Beko RCNE520E40LZX User manual

RCNE520E40LZX
EN SK

Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in modern facilities
with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In case the product
changes hands, do not forget to hand the guide to its new owner along with the product.
This guide will help you use the product quickly and safely.
t Please read the user guide carefully before installing and operating the product.
t Always observe the applicable safety instructions.
t Keep the user guide within easy reach for future use.
t Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide clearly indicates any
variations of different models.
CImportant information and useful
tips.
ARisk of life and property.
BRisk of electric shock.
The product’s packaging is made of
recyclable materials, in accordance
with the National Environment
Legislation.

2 /34 EN Refrigerator / User Guide
1. Safety and environment instructions3
1.1. General safety. . . . . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning. . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.2 For models with water dispenser . . . . . . . . 4
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety. . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with WEEE Directive and Disposing
of the Waste Product . . . . . . . . . . . . . . . . . 5
1.5. Compliance with RoHS Directive . . . . . . . . . 5
1.6. Package information . . . . . . . . . . . . . . . . . . 5
2 Your Refrigerator 6
3 Installation 7
3.1. Right place for installation . . . . . . . . . . . . . . 7
3.2. Attaching the plastic wedges . . . . . . . . . . . . 7
3.3. Adjusting the stands . . . . . . . . . . . . . . . . . . 7
3.4. Power connection . . . . . . . . . . . . . . . . . . . . 8
3.5. Reversing the doors . . . . . . . . . . . . . . . . . . 9
3.6. Reversing the doors . . . . . . . . . . . . . . . . . 10
4 Preparation 11
4.1. What to do for energy saving . . . . . . . . . . . 11
4.2. First Use . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Using the product 12
5.1. Temperature adjustment button . . . . . . . . . 12
5.2. Rapid freezing . . . . . . . . . . . . . . . . . . . . . 12
5.3. Vacation function . . . . . . . . . . . . . . . . . . . 13
5.4. Indicator panel . . . . . . . . . . . . . . . . . . . . . 14
5.5. Indicator panel . . . . . . . . . . . . . . . . . . . . . 16
5.6. Indicator panel . . . . . . . . . . . . . . . . . . . . . 19
5.7. Ice bucket. . . . . . . . . . . . . . . . . . . . . . . . . 21
5.8. Eggholder . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.9. Fan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.10. Vegetable bin . . . . . . . . . . . . . . . . . . . . . 22
5.11.Zero degree compartment . . . . . . . . . . . . 22
5.12.Moving door rack. . . . . . . . . . . . . . . . . . . 22
5.13.Sliding storage box . . . . . . . . . . . . . . . . . 23
5.14.Deodorising Module. . . . . . . . . . . . . . . . . 23
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.15.Moisture controlled vegetable bin . . . . . . . 24
5.16.Automatic ice machine . . . . . . . . . . . . . . 24
5.17.Icematic and ice storage container . . . . . . 25
5.18.Using the water dispenser . . . . . . . . . . . . 25
5.19.Filling the water dispenser's tank . . . . . . . 26
5.20. Cleaning the water tank . . . . . . . . . . . . . 27
5.22.HerbBox/HerbFresh . . . . . . . . . . . . . . . . . 28
5.21.Drip tray . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.23.Freezing fresh food . . . . . . . . . . . . . . . . . 29
5.24.Recommendations for storing frozen foods 29
5.25.Deep freezer details . . . . . . . . . . . . . . . . . 30
5.26.Placing the food. . . . . . . . . . . . . . . . . . . . 30
5.27.Door open alert . . . . . . . . . . . . . . . . . . . . 30
5.28.Changing the opening direction of the door30
5.29.Interior light . . . . . . . . . . . . . . . . . . . . . . . 30
6 Maintenance and cleaning 31
6.1. Avoiding bad odors . . . . . . . . . . . . . . . . . . 31
6.2. Protecting the plastic surfaces . . . . . . . . . 31
6.3. Door Glasses . . . . . . . . . . . . . . . . . . . . . 31
7. Troubleshooting 32

3/34EN
Refrigerator / User Guide
This section provides the safety
instructions necessary to prevent the risk
of injury and material damage. Failure to
observe these instructions will invalidate
all types of product warranty.
Intended use
A
WARNING:
Keep ventilation openings, in
the appliance enclosure or in
the built-instructure, clear of
obstruction.
A
WARNING:
Do not use mechanical
devices or other means to
accelerate the defrosting
process, other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the refrigerant
circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments of the
appliance, unless they are of
the type recommended by the
manufacturer.
This appliance is intended to be used in
household and similar applications such
as
– staff kitchen areas in shops, offices and
other working environments;
– farm houses and by clients in hotels,
motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail
applications.
1.1. General safety
t This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person responsible
for their safety. Children should not be
allowed to play with this device.
t In case of malfunction, unplug the
device.
t After unplugging, wait at least 5
minutes before plugging in again.
t Unplug the product when not in use.
t Do not touch the plug with wet hands!
Do not pull the cable to plug off, always
hold the plug.
t Do not plug in the refrigerator if the
socket is loose.
t Unplug the product during installation,
maintenance, cleaning and repair.
t If the product will not be used for a
while, unplug the product and remove
any food inside.
t Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.
1
1
t Do not use steam or steamed cleaning
materials for cleaning the refrigerator
and melting the ice inside. Steam may
contact the electrified areas and cause
1. Safety and environment instructions

Safety and environment instructions
4 /34 EN Refrigerator / User Guide
short circuit or electric shock!
t Do not wash the product by spraying
or pouring water on it! Danger of
electric shock!
t In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorised
service before doing anything.
t Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
t If the product has LED type lighting,
contact the authorised service for
replacing or in case of any problem.
t Do not touch frozen food with wet
hands! It may adhere to your hands!
t Do not place liquids in bottles and
cans into the freezer compartment.
They may explode.
t Place liquids in upright position after
tightly closing the lid.
t Do not spray flammable substances
near the product, as it may burn or
explode.
t Do not keep flammable materials
and products with flammable gas
(sprays, etc.) in the refrigerator.
t Do not place containers holding
liquids on top of the product.
Splashing water on an electrified
part may cause electric shock and
risk of fire.
t Exposing the product to rain,
snow, sunlight and wind will cause
electrical danger. When relocating
the product, do not pull by holding
the door handle. The handle may
come off.
t Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
t Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the
product to fall down and cause
damage to the parts.
t Take care not to trap the power
cable.
1.1.1 HC warning
If the product comprises a cooling
system using R600a gas, take care to
avoid damaging the cooling system and
its pipe while using and moving the
product. This gas is flammable. If the
cooling system is damaged, keep the
product away from sources of fire and
ventilate the room immediately.
CThe label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
t Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar). If
your water pressure exceeds 80 psi
(5.5 bar), use a pressure limiting
valve in your mains system. If you
do not know how to check your
water pressure, ask for the help of a
professional plumber.

Safety and environment instructions
5/34EN
Refrigerator / User Guide
t If there is risk of water hammer
effect in your installation, always
use a water hammer prevention
equipment in your installation.
Consult Professional plumbers if you
are not sure that there is no water
hammer effect in your installation.
t Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and
100°F (38°C) maximum.
t Use drinking water only.
1.2. Intended use
t This product is designed for
home use. It is not intended for
commercial use.
t The product should be used to store
food and beverages only.
t Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
t The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
t Original spare parts will be provided
for 10 years, following the product
purchasing date.
1.3. Child safety
t Keep packaging materials out of
children’s reach.
t Do not allow the children to play
with the product.
t If the product’s door comprises a
lock, keep the key out of children’s
reach.
1.4. Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be
reused and are suitable for
recycling. Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the collection
center for the recycling of electrical and
electronic equipment. Please consult your local
authorities to learn about these collection
centers.
1.5. Compliance with
RoHS Directive
t This product complies with EU WEEE
Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in
the Directive.
1.6. Package information
t Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.

6 /34 EN Refrigerator / User Guide
1. Cooler compartment door shelf
2. Water dispenser filling tank
3. Egg section
4. Water dispenser reservoir
5. Bottle shelf
6. Sliding storage box
7. Adjustable legs
8. Deep freezer compartment
9. Quick freeze compartment
10. Ice cube tray & Ice bank
11. Vegetable bin
12. Zero degree compartment
13. Interior light
14. Cooler compartment glass shelf
15. Temperature adjustment button
16. Cooler compartment
17. Freezer compartment
2Your Refrigerator
C*optional: Pictures given in this manual are given as example figures and they may not be exactly
the same as your product. If your product does not comprise the relevant parts, the information
pertains to other models.
*1
*2
*3
*4
*5
*5
*6
*8
*9
77
*11
*12
13
*15
16
17
*14
*10
*4

7/34EN
Refrigerator / User Guide
3Installation
3.1. Right place for installation
Contact the Authorized Service for the product's
installation. To ready the product for installation,
see the information in the user guide and make
sure the electric and water utilities are as required.
If not, call an electrician and plumber to arrange
the utilities as necessary.
BWARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
BWARNING: The product’s power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
AWARNING: If the door span is too narrow
for the product to pass, remove the door
and turn the product sideways; if this does
not work, contact the authorized service.
t1MBDFUIFQSPEVDUPOBGMBUTVSGBDFUPBWPJE
vibration.
t1MBDFUIFQSPEVDUBUMFBTUDNBXBZGSPNUIF
heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.
t%POPUFYQPTFUIFQSPEVDUUPEJSFDUTVOMJHIUPS
keep in damp environments.
t5IFQSPEVDUSFRVJSFTBEFRVBUFBJSDJSDVMBUJPOUP
function efficiently.
t*GUIFQSPEVDUXJMMCFQMBDFEJOBOBMDPWF
remember to leave at least 5 cm distance
between the product and the ceiling and the
walls.
t%POPUJOTUBMMUIFQSPEVDUJOFOWJSPONFOUTXJUI
temperatures below -5°C.
3.2. Attaching the plastic wedges
Use the plastic wedges in the provided with
the product to provide sufficient space for air
circulation between the product and the wall.
1. To attach the wedges, remove the screws on the
product and use the screws provided with the wedges.
2. Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
3.3. Adjusting the stands
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.

Installation
8 /34EN Refrigerator / User Guide
3.4. Power connection
AWARNING: Do not use extension or multi
sockets in power connection.
BWARNING: Damaged power cable must
be replaced by Authorized Service.
CWhen placing two coolers in adjacent
position, leave at least 4 cm distance
between the two units.
t Our firm will not assume responsibility for
any damages due to usage without earthing
and power connection in compliance with
national regulations.
t The power cable plug must be easily
accessible after installation.
t Connect the refrigerator to an earthed
socket with 220-240V/50 Hz voltage. The
plug must comprise a 10-16A fuse.
t Do not use multi-group plug with or without
extension cable between the wall socket
and the refrigerator.
C
Hot Surface Warning!
Side walls of your product is equipped
with refrigerant pipes to improve the
cooling system. Refrigerant with high
temperatures may flow through these
areas, resulting in hot surfaces on the
side walls. This is normal and does not
need any servicing. Please pay attention
while touching these areas.

Installation
9/34 EN
Refrigerator / User Guide
3.5. Reversing the doors
Proceed in numerical order .
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20

Installation
10 /34EN Refrigerator / User Guide
3.6. Reversing the doors
Proceed in numerical order .
1
17
1
20
11
13 9
2
10
5
3
20
20
8
18
17
19
45 °
180°
(8) (13)
14
6
4
12
16
15

11/34EN
Refrigerator / User Guide
4.1. What to do for energy saving
AConnecting the product to electronic
energy-saving systems is harmful, as it
may damage the product.
t Do not keep the refrigerator doors open for
long periods.
t Do not place hot food or beverages into the
refrigerator.
t Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
t In order to store the maximum amount of
food into the cooler compartment of your
refrigerator, you should take out the upper
drawers and place it onto the glass rack.
The declared energy consumption of your
refrigerator was determined by taking out the
cooler, ice tray and upper drawers in a way that
will enable maximum storage. Using the below
drawer when storing is strongly recommended.
Energy saving function should be activated for
best energy consumption.
t You should not block the airflow by putting food
in front of the cooler fan. A space of minimum
3cm must be left in front of the protective fan
wire when placing food.
t Depending on the product’s features;
defrosting frozen foods in the cooler
compartment will ensure energy saving and
preserve food quality.
t Food should be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
t Food packages should not be in direct contact
with the heat sensor located in the cooler
compartment. If they are in contact with the
sensor, energy consumption of the appliance
might increase.
t Make sure the foods are not in contact with
the cooler compartment temperature sensor
described below.
4Preparation
4.2. First Use
Before using your refrigerator, make sure the
necessary preparations are made in line with
the instructions in “Safety and environment
instructions” and “Installation” sections.
t Keep the product running with no food
inside for 6 and do not open the door, unless
absolutely necessary.
CA sound will be heard when the
compressor is engaged. It is normal to
hear sound even when the compressor is
inactive, due to the compressed liquids and
gasses in the cooling system.
CFront edges of the product might heat
up. This is normal. These areas are
designed to warm up in order to prevent
condensation.
CIn some models indicator panel turns off
automatically 5 minutes after the door
closes. It will be reactivated when the door
is open or any button is pressed.

12 /34 EN Refrigerator / User Guide
5Using the product
5.1. Temperature adjustment button
Internal temperature of your refrigerator varies
depending on the following reasons:
t Seasonal temperatures,
t Opening the door frequently and leaving it
open for long periods,
t Meals put into the refrigerator without being
cooled to room temperature,
t Location of the refrigerator in the room (e.g.
exposed to sunshine).
t Internal temperature varying due to these
factors can be adjusted via the adjustment
button.
Numbers around the adjustment button indicate
temperature degrees as “°C”.
If the ambient temperature is 20°C, it is recommended
to use the refrigerator temperature adjustment at
4°C. In other ambient temperatures this value can be
customised.
5.2. Rapid freezing
If you want to freeze large amounts of fresh food,
switch the temperature adjustment button to
( ) position before putting the food into the
quick freezing compartment.
It is recommended to keep the button at this
position for 24 hours to freeze maximum amount
of food indicated as the freezing capacity. Pay
special attention not to mix food stolen as frozen
and fresh food.
Remember to switch the temperature adjustment
button back to its previous position.

Using the product
13/34EN
Refrigerator / User Guide
5.3. Vacation function
If doors of the product is not ( ) opened
for at least 12 hours after adjusting the
temperature setting button to the highest,
vacation function is automatically activated.
Button setting must be changed to cancel the
function.
It is not recommended to store food in the
cooler compartment when vacation function is
activated.
t After setting is completed, you can
conceal the temperature setting button by
pressing it inside.

Using the product
14 /34EN Refrigerator / User Guide
5.4. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
45
76
8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional: The figures in this user guide are intended as drafts and may not perfectly match
your product. If your product does not comprise the relevant parts, the information pertains to
other models.

Using the product
15/34EN
Refrigerator / User Guide
1. Fridge compartment indicator
Fridge compartment light is illuminated while
the fridge compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform enough
cooling or in case of a sensor fault, this
indicator is activated. When this indicator
is activated, “E” is displayed on the freezer
compartment temperature indicator, and
numbers such as “1,2,3...” are displayed on
the fridge compartment temperature indicator.
These numbers on the indicator inform service
personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3 seconds to
activate this function. When the vacation
function is activated, “- -” is displayed on the
fridge compartment temperature indicator
and no active cooling is performed on the
fridge compartment. It is not suitable to keep
the food in the fridge compartment when this
function is activated. Other compartments
shall be continued to be cooled as per their set
temperature.
To cancel this function press Vacation button
again.
5. Temperature setting button
Changes the temperature of the relevant
compartment between -24°C... -18°C and
8°C...1°C.
6. Compartment selection button
Selection button: Press compartment selection
button to switch between fridge and freezer
compartments.
7. Freezer compartment indicator
Fridge compartment light is illuminated while
the freezer compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator operates
in energy saving mode. This display shall
be activated if the freezer compartment
temperature is set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.

Using the product
16 /34EN Refrigerator / User Guide
1. Economy
This symbol is illuminated when the freezer
compartment is set to -18°C’ye as the most
economical setting value ( ). Economy indi-
cator is turned off when quick cooling or quick
freeze functions are selected.
2. Power failure/High temperature / error
warning indicator
This indicator ( ) illuminates during power fa-
ilure, high temperature failures and error war-
nings. During sustained power failures, the hig-
hest temperature that the freezer compartment
reaches will flash on the digital display. After
checking the food located in the freezer com-
partment ( ) press the alarm off button to
clear the warning.
5.5. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
C*Optional: The figures in this user guide are intended as drafts and may not perfectly match
your product. If your product does not comprise the relevant parts, the information pertains to
other models.
Please refer to “remedies advised for troubles-
hooting” section on your manual if you observe
that this indicator is illuminated.
3. Energy saving function (display off)
If the product doors are kept closed for a long
time energy saving function is automatically
activated and energy saving symbol is illumina-
ted.When energy saving function is activated,
all symbols on the display other than energy
saving symbol will turn off. When the Energy
Saving function is activated, if any button is
pressed or the door is opened, energy saving
function will be canceled and the symbols on
display will return to normal.


  




Using the product
17/34EN
Refrigerator / User Guide
4. Quick cool
Quick cooling indicator
( ) is illuminated when quick cooling function
is activated and fridge compartment tempera-
ture indicator value is displayed as 1. To cancel
this function press Quick cooling button again.
Quick cooling indicator will turn off and refri-
gerator will return to its normal settings. Quick
cooling function is canceled automatically in 1
hour if you do not cancel it before. If you want
to cool large amounts of fresh food, press the
Quick cooling button before putting the food
into the fridge compartment.
5. Vacation function
In order to activate vacation function, press the
button no. (4) ( ) for 3 seconds, and the va-
cation mode indicator activates. When the va-
cation function is activated, “- -” is displayed
on the fridge compartment temperature indi-
cator and no active cooling is performed on
the fridge compartment. It is not suitable to
keep the food in the fridge compartment when
this function is activated. Other compartments
shall be continued to be cooled as per the-
ir set temperature.To cancel this function press
Vacation function button again.
6. Fridge compartment temperature set-
ting
When the button no. (5) is pressed, you may
set the temperature of the fridge compartment
to 8,7,6,5,4,3,2 and 1 respectively ( ).
7.1. Energy saving function (display off):
Energy saving symbol ( ) is illuminated and
Energy saving function is activated when you
press this button ( ). When energy saving
function is activated, all symbols on the display
other than energy saving symbol will turn off.
When the Energy Saving function is activated,
if any button is pressed or the door is opened,
energy saving function will be canceled and
the symbols on display will return to normal.
Energy saving symbol is turned off and energy
saving function is deactivated when you press
this button ( ) again.
7.2.Alarm off warning:
In case of power failure/high temperature
alarm, after checking the food located in the
freezer compartment press the alarm off button
to clear the warning.
8. Key lock
Press key lock button ( ) simultaneously for
3 seconds. Key lock symbol ( ) will light up
and key lock mode will be activated. Buttons
will not function if the Key lock mode is active.
Press key lock button simultaneously for 3 se-
conds again. Key lock symbol will turn off and
the key lock mode will be exited.
Press the key lock button if you want to pre-
vent changing of the temperature setting of the
refrigerator ( ).
9. Eco fuzzy
Press and hold eco fuzzy button for 1 seconds
to activate eco fuzzy function. Refrigerator will
start operating in the most economic mode at
least 6 hours later and the economic usage in-
dicator will turn on when the function is active
( ). Press and hold eco fuzzy function button
for 3 seconds to deactivate eco fuzzy function.
This indicator is illuminated after 6 hours when
eco fuzzy is activated.
10. Freezer compartment temperature
setting
Temperature setting for freezer compartment
is performed here. When button no. 9 is pres-
sed, you may set the temperature of the fre-
ezer compartment to -18, -19, -20, -21, -22,
-23 and -24 respectively.

Using the product
18 /34EN Refrigerator / User Guide
11. Fast freeze
Press button no. (10) for fast freeze operation,
quick freeze indicator
( ) shall be activated.
Quick freeze indicator is illuminated when qu-
ick freeze function is activated and fridge com-
partment temperature indicator is displayed as
-27. To cancel this function press quick freeze
button ( ) again.
Quick freeze indicator will turn off and refrige-
rator will return to its normal settings. Quick
freeze function is canceled automatically in 24
hour if you do not cancel it before. If you want
to freeze large amounts of fresh food, press the
quick freeze button before putting the food into
the freezer compartment.

Using the product
19/34EN
Refrigerator / User Guide
C*Optional: The figures in this user guide are intended as drafts and may not perfectly match
your product. If your product does not comprise the relevant parts, the information pertains to
other models.
5.6. Indicator panel
Indicator panel allows you to set the temperature and control the other functions related to the
product without opening the door of the product. Just press the inscriptions on relevant buttons for
function settings.
 







1. Power failure/High temperature / error
warning indicator
This indicator ( ) illuminates during power failure,
high temperature failures and error warnings.
During sustained power failures, the highest
temperature that the freezer compartment
reaches will flash on the digital display. After
checking the food located in the freezer
compartment ( ) press the alarm off button to
clear the warning.
Please refer to "remedies advised for
troubleshooting" section on your manual if you
observe that this indicator is illuminated.
2. Energy saving function (display off):
If the product doors are kept closed for a long
time energy saving function is automatically
activated and energy saving symbol is
illuminated. ( )
When energy saving function is activated,
all symbols on the display other than energy
saving symbol will turn off. When the Energy
Saving function is activated, if any button is
pressed or the door is opened, energy saving
function will be canceled and the symbols on
display will return to normal.
Energy saving function is activated during
delivery from factory and cannot be canceled.
