Beko WOS30200SS User manual

WOS30200SS
285.6002.88/R.AA/18.01.2022
7735687919
BUILT-IN OVEN
INSTALLATION MANUAL
IMPORTANT
Before Before beginning installaon, read these instrucons thoroughly and
carefully. Observe all local and naonal codes, requirements, and ordinances.
DO NOT remove permanently axed labels, warnings, or plates from the product
as this may void the warranty. Installers should leave these instrucons with
the consumer who should retain them for the local inspector’s use and for
future reference.

2
BEFORE INSTALLATION
READ AND SAVE THESE
INSTRUCTIONS
PLEASE READ THESE INSTRUCTIONS BEFORE USING
THIS APPLIANCE.
Dear Valued Customer,
Thank you for your purchase - this appliance is intended for normal
household use only. It is not approved for outdoor or other non-household
uses (including sea or air-going vessels). See the Statement of Limited
Warranty. If you have any questions, contact the manufacturer. Do not repair
or replace any part of the appliance unless specifically recommended in this
manual. Refer all servicing to a factory-authorized service center.
This appliance has been manufactured in modern facilities and passed
through strict quality control procedures. To obtain the best performance with
your product, we advise you to read through this installation manual carefully
before installing your product.
PLEASE FOLLOW THESE IMPORTANT STEPS:
• Please read this installation manual carefully before installing the product.
• ALWAYS follow the recommended safety instructions.
• Keep the installation manual in an easily accessible place for future use.
• Please read all the other documents provided with the product.
• Please keep your receipt for any repairs which may be required under war-
ranty.
• Upon delivery, please check that the appliance is not damaged. If you note
any transport damage, please contact the shipping company or the com-
pany where you purchased the appliance immediately and do not connect/
operate the appliance!
• If you pass on the appliance to another person, please provide all docu-
ments with it including original date of purchasing. (The warranty does not
convey if the unit is sold.)
If you should decide not to use this appliance any longer (or decide
to substitute an older model), before disposing of this appliance, it is
recommended that it be made inoperative in an appropriate manner in
accordance to health and environmental protection regulations, ensuring in
particular that all potentially hazardous parts be made harmless, especially in
relation to children who could play with old appliances.

SAFETY INSTRUCTION...............................................................................4
1.1 SAFETY INFORMATION ................................................................4
1.2 BASIC SAFETY INSTRUCTIONS...................................................5
1.3 ELECTRICAL SAFETY ..................................................................5
INTRODUCTION ...........................................................................................8
SPECIFICATIONS.........................................................................................9
DIMENSIONS .............................................................................................10
CUTOUT DIMENSIONS..............................................................................11
5.1 HIGH CUPBOARD INSTALLATION..............................................11
5.2 UNDER COUNTER INSTALLATION.............................................12
5.3 FLUSH MOUNT INSTALLATION ..................................................13
INSTALLATION ...........................................................................................14
6.1 ELECTRICAL REQUIREMENTS ..................................................14
6.2 UNPACKING .................................................................................15
6.3 BEFORE INSTALLATION .............................................................16
6.4 INSTALLATION CONDITIONS......................................................17
6.5 INSTALLATION .............................................................................17
PREPARE FOR USE ............................................................................21
7.1 SETTING THE TIME .....................................................................21
7.2 SETTING CLOCK MODE (12HR OR 24HR) ................................23
7.3 CLEANING....................................................................................23
7.4 INITIAL HEATING..........................................................................24
7.5 PERFORMANCE CHECKLIST .....................................................24
7.6 SERVICE INFORMATION.............................................................24
TABLE OF CONTENTS
3

SAVE THESE INSTRUCTIONS
PLEASE READ THESE INSTRUCTIONS BEFORE
INSTALLING THIS APPLIANCE.
This appliance is intended for normal household use only. It is not approved
for outdoor or other non-household uses (including sea- or air-going vessels).
See the Statement of Limited Warranty. If you have any questions, contact
the manufacturer. Do not repair or replace any part of the appliance unless
specifically recommended in this manual. Refer all servicing to a factory-
authorized service center.
1.1 SAFETY INFORMATION
We have provided many important
safety messages in this manual and
on the appliance. ALWAYS read
and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards
that can kill or hurt you and
others. All safety messages will
be preceded by the safety alert
symbol and the word “DANGER”,
“WARNING”, or “CAUTION”. These
words mean:
DANGER
INDICATES A
HAZARDOUS
SITUATION WHICH, IF
NOT AVOIDED, WILL
RESULT IN DEATH OR
SERIOUS INJURY.
WARNING
Indicates a hazardous
situation which, if not
avoided, could result in
death or serious injury.
CAUTION
Indicates a hazardous
situation which, if not
avoided, could result in
minor personal injury
or product or property
damage.
All safety messages will identify the
hazard, describe how to reduce the
chance of injury, and describe what
can happen if the instructions are
not followed.
1
4
SAFETY INSTRUCTION

WARNING
This product can expose
you to chemicals including
Nickel (Metallic) which
is known to the State of
California to cause cancer.
For more information go to
www.P65Warnings.ca.gov
Note: Nickel is a component
in all stainless steel
and some other metal
components.
1.2 BASIC SAFETY
INSTRUCTIONS
The manufacturer reserves the right
to make changes to the technical
specifications in order to improve the
appliance quality without any prior
notice. s included in this manual
are for schematic purpose only and
may not match exactly with your
appliance. Values stated on the
markings of the appliance or in other
printed documents supplied with
the appliance are obtained under
laboratory conditions as per relevant
standards. These values may
vary according to the usage of the
appliance and ambient conditions.
Proper Installation - Be sure your
appliance is properly installed and
grounded by a qualified technician.
WARNING
To avoid risk of serious
injury or death, the oven
should be installed by
a qualied installer or
technician.
DANGER
RISK OF SUFFOCATION
BY THE PACKAGING
MATERIALS! PACKING
ELEMENTS (I.E.,
PLASTIC BAGS,
POLYSTYRENE FOAM,
NAILS, PACKING
STRAPS, ETC.) SHOULD
NOT BE LEFT AROUND
WITHIN EASY REACH OF
CHILDREN, AS THESE
MAY CAUSE SERIOUS
INJURIES OR DEATH.
1.3 ELECTRICAL SAFETY
If the supplied electrical cord is
damaged, it must be replaced by a
special cord or assembly from the
manufacturer and installed by a
qualified technician.
SAFETY INSTRUCTION
5

WARNING
To avoid risk of serious
injury or death:
• Any additions, changes, or
conversions required in order
for this appliance to satisfacto-
rily meet the application needs
must be made by a qualied
technician.
• Before performing any service,
disconnect the power supply
at the household distribution
panel by removing the fuse
or switching o󰀨 the circuit
breaker.
• Any work on electric equip-
ment and systems may only
be carried out by authorized
qualied technicians.
• In the event the oven has been
damaged, switch o󰀨 the ap-
pliance and disconnect it from
the main supply by removing
the fuse or switching o󰀨 the
circuit breaker.
• DO NOT soak removable
heating elements. Heating
elements should never be im-
mersed in water.
WARNING
To avoid risk of electrical
shock, serious injury, or
death:
• Verify electrical power is turned
o󰀨 at the breaker box until
oven is installed and ready to
operate.
• Only use the supplied cable to
connect the electrical supply. If
the cable is damaged or miss-
ing, contact your service agent
or a qualied technician for a
replacement.
• The cable for further replace-
ments should correspond to
the specications listed in the
installation manual.
SAFETY INSTRUCTION
6

CAUTION
To avoid risk of injury or product
or property damage:
• Use two or more people or
suitable lifting device when
lifting appliance.
• Use only materials and
nishes that will not dis-
color or delaminate and will
withstand temperatures up to
194 °F (90 °C).
• The cooling fan should be
operating when the unit is in
operation. If you notice it is
not, or you observe unusual
or excessive noise, contact
your authorized Beko dealer
before continuing operation.
Failure to do so can result
in damage to the oven or
surrounding cabinets.
• DO NOT use power tools to
remove hardware. Damage to
the hardware or the machine
may occur. DO NOT lose
hardware.
• DO NOT use this product
in rooms unless equipped
with properly adjusted and
functioning Carbon Monoxide
sensors. that are maintained.
Carbon Monoxide sensors
should be installed maximum
6.5 ft. away from the product.
CAUTION
To avoid risk of injury or product
or property damage:
• DO NOT use power tools to
remove hardware. Damage to
the hardware or the machine
may occur. DO NOT lose
hardware.
• DO NOT use this product
in rooms unless equipped
with properly adjusted and
functioning Carbon Monoxide
sensors. that are maintained.
Carbon Monoxide sensors
should be installed maximum
6.5 ft away from the product.
• DO NOT let electrical sup-
ply cord come in contact
with rear surface of oven or
over hot cooking section.
Avoid squeezing, bending or
using clamps on the supply
cord. If the electrical supply
cord is damaged, it must be
replaced.
• The use of cabinets for stor-
age above the oven may
result in a potential burn haz-
ard. Combustible items may
ignite, metallic items may
become hot and cause burns.
• Ensure oven is installed and
secured properly.
SAFETY INSTRUCTION
7

This manual covers the WOD30100SS-WOD30100CF Built-In Wall Oven.
Detailed information about the operation and cleaning of this machine can
be found in the Use & Care Manual. Contact your salesperson or visit www.
bekoappliances.com to obtain a copy.
All height, width, and depth dimensions are shown in inches (as well as
metric). Beko US, Inc. reserves the absolute and unrestricted right to change
product materials and specifications, at any time, without notice. Please
visit our website www.bekoappliances.com or call 888-352-2356 to verify
the latest specifications with final dimensional data and other details prior
to installation and making a cutout. Applicable product limited warranty
information may be found in accompanying product materials, or you may
contact your account manager for further details. Proper installation is the
responsibility of the installer. Product failure due to improper installation is not
covered under the Limited Warranty.
2
8
INTRODUCTION

Specications
Type Built-In
Size 30 in. (762 mm)
Color Stainless Steel
Oven Type Multifunction
Control Type Light Emitting Diode (LED) Display
Accessories/Oven Cavity (Each Oven)
Cavity Enamel Color Black
Rack Positions 6 level wire rack
Oven Lights 2 x 40 W Halogen (each oven)
Chromed Racks 2
Oven Capacity 5.7 cu. ft.
Dimensions
Required Cutout Dim (H x W x D) 28 7/8 in. (733 mm) x 29 3/4 in. (755 mm) x
24 7/16 in. (620 mm)
Overall Height 28 7/8 in. (733 mm)
Overall Width 29 3/4 in. (755 mm)
Overall Depth 24 7/16 in. (620 mm)
Power/Ratings
Voltage/Frequency 120/220-240V, 60Hz 2AC~N
Fuse Protection Min. 20 A
Total Electric Power 4.4 kW
Supply Cord BC-SIL 4x13 AWG max. 4ft
Heating Element Information
Bake 2240 W
Broil 3320 W
Convection Roast 3670 W
3
9
SPECIFICATIONS

29 in. (755 mm)
Front
Top
Side
3/4
28 in. (733 mm)
7/8
24 in. (620 mm)
7/16
26 in. (683 mm)
7/8
23 in. (594 mm)
3/8
23 in. (595 mm)
7/16
4
10
DIMENSIONS

5.1 HIGH CUPBOARD INSTALLATION
26 in. to 28 in.
(682 to 723 mm)
7/8 7/16
24 in.
(610 mm)
28 in.
(724 mm)
1/2
9 in.
(241 mm)
1/2
5 in.
(133 mm)
1/4
Junction box location
(junction box may be
located in adjacent
cabinet.)
5
11
CUTOUT DIMENSIONS

5.2 UNDER COUNTER INSTALLATION
28 in.
(718 mm)
1/4
28 in.
(724 mm)
1/2
5 in.
(133 mm)
4 in.
(102 mm)
36 in.
(915 mm)
Junction box location
(junction box may be
located in adjacent cabinet)
1/4
9 in.
(241 mm)
1/2
24 in.
(610 mm)
3/4 in.
(19 mm)
1 in.
(25 mm)
If installing in lower cabinet, leave 4 in. (102 mm)
minimum clearance below.
CUTOUT DIMENSIONS
12

5.3 FLUSH MOUNT INSTALLATION
29 in.
(736 mm)
ush
cutout
height
30 in.
(762 mm)
24 in.
(622 mm)
ush
inset
depth
1/2
9 in.
(241 mm)
1/2
5 in.
(133 mm)
1/4
Junction box location
(junction box may be
located in adjacent cabinet)
1 in.
(25 mm)
1 in.
(32 mm)
1/4
1 in.
(25 mm)
1 in.
(25 mm)
1 in.
(25 mm)
9” 1/2
(241 mm)
24” 1/2
3/4”
(19 mm)
3/4”
(19 mm)
Reveal cleats
For ush installation you need to two
reveal cleats xed like above gure.
CUTOUT DIMENSIONS
13

Preparation of location and
electrical installation for the oven
is the customer’s responsibility.
The appliance should be properly
installed and grounded by a qualified
technician. The appliance must
be installed in accordance with all
local electrical regulations. Prior
to installation, visually inspect the
appliance for any defects. Do not
install a defective appliance.
6.1 ELECTRICAL
REQUIREMENTS
This appliance must be supplied with
the proper voltage and frequency
and be connected to an individual,
properly grounded branch circuit
protected by a circuit breaker or fuse.
See the rating plate to determine the
rating of the appliance. Use the chart
below to determine the minimum
recommended dedicated circuit
protection to ensure correct fuse
rating.
kW
Rang 240
V
Recommended
Circuit Size
(Dedicated)
<4.8 kW 20 Amp
The main supply data must
correspond to the data specified on
the rating plate of the appliance. The
rating plate is located either bottom
of the control panel when opening
the door or on the rear wall of the
appliance.
WARNING
To avoid risk of electrical
shock, serious injury, or
death, verify electrical
power is turned o󰀨 at the
breaker box until oven
is installed and ready to
operate.
DANGER
ELECTRICAL SHOCK
HAZARD! DO NOT
USE AN ADAPTER
PLUG, AN EXTENSION
CORD, OR REMOVE
GROUNDING PRONG
FROM ELECTRICAL
POWER CORD ,
HAVE A QUALIFIED
ELECTRICIAN INSTALL
AN OUTLET NEAR THE
APPLIANCE. FAILURE
TO FOLLOW THIS
WARNING CAN CAUSE
SERIOUS INJURY, FIRE
OR DEATH.
This appliance is manufactured with
a green GROUND wire connected
to the oven chassis. Ensure power
is disconnected or turned off at the
main supply before making any
electrical connections. Connect
the flexible conduit to the junction
box using a U.L. listed conduit
connector. The following procedures
present the most common ways of
6
14
INSTALLATION

making electrical connections to the
appliance. Ensure connections are
made in accordance with local codes
and ordinances.
• The appliance should be installed
and connected to electrical power
in accordance with national and
local regulations. In the absence of
codes, the National Fuel Gas Code
ANSI Z223.1/NFPA-54 - latest edi-
tion must be followed.
• In Canada, installation must be in
accordance with the current CAN/
CGA B149.1 & 2 Gas Installation
codes and/or local codes. Electrical
installation must be in accordance
with the current CSA C22.1 Cana-
dian Electrical Codes Part 1 and/or
local codes.
• Grounding through the neutral con-
ductor is prohibited for new branch
circuit installations (1996 NEC),
mobile homes, and recreational
vehicles, or in an area where local
codes prohibit grounding through
the neutral conductor.
• The installer must leave these
instructions with the consumer who
should retain for local inspector’s
use and for future reference.
• It is important the installation
location has an adequate electri-
cal system. Prior to installation, a
qualied electrician should ensure
the addition of the appliance will
not overload the branch circuit on
which it will be installed.
• Turn o󰀨 power at main supply
before installing the appliance. The
product should not be connected to
the main supply prior to installation.
Main power must be shut o󰀨 before
removing the appliance for clean-
ing or servicing.
• Do not remove permanently a󰀩xed
labels, warnings, or plates from
oven. This may void the warranty.
6.2 UNPACKING
DANGER
RISK OF SUFFOCATION
BY THE PACKAGING
MATERIALS! PACKING
ELEMENTS (I.E.,
PLASTIC BAGS,
POLYSTYRENE FOAM,
NAILS, PACKING
STRAPS, ETC.) SHOULD
NOT BE LEFT AROUND
WITHIN EASY REACH OF
CHILDREN, AS THESE
MAY CAUSE SERIOUS
INJURIES OR DEATH.
INSTALLATION
15

CAUTION
To avoid risk of injury, or
product or property damage:
• Use two or more people or
suitable lifting device when lift-
ing appliance.
• Remove and discard all pack-
ing materials, including card-
board and tape on the outside
and inside of the range.
• Remove any plastic protective
wrap on all parts.
• Thoroughly wash the interior
with hot, soapy water, rinse,
and wipe dry.
• Dispose of all packing materi-
als according to environmental
standards.
• Check for possible shipping
damage immediately after re-
ceipt. If the oven is found to be
damaged, contact your point of
sale immediately.
• DO NOT connect and operate
the oven if any damage was
found.
Note the time, date, and who
was spoken to, and follow up and
confirm with written or electronic
communication.
All original packing materials must be
kept for inspection purposes.
6.3 BEFORE INSTALLATION
The appliance is intended for
installation in commercially available
kitchen cabinets and a minimum
clearance must be ensured between
the appliance and kitchen walls,
floors, and furniture for safety.
• Surfaces, synthetic laminates, and
adhesives used near or around the
unit must be heat resistant.
• Kitchen cabinets used for installa-
tion must be set level and xed in
place.
• All openings in the wall behind the
oven and in the oor under the
oven must be sealed.
• Drawings used in this manual
are representational and may not
match each appliance exactly.
• Product guarantee is valid after
proper installation. The manufac-
turer will not be responsible for any
hazard or damage resulting from
improper installation or use.
• Always carry the appliance using
two or more people. Do not drag
the appliance across any surface,
as this may damage the surface.
• Remove all shipping materials
inside and outside of the oven.
• Remove all equipment from inside
the oven, including the oven racks
and printed documents.
• Read manual before installing ap-
pliance.
• The California Safe Drinking Water
and Toxic Enforcement Act re-
quires the Governor of California to
publish a list of substances known
INSTALLATION
16

to the State of California to cause
cancer, birth defects, or other
reproductive harm, and requires
businesses to warn of potential
exposure to such substances. This
appliance can cause low-level ex-
posure to some of the substances
listed, including benzene, form-
aldehyde, carbon monoxide, and
toluene.
• All electric wall ovens must be
hard wired (direct wired) into an
approved junction box. A plug and
receptacle is not permitted for this
application. Do not shorten the
exible conduit. The conduit strain
relief clamp must be securely at-
tached to the clamp. If the exible
conduit will not t within the clamp,
do not install the oven until a clamp
of the proper size is obtained.
Junction box may be located in
adjacent cabinet.
6.4 INSTALLATION
CONDITIONS
• All dimensions given in this manual
are in inches and millimeters.
• Oven dimensions and cutout di-
mensions are given in the previous
sections.
• Use cutout dimensions appropriate
for type of cabinet used in installa-
tion.
• Ensure cutout dimensions are ac-
curate for the type of cabinet and
appliance.
• All cabinet construction should be
complete and any dust or debris re-
moved before installing appliance.
• The cabinet shelf the appliance
will be installed on should be able
to withstand the weight of 220 lbs
(100 kg) or more.
• A shelf must be installed between
the oven and any drawer directly
under the oven.
• Use safety gloves before carry the
oven.
6.5 INSTALLATION
1. Open oven door and unlock
hinge clamps.
1
INSTALLATION
17

2. Using both hands, grasp the
sides of the oven door, raise and
lift up and out.
3. Using two or more people and
suitable stand, lift oven and
partially install to cabinet cutout.
4a. Connect green GROUND wire
and white wire from oven to
branch circuit NEUTRAL wire
in junction box. Connect red
and black wires from oven to
corresponding branch circuit red
and black wires in junction box.
(Where local code allows for the
connection of the GROUND wire
from the appliance to the branch
circuit NEUTRAL wire.)
4b. Disconnect green GROUND wire
from white NEUTRAL wire at free
end of appliance conduit and
connect green GROUND wire
from appliance to GROUND wire
(bare or green wire) in junction
box. Connect white NEUTRAL
wire from appliance to NEUTRAL
wire in junction box. Connect
red and black wires from oven to
corresponding branch circuit red
and black wires in junction box.
(Where local code prohibits the
connection of the GROUND wire
from the appliance to the branch
circuit NEUTRAL wire.)
INSTALLATION
18

CAUTION
To avoid risk of injury
or product or property
damage, ensure electrical
supply cord is free and not
clamped, bent, or squeezed.
Do not route electrical
supply cord so that it will be
in contact with rear surface
of oven or over hot cooking
section. If the electrical
supply cord is damaged, it
must be replaced.
5. Push seal area of oven to
position oven in cabinet cutout.
Position oven so oven frame and
cabinet frame are flush.
6. Secure oven to cabinet using
four screws. Do not overtighten
screws.
CAUTION
To avoid risk of tipping,
ensure oven is installed and
secured properly.
7. Install oven racks.
INSTALLATION
19

8. Install oven door to hinges.
9. Lock hinge clamps and close
oven door.
10. Connect or turn on power at main
supply.
11. Ensure appliance powers on.
INSTALLATION
