Barbaros Adora Timer Buılt ın Oven
1/EN
BARBAROS-ADORA TIMER
BUILT IN OVEN
SERVICE MANUAL

Barbaros Adora Timer Buılt ın Oven
2/EN
1.COVER
2.INDEX
1. COVER
2.INDEX
1.COVER ......................................................................................................................................2
3.SAFETY WARNING.....................................................................................................................4
3.1 GENERAL SAFETY ...............................................................................................................................4
3.2. SAFETY FOR CONFİGURATİONS .............................................................................................................4
3.3 INFORMATİONS FOR CONSUMER ...........................................................................................................5
4. TECHNICAL SPECIFICATIONS .....................................................................................................6
5. PRODUCT ASSEMBLY/ ASSEMBLY RULES/ SETTINGS .................................................................7
5.1 PRODUCT TRANSPORTATION ................................................................................................................7
5.2 UNPACKING PRODUCT ........................................................................................................................8
5.3 CONTROLLING THE SETUP PLACE AND ENERGY SOURCES. ............................................................................9
5.3.1 Measurement control of the mounting place ........................................................................9
5.3.3 Electrical connection ............................................................................................................12
6. USE OF PRODUCT ...................................................................................................................13
6.1 TIME SETTINGS ................................................................................................................................13
6.1.1 First Time Setup....................................................................................................................13
6.1.2 Screen Brightness Adjustment..............................................................................................14
6.1.3 Alarm Sound Set ...................................................................................................................15
6.1.4 Key Lock Set ..........................................................................................................................15
6.1.5 Setting the alarm clock.........................................................................................................17
6.1.6 Changing the clock of the day ..............................................................................................18
6.2 OVEN SETTINGS ...............................................................................................................................19
6.2.1 First Working ........................................................................................................................19
6.3 FULLY AUTOMATIC COOKING.............................................................................................................21
6.4 SEMI-AUTOMATIC COOKING ...............................................................................................................22
6.5 STARTING GRID; ..............................................................................................................................23
To turn on the grill;........................................................................................................................23
7.BY PRODUCTS/PRODUCTS LABELS USED...................................................................23
7.1 PERIPHERALACCESSORIES ..................................................................................................................23
7.2.2 Barcode Label .......................................................................................................................25
7.3.3 Energy Label; ........................................................................................................................26
8. GENAREL WORKING PRINCIPLE...............................................................................................28
8.1 OPERATING MODES .........................................................................................................................31
The Normal Operatıng Mode ........................................................................................................31
9. LIST OF COMPONENTS / COMPONENT WORKING PRINCIPLE...................................................32
9.1 TECHNICAL SPECIFICATIONS OF THE COMPONENTS ..................................................................................32
9.2 COMPONENT CODE OF CONDUCT........................................................................................................33

Barbaros Adora Timer Buılt ın Oven
3/EN
10. FAILURE DIAGRAMS .............................................................................................................35
10.1 RESİSTANCE FAULTS........................................................................................................................35
Resistance does not work;the food is not cooked .........................................................................35
10.2 LAMP FAULT .................................................................................................................................36
Furnace is working but the oven does not illuminate ...................................................................36
Oven does not work,oven lamp does not light,.............................................................................37
10.3 TERMOSTAT FAULT.........................................................................................................................38
Furnace runs continuosly,the thermostat is not tripped...............................................................38
10.4 THERMİNAL FAULT ........................................................................................................................39
There is no power from the terminal does not diffuse into the electric furnace...........................39
11. MEASUREMENTS TO BE DONE TO FIND THE FAULT COMPONENTS .......................................41
12. ELECTRICAL CIRCUIT BOARD .................................................................................................43
13. COMPONENT ASSEMBLY / DISASSEMBLY BE USED IN EQUIPMENT........................................44
14.COMPONENT ASSEMBLY / DİSASSEMBLY...............................................................................45
14.1 REMOVING THE PANEL ....................................................................................................................45
14.2 REMOVING THE CLOCK (ADORA TİMER)..............................................................................................47
14.3 CHANGING THE FRONT COVER...........................................................................................................50
14.4 REPLACING THE FRONT DOOR HINGE ..................................................................................................52
14.5 CHANGİNG THE REMOVABLE GLASS COVER ..........................................................................................53
14.6 CHANGING THE HANDLE .................................................................................................................56
14.7 CHANGING THE UPPER WALL ............................................................................................................58
14.8 BI-METAL THERMOSTAT REPLACEMENT...............................................................................................59
14.9 CHANGING THE ENGINE COOLING ......................................................................................................59
14.10 CHANGING THE VENTILATION PLATE .................................................................................................60
14.11 AIR-CONDITIONING THERMOSTAT REPLACEMENT................................................................................61
14.12 REMOVING THE REAR WALL............................................................................................................62
14.13 REMOVING THE SIDE DECOR ...........................................................................................................65
14.14 REPLACEMENT THE BOTTOM PLATE .................................................................................................65
14.15 CHANGİNG THE SWİTCH.................................................................................................................67
14.16 CATALYTIC REMOVAL OF THE INNER SIDE WALL ...................................................................................69
14.17 CHANGİNG THE GRİD RESİSTANCE....................................................................................................70
14.18 CHANGING THE OVEN HEATING .......................................................................................................72
14.19 REPLACING TURBO RESISTANCE.......................................................................................................74
14.20 REPLACEMENT OF OVEN SEAL .........................................................................................................76
14.21 REPLACING TURBO ENGINE.............................................................................................................77
14.22 CHANGING TERMINAL ...................................................................................................................78
14.23 REPLACEMENT THE TELESCOBIC RAIL ................................................................................................80
14.24 REPLACING THE OVEN LAMP ...........................................................................................................80
14.25 SQUARE OVEN LAMP REPLACEMENT .................................................................................................81
14.26 REPLACEMENT THE CATALYZER........................................................................................................82
14.27 REPLACEMENT THE PYRO DOOR LOCK ...............................................................................................83
14.28 REPLACEMENT THE METAL SHEET OF PYRO VENTILATION ......................................................................85
14.29 REPLACEMENT THE ENGINE OF PYRO COOLING...................................................................................87
14.30 REPLACEMENT THE ENGINE THERMOSTAT OF COOLING.........................................................................88

Barbaros Adora Timer Buılt ın Oven
4/EN
3.SAFETY WARNING
This section contains safety instructions that will help protect from risk of personal
injury or property damage.
Throughout this user manual the following symbols are used.
Important information or useful hints about usage.
Warning of hazardous situations with regard to life and property.
Warning of electric shock..
Warning of risk of fire.
Warning of hot surfaces.
3.1 General Safety
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Installation and repair procedures must always be performed by Authorized
Service Agents. The manufacturer shall not be held responsible for damages
arising from procedures carried out by unauthorized persons which may also void
the warranty. Before installation, read the instructions carefully.
•Do not operate the product if it is defective or has any visible damage.
Control that the product function knobs are switched off after every use.
3.2. Safety for Configurations
Control the area of the configuration is appropriate.
It is important that sources of energy is near the product.
Do not lay the network wire on the hot surface.If not wire coalasces and this couses
short circuit.
Be cafeful during the configuration wire is not cut or deformed.If not change them with
new one.
There is not a component to release the gases resulting of the burning in the
product.Set up the product according to the configuration rules.Especially,be careful
with the airing tools and needs.

Barbaros Adora Timer Buılt ın Oven
5/EN
3.3 Informations for Consumer
Product may be hot during the usage.Do not touch with hot parts ,inside the
oven,heating components etc. .When the product is working it is hot so do not put
combustable materials near the product.
Do not wash the product with water! It is dangerous for electrick shock!Ürünü, üzerine s
Do not heat the closed preserve jar or can with the product.Presure may cause the
explosion.
Do not clean while the product is working.
Do not change in anything on the porduct or any repair instead of some problems in the
user guide.
If there is no door or window for airing ,blower must be built.
Use a glove that is heat resistant during put/remove the meal to the hot oven
Do not use the product if front glass is broken or removed or any deformation on the
tweel block.
When tweel block is open, be careful about children do not sit down on it.
Do not hang cloth or towel or something like them on handle.

Barbaros Adora Timer Buılt ın Oven
6/EN
4. TECHNICAL SPECIFICATIONS
Manusoft to see the specifications of the product concerned.

Barbaros Adora Timer Buılt ın Oven
7/EN
5. PRODUCT ASSEMBLY/ ASSEMBLY RULES/ SETTINGS
5.1 Product Transportation
Control the view of the product for any damage which may occur in the carrying period.
To carry or move the product, do not use
door or handle of the product. Door,
handle or hinges can be harmed.
Product should be carried by two person for
safety of the product and ergonomics
When the product is being carried or the
product is being put to the ground, do not put it
keenly, do not drag it and do not skid it from
stairs.

Barbaros Adora Timer Buılt ın Oven
8/EN
5.2 Unpacking Product
To consider product changing in the mounting process, please do not harm package,
product and the product package when extracting.
Take lathes on the product’s front and behind sides, like shown in below.
Extract package with a knife without harming top
and bottom carton.
Take the top carton.

Barbaros Adora Timer Buılt ın Oven
9/EN
Symbols on the package of the products and meaning of them;
Preserve
from damp
Fragile
Carry with
barrow in
this way.
Do not carry
the product
like in the
Carry the product
in this way by
squeezing with
clamp
Do not step on
the product.
5.3 Controlling the setup place and energy sources.
5.3.1 Measurement control of the mounting place
In the setup of the product, local standards about electric and gas should be applied.
Take stripers which are left and
right side of the products.

Barbaros Adora Timer Buılt ın Oven
10/EN
Product is designed according to kitchens’ bench so it is placeable. Appropriate
safety interval should be between kitchen wall and the furniture. For appropriate
interval, please look at the picture.(values are mm type).
Used sides, synthetic laminates and glues should be durable to the head (min.100°C).
Product should be stayed with the same height with kitchen furnitures.
If there is a drawer bottom of the oven, a shelf should be used between oven and the
drawer.
5.3.2 Instead of mounting the product
Taking care not to break the jam and the power cord, oven, slide the cabinet slots, align
and fix it.

Barbaros Adora Timer Buılt ın Oven
11/EN
Right and left in the oven (as shown in the figure) screw holes for mounting the furnace
furnishings.
Oven, secure by means of screws as shown.
The following values for the control of electrical installation products with the product should
be considered.

Barbaros Adora Timer Buılt ın Oven
12/EN
5.3.3 Electrical connection
Connect the product to a grounded outlet/line protected by a fuse of suitable capacity as
stated in the "Technical specifications" table. Have the grounding installation made by a
qualified electrician while using the product with or without a transformer. Our company
shall not be liable for any damages that will arise due to using the product without a
grounding installation in accordance with the local regulations.
Connection must comply with national regulations.
The mains supply data must correspond to the data specified on the type label of the
product.
Open the front door to see the type label.

Barbaros Adora Timer Buılt ın Oven
13/EN
6. USE OF PRODUCT
6.1 Time Settings
NOTE: Time must be set before using the oven.In case of no time setting the oven it will
work.
6.1.1 First Time Setup
Time Symbols used in the display
Key lock
Time of day
Display brightness adjustment
Alarm sound intensity
Cooking time
Cooking end time
The alarm duration
NOTE: Related products while setting screen time operation must be done within 3
seconds. Otherwise, the screen will return to the old image.
1
2
3
4

Barbaros Adora Timer Buılt ın Oven
14/EN
Keys;
1 Settings button
2 Programme touch
3 Plus key
4 Minus key
Set the time of day with the 3 or 4 key.
6.1.2 Screen Brightness Adjustment
The clock will be the official clock is not set to
report that burns. When the time setting will be
lost.
Press the button to adjust the display brightness
settings to activate the display brightness
symbol. (+) And (-) to set the desired brightness
using the key.

Barbaros Adora Timer Buılt ın Oven
15/EN
6.1.3 Alarm Sound Set
6.1.4 Key Lock Set
The use of clock key using the key lock feature is blocked.
The selected display brightness tray "D01" or
"D02" or "D-03" will be displayed.
(+) Or (-) to set the desired intensity using the
keys. The selected alarm sound intensity "B-01",
or "B-02" or "B-03" will be displayed.
Bring settings by pressing the button to
activate the key lock key lock symbol.

Barbaros Adora Timer Buılt ın Oven
16/EN
After setting the key lock "On" appears
and the key lock remains illuminated.
Hours keys can not be used outside of the
settings after setting the key lock key.
The key lock with 4 keys to deactivate.
The display "OFF" will appear.
Set number 1 by pressing the button to open
the key lock key lock symbol is activated.
"On" will appear.

Barbaros Adora Timer Buılt ın Oven
17/EN
6.1.5 Setting the alarm clock
Product time, except for the cooking program can be used for any warning or reminder.
Alarm clock, there is no effect on the receptors of the oven. Warning for use. For example,
the food in the oven can be used if you want to turn the alarm clock at a given moment. Set
time expired, the alarm clock beeps.
Press the program key to activate the
alarm while the alarm time symbol.
(-) And (+) keys to set the alarm time. The
alarm time will remain a symbol of burns
after setting the alarm time.

Barbaros Adora Timer Buılt ın Oven
18/EN
6.1.6 Changing the clock of the day
The symbol starts flashing and the alarm
sounds the alarm time after the alarm time
is completed. You can stop the alarm by
pressing any key.
Press the program key to reset the alarm
time activates the alarm time symbol.
00:00 until the display (-) hold.
Press the key to program the time of day
to activate the clock symbol of the day. (-)
And (+) to set the time of day using a key.

Barbaros Adora Timer Buılt ın Oven
19/EN
6.2 Oven Settings
6.2.1 First Working
.
Products must be heated for about 30 minutes during the first run. In this way, it may have
been burned in the oven during the production no longer be cleaned and layers.
Take all baking trays and racks from the
oven.
Select the highest
temperature..

Barbaros Adora Timer Buılt ın Oven
20/EN
Turn the function knob to the desired operating mode.
Turn the temperature knob to the desired temperature.
The time of day is not set timer from 12:00
onwards increase-or / will begin to progress.
The time of day clock symbol will appear on
the screen to notify you that it is set. The
symbol will disappear when the timer is set.
