BELL LABS INNOVATIONS Lucent Technologies CentreVu Sun Ultra 5 User manual

CentreVu
Call Management System
Sun

Ultra

5 Computer
Connectivity Diagram
585-215-872
Comcode 108620238
Issue 2
October 1999

1
Preparing for the Installation 0
This section contains information that will help you prepare for the Ultra
*5
computer installation.
Safety
Precautions 0
For your protection, observe the following safety precautions when setting up
your equipment.
●Follow all cautions, warnings, and instructions marked on the
equipment.
●Never push objects of any kind through openings in the equipment as
they may touch dangerous voltage points or short out components that
could result in fire or electric shock.
●Refer servicing of equipment to qualified personnel.
●To further protect both yourself and the equipment, observe the
following precautions.
* Ultra is a trademark of Sun Microsystems, Inc.
Item Problem Precaution
Wrist or foot
strap ESD Wear a conductive wrist strap or foot strap when handling printed circuit
boards.
Cover panels System
damage and
overheating
Re-install all cabinet cover panels after
performing any service work on the
system.
Card cage slot
filler panels System damage and
overheating
Make sure all empty board slots have a
filler panel installed.

Preparing for the Installation
2 CentreVu CMS Sun Ultra 5 Computer Connectivity Diagram
System
Precautions 0
Ensure that the voltage and frequency of the power outlet used matches
the electrical rating labels on the equipment.
Wear antistatic wrist straps when handling any magnetic storage devices,
and printed circuit boards.
Each of the following items requires access (by way of a separate power
cord):
●
Ultra 5 computer, external peripherals, and monitor used for
diagnostics. The
Ultra 5 should be powered by a non-switched,
dedicated, 15-amp circuit.
●The
Ultra 5 computer uses nominal input voltages of 100-125
and 200-240 V AC at 50-60 Hz.
Sun
*products are designed to work
with single-phase power systems having a grounded neutral
conductor under safety precautions. To reduce the risk of electrical
shock, do not plug
Sun products into another type of power source.
Contact your facilities manager or qualified electrician if you are
unsure what type of power is supplied to your building.
DO NOT make mechanical or electrical modifications to the
computer. Sun Microsystems is not responsible for regulatory
compliance of modified computers.
Tools Required 0This list represents the tools you will need:
●No. 2 Phillips screwdriver (magnetized tip suggested)
●Needle-nose pliers
●Grounding wrist strap
●Antistatic mat.
* Sun is a registered trademark of Sun Microsystems, Inc.
!WARNING:

Front and Back Panels
3
Front and Back Panels 0
Familiarize yourself with the layout of the Ultra 5. These figures show the
following:
●Front Panel. This figure shows the front panel of the
Ultra 5. The
diskette drive is not available if the optional second internal hard
drive has been installed.
●Rear Panel (UltraSCSI). This figure shows the rear panel when you
have an UltraSCSI card, which is always installed in PCI slot 2. The
UltraSCSI card has two 68-pin SCSI connectors. Other PCI cards
may be installed in slots 1 and 3.
●Rear Panel (
SunSwift
*). This figure shows the rear panel when you
have a
SunSwift card, which is always installed in PCI slot 2. The
* SunSwift is a trademark of Sun Microsystems, Inc.

Front and Back Panels
4 CentreVu CMS Sun Ultra 5 Computer Connectivity Diagram
SunSwift card has one 68-pin SCSI connector and one ethernet
RJ45 connector. Other PCI cards may be installed in slots 1 and 3.
Identifying PCI
Cards 0
The following table shows where the different PCI cards can be installed
in the
Ultra 5 computer.
PCI Card PCI Slot Comments
UltraSCSI
or
SunSwift
PCI 2 Required. A SunSwift card is used when two
ethernet connections are required.
HSI/P PCI 1 and
PCI 3 Optional. HSI/P cards are not required when using ethernet for ACD connectivity. Use PCI 1 to
support four ACDs if you have only one HSI/P
card. Use PCI 1 and 3 to support eight ACDs
when you have two HSI/P cards.
SAI/P PCI 1 and
PCI 3 Optional.
Token Ring PCI 3 Optional.

Connectivity Diagrams and Parts List
5
Connectivity Diagrams and Parts List 0
The following diagram shows how equipment is connected to the Ultra 5
when an UltraSCSI card is installed.

Connectivity Diagrams and Parts List
6 CentreVu CMS Sun Ultra 5 Computer Connectivity Diagram
The following diagram shows how equipment is connected to the Ultra 5
when a
SunSwift card is installed.

Connectivity Diagrams and Parts List
7
The following table lists parts required to connect most of the external
devices to the
Ultra 5. For information about connecting terminals,
printers, and modems to the
Ultra 5, see CentreVu Call Management
System Terminals, Printers, and Modems
(585-215-874). For information
about switch connections, see
CentreVu Call Management System
Switch Connections and Administration
(585-215-876).
Connectivity
Diagram
Call Out
Comcode,
or Part of
Comcode
Vendor Part
Number Description
A 108599671 F530-2154-xx Keyboard cable (15 feet, 4 meters)
B 108599671 370-1398-xx Mouse with cable
C 108599671 F530-2020-xx Monitor cable (15 feet, 4 meters)
D 408106664 X6540A UltraSCSI card (Dual-port PCI Adapter with
Two VHDCI cables)
E 407938679 595-4258-xx SunSwift card (10/100 Base-T F/W UltraSCSI
PCI Adapter)
F 408106664 F530-2453-xx 68-to-68 pin VHDCI cable
G 407934470 595-4851-xx 68-to-68 pin SCSI cable
407996958 F530-1430-xx Loopback plug for HSI/P ports
H407938653 1040A HSI/P card (up to two may be installed)
I Quad cable (one per HSI/P card)
J 407086818 EDN37J0010-MM RS-449 cable (10 feet, 3 meters)
K 407086826 ANIXTER #143987 Category 5 UTP cord (10 feet, 3 meters)
L 407086859 AT-210TS
CentreCOM
*10Base-T transceiver
M 846373413 DB9-to-RJ45 straight-through modem adapter
N 846983039 Shielded modular cord (10 feet, 3 meters)
O 846362770 ED3P00170G-1308 RJ45-to-DB25 remote console adapter
P 407633999 Model 839
Sportster
†33.6 remote console faxmodem
Q 408045326 Parallel printer cable
R 108599671 SG-XTAPSLR-010A SLR-5 tape drive
S407350719 X1041A SAI/P card (up to two may be installed)
T SAI/P patch panel (one per SAI/P card)
* CentreCOM is a registered trademark of Allied Telesis.
†
Sportster is a registered trademark of U.S. Robotics, Inc.
