Beko WCV9612 Series User manual

Washing Machine
User’s Manual
EN VN
WCV7512*
WCV8612*
WCV9612*

This product was manufactured using the latest technology in environmentally friendly conditions.
EN1

1
This section includes security instructions which may help prevent the injuries and material
damage risks. All kinds of warranties shall be invalid if these instructions are not observed.
Never place the product on a carpet-covered floor. Electrical parts will get overheated since air
cannot circulate from under the device.This will cause problems with your product.
Unplug the product if it is not in use.
Always have the installation and repairing procedures carried out by the Authorised Service
Agent. The manufacturer shall not be held liable for damages that may arise from procedures
carried out by unauthorised persons.
The water supply and draining hoses must be securely fastened and remain undamaged.
Otherwise, water leak may occur.
While there is still water inside the product, never open the loading door or remove the filter.
Otherwise, risk of flooding and injury from hot water will occur.
Do not force open the locked loading door. Door can be opened a few minutes after the washing
cycle ends. In case of forcing the loading door to open, the door and the lock mechanism may
get damaged.
Use detergents, softeners and supplements suitable for automatic washing machines only.
Follow the instructions on the label of textiles and the detergent package.
This product can be used by the children who are at the age of 8 and over and the people whose
physical, sensory or mental skills are not fully developed or who do not have necessary required
experience and knowledge as long as they are supervised or trained about the safe use of the
product and its risks. Children should not play with the device. Cleaning and maintenance works
should not be performed by children unless they are supervised by someone. Children of less
than 3 years should be kept away unless continuously supervised.
Packaging materials may be dangerous for the children. Keep packaging materials in a safe place
away from reach of the children.
Electrical products are dangerous for the children. Keep the children away from the product when
it is in use. Do not allow them to play with the product. Use child lock to prevent children from
intervening with the product.
Do not forget to close the loading door when leaving the room where the product is located.
Store all detergents and additives in a safe place away from the reach of the children by closing
the cover of the detergent container or sealing the detergent package.
If the product has a failure, it should not be operated unless it is repaired by the Authorised Service
Agent. Risk of electric shock!
This product is designed to resume operating in the event of powering on after a power interruption.
If you wish to cancel the programme, see "Cancelling the programme" section.
Plug the product into a grounded outlet protected by a 16 A fuse. Do not neglect to have the
grounding installation made by a qualified electrician. Our company shall not be liable for any
damages that will arise when the product is used without grounding in accordance with the local
regulations.
Do not wash the product by spraying or pouring water onto it! Risk of electric shock!
Never touch the power cable plug with wet hands! Do not grab the power cord to unplug the
machine, always unplug it by holding the socket with one hand, and pulling the plug with the
other hand.
Product should be unplugged during installation, maintenance,cleaning and repair procedures.
If the power cable is damaged, it must be replaced by the manufacturer, after sales service or a
similarly qualified person(preferably an electrician) or someone designated by the importer in
order to avoid possible risks.
General safety instructions
1.1 Life and property safety
1.2 Children's safety
1.3 Electrical safety
EN2

1.4 Hot surface safety
2.1 Compliance with WEEE Directive
2.2 Package information
While washing the laundry at high temperatures,the loading
door glass will get hot.Considering this fact,during washing
operation keep the children away from the loading door of
the product to prevent them touching it.
2
Important instructions for environment
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which
can be reused and are suitable for recycling. Do not dispose of the waste product
with normal domestic and other wastes at the end of its service life. Take it to the
collection center for the recycling of electrical and electronic equipment. Please
consult your local authorities to learn about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials specified in the Directive.
Packaging materials of the product are manufactured from recyclable materials in accordance
with our National Environment Regulations. Do not dispose of the packaging materials together
with the domestic or other wastes. Take them to the packaging material collection points
designated by the local authorities.
This product has been designed for domestic use. It is not for commercial purposes or it should not
be used out of its intended use.
The product must only be used for washing and rinsing of laundry that are marked accordingly.
The manufacturer waives any responsibility arisen from incorrect usage or transportation.
The service life of your product is 10 years. During this period, original spare parts will be available
to operate the appliance properly.
3
Intended use
4 Technical specifications
Supplier name or trademark
Complying Commission Delegated Regulation (EU) No 1061/2010
Beko
Model name WCV9612XB0ST
Rated capacity (kg) 9.0
Maximum spin speed (rpm) 1200
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Net weight (±4 kg.) 72
Single Water inlet / Double Water inlet • / -• / -• / -
• Available
Electrical input (V/Hz) 220-240 V~ / 50Hz
Total power (W) 2000-2350
Main model code 9211
Beko
WCV8612XB0ST
8.0
1200
84
60
55
63
220-240 V~ / 50Hz
2000-2350
9210
Beko
WCV7512XB0ST
7.5
1000
84
60
55
59
220-240 V~ / 50Hz
Total current (A) 101010
2000-2350
9210
Technical specifications may be changed without prior notice to improve the quality of the product.
EN3

4.1 Installation
Apply to the nearest authorised service agent for the installation of your product.
Preparation of the location and electrical, tap water and waste water installations at the place of
installation is under customer's responsibility.
Make sure that the water inlet and discharge hoses as well as the power cable are not folded,
pinched or crushed while pushing the product into its place after installation or cleaning
procedures.
Make sure that the installation and electrical connections of the product are performed by
authorised service. Manufacturer shall not be held liable for damages that may arise from
procedures carried out by unauthorised persons.
Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
4.1.2 Removing packaging reinforcement
4.1.3 Removing the transportation locks
Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other
similar surfaces.
When the washing machine and dryer are placed on top of each other, their total weight –when
loaded– amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient
load carrying capacity!
Do not place the product on the power cable.
Do not install the product in the environments where the temperature falls below 0 ºC.
Leaving a gap at the sides of the machine is suggested to reduce vibration and noise
On a graduated floor, do not place the product next to the edge or on a platform.
Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not
use them on the product.
1.Loosen all bolts with an appropriate wrench until they turn freely.
2.Remove the transport safety bolts by turning them slightly.
3.Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.
Tilt the machine backwards to remove the packaging reinforcement.
Remove the packaging reinforcement by pulling the ribbon.
Do not make this operation alone by yourself.
CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the
product will be damaged.
Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again
in the future.
Install the transport safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!
4.1.4 Connecting water supply
The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a
pressure reducing valve if water pressure is higher.
EN4

4.1.5 Connecting the drain hose to the drain
4.1.6 Adjusting the feet
Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands in a stable and balanced way.
3. Tighten all lock nuts by hand again.
CAUTION:
CAUTION:
Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.
laundry will get damaged or the product will switch to protection mode and will not operate.
1
• Connect the drain hose to a minimum height of 40
cm and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on
the floor level or close to the ground (less than 40 cm
above the ground), water discharge becomes more
difficult and the laundry may come out excessively
wet. Therefore, follow the heights described in the
figure.
• To prevent the waste water to go back into the machine again and to ensure easy drainage,
do not immerse the end of the hose into the waste water or do not insert it into the drain for more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be
pinched between the drain and the machine.
• If the length of the hose is too short, use it by adding an original extension hose. Length of the
hose may not be longer than 3.2 m. To avoid water leak failures, the connection between the
extension hose and the drain hose of the product must be fitted well with an appropriate clamp as
not to come off and leak.
2 When hose connection is completed, check whether there is
leak problems at the connection points by opening the taps
fully. If any leaks occur, turn off the tap and remove the nut.
Retighten the nut carefully after checking the seal. In order to
prevent the water leaks and resultant damages, keep the taps
closed when you do not use the product.
Tighten the nuts of the hose by hand. Never use a tool when
tightening the nuts.
CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge.
Moreover, there is risk of scalding due to high washing temperatures! In order to prevent such situations and
make sure that the machine performs water intake and discharge processes without any problem, fix the drain
hose securely.
40 cm
100 cm
CAUTION:
CAUTION:
Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and
cause crushing and vibration problems.
In order to ensure that the product operates more silently and vibration-free, it must stand level and
EN5

4.1.7 Electrical connection
4.1.8 Initial use
Use an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to the quality control processes in
the production. It is not harmful for the product.
Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable
for any damages that will arise when the product is used without grounding in accordance with the
local regulations.
* Sort laundry according to type of fabric, color, and degree of soiling and allowable water
temperature.
* Always obey the instructions given on the garment tags.
• Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons
will damage the machine. Remove the metal pieces or wash the clothes by putting them in a
laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets
inside out and brush. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “machine washable” or “hand washable” labeled products only with an appropriate
programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash
them separately.
• Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.
• Only use the dyes / color changers and descaling agents which are appropriate to machine wash.
Always follow the instructions on the package.
• Wash trousers and delicate laundry turned inside out.
• Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will
reduce pilling.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must
be shaken off before placing into the machine. Such dusts and powders on the laundry may build
up on the inner parts of the machine in time and can cause damage.
Before starting to use the product make sure that the preparations
are made which are in line with the “Important Safety and
Environment Instructions” and the instructions in the “Installation”
section.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
machine, apply the method which is described in the section 4.4.2.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements.
Use of a Groud Fault Circuit Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified
electrician install a 16 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs.
4.2 Preparation
4.2.1 Sorting the laundry
4.2.2 Sorting the laundry
CAUTION:Damaged power cables must be replaced by the Authorised Service Agents.
EN6

Following information will help you use the product in an ecological and energy-efficient manner.
• Operate the product in the highest capacity allowed by the programme you have selected, but do
not overload; see, "Programme and consumption table". See, “Programme and consumption table"
• Always follow the instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during
washing process.
• Do not use more detergent than the recommended amount specified on its package.
4.2.3 Things to be done for energy saving
1. Open the laundry cover.
2. Put the laundry items into the machine in a loose manner.
3. Push and close the loading cover until you hear the locking sound. Ensure that no items are
caught in the door. The loading door is locked while a programme is running. The door can only
be opened a while after the programme comes to an end.
4.2.4 Loading the laundry
The maximum load capacity depends on the type of laundry, the degree of soiling and the
washing programme desired.
Machine automatically adjusts the water amount according to the weight of the laundry put inside it.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing programme.
• While the washing cycle is in progress, do not leave the detergent dispenser open!
• When using a programme without prewash, do not put any detergent into the prewash
compartment (compartment nr. "1").
• In a programme with prewash, do not put liquid detergent into the prewash compartment
(compartment nr. "1").
• Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place
the detergent bag or the dispensing ball directly among the laundry in the machine.
If you are using liquid detergent, do not forget to place the liquid detergent container into the main
wash compartment (compartment number “2”).
Choosing the detergent type
Detergent type to be used depends on the fabric type and color.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.)
used solely for delicate clothes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woolens with special detergent made specifically for woolens.
The detergent drawer is composed of three
compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there is a siphon piece in the
softener compartment.
4.2.5 Correct load capacity
4.2.6 Using detergent and softener
WARNING:Follow the information in the “Programme and consumption table”. When overloaded, machine's
washing performance will drop. Moreover, noise and vibration problems may occur.
When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the
manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if
available.
13
2
EN7

Adjusting detergent amount
The amount of washing detergent to be used depends on the amount of laundry, the degree of
soiling and water hardness.
• Do not use amounts exceeding the dosage quantities recommended on the detergent package
to avoid problems of excessive foam, poor rinsing, financial savings and finally, environmental
protection.
• Use lesser detergent for small amounts or lightly soiled clothes.
Using softeners
Pour the softener into the softener compartment of the detergent drawer.
• Do not exceed the (>max<) level sign on the softener compartment.
• If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer.
If the product does not contain a liquid detergent cup:
• Do not use liquid detergent for the prewash in a programme with prewash.
• Liquid detergent stains your clothes when used with Delayed Start function. If you are going to
use the Delayed Start function, do not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and your machine does not contain a special liquid
detergent cup, put the gel detergent into the main wash detergent compartment during first
water intake. If your machine contains a liquid detergent cup, fill the detergent into this cup before
starting the programme.
• If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly
into the drum before washing.
• Put tablet detergents into the main wash compartment (compartment nr. "2") or directly into the
drum before washing.
Using starch
• Put the liquid soda, powder soda or the fabric dye into the softener compartment.
Do not use softener and starch together in a washing cycle.
Wipe the inside of the machine with a damp and clean cloth after using starch.
Using limescale remover
• When required, use limescale removers manufactured specifically for washing machines only.
Using bleaches
Add the bleach at the beginning of the washing cycle by selecting a prewash program. Do not put
detergent in the prewash compartment. As an alternative application, select a programme with
extra rinse and add the bleaching agent while the machine is taking water from the detergent
compartment during first rinsing step.
• Put the liquid detergent container into the
compartment no “2”.
• If the liquid detergent lost its fluidity, dilute
it with water before putting it into the
detergent container.
• When you want to use liquid detergent,
pull the apparatus towards yourself. The
part that falls down will serve as a barrier
for the liquid detergent.
• If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the
apparatus must be secured at top position.
Using liquid detergents
If the product contains a liquid detergent cup:
If the product is equipped with a liquid detergent part:
CAUTION:Use only detergents manufactured specifically for washing machines.
CAUTION:Do not use soap powder.
2
2
EN8

• Do not use bleaching agent and detergent by mixing them.
• Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it
causes skin irritation. Do not pour the bleach onto the laundry and do not use it with the colored
items.
• When using oxygen-based decolorant, select a program which washes the laundry at a low
temperature.
• Oxygen-based decolorant can be used with the detergent; however, if it is not at the same
consistence, first put detergent in the compartment number “2” in the detergent dispenser and
wait for the machine to flush the detergent when taking in water. While the machine continues
taking in water, add decolorant in the same compartment.
4.2.7 Tips for efficient washing
Clothes
Soiling Level
Light Colours and
Whites
Heavily
Soiled
(Recommended temperature
range based on soiling level:
40-90 oC)
(difficult stains
such as grass,
coffee, fruits
and blood.)
It may be necessary to pretreat
the stains or perform
prewash. Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended for
heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches. Use
detergents without bleach.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.
Normally
Soiled
(For example,
stains caused
by body on
collars and
cuffs)
Powder and liquid detergents
recommended for whites
can be used at dosages
recommended for normally
soiled clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
normally soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.
Lightly
Soiled
(No visible
stains exist.)
Powder and liquid detergents
recommended for whites
can be used at dosages
recommended for lightly soiled
clothes.
Powder and liquid detergents
recommended for colors
can be used at dosages
recommended for lightly
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woolen and silk
clothes must
be washed with
special woolen
detergents.
(Recommended temperature
range based on soiling level:
cold -40 oC)
(Recommended
temperature range
based on soiling level:
cold -40 oC)
(Recommended
temperature range
based on soiling
level: cold -30 oC)
Colours Black/Dark
Colours
Delicates/
Woolens/
Silks
EN9

4.3 Operating the product
4.3.1 Control panel
1.Make sure that the hoses are connected tightly.
2.Plug in your machine.
3.Turn the tap on completely.
4.Place the laundry in the machine.
5.Add detergent and fabric softener.
4.3.2 Preparing the machine
1.Select the programme suitable for the type, quantity and soiling degree of the laundry in
accordance with the "Programme and consumption table" and the temperature table below.
2.Select the desired programme with the Programme Selection knob.
4.3.3 Programme selection and tips for efficient washing
1 - Programme Selection knob (Uppermost
position On / Off)
2 - Display
3 - Delayed Start Button
4 - Programme Follow-up indicator
5 - Start / Pause button
6 - Auxiliary function button 3
7 - Auxiliary function button 2
8 - Auxiliary function button 1
9 - Spin Speed Adjustment button
10 - Temperature Adjustment button
EN10
60°
1200
20°
90°
40°
30°
1000
800
600
1 2 3 4
57 68910

4.3.4 Programme and consumption table
• : Selectable
* : Automatically selected, no canceling.
** : Energy Label programme (TCVN 8526:2013)
***: If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.
- : See the programme description for maximum load.
** "Cotton Economic 40°C and Cotton Economic 60°C are standard programmes." These programmes are known as '40°C
cotton standard programme' and '60°C cotton standard programme' and indicated with the symbols on the
panel.
Max Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
prewash Fast+
Anti-Crease+ PHR
Selectable temperature range °C
90 7.5 92 2.25 1600 Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 30
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 60
Cold - 60
Cold - 60
Cold - 60
Cold - 60
60 7.5 92 1.70 1600 • • • •
• • • •
• • • •
• • • •
• • • •
• •
•
•
•
•
••
• • •
• •
• •
•
•
• •
40 7.5 89 1.05 1600
20** 7.5 89 0.18 1600
60 7.5 52 0.90 1600
60 3.75 42 0.70 1600
40 3.75 42 0.60 1600
60 3 65 1.20 1200
40 3 63 0.75 1200
90 7.5 62 2.00 1400
60 7.5 62 1.10 1400
30 7.5 60 0.20 1400
Daily Xpress / Xpress Super Short + Fast 30 2 41 0.15 1400
Mix 40 40 3.5 65 0.75 800
Wool/Hand wash 40 1.5 55 0.55 1200
Delicates 40 3.5 51 0.65 1200 *
*
Outdoor/Sports 40 3.5 44 0.45 1200
Darkwash/Jeans 40 3 82 0.85 1200
StainExpert 60 3.5 70 1.50 1600 30 - 60
Steam Down Wear 60 1.5 75 1.75 1000 40 - 60
Steam Shirts 60 3 65 1.70 800 40 - 60
Steam Hygiene+ 90 7.5 132 3.00 1600 40 - 90
Steam Drum Cleaning 90 - 77 2.50 600 90
Daily Xpress / Xpress Super Short
EN Auxiliary functions
Program
Cottons
WCV7512*
Cottons Eco
Synthetics
EN11

• : Selectable
* : Automatically selected, no canceling.
** : Energy Label programme (TCVN 8526:2013)
***: If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.
- : See the programme description for maximum load.
** "Cotton Economic 40°C and Cotton Economic 60°C are standard programmes." These programmes are known as '40°C
cotton standard programme' and '60°C cotton standard programme' and indicated with the symbols on the
panel.
Auxiliary functions
WCV8612*
90 8
8
8
8
8
8
8
8
95 2.40 1600
60 95 1.80 1600 • • • •
• • • •
• • • •
• • • •
• • • •
• •
•
•
•
•
••
•
•
• •
• •
• •
•
•
• •
40 93 0.97 1600
20** 93 0.267 1600
60 52 0.90 1600
60 4
4
42 0.70 1600
40 42 0.60 1600
60 3 75 1.35 1200
40 3 70 0.85 1200
90 66 2.00 1400
60 66 1.20 1400
30 66 0.20 1400
30 2 40 0.15 1400
40 3.5 83 1.00 800
40 1.5 62 0.55 1200
40 3.5 60 0.67 1200 *
*
40 3.5
3.5
58 0.60 1200
40 88 1.05 1200
60 4 85 1.70 1600 30 - 60
60 3 105 1.90 1000 40 - 60
60 2 70 1.90 800 40 - 60
90 8 135 2.70 1600 40 - 90
90 - 85 2.60 600 90
EN
Program
Max Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
prewash Fast+
Anti-Crease+ PHR
Selectable temperature range °C
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 30
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 60
Cold - 60
Cold - 60
Cold - 60
Cold - 60
Daily Xpress / Xpress Super Short + Fast
Mix 40
Wool/Hand wash
Delicates
Outdoor/Sports
Darkwash/Jeans
StainExpert
Steam Down Wear
Steam Shirts
Steam Hygiene+
Steam Drum Cleaning
Daily Xpress / Xpress Super Short
Cottons
Cottons Eco
Synthetics
EN12

• : Selectable
* : Automatically selected, no canceling.
** : Energy Label programme (TCVN 8526:2013)
***: If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.
- : See the programme description for maximum load.
** "Cotton Economic 40°C and Cotton Economic 60°C are standard programmes." These programmes are known as '40°C
cotton standard programme' and '60°C cotton standard programme' and indicated with the symbols on the
panel.
Auxiliary functions
WCV9612*
90 9
9
9
9
9
99 2.50 1600
60 99 1.90 1600 • • • •
• • • •
• • • •
• • • •
• • • •
• •
•
•
•
•
••
•
•
• •
• •
• •
•
•
• •
40 99 0.99 1600
20** 23 0.21 1600
60 55 1.10 1600
60 4.5
4.5
46 0.80 1600
40 46 0.70 1600
60 3 75 1.35 1200
40 3 70 0.90 1200
90 9
9
9
66 2.20 1400
60 66 1.20 1400
30 66 0.20 1400
30 2 40 0.15 1400
40 3.5 83 1.00 800
40 1.5 62 0.55 1200
40 3.5 60 0.79 1200 *
*
40 3.5 58 0.60 1200
40 3 88 1.05 1200
60 4 85 1.70 1600 30 - 60
60 2 105 1.90 1000 40 - 60
60 3 70 1.90 800 40 - 60
90 8 135 2.00 1600 40 - 90
90 - 85 2.60 600 90
EN
Program
Max Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
prewash Fast+
Anti-Crease+ PHR
Selectable temperature range °C
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 90
Cold - 30
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 40
Cold - 60
Cold - 60
Cold - 60
Cold - 60
Cold - 60
Daily Xpress / Xpress Super Short + Fast
Mix 40
Wool/Hand wash
Delicates
Outdoor/Sports
Darkwash/Jeans
StainExpert
Steam Down Wear
Steam Shirts
Steam Hygiene+
Steam Drum Cleaning
Daily Xpress / Xpress Super Short
Cottons
Cottons Eco
Synthetics
EN13

4.3.1 Control panel
4.3.6 Additional programmes
Water and power consumption may vary subject to the changes in water pressure, water hardness and
temperature,ambient temperature, type and amount of laundry, selection of auxiliary functions and spin
speed, and changes in electric voltage.
You can see the washing duration on the display of your machine while selecting a programme. Depending
on the amount of laundry you have loaded into your machine, there may be a difference of 1-1.5 hours
between the duration shown on the display and the actual duration of the wash cycle. Duration will be
automatically updated soon after the washing starts.
The auxiliary functions in the table may vary according to the model of your machine.
Depending on the type of fabric, use the following main programmes.
• Cottons
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.)
in this programme. When the quick wash function button is pressed, programme duration
becomes notably shorter but effective washing performance is ensured with intense washing
movements. If the quick wash function is not selected, superior washing and rinsing performance
is ensured for your heavily soiled laundry.
• Synthetics
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this
programme. The programme duration gets notable shorter and washing with high performance is
ensured. If the quick wash function is not selected, superior washing and rinsing performance is
ensured for your heavily soiled laundry.
• Wool / Hand Wash
Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with
the tag of your clothes. Your laundry will be washed with a very gentle washing action in order not
to damage the clothes.
For special cases, additional programmes are available in the machine.
• Cottons Eco
Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than
all other programmes, it provides high energy and water savings. Actual water temperature may be
different from the stated wash temperature. When you load the machine with less laundry (e.g. ½
capacity or less), periods in programme stages may automatically get shorter. In this case, energy
and water consumption will decrease more, providing a more economic wash.
• Delicates
You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this
programme. It washes with more delicate washing action. Wash your clothes whose colour you
want to preserve either at 20degrees or by selecting the cold wash option.
• Daily Xpress / Xpress Super Short
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The
programme duration can be reduced up to 14 minutes when the quick wash function is selected.
When the quick wash function is selected, maximum 2 (two) kg of laundry must be washed.
• Dark Wash / Jeans
Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high
performance washing with special drum movement even if the temperature is low. It is
recommended to use liquid detergent or woolen shampoo for dark coloured laundry. Do not wash
your delicate clothes containing wool or etc.
• Mix 40
Use to wash your cotton and synthetic clothes together without sorting them.
Additional programmes may differ according to the model of the machine.
The wool wash cycle of this machine has been approved by The
Woolmark Company for the washing of machine washable wool products
provided that the products are washed according to the instructions on
the garment label and those issued by the manufacturer of this washing
machine.M1730 / M1546 / M13985.
The Woolmark symbol is a Certification mark in many countries.
EN14

When quick function is selected:
Blood Tea Red Wine
Chocolate Coffee Curry
Pudding Fruit juice Jam
Egg Ketchup Coal
• Shirts
This programme is used to wash the shirts made from cotton,synthetic and synthetic blanded fabric
altogether.It reduces wrinkles.Steam is applied at the end of the programme to help the wrinkle reducing
function.The special spin profile and steam applied at the end of the programme reduce the wrinkles on
your shirts.When the quick wash function is selected,the Pre-treatment algorithm is executed.
• Outdoor / Sports
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics
mix and water repellent covers such as gore-tex etc. It makes sure your garments are washed gently
thanks to special rotating movements.
• Down Wear
Use this programme to wash your coats, vest, jackets etc. containing feathers with a “machinewashable”
label on them. Thanks to special spinning profiles, it is ensured that the water reaches the air gaps
amongst the feathers. Steam is applied at the end of the programme to soften bulky laundry such as
towels.
• StainExpert
The machine has a special stain programme which enables the removal of different types of stains
in the most effective way. Use this programme only for durable colourfast cotton laundry. Do not
wash delicate and pigmenting clothes and laundry in this programme. Before washing, garment tags
should be checked (recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas,
aprons, table clothes, beddings, duvet cover, bed sheet, pillowcase, bath-beach towel, towel, socks,
cotton underwear that are suitable for washing at high temperature and long time). In the
automatic stain programme, you can wash 24 types of stains divided into two different groups
according to quick function selection. You can see stain groups based on the selection of the quick
function. You can find stain groups based on quick function below:
• Apply the pre-treatment chemical on your garments directly or add it togther with detergent when
the machine starts to take water from the main washing compartment.Thus,you can obtain the same
performance as you obtain with normal washing in a much shorter period of time.Usage life of your
shirts increases.
Allergy UK is the brand of the British Allergy Association. Seal of Approval is
created to guide people that require recommendation about a product that the
related product restricts / reduces / eliminates the allergens or reduces the
allergen content significantly in the ambient where allergy patients exist. It aims
to provide assurance that the products are tested scientifically or examined in a
way to provide measurable results
• Hygiene
Applying a steam step at the beginning of the programme allows to soften the dirt easily. Use this
programme for your laundry (baby clothes, bed sheets, bedlinen,underwear, etc. cotton items) that
requires an anti-allergic and hygienic washing at high temperature with intensive and long washing
cycle. The high level of hygiene is ensured thanks to the steam application before the programme, long
heating duration and additional rinsing step.
• Pogramme was tested by “The British Allergy Foundation“ (Allergy UK) with the 60°C temperature
option selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria
and mould.
When quick function is not selected:
Butter Sweat Salad Dressing
Grass Collar Soil Make-up
Mud Food Machine Oil
Coke Mayonnaise Baby Food
EN15

4.3.7 Special programmes
If a second auxiliary function conflicting with the first one is selected before starting the
machine, the function selected first will be canceled and the second auxiliary function
selection will remain active.
An auxiliary function that is not compatible with the programme cannot be selected.
(See, "Programme and consumption table")
Auxiliary Function buttons may vary according to the model of the machine.
• Select the stain programme.
• Select the stain you want to clean by locating it in the groups above and selecting the related group
with the quick auxiliary function button.
• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.
For specific applications, select any of the following programmes.
• Rinse
Use when you want to rinse or starch separately.
• Spin+Drain
You can use this function to remove the water on the garment of drain the water in the machine.
Before selecting this programme, select the desired spin speed and press Start / Pause button. First,
the machine will drain the water inside of it. Then, it will spin the laundry with the set spin speed and
drain the water coming out of them.
If you wish to drain only the water without spinning your laundry, select the Pump+Spin programme
and then select the No Spin function with the help of Spin Speed Adjustment button. Press Start /
Pause button.
Use a lower spin speed for delicate laundries.
4.3.8 Temperature selection
Whenever a new programme is selected, the recommended temperature value for the selected
programme appears on the temperature indicator.
To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease
gradually. Temperature level lights will not turn on when the cold level is selected.
If the programme has not reached the heating step, you can change the temperature
without switching the machine to Pause mode.
4.3.9 Spin speed selection
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the spin speed indicator.
To decrease the spin speed, press the Spin Speed Adjustment button. Spin speed decreases
gradually. Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear
on the display. When "No Spin" is selected, the rinse level indicator lights will not turn on.
Rinse hold
If you are not going to unload your clothes immediately after the programme completes, you can use
rinse hold function to keep your laundry in the final rinsing water in order to prevent them from
getting wrinkled when there is no water in the machine. Press Start / Pause button after this
process if you want to drain the water without spinning your laundry. Programme will resume and
complete after draining the water.
If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button.
The programme will resume. Water is drained, laundry is spun and the programme is completed.
4.3.10 Auxiliary function selection
Select the desired auxiliary functions before starting the programme. Furthermore, you may also
select or cancel auxiliary functions that are suitable to the running programme without pressing the
Start / Pause button when the machine is operating. For this, the machine must be in a step before
the auxiliary function you are going to select or cancel. If the auxiliary function cannot be selected or
canceled, light of the relevant auxiliary function will blink 3 times to warn the user.
If the programme has not reached the spinning step, you can change the speed without
switching the machine to Pause mode.
EN16

4.3.10.1 Auxiliary functions
• Prewash
A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy,
water, detergent and time.
Prewash without detergent is recommended for tulle and curtains.
Even if another programme is selected with the Programme Selection knob while the Child Lock is active,
previously selected programme will continue running.
If the Programme Selection knob is turned when the Child Lock is active, "Con" appears on the display. The Child
Lock does not allow any change in the programmes and the selected temperature, speed and auxiliary functions.
Do not run the programme when there is something in the machine. If you try to do so,
the machine detects that there is load inside and aborts the programme.
This is not a washing programme. It is a maintenance programme.
• Fast+
When this function is selected, the durations of the relevant programmes get shorter by 50%.
Thanks to the optimised washing steps, high mechanic activity and optimum water consumption,
high washing performance is achieved in spite of the reduced duration.
• Extra Rinse
This function enables the product to make another rinsing in addition to the one already made after
the main wash. Thus, the risk for sensitive skins (babies, allergic skins, etc.) to be effected by the
minimal detergent remnants on the laundry can be reduced.
• Drum Cleaning+
Press and hold the auxiliary function button 1 for 3 seconds to select the programme.Use regularly
(once in every 1-2 months) to clean the drum and provide the required hygiene.Steam is applied before
the programme to soften the residues in the drum.Operate the programme while the machine is
completely empty. To obtain better results, put powder lime-scale remover for washing machines into
the detergent compartment no. “2”. When the programme is over, leave the loading door ajar so that
the inside of the machine gets dry.
When you select this function, load your machine with half of the maximum laundry
specified in the programme table.
4.3.10.2 Functions/Programmes Selected by Pressing the Function Buttons for 3 Seconds
Child Lock is not deactivated after power failures or when the machine is unplugged.
In addition to the method above, to deactivate the Child Lock, switch the Programme Selection
knob to On / Off position when no programme is running, and select another programme.
• Child lock
Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid
any changes in a running programme.
• Anti-Crease
If you press and hold the auxiliary function button 3 for 3 seconds, this function will be selected
and the programme follow-up light of the relevant programme will turn on. When this function is
selected, the drum will rotate for up to eight hours to ensure that the clothes do not crease at
the end of the programme. At any time during these eight hours, you can cancel the programme
To activate the Child Lock:
2. Pres and hold the Auxiliary Function button for 3 seconds. C03, C02, C01 will appear on the display
respectively while you keep the button pressed for 3 seconds. Then, while the light of the Auxiliary
Function button 2 is flashing, "Con" will appear on the display indicating that the child lock has been
activated. If you press any button or turn the Programme Selection knob when the Child Lock is
active, same phrase will appear on the display.
To deactivate the Child Lock:
Press and hold the Auxiliary Function button 2 for 3 seconds while a programme is running. C03,
C02, C01 will appear on the display respectively while you keep the button pressed for 3 seconds.
Then, while the light of the auxiliary function button 2 is flashing, "COF" will appear on the display
indicating that the child lock has been deactivated.
EN17

Do not use liquid detergents when you set Delayed Start! There is the risk of staining of the clothes.
Additional laundry may be loaded during the delayed start period.
5. At the end of the countdown, duration of the selected programme will be displayed. “_” will
disappear and the selected programme will start.
Changing the delayed start period
If you want to change the time during countdown:
1. Press the Delayed Start button. Time will increase by 1 hour each time you press the button.
2. If you want to decrease the delayed start time, press Delayed Start button repeatedly until the
desired delayed start time appears on the display.
Canceling the Delayed Start function
If you want to cancel the delayed start countdown and start the programme immediately:
1. Set the Delayed Start period to zero or turn the Programme Selection knob to any programme.
Thus, Delayed Start function will be canceled. The End/Cancel light flashes continuously.
2. Then, select the programme you want to run again.
3. Press Start / Pause button to start the programme.
4.3.11 Delayed Start
and unload the machine. Just press any button or turn the programme selection knob to end the
function. The programme follow-up light will remain on even if you end the function by pressing
any button. If you end the function by turning the programme selection knob, the programme
follow-up light will remain on or go off depending on the selected programme. If you do not
cancel the function by pressing the Auxiliary Function button 3 for 3 seconds, it will be used in
the next washing cycles as well.
With the Delayed Start function the startup of the programme may be delayed up to 19 hours.
Delayed start time can be increased by increments of 1 hour.
4.3.12 Starting the programme
1. Press Start / Pause button to start the programme.
2. Programme follow-up light showing the startup of the programme will turn on.
4.3.13 Progress of programme
Progress of a running programme can be followed from the Programme Follow-up indicator. At
the beginning of every programme step, the relevant indicator light will turn on and light of the
completed step will turn off.
You can change the auxiliary functions, speed and temperature settings without stopping the
programme flow while the programme is running. To do this, the change you are going to make must
be in a step after the running programme step. If the change is not compatible, relevant lights will
flash for 3 times.
4.3.14 Loading door lock
There is a locking system on the loading door of the machine that prevents opening of the loading
door in cases when the water level is unsuitable.
Loading door light will start flashing when the machine is switched to Pause mode. Machine checks
the level of the water inside. If the level is suitable, Loading Door light illuminates steadily within 1-2
minutes and the loading door can be opened.
1. Open the loading door, place the laundry and put detergent, etc.
2. Select the washing programme, temperature, spin speed and, if required, the auxiliary functions.
3. Set the desired time by pressing the Delayed Start button.
4. Press Start / Pause button. The delayed start time you have set is displayed. Delayed start
countdown starts. “_” symbol next to the delayed start time moves up and down on the display.
If no programme is started or no button is pressed within 1 minute during programme selection process, the
machine will switch to Pause mode and the illumination level of the temperature, speed and loading door
indicator lights will decrease. Other indicator lights and indicators will turn off. Once the Programme Selection
knob is rotated or any button is pressed, indicator lights and indicators will turn on again.
If the machine does not pass to the spinning step, Rinse Hold function might be active or the automatic
unbalanced load detection system might be activated due to the unbalanced distribution of the laundry in the
machine.
EN18

4.3.15 Changing the selections after programme has started
Switching the machine to pause mode
Press the Start / Pause button to switch the machine to pause mode while a programme is running.
The light of the step which the machine is in starts flashing in the Programme Follow-up indicator to
show that the machine has been switched to the pause mode.
Also, when the loading door is ready to be opened, Loading Door light will also illuminate
continuously in addition to the programme step light.
Changing the auxiliary function, speed and temperature
Depending on the step the programme has reached, you can cancel or select the auxiliary functions.
See, "Auxiliary function selection".
You can also change the speed and temperature settings. See, "Spin speed selection" and
"Temperature selection".
Adding or taking out laundry
1. Press Start / Pause button to switch the machine to pause mode. The programme follow-up light
of the relevant step during which the machine was switched into the pause mode will flash.
2. Wait until the Loading Door can be opened.
3. Open the Loading Door and add or take out the laundry.
4. Close the Loading Door.
5. Make changes in auxiliary functions, temperature and speed settings if necessary.
6. Press Start / Pause button to start the machine.
4.3.16 Cancelling the programme
To cancel the programme, turn the Programme Selection knob to select another programme.
Previous programme will be cancelled. End / Cancel light will flash continuously to notify that the
programme has been canceled.
Your machine will end the programme when you turn the Programme Selection knob; however, it
does not drain the water inside. When you select and start a new programme, the newly selected
programme will start depending on the step the previous programme was canceled in. For example,
it may take in additional water or continue to wash with the water inside.
4.3.17 End of programme
“End” appears on the display at the end of the programme.
1. Wait until the loading door light illuminates steadily.
2. Press On / Off button to switch off the machine.
3. Take out your laundry and close the loading door. Your machine is ready for the next washing
cycle.
4.3.18 Your machine features "Standby Mode".
After you switch on your machine with On-Off button, if no programme is started or no other
procedure is performed at the selection step or no action is taken within approx. 2 minutes after
the selected programme ends, your machine will switch to energy saving mode automatically.
The brightness of the indicator lights will decrease. Also, if your product has a display that shows
programme time, this display will be completely turned off. If you turn the Programme Selection
knob or touch any button, lights and display will switch back to previous condition. The selections
which you make when exiting from the energy efficiency may change. Please check the correctness
of your selections before starting the programme. If necessary, please make your settings again. This
is not an error.
If the level is unsuitable, Loading Door light turns off and the loading door cannot be opened. If you
are obliged to open the Loading Door while the Loading Door light is off, you must cancel the current
programme. See. "Cancelling the programme"
If no change is allowed, the relevant light will flash 3 times.
Depending on the step where the programme was canceled in, you may have to put
detergent and softener again for the programme you have selected anew.
EN19
