Washing Machine
User’s Manual
WMY 71033 PTLMB3
EN ET BG UK

This product was manufactured using the latest technology in environmentally friendly conditions.

3/ EN Washing Machine / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal injury
or property damage. Failure to follow these instructions shall void any warranty.
1.1 General safety
• This product can be used by children at and above 8 years old and by persons whose
physical, sensory or mental capabilities were not fully developed or who lack expe-
rience and knowledge provided that they are supervised or trained on the safe usage
of the product and the risks it brings out. Children must not play with the product.
Cleaning and maintenance works should not be performed by children unless they
are supervised by someone. Children of less than 3 years should be kept away unless
continuously supervised.
• Never place the product on a carpet-covered floor. Otherwise, lack of airflow beneath
the machine will cause electrical parts to overheat. This will cause problems with your
product.
• If the product has a failure, it should not be operated unless it is repaired by the
Authorized Service Agent. There is the risk of electric shock!
• This product is designed to resume operating in the event of powering on after a
power interruption. If you wish to cancel the programme, see "Cancelling the pro-
gramme" section.
• Connect the product to a grounded outlet protected by a 16 A fuse. Do not neglect to
have the grounding installation made by a qualified electrician. Our company shall not
be liable for any damages that will arise when the product is used without grounding
in accordance with the local regulations.
• The water supply and draining hoses must be securely fastened and remain undama-
ged. Otherwise, there is the risk of water leakage.
• Never open the loading door or remove the filter while there is still water in the drum.
Otherwise, risk of flooding and injury from hot water will occur.
• Do not force open the locked loading door. The loading door will be ready to open just
a few minutes after the washing cycle comes to an end. In case of forcing the loading
door to open, the door and the lock mechanism may get damaged.
• Unplug the product when not in use.
• Never wash the product by spreading or pouring water onto it! There is the risk of
electric shock!
• Never touch the plug with wet hands! Never unplug by pulling on the cable, always
pull out by grabbing the plug.
• Use detergents, softeners and supplements suitable for automatic washing machines
only.
• Follow the instructions on the textile tags and on the detergent package.
• The product must be unplugged during installation, maintenance, cleaning and repai-
ring procedures.
• Always have the installation and repairing procedures carried out by the Authorized
Service Agent. Manufacturer shall not be held liable for damages that may arise from
procedures carried out by unauthorized persons.

4/ EN Washing Machine / User’s Manual
• If the power cable is damaged, it must be replaced by the manufacturer, after sales
service or a similarly qualified person (preferably an electrician) or someone designa-
ted by the importer in order to avoid possible risks.
• Place the product on a rigid, flat and level surface.
• Do not place it on a long-pile rug or similar surfaces.
• Do not place the product on a high platform or near the edge on a cascaded surface.
• Do not place the product on the power cable.
• Never use sponge or scrub materials. These will damage the painted, chrome plated
and plastic surfaces.
1.2 Intended use
• This product has been designed for domestic use. It is not suitable for commercial
use and it must not be used out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transporta-
tion.
1.3 Children's safety
• Packaging materials are dangerous to children. Keep packaging materials in a safe
place away from reach of the children.
• Electrical products are dangerous for the children. Keep children away from the pro-
duct when it is in use. Do not let them to tamper with the product. Use child lock to
prevent children from intervening with the product.
• Do not forget to close the loading door when leaving the room where the product is
located.
• Store all detergents and additives in a safe place away from the reach of the children
by closing the cover of the detergent container or sealing the detergent package.
While washing the laundry at high temperatures, the loading door glass
becomes hot. Therefore, keep especially the children away from the
loading door of the machine while the washing operation is in progress.
1.4 Package information
• Packaging materials of the product are manufactured from recyclable materials in ac-
cordance with our National Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.
1.5 Disposing of the waste product
• This product has been manufactured with high quality parts and materials which can
be reused and are suitable for recycling. Therefore, do not dispose the product with
normal domestic waste at the end of its service life. Take it to a collection point for the
recycling of electrical and electronic equipment. Please consult your local authorities
to learn the nearest collection point. Help protect the environment and natural resour-
ces by recycling used products. For children's safety, cut the power cable and break
the locking mechanism of the loading door so that it will be non-functional before dis-
posing of the product.

5/ EN Washing Machine / User’s Manual
1.6 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Do not dispose of the
waste product with normal domestic and other wastes at the end of its servi-
ce life. Take it to the collection center for the recycling of electrical and elec-
tronic equipment. Please consult your local authorities to learn about these
collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited materials specified in the Directive.
2 Installation
Refer to the nearest Authorised Service Agent for installation
of the product. To make the product ready for use, review
the information in the user manual and make sure that the
electricity, tap water supply and water drainage systems are
appropriate before calling the Authorized Service Agent. If
they are not, call a qualified technician and plumber to have
any necessary arrangements carried out.
CPreparation of the location and electrical, tap water and
waste water installations at the place of installation is
under customer's responsibility.
Make sure that the water inlet and discharge hoses
as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after
installation or cleaning procedures.
BWARNING: Installation and electrical connections
of the product must be carried out by the Authorized
Service Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried out by
unauthorized persons.
AWARNING: Prior to installation, visually check if
the product has any defects on it. If so, do not have it
installed. Damaged products cause risks for your safety.
2.1 Appropriate installation location
• Place the machine on a rigid floor. Do not place it on a
long pile rug or similar surfaces.
• Total weight of the washing machine and the dryer -with
full load- when they are placed on top of each other
reaches to approx. 180 kilograms. Place the product
on a solid and flat floor that has sufficient load carrying
capacity!
• Do not place the product on the power cable.
• Do not install the product at places where temperature
may fall below 0ºC.
• Place the product at least 1 cm away from the edges of
other furniture.
2.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging
reinforcement. Remove the packaging reinforcement by
pulling the ribbon.
2.3 Removing the transportation locks
AWARNING: Do not remove the transportation locks
before taking out the packaging reinforcement.
WARNING: Remove the transportation safety bolts
before operating the washing machine! Otherwise, the
product will be damaged.
1. Loosen all the bolts with a suitable spanner until they
rotate freely (C).
2. Remove transportation safety bolts by turning them
gently.

6/ EN Washing Machine / User’s Manual
3. Attach the plastic covers supplied in the User Manual bag
into the holes on the rear panel. (P)
CKeep the transportation safety bolts in a safe place to
reuse when the washing machine needs to be moved
again in the future.
Never move the product without the transportation safety
bolts properly fixed in place!
2.4 Connecting water supply
CThe water supply pressure required to run the product is
between 1 to 10 bars (0.1 – 1 MPa). It is necessary to
have 10 – 80 liters of water flowing from the fully open
tap in one minute to have your machine run smoothly.
Attach a pressure reducing valve if water pressure is
higher.
If you are going to use the double water-inlet product
as a single (cold) water-inlet unit, you must install the
supplied stopper to the hot water valve before operating
the product. (Applies for the products supplied with a
blind stopper group.)
AWARNING: Models with a single water inlet should not
be connected to the hot water tap. In such a case the
laundry will get damaged or the product will switch to
protection mode and will not operate.
WARNING: Do not use old or used water inlet hoses
on the new product. It may cause stains on your laundry.
1. Connect the special hoses supplied with the product to
the water inlets on the product. Red hose (left) (max. 90
ºC) is for hot water inlet, blue hose (right) (max. 25 ºC) is
for cold water inlet.
AWARNING: Ensure that the cold and hot water
connections are made correctly when installing the
product. Otherwise, your laundry will come out hot at the
end of the washing process and wear out.
2. Tighten all hose nuts by hand. Never use a tool when
tightening the nuts.
3. Open the taps completely after making the hose
connection to check for water leaks at the connection
points. If any leaks occur, turn off the tap and remove the
nut. Retighten the nut carefully after checking the seal. To
prevent water leakages and damages caused by them,
keep the taps closed when the machine is not in use.
2.5 Connecting to the drain
• The end of the drain hose must be directly connected to
the wastewater drain or to the washbasin.
AWARNING: Your house will be flooded if the hose
comes out of its housing during water discharge.
Moreover, there is risk of scalding due to high washing
temperatures! To prevent such situations and to ensure
smooth water intake and discharge of the machine, fix
the end of the discharge hose tightly so that it cannot
come out.
• The hose should be attached to a height of at least 40
cm, and 100 cm at most.
• In case the hose is elevated after laying it on the floor
level or close to the ground (less than 40 cm above the
ground), water discharge becomes more difficult and the
laundry may come out excessively wet. Therefore, follow
the heights described in the figure.
100cm
40cm
• To prevent flowing of dirty water back into the machine
and to allow for easy discharge, do not immerse the hose
end into the dirty water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be bent, it should not be
stepped on and the hose must not be pinched between
the drain and the machine.
• If the length of the hose is too short, use it by adding
an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures,
the connection between the extension hose and the
drain hose of the product must be fitted well with an
appropriate clamp as not to come off and leak.
2.6 Adjusting the feet
AWARNING: In order to ensure that the product
operates more silently and vibration-free, it must stand
level and balanced on its feet. Balance the machine
by adjusting the feet. Otherwise, the product may
move from its place and cause crushing and vibration
problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level and
balanced.
3. Tighten all lock nuts again by hand.

7/ EN Washing Machine / User’s Manual
AWARNING: Do not use any tools to loosen the lock
nuts. Otherwise, they will get damaged.
2.7 Electrical connection
Connect the product to a grounded outlet protected by a 16
A fuse. Our company shall not be liable for any damages
that will arise when the product is used without grounding in
accordance with the local regulations.
• Connection must comply with national regulations.
• Power cable plug must be within easy reach after
installation.
• If the current value of the fuse or breaker in the house is
less than 16 Amps, have a qualified electrician install a
16 Amp fuse.
• The voltage specified in the "Technical specifications"
section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-
plugs.
BWARNING: Damaged power cables must be
replaced by the Authorized Service Agents.
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water supply connections.
3. Drain all water that has remained in the product.
4. Install transportation safety bolts in the reverse order of
removal procedure;
CNever move the product without the transportation
safety bolts properly fixed in place!
AWARNING: Packaging materials are dangerous to
children. Keep packaging materials in a safe place
away from reach of the children.
• Tough stains must be treated properly before washing. If
unsure, check with a dry cleaner.
• Use only dyes/colour changers and limescale removers
suitable for machine wash. Always follow the instructions
on the package.
• Wash trousers and delicate laundry turned inside out.
• Keep laundry items made of Angora wool in the freezer
for a few hours before washing. This will reduce pilling.
• Laundry that are subjected to materials such as flour,
lime dust, milk powder, etc. intensely must be shaken off
before placing into the machine. Such dusts and powders
on the laundry may build up on the inner parts of the
machine in time and can cause damage.
3.3 Things to be done for energy saving
Following information will help you use the product in an
ecological and energy-efficient manner.
• Operate the product in the highest capacity allowed by
the programme you have selected, but do not overload;
see, "Programme and consumption table".
• Always follow the instructions on the detergent
packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly
soiled laundry.
• Do not use prewash and high temperatures for laundry
that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the
highest spin speed recommended during washing
process.
• Do not use detergent in excess of the amount
recommended on the detergent package.
3.4 Initial use
Before starting to use the product, make sure that all
preparations are made in accordance with the instructions in
sections “Important safety instructions” and “Installation”.
To prepare the product for washing laundry, perform first
operation in Drum Cleaning programme. If your product
is not equipped with Drum Cleaning programme, perform
the Initial Use procedure in accordance with the methods
described under “5.2 Cleaning the loading door and the
drum” section of the user manual.
CUse an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to
the quality control processes in the production. It is not
harmful for the product.
3.5 Correct load capacity
The maximum load capacity depends on the type of laundry,
the degree of soiling and the washing programme desired.
The machine automatically adjusts the amount of water
according to the weight of the loaded laundry.
3 Preparation
3.1 Sorting the laundry
• Sort laundry according to type of fabric, colour, and
degree of soiling and allowable water temperature.
• Always obey the instructions given on the garment tags.
3.2 Preparing laundry for washing
• Laundry items with metal attachments such as,
underwired bras, belt buckles or metal buttons will
damage the machine. Remove the metal pieces or wash
the clothes by putting them in a laundry bag or pillow
case.
• Take out all substances in the pockets such as coins,
pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause
noise problem.
• Put small size clothes such as infant's socks and nylon
stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove
curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and
tears.
• Wash “machine washable” or “hand washable” labeled
products only with an appropriate programme.
• Do not wash colours and whites together. New, dark
coloured cottons release a lot of dye. Wash them
separately.

8/ EN Washing Machine / User’s Manual
• When washing dark coloured clothes and quilts, it is
recommended to use liquid detergent.
• Wash woolens with special detergent made specifically
for woolens.
Awarning: Use only detergents manufactured specifically
for washing machines.
warning: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used depends
on the amount of laundry, the degree of soiling and water
hardness.
• Do not use amounts exceeding the dosage quantities
recommended on the detergent package to avoid
problems of excessive foam, poor rinsing, financial
savings and finally, environmental protection.
• Use lesser detergent for small amounts or lightly soiled
clothes.
Using softeners
Pour the softener into the softener compartment of the
detergent drawer.
• Do not exceed the (>max<) level marking in the softener
compartment.
• If the softener has lost its fluidity, dilute it with water
before putting it in the detergent drawer.
Using liquid detergents
If the product contains a liquid detergent cup:
• Make sure that you have placed the liquid detergent cup
in compartment nr. "2".
• If the liquid detergent has lost its fluidity, dilute it with
water before putting in the detergent cup.
Clothes
Light colours and whites
(Recommended temperature range based
on soiling level: 40-90 °C)
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits and
blood.)
It may be necessary to pre-treat the stains
or perform prewash. Powder and liquid
detergents recommended for whites can be
used at dosages recommended for heavily
soiled clothes. It is recommended to use
powder detergents to clean clay and soil
stains and the stains that are sensitive to
bleaches.
Normally Soiled
(For example,
stains caused by
body on collars
and cuffs)
Powder and liquid detergents recommended
for whites can be used at dosages
recommended for normally soiled clothes.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid detergents recommended
for whites can be used at dosages
recommended for lightly soiled clothes.
Awarning: Follow the information in the “Programme
and consumption table”. When overloaded, machine's
washing performance will drop. Moreover, noise and
vibration problems may occur.
3.6 Loading the laundry
1. Open the loading door.
2. Place laundry items loosely into the machine.
3. Push the loading door to close until you hear a locking
sound. Ensure that no items are caught in the door.
CThe loading door is locked while a programme is running.
The door can only be opened a while after the programme
comes to an end.
Awarning: In case of misplacing the laundry, noise and
vibration problems may occur in the machine.
3.7 Using detergent and softener
CWhen using detergent, softener, starch, fabric dye, bleach
or limescale remover read the manufacturer's instructions
on the package carefully and follow the suggested dosage
values. Use measuring cup if available.
Detergent Drawer
The detergent drawer is composed of three compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– (*) in addition, there is siphon piece in the softener
compartment.
1
3
2
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing
programme.
• Never leave the detergent drawer open while the washing
programme is running!
• When using a programme without prewash, do not
put any detergent into the prewash compartment
(compartment nr. "1").
• In a programme with prewash, do not put liquid detergent
into the prewash compartment (compartment nr. "1").
• Do not select a programme with prewash if you are using
a detergent bag or dispensing ball. Place the detergent
bag or the dispensing ball directly among the laundry in
the machine.
• If you are using liquid detergent, do not forget to place
the liquid detergent cup into the main wash compartment
(compartment nr. "2").
Choosing the detergent type
The type of detergent to be used depends on the type and
colour of the fabric.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents
(liquid detergent, wool shampoo, etc.) used solely for
delicate clothes.

9/ EN Washing Machine / User’s Manual
Clothes
Colours
(Recommended temperature range based
on soiling level: cold -40 °C)
Soiling Level
Heavily Soiled
Powder and liquid detergents recommended
for colours can be used at dosages
recommended for heavily soiled clothes. It is
recommended to use powder detergents to
clean clay and soil stains and the stains that
are sensitive to bleaches. Use detergents
without bleach.
Normally Soiled
Powder and liquid detergents recommended
for colours can be used at dosages
recommended for normally soiled clothes.
Use detergents without bleach.
Lightly Soiled
Powder and liquid detergents recommended
for colours can be used at dosages
recommended for lightly soiled clothes. Use
detergents without bleach.
Dark colours
(Recommended temperature range based
on soiling level: cold -40 °C)
Soiling Level
Heavily Soiled Liquid detergents suitable for colours and dark colours can be used at dosages
recommended for heavily soiled clothes.
Normally Soiled Liquid detergents suitable for colours and dark colours can be used at dosages
recommended for normally soiled clothes.
Lightly Soiled Liquid detergents suitable for colours and dark colours can be used at dosages
recommended for lightly soiled clothes.
Delicates/Woollens/Silks
(Recommended temperature range based
on soiling level: cold -30 °C)
Soiling Level
Heavily Soiled
Prefer liquid detergents produced for
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
Normally Soiled
Prefer liquid detergents produced for
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
Lightly Soiled
Prefer liquid detergents produced for
delicate clothes. Woollen and silk clothes
must be washed with special woollen
detergents.
If the product does not contain a liquid detergent
cup:
• Do not use liquid detergent for the prewash in a
programme with prewash.
• Liquid detergent stains your clothes when used with
Delayed Start function. If you are going to use the Delayed
Start function, do not use liquid detergent.
Using gel and tablet detergent
Apply the following instructions when using tablet, gel and
similar detergents.
• If the gel detergent thickness is fluidal and your machine
does not contain a special liquid detergent cup, put the
gel detergent into the main wash detergent compartment
during first water intake. If your machine contains a liquid
detergent cup, fill the detergent into this cup before
starting the programme.
• If the gel detergent thickness is not fluidal or in the shape
of capsule liquid tablet, put it directly into the drum before
washing.
• Put tablet detergents into the main wash compartment
(compartment nr. "2") or directly into the drum before
washing.
CTablet detergents may leave residues in the detergent
compartment. If you encounter such a case, place the
tablet detergent between the laundry, close to the lower
part of the drum in future washings.
Use the tablet or gel detergent without selecting the
prewash function.
Using starch
• Add liquid starch, powder starch or the fabric dye into the
softener compartment.
• Do not use softener and starch together in a washing
cycle.
• Wipe the inside of the machine with a damp and clean
cloth after using starch.
Using bleaches
• Select a programme with prewash and add the bleaching
agent at the beginning of the prewash. Do not put
detergent in the prewash compartment. As an alternative
application, select a programme with extra rinse and add
the bleaching agent while the machine is taking water
from the detergent compartment during first rinsing step.
• Do not use bleaching agent and detergent by mixing
them.
• Use just a little amount (approx. 50 ml) of bleaching agent
and rinse the clothes very well as it causes skin irritation.
Do not pour the bleaching agent onto the clothes and do
not use it for coloured clothes.
• When using oxygen based bleaches, select a programme
that washes at a lower temperature.
• Oxygen based bleaches can be used together with
detergents; however, if its thickness is not the same
with the detergent, put the detergent first into the
compartment nr. "2" in the detergent drawer and wait
until the detergent flows while the machine is taking
in water. Add the bleaching agent from the same
compartment while the machine is still taking in water.
Using limescale remover
• When required, use limescale removers manufactured
specifically for washing machines only.

10 / EN Washing Machine / User’s Manual
4 Operating the product
4.1 Control panel
1 - Programme Selection knob (Uppermost position On / Off)
2 - Display
3 - Delayed Start Indicator
4 - Programme Follow-up indicator
5 - Start / Pause button
6 - Auxiliary Function buttons
7 - Spin Speed Adjustment button
8 - Temperature Adjustment button
1 2 3
4
5678
4.2 Preparing the machine
1.Make sure that the hoses are connected tightly.
2.Plug in your machine.
3.Turn the tap on completely.
4.Place the laundry in the machine.
5.Add detergent and fabric softener.
4.3 Programme selection and tips for efficient
washing
1. Select the programme suitable for the type, quantity
and soiling degree of the laundry in accordance with
the "Programme and consumption table" and the
temperature table below.
2.Select the desired programme with the Programme
Selection button.
4.4 Main programmes
Depending on the type of fabric, use the following main
programmes.
• Cottons
Use this programme for your cotton laundry (such as bed
sheets, duvet and pillowcase sets, towels, bathrobes,
underwear, etc.). Your laundry will be washed with vigorous
washing action for a longer washing cycle.
• Synthetics
Use this programme to wash your synthetic clothes (shirts,
blouses, synthetic/cotton blends, etc.). It washes with a
gentle action and has a shorter washing cycle compared to
the Cotton programme.
For curtains and tulle, use the Synthetic 40°C programme
with prewash and anti-creasing functions selected. As their
meshed texture causes excessive foaming, wash the veils/
tulle by putting little amount of detergent into the main
wash compartment. Do not put detergent in the prewash
compartment.
• Woollens
Use this programme to wash your woolen clothes. Select
the appropriate temperature complying with the tags of your
clothes. Use appropriate detergents for woollens.
“The wool wash cycle of this machine has been
approved by The Woolmark Company for the washing
of machine washable wool products provided that the
products are washed according to the instructions
on the garment label and those issued by the
manufacturer of this washing machine. M1425”
“In UK, Eire, Hong Kong and India the Woolmark trade
mark is a Certification trade mark.”
4.5 Additional programmes
For special cases, additional programmes are available in
the machine.
CAdditional programmes may differ according to the model
of the machine.
• Cotton Economic
By washing normally soiled cotton and linen laundry
in this programme, you can ensure higher energy and
water efficiency than other cotton programmes do. Actual
water temperature may be different from the stated wash
temperature. While doing the laundry at lesser amounts (e.g.
half capacity or less) duration of the program may reduce
automatically at the later stages of the program. In this
case, energy and water consumption will reduce for a more
economic wash. This feature is provided in the models with
the remaining time indicator.
• BabyProtect
This is a long lasting programme which you may use for
your laundry for which you require an anti-allergic and
hygienic washing at high temperature with intensive and
long washing cycle.
