-
ratively short and normally do not need to be considered.
The reaction time on the ControlNet depends on the NUT and the transfer
rate
K-Bus reaction time The reaction time on K-Bus is determined by movement and backing up of
the data. The following table contains measured values for typical setups.
Extrapolation to larger quantities is possible.
Terminals fitted on the bus coupler Run time on the K-bus
Digital
OUT
Digital
IN
Analog
IN/OUT
T_Zyklus
(us)
4 0 0 150
8 0 0 170
12 0 0 170
16 0 0 200
20 0 0 200
24 0 0 220
28 0 0 220
32 0 0 245
0 4 0 150
0 8 0 180
0 12 0 180
0 16 0 200
0 20 0 200
0 24 0 230
0 28 0 230
0 32 0 250
4 4 0 170
8 8 0 195
12 12 0 220
16 16 0 250
20 20 0 275
24 24 0 300
28 28 0 325
32 32 0 350
4 4
1
(KL3202)
630
4 4
2
(KL3202)
700

ControlNet coupler BK7000 in the ControlNet
17 BK 7000
ControlNet coupler BK7000 in the ControlNet
Introducing the system
The deterministic control network is a serial communication system for
communication between devices that wish to exchange time-critical appli-
cation information in a deterministic and predictable manner. These devi-
ces include simple I/O devices, such as sensors/actuators as well as com-
plex control devices such as robots, programmable logic controllers, wel-
ders, process controllers, etc. Unlike general-purpose communication sys-
tems that rely on the destination delivery model, this network uses the pro-
ducer/consumer model. The producer/consumer model allows the ex-
change of time-critical application information between a sending device
(e.g., the producer) and many receiving devices (e.g., the consumers) wi-
thout the need to send the data multiple times to multiple destinations. This
is accomplished by attaching a unique identifier to each piece of applicati-
on information that is being produced onto the network medium. Any devi-
ce that requires a specific piece of application information simply filters the
data on the network medium for the appropriate identifier. Many devices
can receive the same produced piece of application information from a
single producing device. The deterministic control network provides a high
degree of protocol efficiency by utilising an implied token passing mecha-
nism. This mechanism allows all devices equal access to the network wi-
thout the network overhead associated with passing a “token” to each de-
vice granting it permission to send data. The protocol utilises a time-based
Scheduling mechanism that provides network devices with deterministic
and predictable access to the medium while preventing network collisions.
This scheduling mechanism allows time-critical data, which is required on a
periodic, repeatable and predictable basis, to be produced on a predefined
schedule without the loss of efficiency associated with continuously re-
questing or “polling” for the required data. The network protocol supports
an additional mechanism that allows data that is not time-critical in nature
or that is only required on a occasional basis to utilise any available net-
work time. This unscheduled data is transmitted after the production of the
time-critical data has been completed and before the beginning of the next
scheduled production of time-critical data.

ControlNet coupler BK7000 in the ControlNet
BK 7000 18
The transfer medium: plugs and cables
Physics of the transmission The physical data transfer is defined in the ControlNet standard.
The BK7000 supports redundant media access with the two BNC connec-
tors A and B. Additionally a monitor or configurating system can be con-
nected over the NAP-Port.
Setting the station
Addresses
The station address is set by way of the rotary switches on the left of the
bus coupler. The address is set as a decimal number. The top rotary switch
stands for the units position and the bottom one stands for the tens position
of the address. (Example: station address 18: bottom rotary switch = 1, top
rotary switch = 8). To ensure that the rotary switch setting is saved by the
BK7000 it must be reset (by briefing interrupting the power supply or by
means of a software reset).
Address selector
Configuring the master
The assembly object of the BK7000 represents the process image buffer of
the terminal bus inputs and outputs. The data of this buffer can be sent or
received over a single connection. Assembly objects are used to produce
(terminal bus inputs) and/or consume (terminal bus outputs) data to/from
the network.
So the inputs and ouputs of the terminals will be connected to the Control-
Net with the assembly object. All output data will be sent from the scanner
in one scheduled telegram and all input data will be sent to the scanner in
another scheduled telegram.

ControlNet coupler BK7000 in the ControlNet
19 BK 7000
To set up this connection, the following parameters of the FwdOpen-
service have to be adjusted:
Net O->T connection
parameters
network connection type Multicast
fixed/variable Fixed
priority Scheduled priority
size No of bytes (word-aligned) of the terminal bus output
data (depending on the calculating rules for terminal
bus input and output data) + 4 bytes scanner status +
2 bytes transport header
Net T->O connection
parameters
network connection type Point-To-Point
fixed/variable Fixed
priority Scheduled priority
size No of bytes (word-aligned) of the terminal bus input
data (depending on the calculating rules for terminal
bus input and output data) + 4 bytes adapter status + 2
bytes transport header
Transport class /
trigger
client / server Client
transport type Cyclic
transport class Class 1
Connection path class 0x04
connection point inputs 0x00
connection point outputs 0x00
electronic key, vendor ID 0x006C
electronic key, product ty-
pe
0x0080
electronic key, product co-
de
0x1B58
