Refrigerator
User manual

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use ...............................................4
General safety ............................................4
For products with a .................................. 7
water dispenser;........................................ 7
Child safety .................................................. 7
Compliance with WEEE Directive and
Disposing of the Waste Product: .......8
Package information................................8
HC warning...................................................8
Things to be done for energy saving 9
3 Installation 10
Points to be paid attention to when
the relocation of the refrigerator.....10
Electrical connection .............................10
Disposing of the packaging................. 11
Disposing of your old refrigerator....11
Placing and Installation.........................11
Adjusting the legs...................................12
Installing the lower ventilation
cover .............................................................12
Changing the illumination lamp .......12
Turbo Cooling Fan....................................13
Icematic and ice storage container..13
Reversing the doors...............................14
CONTENTS
4 Preparation 15
5 Using your refrigerator 16
Thermostat setting button.................16
Defrost.........................................................16
Water Dispenser ......................................17
*May not be available in all models..17
6 Maintenance and
cleaning 19
Protection of plastic surfaces ...........19
7 Troubleshooting 20

EN
3
1Your refrigerator
1. Interior light
2. Thermostat knob
3. Fan
4. Adjustable body shelves
5. Defrost water collection channel -
Drain tube
6. Crisper cover
7. Salad crisper
8. Ice bank
9. Icebank tray
10.Freezer compartment
11.Air grille
12.Adjustable front feet
13.Adjustable door shelves
14.Egg holders
15.Bottle shelf
16.Water dispenser
17.Fridge compartment
18.Freezer compartment
CFigures that take place in this instruction manual are schematic and may
not correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
13
4
7
5
1
15
17
18
14
3
8
2
6
10
12
11
9
15
16

EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe
this information may cause
injuries or material damage.
Otherwise, all warranty and
reliability commitments will
become invalid.
Original spare parts will be
provided for 10 years, following
the product purchasing date.
Intended use
A
WARNING:
Keep ventilation
openings, in the
appliance enclosure or
in the built-in structure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrostingprocess,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of
the appliance, unless
they are of the type
recommended by the
manufacturer.
A
WARNING:
Do not store explosive
substances such as
aerosol cans with a
flammable propellant in
this appliance.
This appliance is intended
to be used in household and
similar applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
General safety
• When you want to dispose/
scrap the product, we
recommend you to consult the
authorized service in order to
learn the required information
and authorized bodies.
• Consult your authorized
service for all your questions
and problems related to the
refrigerator. Do not intervene
or let someone intervene
to the refrigerator without
notifying the authorised
services.
• For products with a freezer
compartment; Do not eat
cone ice cream and ice
cubes immediately after

EN
5
you take them out of the
freezer compartment! (This
may cause frostbite in your
mouth.)
• For products with a freezer
compartment; Do not put
bottled and canned liquid
beverages in the freezer
compartment. Otherwise,
these may burst.
• Do not touch frozen food by
hand; they may stick to your
hand.
• Unplug your refrigerator
before cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never
be used in cleaning and
defrosting processes of your
refrigerator. In such cases, the
vapor may get in contact with
the electrical parts and cause
short circuit or electric shock.
• Never use the parts on your
refrigerator such as the door
as a means of support or step.
• Do not use electrical devices
inside the refrigerator.
• Do not damage the parts,
where the refrigerant is
circulating, with drilling or
cutting tools. The refrigerant
that might blow out when
the gas channels of the
evaporator, pipe extensions
or surface coatings are
punctured causes skin
irritations and eye injuries.
• Do not cover or block the
ventilation holes on your
refrigerator with any material.
• Electrical devices must be
repaired by only authorised
persons. Repairs performed by
incompetent persons create a
risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s
mains supply by either turning
off the relevant fuse or
unplugging your appliance.
• Do not pull by the cable when
pulling off the plug.
• Ensure highly alcoholic
beverages are stored securely
with the lid fastened and
placed upright.
• Never store spray cans
containing flammable and
explosive substances in the
refrigerator.
• Do not use mechanical devices
or other means to accelerate
the defrosting process, other
than those recommended by
the manufacturer.
• This product is not intended
to be used by persons with
physical, sensory or mental
disorders or unlearned
or inexperienced people
(including children) unless
they are attended by a person
who will be responsible
for their safety or who will
instruct them accordingly for
use of the product
• Do not operate a damaged
refrigerator. Consult with the
service agent if you have any
concerns.

EN
6
• Electrical safety of your
refrigerator shall be
guaranteed only if the earth
system in your house complies
with standards.
• Exposing the product to
rain, snow, sun and wind is
dangerous with respect to
electrical safety.
• Contact authorized service
when there is a power cable
damage to avoid danger.
• Never plug the refrigerator
into the wall outlet during
installation. Otherwise, risk
of death or serious injury may
arise.
• This refrigerator is intended
for only storing food items.
It must not be used for any
other purpose.
• Label of technical
specifications is located on the
left wall inside the refrigerator.
• Never connect your
refrigerator to electricity-
saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the
blue light with optical tools.
• For manually controlled
refrigerators, wait for at
least 5 minutes to start the
refrigerator after power
failure.
• This operation manual should
be handed in to the new
owner of the product when it
is given to others.
• Avoid causing damage
on power cable when
transporting the refrigerator.
Bending cable may cause fire.
Never place heavy objects on
power cable. Do not touch the
plug with wet hands when
plugging the product
• Do not plug the refrigerator if
the wall outlet is loose.
• Water should not be sprayed
on inner or outer parts of the
product for safety purposes.
• Do not spray substances
containing inflammable gases
such as propane gas near the
refrigerator to avoid fire and
explosion risk.
• Never place containers filled
with water on top of the
refrigerator; in the event of
spillages, this may cause
electric shock or fire.
• Do not overload the
refrigerator with food. If
overloaded, the food items
may fall down and hurt you
and damage refrigerator
when you open the door.
• Never place objects on top of
the refrigerator; otherwise,
these objects may fall down
when you open or close the
refrigerator’s door.

EN
7
• As they require a precise
temperature, vaccines,
heat-sensitive medicine and
scientific materials and etc.
should not be kept in the
refrigerator.
• If not to be used for a long
time, refrigerator should be
unplugged.A possible problem
in power cable may cause fire.
• Refrigerator may move
if adjustable legs are not
properly secured on the floor.
Properly securing adjustable
legs on the floor can prevent
the refrigerator to move.
• When carrying the
refrigerator, do not hold it
from door handle. Otherwise,
it may be snapped.
• When you have to place your
product next to another
refrigerator or freezer, the
distance between devices
should be at least 8cm.
Otherwise, adjacent side walls
may be humidified.
• The product shall never be
used while the compartment
which is located at the top or
back of your product and in
which electronic boards are
available (electronic board box
cover) (1) is open.
1
1
For products with a
water dispenser;
• Pressure for cold water inlet
shall be maximum 90 psi (6.2
bar). If your water pressure
exceeds 80 psi (5.5 bar), use a
pressure limiting valve in your
mains system. If you do not
know how to check your water
pressure, ask for the help of a
professional plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers is you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
• Use only potable water.
Child safety
• If the door has a lock, the key
should be kept away from
reach of children.
• Children must be supervised
to prevent them from
tampering with the product.

EN
8
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE
Directive (2012/19/
EU). This product bears
a classification symbol
for wasteelectrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable
for recycling. Therefore, do
not dispose the product with
normal domestic waste at the
end of its service life. Take it to a
collection point for the recycling
of electrical and electronic
equipment. Please consult your
local authorities to learn the
nearest collection point. Help
protect the environment and
natural resources by recycling
used products. For children’s
safety, cut the power cable and
break the locking mechanism
of the door, if any, so that it
will be non-functional before
disposing of the product.
Package information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature
and our national asset wealth.
If you want to contribute to the
re-evaluation of the packaging
materials,youcanconsulttoyour
environmentalist organizations
or the municipalities where you
are located.
HC warning
If your product's cooling
system contains R600a:
This gas is flammable.
Therefore, pay attention to not
damaging the cooling system
and piping during usage and
transportation. In the event
of damage, keep your product
away from potential fire sources
that can cause the product
catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system
contains R134a.
Typeofgas used in the product
is stated in the type label which
is on the left wall inside the
refrigerator.
Never throw the product in fire
for disposal.

EN
9
Things to be done for
energy saving
• Do not leave the doors of your
refrigerator open for a long
time.
• Do not put hot food or drinks
in your refrigerator.
• Do not overload your
refrigerator so that the air
circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near
heat emitting appliances
such as ovens, dishwashers
or radiators. Keep your
refrigerator at least 30cm
away from heat emitting
sources and at least 5cm from
electrical ovens.
• Pay attention to keep your
food in closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food
items in the freezer when
you remove the shelf or
drawer of the freezer. Energy
consumption value stated for
your refrigerator has been
determined by removing
freezer shelf or drawer and
under maximum load. There
is no harm to use a shelf
or drawer according to the
shapes and size of food to be
frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve
the food quality.

EN
10
3Installation
BIn case the information which are
given in the user manual are not
taken into account, manufacturer
will not assume any liability for this.
Points to be paid attention
to when the relocation of
the refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged,
shelves, accessories, crisper, etc.
inside your refrigerator should be
fixed with adhesive tape and secured
against impacts. Package should be
bound with a thick tape or sound
ropes and the transportation rules
on the package should be strictly
observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the refrigerator,
Check the following before you
start to use your refrigerator:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges
are intended to keep the distance
which will ensure the air circulation
between your refrigerator and the
wall. (The picture is drawn up as a
representation and it is not identical
with your product.)
2. Clean the interior of the
refrigerator as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the
refrigerator to the wall socket. When
the fridge door is opened, fridge
internal lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give
rise to noise, even if the compressor
is not running and this is quite normal.
5. Front edges of the refrigerator
may feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in
compliance with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.

EN
11
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots designated
by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator
without giving any harm to the
environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the
room where the refrigerator will be
installed is not wide enough for the
refrigerator to pass through, then call
the authorized service to have them
remove the doors of your refrigerator
and pass it sideways through the door.
1. Install your refrigerator to a
place that allows ease of use.
2. Keep your refrigerator away
from heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator
in order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on the
materials such as rug or carpet.
4. Place your refrigerator on an
even floor surface to prevent jolts.

EN
12
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator
by turning its front legs as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone
to slightly lift the refrigerator will
facilitate this process.
Installing the lower
ventilation cover
You can nstall the lower ventlaton
cover as llustrated n the fgure.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call
your AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose
of this lamp is to assist the user to
place foodstuffs in the refrigerator/
freezer in a safe and comfortable
way.The lamps used in this appliance
have to withstand extreme physical
conditions such as temperatures
below -20 °C.
(only chest and upright freezer)

EN
13
Turbo Cooling Fan
“Turbo cooling fan is designed to
ensure homogenous distribution
and circulation of the cold air inside
your refrigerator. Operation time
of the turbo cooling fan may vary
depending on the properties of
your product. While the turbo fan
works only with the compressor in
some products, the control system
determines its operation time in
some products in accordance with the
cooling requirement. This situation
is explained on a separate warning
and information label attached on the
refrigerator in products equipped with
turbo fans running under different
conditions than the compressor.”
Icematic and ice storage
container
*May not be available in all models
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do not
put water in it. Otherwise, it will break.

EN
14
Reversing the doors
Proceed in numerical order
25
24
1
6
3
17
18
7
9
10
23
22
22
2
4
5
4
26
19
16
180°
20
19
12
13
11
27
11
14
15
27
45°
8
21

EN
15
4Preparation
• Your refrigerator should be installed
at least 30 cm away from heat
sources such as hobs, ovens, central
heater and stoves and at least 5
cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be
10°C. Operating your refrigerator
under cooler conditions is not
recommended with regard to its
efficiency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigerators are to be
installed side by side, there should
be at least 2 cm distance between
them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the
initial six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
• Food contact with the temperature
sensor in the freezer compartment
may increase energy consumption
of the appliance. Thus any contact
with the sensor(s) must be avoided.
• In some models, the instrument
panel automatically turns off 5
minutes after the door has closed.
It will be reactivated whenthe door
has opened or pressed on any key.
• Due to temperature change as
a result of opening/closing the
product door during operation,
condensation on the door/body
shelves and the glass containers is
normal

EN
16
5Using your refrigerator
Thermostat setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonaltemperatures,
• Frequentopeningofthedoorand
leaving the door open for long
periods,
• Foodputintotherefrigerator
without cooling down to the room
temperature,
• Thelocationoftherefrigeratorin
the room (e.g. exposing to sunlight).
• Youmayadjustthevaryinginterior
temperature due to such reasons
by using the thermostat. Numbers
around the thermostat button
indicates the cooling degrees.
• Iftheambienttemperatureishigher
than 32°C, turn the thermostat
button to maximum position.
• Iftheambienttemperatureislower
than 25°C, turn the thermostat
button to minimum position.
Defrost
Fridge compartment
Fridge compartment performs full-
automatic defrosting. Water drops
and a frosting up to 7-8 mm can occur
on the inner rear wall of the fridge
compartment while your refrigerator
cools down. Such formation is normal
as a result of the cooling system.
The frost formation is defrosted by
performing automatic defrosting
with certain intervals thanks to the
automatic defrosting system of the
rear wall. User is not required to scrape
the frost or remove the water drops.
Water resulting from the defrosting
passes from the water collection
groove and flows into the evaporator
through the drain pipe and evaporates
here by itself.
Check regularly to see if the drain
pipe is clogged or not and clear it with
the stick in the hole when necessary.
Deep freezer compartment does not
perform automatic defrosting in order
topreventdecayingofthe frozenfood.
The freezer compartment defrosts
automatically.

EN
17
Water Dispenser
*May not be available in all models
The water dispenser is a very useful
feature allowing cold water on tap
without opening the door of your
refrigerator .As you will not have to
openyourrefrigeratordoorfrequently,
you will have saved energy.
Using the water dispenser
Pushthelever ofthe waterdispenser
with your glass. The dispenser will
cease operating once you release the
lever.
When operating the water dispenser,
maximum flow can be obtained
by pressing the lever fully. Please
remember that the amount of flow
from the dispenser is subject to the
degree you press the lever.
As the level of the water in your
glass/container rises, slightly lessen
the pressure on the lever to prevent
the overspill. If you slightly press the
lever, the water will drip; this is quite
normal and not a failure.
Filling the water dispenser's tank
Open the cover of the water tank as
shown in the figure. Fill in the pure and
clean drinking water. Close the cover.
To avoid flowing of water by mistake,
we recommend you to lock the water
dispenser .
Warning!
• Do not fill the water tank with
any other liquid except for water
such as fruit juices, carbonated
beverages or alcoholic drinks which
are not suitable to use in the water
dispenser. Water dispenser will
be irreparably damaged if these
kinds of liquids are used. Warranty
does not cover such usages. Some
chemical substances and additives
contained in these kinds of drinks/
liquids may damage the water tank.
• Use clean and pure drinking water
only.
• Capacity of the water tank is 2.2
Litres (3.8 pints); do not overfill.

EN
18
• Push the arm of the water dispenser
with a rigid glass. If you are using
disposable plastic glasses, push the
lever with your fingers from behind
the glass.
1
1
2
Cleaning the water tank
Release the tank cover from the
water tank by opening latches at
both sides. Remove the water tank
and clean with warm and clean water.
Place the water tank to its seating,
install the tank cover and close the
latches.
3
Make sure that the parts removed
(if any) during cleaning are properly
attached to their original places.
Otherwise, water leakage may occur.
Important:
Components of the water tank and
waterdispenser should notbe washed
in dishwasher.
Water tray
Water that dripped while using the
water dispenser accumulates in the
spillage tray. Take out the spillage
tray by pulling it towards yourself and
empty it regularly.
Take out the plastic strainer by
pressing it on sides.
Take the water valve out of the
water tank. When replacing it, make
sure that the seal is in place.

EN
19
6Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
B We recommend that you unplug the
appliance before cleaning.
B Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish
for cleaning.
B For non-No Frost products,
water drops and frosting up to a
fingerbreadth occur on the rear wall
of the Fridge compartment. Do not
clean it; never apply oil or similar
agents on it.
B Only use slightly damp microfiber
cloths to clean the outer surface
of the product. Sponges and other
types of cleaning cloths may scratch
the surface.
C Use lukewarm water to clean the
cabinet of your refrigerator and wipe
itdry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe
itdry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to
be used for a long period of time,
unplug the power cable, remove all
food, clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
A Never use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
A Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water
and a soft cloth for cleaning and
then wipe it dry.
Protection of plastic
surfaces
CDonot put the liquid oils or oil-
cooked meals in your refrigerator
in unsealed containers as they
damage the plastic surfaces of your
refrigerator. In case of spilling or
smearing oil on the plastic surfaces,
clean and rinse the relevant part
of the surface at once with warm
water.
