Beko WTV9716XWWST User manual

Washing Machine
User Manual
WTV9716XWWST
2820530185_EN/ 26-05-22.(16:41)
Document Number :

2 / EN Washing Machine / User’s Manual
1 General safety instructions
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 Life and property safety
uNever place the product on a carpet-covered floor. Otherwise, lack of airflow
beneath the machine will cause electrical parts to overheat. This will cause
problems with your product.
uUnplug the product if it is not in use.
u
Always have the installation and repairing procedures carried out by the
Authorised Service Agent. The manufacturer shall not be held liable for
damages that may arise from procedures carried out by unauthorised persons.
uThe water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, there is the risk of water leakage.
u
While there is still water inside the product, never open the loading door or
remove the filter. Otherwise, risk of flooding and injury from hot water will occur.
uDo not force open the locked loading door. The door will open immediately
after the washing cycle has ended. If the door does not open, apply the
solutions provided for "Loading door cannot be opened." error in the
Troubleshooting section. In case of forcing the loading door to open, the
door and the lock mechanism may get damaged.
uUse detergents, softeners and supplements suitable for automatic washing
machines only.
u
Follow the instructions on the label of textile products and the detergent package.
u
The water supply pressure required to run the product is between 1 to 10 bars
(0.1 – 1 MPa).
u
Do not use old or used water inlet hoses on the new product. It may cause stains
on your laundry.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN Washing Machine / User’s Manual
1.2 Children's safety
u
This product can be used by children at and above 8 years old and by persons
whose physical, sensory or mental capabilities were not fully developed or
who lack experience and knowledge provided that they are supervised or
trained on the safe usage of the product and the risks it brings out. Children
should not play with the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by someone. Children
under the age of 3 should be kept away unless continuously supervised.
uPackaging materials are dangerous for the children. Keep packaging
materials in a safe place away from reach of the children.
uElectrical products are dangerous for the children. Keep children away from
the product when it is in use. Do not allow them to play with the product.
Use child lock to prevent children from intervening with the product.
uDo not forget to close the loading door when leaving the room where the
product is located.
uStore all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
1.3 Electrical safety
uIf the product has a failure, it should not be operated unless it is repaired by
the Authorised Service Agent! There is the risk of electric shock!
uThis product is designed to resume operating in the event of powering
on after a power interruption. If you wish to cancel the programme, see
"Cancelling the programme" section.
uPlug the product into a grounded outlet protected by a 16 A fuse. Do not
neglect to have the grounding installation made by a qualified electrician.
Our company shall not be liable for any damages that will arise when the
product is used without grounding in accordance with the local regulations.
uDo not wash the product by spraying or pouring water onto it! There is the
risk of electric shock!

4 / EN Washing Machine / User’s Manual
uNever touch the power cable plug with wet hands! Never unplug by pulling
on the cable. Always press on the plug with one hand and pull out the plug
by grabbing with the other hand.
uProduct should be unplugged during installation, maintenance, cleaning
and repair procedures.
u
If the power cable is damaged, it must be replaced by the manufacturer,
authorised service or a similarly qualified person (preferably an electrician)
or someone designated by the importer in order to avoid possible risks.
1.4 Hot surface safety
The glass of the loading door gets too hot while
washing at higher temperatures. Therefore,
especially do not allow children touch the
loading door glass while washing.

5 / EN Washing Machine / User’s Manual
2Important instructions for environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which can be
reused and are suitable for recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take it to the collection center for the
recycling of electrical and electronic equipment. Please consult your local authorities to learn
about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful
and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance with our
National Environment Regulations. Do not dispose of the packaging materials together with the domestic or
other wastes. Take them to the packaging material collection points designated by the local authorities.
3 Intended use
• This product has been designed for domestic use. It is not for commercial purposes or it should not be used
out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transportation.
• The service life of your product is 10 years. During this period, original spare parts will be available to
operate the appliance properly.
• This appliance is intended to be used in household and similar applications such as:
– staff kitchen areas in shops, offices and other working environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of flats or in launderettes.

6 / EN Washing Machine / User’s Manual
4Technical specifications
AWARNING: Consumption values are applicable for cases where the wireless network connection is off.
C
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
The model information as stored in the product database can be reached by
entering following website and searching for your model identifier (*) found
on energy label.
https://eprel.ec.europa.eu/
Supplier name or trademark Beko
Model name WTV9716XWWST
7158145300
Rated capacity (kg) 9
Maximum spin speed (rpm) 1400
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 64
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 138
Rinse Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying

7 / EN Washing Machine / User’s Manual
4.1 Installation
C
Your washing machine automatically detects the amount of laundry placed inside when selecting a program.
While installing the product, before the first use, calibration should be done to ensure that the laundry amount is detected in the
most accurate way.
To do this, select the Drum Cleaning* program and cancel the spin function. Start the program without laundry. Wait for the
program to finish, which will take about 15 minutes.
*The program name may vary depending on the model. For the appropriate program selection, review the program descriptions section.
• Apply to the nearest authorised service agent for the installation of your product.
• Preparation of the location and electrical, tap water and waste water installations at the place of installation
is under customer's responsibility.
• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after installation or cleaning procedures.
• Make sure that the installation and electrical connections of the product are performed by authorised
service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by
unauthorised persons.
• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar
surfaces.
• When the washing machine and dryer are placed on top of each other, their total weight –when loaded–
amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying
capacity!
• Do not place the product on the power cable.
• Do not install the product in the environments where the temperature falls below 0 ºC.
• Leaving a gap at the sides of the machine is suggested to reduce vibration and noise
• On a graduated floor, do not place the product next to the edge or on a platform.
• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them
on the product.
4.1.2 Removing packaging reinforcement (If the product has)
Tilt the machine backwards to remove the packaging reinforcement.
Remove the packaging reinforcement by pulling the ribbon. Do not make
this operation alone by yourself.
4.1.3 Removing the transportation locks
1 Loosen all bolts with an appropriate wrench until they turn freely.
2 Remove the transport safety bolts by turning them slightly.
3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.

8 / EN Washing Machine / User’s Manual
ACAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be
damaged.
CKeep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the
future.
Install the transport safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!
4.1.4 Connecting water supply
C
It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run
smoothly. Attach a pressure reducing valve if water pressure is higher.
ACAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will
get damaged or the product will switch to protection mode and will not operate.
1 Tighten the nuts of the hose by hand. Never use a tool when
tightening the nuts.
2 When hose connection is completed, check whether there is leak
problems at the connection points by opening the taps fully. If any
leaks occur, turn off the tap and remove the nut. Retighten the nut
carefully after checking the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed when you do not use
the product.
4.1.5 Connecting the drain hose to the drain
• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.
ACAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine
performs water intake and discharge processes without any problem, fix the drain hose securely.
40 cm
100 cm
• Connect the drain hose to a minimum height of 40 cm
and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on the
floor level or close to the ground (less than 40 cm above
the ground), water discharge becomes more difficult and
the laundry may come out excessively wet. Therefore,
follow the heights described in the figure.
• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, use it by adding an original extension hose. The overall length of the
hose shall not be longer than 3.2 m. To avoid water leak failures, the connection between the extension
hose and the drain hose of the product must be fitted well with an appropriate clamp as not to come off
and leak.

9 / EN Washing Machine / User’s Manual
4.1.6 Adjusting the feet
ACAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced
on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing
and vibration problems.
CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands in a stable and balanced way.
3. Tighten all lock nuts by hand again.
4.1.7 Electrical connection
Connect the product to a grounded outlet protected by a 16 A fuse. The Manufacturer shall not be liable for any
damages that will arise when the product is used without grounding in accordance with the local regulations.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. Use of a
Groud Fault Circuit Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician
install a 16 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs.
BCAUTION: Damaged power cables must be replaced by the Authorised Service Agents.
4.1.8 Initial use
Before starting to use the product make sure that the preparations are
made which are in line with the “Important Safety and Environment
Instructions” and the instructions in the “Installation” section.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
machine, apply the method which is described in the section 4.4.2.
CUse an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to the quality control processes in the production. It is not harmful for
the product.

10 / EN Washing Machine / User’s Manual
4.2 Preparation
4.2.1 Sorting the laundry
• Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature.
• Always observe the instructions given on the garment care labels.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the
machine. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “Machine washable” or “Hand washable” labelled products only with an appropriate programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them
separately.
• Tough stains must be treated properly before washing.
• Only use the dyes / colour changers and descaling agents which are appropriate for machine wash. Always
follow the instructions on the package.
• Wash trousers and delicate laundry turned inside out.
• Keep laundry items made of Angora wool in a plastic bag in the freezer for a few hours before washing.
This can reduce piling.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken
off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts
of the product in time and can cause damage.
4.2.3 Tips for energy and water saving
Following information will help you use the product in an ecological and energy/water-efficient manner.
• Operate the product in the highest load capacity allowed for the programme you have selected, but do not
overload. See, "Programme and consumption table".
• Observe the temperature instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing
process.
• Do not use more detergent than the recommended on the detergent packaging.
4.2.4 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the product in a loose manner.
3 Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.
The loading door is locked while a programme is running. The door lock will open immediately after the
washing programme has ended. Then you can open the loading door. If the door does not open, apply the
solutions provided for "Loading door cannot be opened." error in the Troubleshooting section.
4.2.5 Correct load capacity
The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing
programme.
The machine automatically adjusts the water amount according to the weight of the laundry put inside it.
AWARNING: Comply with the information in the section "Programme and consumption table". When overloaded,
product's washing performance will drop. Moreover, noise and vibration problems may occur.

11 / EN Washing Machine / User’s Manual
4.2.6 Using detergent and softener
C
When using detergent, softener, starch, fabric dye, bleach and descaling agents; read the manufacturer's instructions written
on the package and follow the dosages specified. Use measuring cup if available.
1
3
2
The detergent drawer is composed of three compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there is a siphon piece in the softener compartment.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing programme.
• While the washing cycle is in progress, do not leave the detergent drawer open!
• When using a programme without prewash, do not put any detergent into the prewash compartment
(compartment no. "1").
• If you are using a program with prewash, start the machine after adding powder detergent to the prewash and
main wash compartments (compartments 1 and 2).
• Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place the
detergent bag or the dispensing ball directly among the laundry in the product.
• If you are using liquid detergent, do not forget to place the liquid detergent container into the main wash
compartment (compartment no. “2”).
Choosing the detergent type
Detergent type to be used depends on the washing programme, fabric type and colour.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) intended
solely for delicate clothes and at suggested programmes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woollens at suggested programme with special detergent made specifically for woollens
• Please review the programme descriptions part for suggested programme for different textiles.
• All recommendations about detergents are valid for selectable temperature range of programmes.
AWARNING: Use only detergents manufactured specifically for washing machines.
WARNING: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and
water hardness.
• Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid
problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.
• Use less detergent for small loads, lightly soiled clothes and short duration programmes, especially in soft
water areas.
Using softeners
Pour the softener into the softener compartment of the detergent drawer.
• Do not exceed the (>max<) level sign on the softener compartment.
• If the softener has lost its fluidity, dilute it with water before adding it in the detergent compartment.
AWARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing
machines to soften the clothes.
Using liquid detergents
If the product contains a liquid detergent cup:
• Put the liquid detergent container into the compartment no “2”.
• If the liquid detergent lost its fluidity, dilute it with water before putting it into the detergent container.

12 / EN Washing Machine / User’s Manual
2
2
If the product is equipped with a liquid detergent part:
• When you want to use liquid detergent, press on the point shown to rotate the apparatus. The part that falls
off will function as a barrier for the liquid detergent. If required, clean the apparatus with water when it is
in place or by removing it. If you will use powder detergent, the apparatus must be secured at top position.
The fan that you would see in this position will mix the powder detergent and help it to dissolve.
If the product does not contain a liquid detergent cup:
• Do not use liquid detergent for the prewash in a programme with prewash.
• Liquid detergent stains your clothes when used with "End Time" function that delays start time. If you are
going to use the End Time function, do not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and your product does not contain a special liquid detergent container,
put the gel detergent into the main wash detergent compartment during first water intake. If your product
contains a liquid detergent container, fill the detergent into this container before starting the programme.
• If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly into the
drum before washing.
• Put tablet detergents into the main wash compartment (compartment no. "2") or directly into the drum
before washing.
Using starch
• Add liquid starch, powder starch or the dyestuff into the softener compartment.
• Do not use softener and starch together in a washing cycle.
• Wipe the inside of the product with a damp and clean cloth after using starch.
Using limescale remover
• When required, use limescale removers manufactured specifically for washing machines only.
Using bleaches
• Select a programme with prewash and add the bleach at the beginning of the prewash. Do not put detergent
in the prewash compartment. As an alternative application, select a programme with extra rinse and add the
bleach while the product is taking water from the detergent compartment during first rinsing step.
• Do not use bleach and detergent by mixing them.
• Use just a little amount (approx. 50 ml) of bleach and rinse the clothes very well as it causes skin irritation.
• Do not pour the bleach onto the laundry.
• Do not use it with the coloured items.
• When using an oxygen-based bleach, select a programme which washes the laundry at a low temperature.
• Oxygen-based bleach can be used together with the detergent. However, if its thickness is not the same
with the detergent, put the detergent first into the compartment no. "2" in the detergent drawer and wait
until the detergent flows while the product is taking in water. While the product continues taking in water,
add bleach in the same compartment.

13 / EN Washing Machine / User’s Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woollens/Silks
(Recommended temperature
range based on soiling level:
40-90°C)
(Recommended temperature
range based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold -40°C)
(Recommended
temperature range
based on soiling level:
cold-30°C)
Soiling Level
Heavily Soiled
(difficult stains such
as grass, coffee, fruits
and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colours can be used at
dosages recommended for
heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches.
Detergents which do not
contain bleach should be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
Normally Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for lightly soiled
clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
4.2.8 Displayed Programme Time
You can see the programme duration on the display of your machine while selecting a programme.
Depending on the amount of laundry you have loaded into your machine, foaming, unbalanced load
conditions, fluctuations in power supply, water pressure and programme settings, the programme duration is
automatically adjusted while the programme is running.
SPECIAL CASE: At programme start of Cottons and Cotton Eco programmes, display shows the duration of half
load, which is the most common use case. After programme starts, in 20-25 minutes actual load is detected by
the machine. And if the detected load is higher than half load; washing programme will be adjusted accordingly
and programme duration increased automatically. You may follow this change on the display.

14 / EN Washing Machine / User’s Manual
4.3 Operating the product
APlease read the “Safety Instructions” section first!
4.3.1 Control panel
4.3.2 Display symbols
1200
1000
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a- Temperature indicator
b- Spin speed indicator
c- Duration information
d - Door lock is engaged symbol
e- Programme follow-up indicator
f- No Water indicator
g - Add Garment indicator
h- Bluetooth Connection indicator
i- Remote Control indicator
j - Delayed Start Enabled indicator
k - Auxiliary Function indicators 3
l- Child Lock is Engaged symbol
m- Auxiliary Function indicators 2
n- Auxiliary Function indicators 1
o- No Spin Indicator
p- Rinse Hold Indicator
r- Cold Water indicator
CThe visuals used for machine description in this section are schematic and may not match exactly with the features of your
machine.
1 2 3 4
79 8101112 6 5
1 - Programme Selection knob
2 - Temperature level lights
3 - Spin level indicator lights
4 - Display
5 - Start / Pause button
6 - Remote Control button.
7 - End Time Setting button
8 - Auxiliary Function button 3
9 - Auxiliary Function button 2
10 - Auxiliary Function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button

15 / EN Washing Machine / User’s Manual
4.3.3 Programme and consumption table
• : Selectable.
* : Automatically selected, cannot be cancelled.
*** : Eco 40-60 with 40 °C temperature selection is the test programme in accordance with EN 60456:2016/A11:2020 and
energy label with Commission Delegated Regulation (EU) 2019/2014
***** : These programmes can be used with the HomeWhiz application. Energy consumption may increase with connection.
- : See the programme description for maximum load.
EN Auxiliary functions
Programme
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed Steam Extra Rinse Fast+ Prewash Anti Crease+
Temperature (°C)
Katoen
90 9 98 2,65 1400 • • • • • Cold - 90
60 9 98 1,90 1400 • • • • • Cold - 90
40 9 95 1,10 1400 • • • • • Cold - 90
Eco 40-60
40*** 9 57 0,700 1400 40-60
40*** 4,5 50 0,460 1400 40-60
40*** 2,5 42 0,330 1400 40-60
Synthetisch 60 4 73 1,38 1200 • • • • • Cold - 60
40 4 70 0,90 1200 • • • • • Cold - 60
Xpress / Super Xpress
90 9 76 2,30 1400 • • • • Cold - 90
60 9 76 1,30 1400 • • • • Cold - 90
30 9 76 0,25 1400 • • • • Cold - 90
Xpress / Super Xpress + Fast+ 30 2 48 0,15 1400 • • • • Cold - 90
Wol 40 2 55 0,55 1200 • Cold - 40
Delicaat 40 4 58 0,80 800 • Cold - 40
Donker textiel 40 5 86 0,95 1200 • * • • • Cold - 40
Sportkledij 40 5 58 0,60 1200 • Cold - 40
StainExpert 60 4,5 80 1,70 1400 • • 30-60
Hygiene+ 90 9 125 2,90 1400 * * 20-90
Jas/Dekbed 60 - 95 1,40 800 • • Cold - 60
Hemden 60 4 65 1,40 800 • • • • • Cold - 60
Drum Clean 90 - 80 2,70 600 * 90
Downloaded Program*****
Mix 40 4 73 1,00 800 • • • • Cold - 40
Curtain 40 2 90 0,80 800 * • Cold - 40
Lingerie 30 1 76 0,32 600 * Cold - 30
Soft Toys 40 2 65 0,82 600 * Cold - 40
Towel 60 4 100 1,20 800 • * Cold - 60

16 / EN Washing Machine / User’s Manual
CPlease read installation section of the manual before first use.
The auxiliary functions in the table may vary according to the model of your machine.
Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry
you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the
actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.
"Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or removed."
"The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your machine."
Always select the lowest appropriate temperature. The most efficient programmes in terms of energy consumption are generally
those that perform at lower temperatures and longer duration.
Noise and remaining moisture content are influenced by the spinning speed: the higher the spinning speed in the spinning phase,
the higher the noise and the lower the remaining moisture content.
4.3.4 Programme selection
1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with
"Programme and consumption table".
C
Programmes are limited with the highest spin speed appropriate for that particular type of fabric.
When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
2 Select the desired programme with the Programme Selection knob.
Consumption Values (EN)
Temperature Selection (°C) Spin Speed (rpm) Capacity (kg) Program Duration (hh:mm) Energy Consumption (kWh/cycle) Water Consumption(L/ cycle) Laundry Temperature (°C) Remaining Moisture Content (%)
Eco 40-60
40 1400 9 03:48 0,700 57 29 53
40 1400 4,5 02:53 0,460 50 28 53
40 1400 2,5 02:53 0,330 42 24 53
Katoen 20 1400 9 04:00 0,700 95 20 53
Katoen 60 1400 9 04:00 1,900 98 60 53
Synthetisch 40 1200 4 02:35 0,900 70 40 40
Xpress / Super Xpress 30 1400 9 00:28 0,250 76 23 62
The consumption values given for programmes other than the Eco 40-60 programme are only indicative.

17 / EN Washing Machine / User’s Manual
4.3.5 Programmes
• Eco 40-60
The Eco 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at 40 °C
or 60 °C, together in the same cycle, and that this programme is used to assess the compliance with the EU
ecodesign legislation.
Although it washes longer than all other programmes, it provides high energy and water savings. Actual water
temperature may be different from the stated wash temperature. When you load the machine with less laundry
(e.g. ½ capacity or less), periods in programme stages may automatically get shorter. In this case, energy and
water consumption will decrease.
• Katoen (Cottons)
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this
programme. When the quick wash function button is pressed, programme duration becomes notably shorter
but effective washing performance is ensured with intense washing movements. If the quick wash function is
not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Synthetisch (Synthetics)
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.
The programme duration gets notable shorter and washing with high performance is ensured. If the quick wash
function is not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Wol (Woollens / Hand Wash)
Use to wash your woollen/delicate laundry. Select the appropriate temperature complying with the tag of your
clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.
• Hygiene+
Applying a steam step at the beginning of the programme allows to soften the dirt easily.
Use this programme for your laundry (baby clothes, bed sheets, bedlinen, underwear, etc. cotton items) that
requires an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle. The
high level of hygiene is ensured thanks to the steam application before the programme, long heating duration
and additional rinsing step.
• Programme was tested by „The British Allergy Foundation„ (Allergy UK) with the 60°C temperature option
selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and mould.
Allergy UK is the brand of the British Allergy Association. Seal of Approval is created to
guide people that require recommendation about a product that the related product restricts
/ reduces / eliminates the allergens or reduces the allergen content significantly in the
ambient where allergy patients exist. It aims to provide assurance that the products are
tested scientifically or examined in a way to provide measurable results.
• Jas / Dekbed (Duvet / Down Wear)
Use this programme to wash your fibre duvets that bear "machine washable" tag. Check that you have loaded
the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading
the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the
machine paying attention to place it in a way that it will not contact the bellow or the glass.
Besides, use this programme to wash your coats, vest, jackets etc. containing feathers with a "machine-
washable" label on them.
C
Do not load more than 1 double fibre duvet (200 x 200 cm).
Do not wash your duvets, pillows and etc. that contain cotton in the machine.
A
WARNING: Do not use the washing machine to wash materials such as carpets, rugs etc. Permanent damage occurs
in the machine.
• Centrifugeren + Pompen (Spin+Drain)
You can use this function to remove the water on the garment of drain the water in the machine.

18 / EN Washing Machine / User’s Manual
• Spoelen (Rinse)
Use when you want to rinse or starch separately
• Curtain
You can use this programme to wash your tulles and curtains. As their meshed texture causes excessive
foaming, put little amount of detergent into the main wash compartment. Thanks to the special spin profile of
the programme, tulles and curtains crease lesser. Do not load your curtains above the specified capacity in
order not to damage them.
C
It is recommended to use special detergents produced for curtains in the powder detergent compartment in this programme.
• Hemden (Shirts)
This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics altogether.
It reduces wrinkles. Steam is applied at the end of the programme to help the wrinkle reducing function. The
special spin profile and steam applied at the end of the programme reduce the wrinkles on your shirts. When the
quick wash function is selected, the Pre-treatment algorithm is executed.
• Apply the pre-treatment chemical on your garments directly or add it together with detergent when the
machine starts to take water from the main washing compartment. Thus, you can obtain the same performance
as you obtain with normal washing in a much shorter period of time. Usage life of your shirts increases.
• Xpress / Super Xpress
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme
duration can be reduced down to 14 minutes when the quick wash function is selected. When the quick wash
function is selected, maximum 2 (two) kg of laundry must be washed.
• Donker textiel (DarkCare / Jeans)
Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high performance
washing with special drum movement even if the temperature is low. It is recommended to use liquid detergent
or woollen shampoo for dark coloured laundry. Do not wash your delicate clothes containing wool or etc.
• Mix
Use to wash your cotton and synthetic clothes together without sorting them.
• Delicaat (GentleCare)
You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It
washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20
degrees or by selecting the cold wash option.
• Lingerie
You can use this programme to wash delicate garments that are suitable for hand wash and delicate women's
underwear. Small amount of garments must be washed in a washing net. Hooks, buttons etc. must be done up
and zips must be zipped up.
• Sportkledij (Outdoor / Sports)
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and
water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special
rotating movements.
• StainExpert
The machine has a special stain programme which enables the removal of different types of stains in the most
effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate and pigmenting
clothes and laundry in this programme. Before washing, garment tags should be checked (recommended for
cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed sheets, duvet covers,
pillowcases, bath-beach towels, towels, socks, cotton underwear that are suitable for washing at high temperature
and long time). You can use automatic stain programme to wash 24 types of stains divided into three different
groups that can be selected with the “Quick Wash” setting button. Below you can find the soil groups that can

19 / EN Washing Machine / User’s Manual
be selected with the “Quick Wash” setting button. Depending on the selected stain group, a special washing
programme for which duration of rinse hold, washing action, washing and rinsing duration are modified.
Below you can find the soil groups that can be selected with the “Quick Wash” setting button:
When “Quick Wash” is not
selected
When the “Quick Wash” button
is pressed once
When the “Quick Wash” button
is pressed twice
Sweat Blood
Tea
Collar soil Chocolate
Coffee
Meal Pudding
Fruit juice
Mayonnaise Grass
Ketchup
Salad dressing Mud
Red wine
Make-up Egg
Starch
Machine oil Butter
Jam
Baby food Curry
Coal
• Select the stain programme.
• Select the stain you want to clean by locating it in the groups above and selecting the related group with the
quick auxiliary function button.
• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.
• Downloaded Program
This is a special programme that allows you to download different programmes when you want to. At the start,
there is a programme you can see with the HomeWhiz application as default. However, you can use the HomeWhiz
application to select a programme from the predetermined programme set, and then change and use it.
CIf you want to use HomeWhiz feature and Remote Control function, you must select Downloaded Programme. Detailed
information can be found in 4.3.15 HomeWhiz Feature and Remote Control Function.
• Soft Toys
Soft toys must be washed in a delicate programme due to their delicate fabrics, and the fibre and accessories
they contain. Thanks to its delicate washing movements and spinning profile, the soft toys programme protects
the toys during washing. It is recommended to use liquid detergent.
CFragile toys with hard surfaces must not be washed under any circumstances.
Toys must not be washed together with your garments since they may harm laundry.
• Towel
Use this programme to wash durable cotton laundry such as towels. Load the towels into the machine paying
attention to place them in a way that they will not contact the bellow or the glass.
4.3.6 Temperature selection
-
-
-
-
-
-
Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature
indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the
current programme.

20 / EN Washing Machine / User’s Manual
Press the Temperature Adjustment button to change the temperature. Temperature decreases gradually.
CNo change can be made in programmes where temperature adjustment is not allowed.
You can also change the temperature after the washing starts. This change can be made if the washing steps
allow it. Changes cannot be made if the steps do not allow it.
CIf you scroll to cold wash option and press Temperature Adjustment button again, the recommended maximum temperature
for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the
temperature.
4.3.7 Spin speed selection
-
-
-
-
-
-
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the Spin Speed indicator.
CIt is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current
programme.
Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually.
Then, depending on the model of the product, "Rinse Hold " and "No Spin " options appear on the display.
If you are not going to unload your laundry immediately after the programme completes, you can use Rinse
Hold function in order to prevent them from getting wrinkled when there is no water in the machine.
This function holds the laundry in the final rinsing water.
If you want to spin your laundry after the Rinse Hold function:
- Adjust the Spin Speed.
- Press Start / Pause / Cancel. The programme will resume. Machine drains the water and spins the laundry.
If you want to drain the water at the end of the programme without spinning, use No Spin function.
CNo change can be made in programmes where spin speed adjustment is not allowed.
You can change the spin speed after the washing starts if the washing steps allow it. Changes cannot be
made if the steps do not allow it.
Rinse hold
If you are not going to unload your clothes immediately after the programme completes, you can use rinse
hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled
when there is no water in the machine. Press Start / Pause button after this process if you want to drain the
water without spinning your laundry. Programme will resume and complete after draining the water.
If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button.
The programme will resume. Water is drained, laundry is spun and the programme is completed.
