Beko GNE 60520 X User manual

GNE 60520 X
Refrigerator
Congélateur /
réfrigérateur
Kühlschrank/
Gefrierschrank
Frigorifero
Frigorífico
Ψυγείο
Hűtőszekrény
Хладилник
Šaldytuvas
Chłodziarka
Frigorífico
Холодильники

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
www.beko.com
This product was manufactured using the latest technology in environmentally friendly conditions.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling

EN
2
1 The refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
For products with a water dispenser;.6
Child safety........................................6
HCA Warning ....................................6
Things to be done for energy saving..6
Recommendations for freshfood
compartment.....................................7
3 Installation 8
Points to be considered when re-
transporting your refrigerator .............8
Before operating your refrigerator ......8
Electric connection ............................9
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Placing and Installation ......................9
Floor balance adjustment ................10
Adjusting the gap between the upper
door ................................................10
Changing the illumination lamp .......11
4 Preparation 12
5 Using your refrigerator 13
Indicator Panel.................................13
Door Open Alarm: ..........................15
Indicator Panel.................................16
Door Open Alarm: ..........................18
Egg tray...........................................19
Sliding Body Shelves .......................19
Chiller compartment ........................19
Crisper ............................................20
Movable Middle Section .................21
Blue light .........................................21
Telescopic Drawer ..........................22
Freezing fresh food .......................... 23
Recommendations for preservation of
frozen food ...................................... 23
Placing the food ..............................24
Deep-freeze information ..................24
6 Maintenance and
cleaning 25
Protection of plastic surfaces ..........25
7 Recommended solutions
for the problems 26
CONTENTS

EN
3
1The refrigerator
A- Fridge compartment
B- Freezer compartment
1- Butter & Cheese shelf
2- Fridge compartment door
shelves
3- Fridge compartment glass
shelves
4- Diffuser cover
5- Illumination lens
6- Movable middle section
7- Chiller compartment
8- Bottle shelf
9- Crisper
10- icebox
11- Movable separators
CFigures that take place in this instruction manual are schematic and may
not correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
2
A
B
3
4
5
6
7
8
9
1
11
11
10

EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe this
information may cause injuries or
material damage. Otherwise, all
warranty and reliability commitments
will become invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
Intended use
This product is intended to be used
– indoors and in closed areas such as
homes;
– in closed working environments such
as stores and offices;
– in closed accommodation areas such
as farm houses, hotels, pensions.
• This product should not be used
outdoors.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
• For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment. Otherwise, these may
burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances
in the refrigerator.

EN
5
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact authorized service when
there is a power cable damage to
avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
• Label of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
• For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may
cause fire. Never place heavy objects
on power cable. Do not touch the
plug with wet hands when plugging
the product.
• Do not plug the refrigerator if the wall
outlet is loose.
• Water should not be sprayed directly
on inner or outer parts of the product
for safety purposes.
• Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
• Never place containers filled with
water on top of the refrigerator,
otherwise this may cause electric
shock or fire.
• Do not overload your refrigerator
with excessive amounts of food. If
overloaded, the food items may fall
down and hurt you and damage
refrigerator when you open the door.
Never place objects on top of the
refrigerator; otherwise, these objects
may fall down when you open or
close the refrigerator's door.
• As they require a precise
temperature, vaccines, heat-sensitive
medicine and scientific materials
and etc. should not be kept in the
refrigerator.
• If not to be used for a long time,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.

EN
6
• The plug's tip should be regularly
cleaned; otherwise, it may cause fire.
• The plug’s tip should be cleaned
regularly with a dry cloth; otherwise, it
may cause fire.
• Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
• When carrying the refrigerator, do not
hold it from door handle. Otherwise, it
may be snapped.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children must be supervised to
prevent them from tampering with the
product.
HCA Warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type plate which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is
not prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the food
quality.

EN
7
Recommendations for
freshfood compartment
* OPTIONAL
• Please do not let any foodstuff to
come to contact with the temperature
sensor in freshfood compartment.
In order to maintain freshfood
compartment at ideal storage
temperature, the sensor must not be
blocked by fodstuffs.
• Do not place hot foodstuff in your
appliance.
temperature
sensor
food
MILK
juice
etc.
temperature
sensor
temperature
sensor
food
MILK
juice
etc.
temperature
sensor

EN
8
3Installation
CPlease remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be
emptied and cleaned prior to any
transportation.
2. Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
CAlways remember...
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1. Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2. You can install the 2 plastic wedges
as illustrated in the figure. Plastic
wedges will provide the required
distance between your refrigerator
and the wall in order to allow the air
circulation. (The illustrated figure is
only an example and does not match
exactly with your product.)
3. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
4. Plug the refrigerator into the wall
outlet. When the door is open the
respective interior light will come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
6. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.

EN
9
Electric connection
Connect your refrigerator to a
grounded socket which is being
protected by a fuse with the
appropriate capacity.
Important:
BThe connection must be in
compliance with national regulations.
BThe power cable plug must be easily
accessible after installation.
B Voltage and allowable fuse protection
are specified in the “Technical
Specifications” section.
BThe specified voltage must be equal
to your mains voltage.
BExtension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
before it is repaired! There is danger
of electric shock!
BWarning against electric voltage.
Disposing of the packaging
AThe packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose them of by
classifying them in accordance
with the waste instructions. Do not
dispose them of along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old machine without
giving any harm to the environment.
AYou may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
A Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
ACaution: Never plug the refrigerator
into the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, than call the authorized
service to have them remove the
doors of your refrigerator and pass it
sideways through the door.
1. Install your refrigerator to a place
that allows ease of use.
2. Keep your refrigerator away from
heat sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling
and at least 5 cm with the wall.
If the floor is covered with a carpet,
your product must be elevated 2.5 cm
from the floor.
4. Place your refrigerator on an even
floor surface to prevent jolts.
5. Do not keep your refrigerator in
ambient temperatures under 10°C.

EN
10
Floor balance adjustment
AIf your refrigerator is unbalanced;
1- Ventilation cover is removed by
unscrewing its screws as illustrated
in the figure before the procedure.
You can balance your refrigerator by
turning the front legs of it as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the refrigerator will facilitate
this process.
2. After the balance issue is remedied,
install back the ventilation cover and
fasten the screws.
D
A B C
3. Remove the screws fastening the
lower ventilation cover using a Philips
screwdriver.
Adjusting the gap between
the upper door
CYou can adjust the gap between
the fridge compartment doors as
illustrated in the figures.
Door shelves should be empty when
adjusting the door height.
C Using a screwdriver, remove the
screw of upper hinge cover of the door
you want to adjust.

EN
11
C Adjust the door appropriately as
you desire by loosing the screws.
C Fix the door you have adjusted by
tightening the screws without changing
the position of the door.
C Replace the hinge cover and fix
with the screw.
Changing the illumination
lamp
To change the lamp used for
illumination of your refrigerator, please
call your Authorized Service.

EN
12
4Preparation
CYour refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
CThe ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
CPlease make sure that the interior
of your refrigerator is cleaned
thoroughly.
CIf two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
CWhen you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
COriginal packaging and foam
materials should be kept for future
transportations or moving.

EN
13
5Using your refrigerator
Indicator Panel
This touch-control indicator panel allows you to set the temperature without
opening the door of your refrigerator. Just touch the relevant button with your
finger to set the temperature.
* OPTIONAL
2
3
15
5
6
1 4
8 1617 7 10
914 1213 11
1. Fridge Compartment Temperature
Setting Button
2. Eko-Ekstra Button
3. Freezer Compartment Temperature
Setting Button
4. Quick Cool Button
5. Vacation Button
6. Fast Freeze Button
7. Fridge Compartment Temperature
Indicator
8. Eco Extra Function Indicator
9. Freezer Compartment Temperature
Indicator
10.Quick Cool Function Indicator
11. Vacation Function Indicator
12.Quick Freeze Function Indicator
13.Economy Mode Indicator
14.Error Status Indicator
15. Key Lock Indicator
16. Ionizer Indicator Light
17.Humidity Indicator
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

EN
14
1- Fridge Compartment
Temperature Setting Button
Press this button to set the
temperature of the fridge compartment
to 8, 6, 4, 2, 8... respectively.
Press this button to set the
desired temperature for the Fridge
Compartment.
2- Eko-Ekstra Button
Press this button briefly to activate the
Eco Extra function.
3- Freezer Compartment
Temperature Setting Button
Press this button to set the
temperature of the freezer
compartment to -18, -20, -22, -24,
-18... respectively. Press this button
to set the desired temperature for the
Freezer Compartment.
4. Quick CoolButton
Press this button briefly to activate
the Quick Cool function. Press this
button again to deactivate the selected
function.
5- Vacation Button
Press this button briefly to activate
the Vacation function. To stop ice
formation, press the same button for 3
seconds.
6- Fast Freeze Button
Press this button briefly to activate
the Fast Freeze function. Press this
button again to deactivate the selected
function.
7- Fridge Compartment
Temperature Indicator
Indicates the temperature set for
Fridge Compartment.
8- Eco Extra Function Indicator
Indicates that the Eco Extra function
is active. If this function is active, your
refrigerator will automatically detect
the least usage periods and energy-
efficient cooling will be performed
during those times. Economy indicator
will be active while energy-efficient
cooling is performed.
9- Freezer Compartment
Temperature Indicator
It indicates the temperature set for
Freezer Compartment.
10- Quick Cool Function Indicator
Indicates that the Quick Cool function
is active. Use this function when
you place fresh food into the fridge
compartment or when you need to
cool your food quickly. When this
function is active, your refrigerator will
run for 2 hours without stopping.
Press the relevant button again to
deactivate this function.
11- Vacation Function Indicator
Indicates that the vacation function
is active. If this function is active,
"- -" appears on the indicator of the
fridge compartment and no cooling is
performed in the fridge compartment.
Other compartments will be cooled in
accordance with the temperature set
for them.
Press the relevant button again to
deactivate this function.
12- Quick Freeze Function
Indicator
Indicates that the Quick Freezer
function is active. Use this function
when you place fresh food into the
freezer compartment or when you
need ice. When this function is active,
your refrigerator will run for 6 hours
without stopping.
Press the relevant button again to
deactivate this function.
13- Economy Mode Indicator
Indicates that the refrigerator is
running in energy-efficient mode. This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling is
being performed due to Eco-Extra
function.

EN
15
14- Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor
failure, this indicator will be activated.
When this indicator is active,
Freezer Compartment Temperature
indicator will display "E" and Fridge
Compartment Temperature Indicator
will display numbers such as "1,2,3…".
These numbers on the indicator
provides information about the error to
the service personnel.
15- Key Lock Indicator
Use this function if you do not want
your refrigerator temperature setting
changed. Press Eco Extra Button and
Freezer Compartment Temperature
Setting Button simultaneously for
a long time (3 sec) to activate this
feature.
Press the relevant buttons again to
deactivate this function.
16- Ionizer Indicator Light
Indicator light lights up continuously.
This light indicates that your
refrigerator is protected against the
bacteria.
17- Humidity Indicator
Indicator light lights up continuously.
This light indicates that the food kept
in the refrigerator is preserved for a
long time under ideal humidity.
Door Open Alarm:
In case of leaving any of the Fridge
Compartment or Cool Control
Compartment doors open minimum
for 1 minute, audible Door Open Alarm
will be activated and heard. Just press
any button on the indicator or close
the open door to silence the alarm.

EN
16
Indicator Panel
This touch-control indicator panel allows you to set the temperature without
opening the door of your refrigerator. Just touch the relevant button with your
finger to set the temperature.
* OPTIONAL
1 8 17 16 7 10 4
5
6
19
11 18121391420
15
3
2
21
1. Fridge Compartment Temperature
Setting Button
2. Eco-Ekstra Button
3. Freezer Compartment Temperature
Setting Button
4. Quick Cool Button
5. Vacation Function Button
6. Fast Freeze Button
7. Fridge Compartment Temperature
Indicator
8. Eco Extra Function Indicator
9. Freezer Compartment Temperature
Indicator
10.Quick Cool Function Indicator
11. Vacation Function Indicator
12.Quick Freeze Function Indicator
13.Economy Mode Indicator
14.Error Status Indicator
15. Key Lock Indicator
16. Ionizer Indicator Light
17.Humidity Indicator
18.Ice Machine OFF indicator
19.Ice Machine ON/OFF Button
20.Change Filter Warning Indicator
21.Filter Status Reset Button
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

EN
17
1- Fridge Compartment
Temperature Setting Button
Press this button to set the
temperature of the fridge compartment
to 8, 6, 4, 2, 8... respectively.
Press this button to set the
desired temperature for the Fridge
Compartment.
2- Eco-Ekstra Button
Press this button briefly to activate the
Eco Extra function.
3- Freezer Compartment
Temperature Setting Button
Press this button to set the
temperature of the freezer
compartment to -18, -20, -22, -24,
-18... respectively. Press this button
to set the desired temperature for the
Freezer Compartment.
4. Quick CoolButton
Press this button briefly to activate
the Quick Cool function. Press this
button again to deactivate the selected
function.
5- Vacation Button
Press this button briefly to activate
the Vacation function. To stop ice
formation, press the same button for 3
seconds.
6- Fast Freeze Button
Press this button briefly to activate
the Fast Freeze function. Press this
button again to deactivate the selected
function.
7- Fridge Compartment
Temperature Indicator
Indicates the temperature set for
Fridge Compartment.
8- Eco Extra Function Indicator
Indicates that the Eco Extra function
is active. If this function is active, your
refrigerator will automatically detect
the least usage periods and energy-
efficient cooling will be performed
during those times. Economy indicator
will be active while energy-efficient
cooling is performed.
9- Freezer Compartment
Temperature Indicator
It indicates the temperature set for
Freezer Compartment.
10- Quick Cool Function Indicator
Indicates that the Quick Cool function
is active. Use this function when
you place fresh food into the fridge
compartment or when you need to
cool your food quickly. When this
function is active, your refrigerator will
run for 2 hours without stopping.
Press the relevant button again to
deactivate this function.
11- Vacation Function Indicator
Indicates that the vacation function
is active. If this function is active,
“- -” appears on the indicator of the
fridge compartment and no cooling is
performed in the fridge compartment.
Other compartments will be cooled in
accordance with the temperature set
for them.
Press the relevant button again to
deactivate this function.
12- Quick Freeze Function
Indicator
Indicates that the Quick Freezer
function is active. Use this function
when you place fresh food into the
freezer compartment or when you
need ice. When this function is active,
your refrigerator will run for 6 hours
without stopping.
Press the relevant button again to
deactivate this function.
13- Economy Mode Indicator
Indicates that the refrigerator is
running in energy-efficient mode. This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling is
being performed due to Eco-Extra
function.

EN
18
14- Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor
failure, this indicator will be activated.
When this indicator is active,
Freezer Compartment Temperature
indicator will display “E” and Fridge
Compartment Temperature Indicator
will display numbers such as “1,2,3…”.
These numbers on the indicator
provides information about the error to
the service personnel.
15- Key Lock Indicator
Use this function if you do not want
your refrigerator temperature setting
changed. Press Eco Extra Button and
Freezer Compartment Temperature
Setting Button simultaneously for
a long time (3 sec) to activate this
feature.
Press the relevant buttons again to
deactivate this function.
16- Ionizer Indicator Light
Indicator light lights up continuously.
This light indicates that your
refrigerator is protected against the
bacteria.
17- Humidity Indicator
Indicator light lights up continuously.
This light indicates that the food kept
in the refrigerator is preserved for a
long time under ideal humidity.
18-Ice Machine OFF Indicator
If you do not want to get ice from
the refrigerator, you need to use this
function. You may use this function
by pressing the ice machine ON/OFF
button for 3 seconds.
19-Ice Machine ON/OFF Button
To stop ice formation, ice machine ON/
OFF button is pressed for 3 seconds.
When ice cancel is selected, no water
will be sent to the ice box. Despite this,
some ice may be left over in the ice
box which may be taken from there. To
restart ice formation, ice machine ON/
OFF button has to be pressed for 3
seconds.
20- Change Filter Warning
İndicator
When the filter usage time has
elapsed, change filter warning
indicator starts to illuminate.
21-Filter Status Reset Button
Filter of your refrigerator must be
replaced every 6 months. Your
refrigerator calculates this time
automatically and the filter change
waning indicator illuminates when the
filter usage time has elapsed. Press
filter status reset button for 3 seconds
to allow the refrigerator to calculate
the new filter time automatically after
changing the filter.
Door Open Alarm:
When the door of the fridge
compartment remains open for 1
minute, an audible Door Open Alarm
will be activated and heard. Just press
any button on the indicator or close
the open door to silence the alarm.

EN
19
Egg tray
You can install the egg holder to the
desired door or body shelf.
Never store the egg holder in the
freezer compartment
Sliding Body Shelves
Sliding body shelves can be pulled
by slightly lifting up from the front and
moved back and forth. They come to
a stop point when pulled towards front
to allow you reach the foods placed at
the back of the shelf; when it is pulled
after slightly lifted upwards at the
second stop point, the body shelf will
be released.
The shelf should be hold tightly from
the bottom as well in order to prevent
it from tipping over. The body shelf is
placed on the rails at the sides of the
refrigerator body by bringing it to one
lower or one upper level.
The body shelf should be pushed
backwards to seat it completely.
1
2
3
4
Chiller compartment
Chiller compartments enable the
foods to be frozen become ready
for freezing. You can also use these
compartments to store your food at a
temperature a few degrees below the
fridge compartment.
You can increase the inner volume of
your refrigerator by removing any of
the chiller compartments. To do this,
pull the compartment towards yourself;
the compartment will lean against the
stopper and stop. This compartment
will be released when you lift it about 1
cm and pull it towards yourself.
