Belgard DESIGNFORMS COUNTER COMBO A 1 SHELVING UNIT & 1 SOLID... User manual

COUNTER COMBO A
- 1 SHELVING UNIT & 1 SOLID UNIT

1
COUNTER COMBO A -
1 SHELVING UNIT & 1 SOLID UNIT
37.10”
25.50”
59.00”
37"
25"
59"
COMPONENTS
Build side by side.
Wood top construction
instructions follow in
this guide.
Single Counter (x1) Single Shelf (x1)

2
COUNTER COMBO A -
1 SHELVING UNIT & 1 SOLID UNIT
WOOD CUTS
Countertop only.
1 = 59"
2 = 59"
3 = 18"
1
11
1
2 3 3
1 1
11
2 3 3
2" x 6" x10'
PRESSURE
TREATED WOOD
2" x 4" x8'
PRESSURE
TREATED WOOD
x1x2 x1 B #8 2"
DECK SCREW
x20OUTDOOR
SILICONE

3
COUNTER COMBO A -
1 SHELVING UNIT & 1 SOLID UNIT
REQUIRED TOOLS
SAFETY EQUIPMENT
MIN 1¾"
DEEP HEX SOCKET
7/16" WITH 1/4" DRIVE
SOCKET ADAPTOR
1/4" HEX SHANK TO 1/4" DRIVE
DRILL SKILL SAW
MEASURING TAPE
GLOVES
CARPENTER SQUARE
SAFETY GLASSES
LEVEL
SAFETY BOOTS
RUBBER MALLET

4
BASE PREPARATION
SLAB OR PAVER
SLAB OR PAVER
BEDDING SAND 1"
COMPACTED AGGREGATES 6"- 8"
COMPACTED AGGREGATES 6"- 8"
COMPACTED AGGREGATES 6"- 8"
SOIL
SOIL
SOIL
REINFORCED POURED CONCRETE FOUNDATION 2"
ALWAYS LEVEL GROUND BEFORE INSTALLATION
ON COMPACTED FOUNDATION
ON POURED CONCRETE
ON NEW OR EXISTING PATIO
COUNTER COMBO A -
1 SHELVING UNIT & 1 SOLID UNIT

5
TIPS & TRICKS
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
PREBUILD:
• Prebuild all hardware prior to starting build.
• When assembling hardware SNAP the bolt into place
with the plastic sliders. Pressing down on something
at and hard will help. (Fig. A)
• Do not over hand tighten the slider/bolt piece and the
nut on the completed brackets. They should be loosely
attached so they slide into the channels on the panels.
Leave a space of ¼ in. (Fig. B)
INSTALL:
• Always start in the corner when starting a build. (Fig. C)
• Set the drill clutch (torque) at a low level to deliver a
torque range of 50-65lbs per inch. Refer to your drill
manual for torque adjustment instructions.
• Use a rubber mallet to assist with moving/aligning/
adjusting panel placement during assembly.
WHEN BUILDING WOODEN COMPONENTS:
• Do not exceed prescribed length. Exact measurements
are required for proper assembly.
• Ensure your cuts are straight.
• Do not over tighten the screws into the wood
- this can cause buckling.
• Pre-drill holes for 45º corner assemblies.
• Use cedar or pressure treated wood for outdoor use.
• Seal wooden components for prolonged use.
WHEN BUILDING PLANTERS:
• Line the inside of the planters or garden beds with a
geotextile fabric to help with water management.
90°
Fig. A
Fig. B
Fig. C

6
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
COMPONENTS
Small Panel (x2)
6" x 24"
Large Panel (x9)
12" x 24"
Hardware Kit (x3)

7
1 1
2 3
1 1
3
5 6
4 4
WOOD CUTS
Shelves only.
4 = 23"
5 = 19 x 23"
6 = 21 x 23"
4
5 6
4
2" x 2" x8'
PRESSURE
TREATED WOOD
2' x4' x ¾"
PLYWOOD
x1 x1
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
A #8 1"
DECK SCREW
x10

8
BRACKET A x2 x3 x1 x3 x2
2
1
x6
BRACKET A1
1
x2 x2 x1 x2
2
x3 x1
BRACKET A2
1
x2 x2 x1 x2
2
x3 x1
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT

9
BRACKET C x8 x1 x2 x2 x2
1
BRACKET C1 x1 x1 x2 x2 x2
1
ASSEMBLY I x6 J x6
1
x1 x1
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT

10
90°
2
1
A
90º
I
x2
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Bracket A
at side up to hold
the shelf wood.

11
4
3A1
I
J
A1
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT

12
6
5
=
11"
A
A
A2
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Bracket A
at side up to hold
the shelf wood.

13
=
8
7
11"
J
A
IA2
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT

14
10
9
C
AC
C
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Bracket A
at side up to hold
the shelf wood.

15
6”
12
11
A
C
6" A
C
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
C
Install Bracket A
at side up to hold
the shelf wood.

16
6”
13
6"
A
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Bracket A
at side up to hold
the shelf wood.

17
14
C1
C
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Brackets C and C1
at side up to hold the
shelf wood.

18
6”
15
6"
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
Install Brackets C and C1
at side up to hold the
shelf wood.

19
16
C
COMPONENT 1
SINGLE COUNTER - SHELVING UNIT
