Bend-Pak PCL-18B User manual

1
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION AND OPERATION. BY PROCEEDING YOU AGREE THAT
YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF
THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
Manual Revision A5 - Feb. 2020
Manual Part Number 5900170
INSTALLATION AND OPERATION MANUAL
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, concerns for material
damaged in shipment must be noted by the purchaser on
the delivery receipt at the time shipment is received to
ensure proper handling by the shipper.
BE SAFE
Your new lift was designed and built with safety in mind.
However, your overall safety can be increased by proper
training and thoughtful operation on the part of the operator.
DO NOT operate or repair this equipment without reading
this manual and the important safety instructions shown
inside.
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-800-253-2363
Tel: [phone]
www.bendpak.com
Keep this operation manual near the
machine at all times. Make sure that ALL
USERS read this manual.
Portable Column Lifting System
Model: PCL-18B
IMPORTANT
Reference ANSI/ALI ALIS, Safety
Requirements for Installation and Service of
Automotive Lifts before installing lift.

2
PCL-18B
Portable Column Lift
This instruction manual has been prepared especially for you.
Your new lift is the product of over 40 years of continuous research, testing and development;
it is the most technically advanced lift on the market today.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION & OPERATION BEGINS
RECORD HERE THE LIFT AND
POWER UNIT INFORMATION WHICH IS
LOCATED ON THE SERIAL NUMBER
DATA PLATES ON THE LIFT AND
ON THE POWER UNIT
Power Unit Model # _____________
Power Unit Date Of Mfg. _____________
Power Unit Serial # _____________
This information is required when
calling for parts or warranty issues.
PRODUCT WARRANTY
Our comprehensive product warranty means more than a commitment to you; it’s also a commitment to the value of your
new BendPak lift. For full warranty details contact your nearest BendPak dealer or visit:
http://www.bendpak.com/support/warranty/
OUR LIFTS ARE SHIPPED WITHOUT OIL.
ADD OIL TO POWER UNIT TANK BEFORE USE.
READ SECTION 8 FOR MORE INFORMATION.

3
IMPORTANT NOTICE
Do not attempt to install this lift if you have never been
trained on basic automotive lift installation procedures.
Never attempt to lift components without proper lifting
tools such as forklift or cranes. Stay clear of any moving
parts that can fall and cause injury. These instructions
must be followed to ensure proper installation and
operation of your lift. Failure to comply with these
instructions can result in serious bodily harm and void
product warranty. Manufacturer will assume no liability
for loss or damage of any kind, expressed or implied,
resulting from improper installation or use of this product.
PLEASE READ ENTIRE MANUAL
PRIOR TO INSTALLATION.
DEFINITIONS OF
HAZARD LEVELS
Identify the hazard levels used in this manual with the
following denitions and signal words:
Watch for this symbol. It means immediate hazards
which will result in severe personal injury or death.
Beware of this symbol. It means hazards or unsafe
practices could result in severe personal injury or death.
Take note of this symbol. It means hazards or unsafe
practices which may result in minor personal injury,
product or property damage.
OWNER’S RESPONSIBILITY
To maintain the lift and user safety, the
owner’s responsibility is to read and
follow these instructions:
t Follow all installation and operation instructions.
t Make sure installation conforms to all applicable Local,
State, and Federal Codes, Rules, and Regulations;
such as State and Federal OSHA Regulations and
Electrical Codes.
t Carefully check the lift for correct initial function.
t Read and follow the safety instructions. Keep them
readily available for machine operators.
t Make certain all operators are properly trained, know
how to safely and correctly operate the unit, and are
properly supervised.
t Allow unit operation only with all parts in place and
operating safely.
t Carefully inspect the unit on a regular
basis and perform all maintenance as
required.
t Service and maintain the unit only
with authorized or approved replacement parts.
t Keep all instructions permanently with the unit and
all decals on the unit clean and visible.
BEFORE YOU BEGIN
NOTIFY THE CARRIER AT ONCE if any hidden loss or
damage is discovered after receipt and request the carrier
to make an inspection. If the carrier will not do so, prepare
a signed statement to the effect that you have notied the
carrier (on a specic date) and that the carrier has failed to
comply with your request.
IT IS DIFFICULT TO COLLECT FOR LOSS OR DAMAGE
AFTER YOU HAVE GIVEN THE CARRIER A CLEAR
RECEIPT. Support claim with copies of the Bill of Lading,
freight bill, invoice, and photographs, if available. BendPak’s
willingness to assist in helping you process your claim does
not make BendPak responsible for collection of claims or
replacement of lost or damaged materials.

4
Warranty / Serial Number Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Definitions of Hazard Levels . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Owner’s Responsibility . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installer/Operator Agreement/ Protective Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety / Warning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Section 1 / Selecting Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Section 2 / Floor Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Concrete Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assembly View / Parts Inventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Section 3 / Layout / Specifications /Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Section 4 / Hydraulic Jacking System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Section 5 / Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Section 6 / Communication Cable and Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Column Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Section 7 / Control Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Section 8 / Initial Start-up and PLC System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Section 9 / Testing Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Section 10 / Operation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-23
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23-24
Product Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-28
Safe Lift Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29-30
Troubleshooting and Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-34
Installation Form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Part Breakdowns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-46
Crossbeam Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
TABLE OF CONTENTS

5
INSTALLER / OPERATOR
PLEASE READ AND FULLY
UNDERSTAND. BY PROCEEDING
YOU AGREE TO THE FOLLOWING:
t I have visually inspected the site where the lift is
to be installed and verified the concrete to be in good
condition and free of cracks or other defects. I understand
that installing a lift on cracked or defective concrete could
cause lift failure resulting in personal injury or death.
t I understand that a level floor is required for proper
installation and level lifting.
t I understand that I am responsible if my floor is of
questionable slope and that I will be responsible for all
charges related to pouring a new level concrete slab if
required.
t I will assume full responsibility for the concrete floor
and condition thereof, now or later, where the above
equipment model is to be installed. Failure to follow
Danger, Warning, and Caution instructions may lead to
serious personal injury or death to operator or bystander
or damage to property.
t I understand that BendPak lifts are designed to be
installed in indoor locations only. Failure to follow
installation instructions may lead to serious personal
injury or death to operator or bystander or damage to
property or lift.
Failure to follow Danger, Warning, and Caution
instructions may lead to serious personal injury or death
to operator or bystander or damage to property.
Please read the entire manual prior to installation.
Do not operate this machine until you have read and
have understood all of the Danger, Warning and
Caution alerts in this manual. For additional copies
or further information, contact:
BendPak Inc.
1645 Lemonwood Dr.
Santa Paula, CA. 93060
1-805-933-9970
www.bendpak.com
INSTALLER / OPERATOR
PROTECTIVE EQUIPMENT
Personal protective equipment helps to make installation
and operation safer; however, it does not take the place
of safe operating practices. Always wear durable work
clothing during any installation and/or service activity.
Shop aprons or shop coats may also be worn, however
loose-fitting clothing should be avoided.
Tight-fitting leather gloves are recommended
to protect the technician’s hands when
handling parts. Sturdy leather steel-toe
work shoes and oil resistant soles should
be used by all service personnel to help
prevent injury during typical installation and
operation activities.
Eye protection is essential during installation
and operation activities. Safety glasses with
side shields, goggles, or face shields are
acceptable. Back belts provide support
during lifting activities and are also helpful in
providing worker protection. Consideration
should also be given to the use of hearing protection if
service activity is performed in an enclosed area, or if
noise levels are high.
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED
COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OR YOURSELF AND OTHERS
AND CAN CAUSE PERSONAL INJURY OR DEATH. READ AND FOLLOW ALL INSTRUCTIONS IN
THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.

6
1. Carefully remove the crating and packing materials.
CAUTION! Be careful when cutting steel banding
material as items may become loose and fall causing
personal harm or injury.
2. Check the voltage, phase and proper amperage
requirements for the motor shown on the motor plate.
Wiring should be performed by a certied electrician only.
IMPORTANT SAFETY INSTRUCTIONS
Read these safety instructions entirely
IMPORTANT NOTICE
Do not attempt to install this lift if you have never been trained on
basic automotive lift installation procedures.
Never attempt to lift components without proper lifting tools such as forklift or cranes.
Stay clear of any moving parts that can fall and cause injury.
1. READ and understand all instructions and all safety
warnings before operating lift.
2. Care must be taken as burns can occur from touching
hot components.
3. DO NOT operate equipment with a damaged cord or
if the equipment has been dropped or damaged until it has
been examined by a qualied service person.
4. DO NOT let a cord hang over the edge of the table,
bench, or counter or come in contact with hot manifolds or
moving fan blades.
5. If an extension cord is necessary, a cord with a current
rating equal to or more than that of the equipment should be
used. Cords rated for less current than the equipment may
overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled.
6. ALWAYS unplug equipment from
electrical outlet when not in use. Never use
the cord to pull the plug from the outlet. Grasp
plug and pull to disconnect.
7. Let equipment cool completely before
putting away. Loop cord loosely around cable
hook when storing.
8. DO NOT operate equipment in the vicinity of open con-
tainers of ammable liquids (gasoline) to reduce the risk of
re.
9. Adequate ventilation should be provided when working
on operating internal combustion engines.
10. Keep hair, loose clothing, ngers, and all parts of body
away from moving parts. Keep feet clear of lift
when lowering. Avoid pinch points.
11. DANGER! To reduce the risk of electric
shock, do not use on wet surfaces or expose
to rain. The power unit used on this lift contains
high voltage. Disconnect power at the recep-
tacle or at the circuit breaker switch before
performing any electrical repairs. Secure
plug so that it cannot be accidentally plugged
in during service. Or mark circuit breaker
switch so that it cannot be accidentally
switched on during service.
12. Use only as described in this manual.
Use only manufacturer’s recommended
attachments.
13. ALWAYS WEAR SAFETY GLASSES.
Everyday eyeglasses only have impact
resistant lenses, they are not safety
glasses.
14. CONSIDER WORK ENVIRONMENT. Keep work area
clean. Cluttered work areas invite injuries. Keep areas well lit.
15. GUARD AGAINST ELECTRIC SHOCK. This lift must be
grounded while in use to protect operator from electric shock.
Never connect the green power cord wire to a live terminal.
This is for ground only.
16. Only trained operators should operate this lift. All
non-trained personnel should be kept away from the work
area. Never let non-trained personnel come in contact with,
or operate lift.
17. DO NOT override self-closing lift controls.
18. CLEAR AREA if vehicle is in danger of falling.
19. ALWAYS make sure the safeties are
engaged before attempting to work on or
near a vehicle.
20. WARNING! RISK OF EXPLOSION.
This equipment has internal arcing or
sparking parts which should not be
exposed to ammable vapors. This
machine should not be located in a recessed area or below
oor level.
21. MAINTAIN WITH CARE. Keep lift clean for better and
safer performance. Follow manual for proper lubrication and
maintenance instructions. Keep control handles, buttons and
displays dry, clean and free from grease and oil.
22. Check for damaged parts. Check for alignment of
moving parts, breakage of parts or any condition that may
affect operation of lift. Do not use lift if any component is
broken or damaged.
23. NEVER remove safety related components from the lift.
Do not use lift if safety related components are missing or
damaged.
24. STAY ALERT. Use common sense and watch what you
are doing. Remember, SAFETY FIRST.
SAVE THESE INSTRUCTIONS

7
IMPORTANT INSTRUCTIONS
These instructions must be followed to ensure proper installation and operation
of your lift. Failure to comply with these instructions can result in serious
bodily harm and void product warranty. Manufacturer will assume no liability for
loss or damage of any kind, expressed or implied, resulting from
improper installation or use of this product.
PLEASE READ ENTIRE MANUAL PRIOR TO INSTALLATION
SECTION 1
(SELECTING SITE)
Before installing your new lift, check the following.
1. LIFT LOCATION: Always use architectural plans
when available. Check the layout dimension against the
oor plan requirements, making sure that adequate space
is available.
2. OVERHEAD OBSTRUCTIONS: The area where the
lift will be located should be free of overhead obstructions
such as heaters, building supports, electrical lines, etc.
3. DEFECTIVE FLOOR: Visually inspect the site where
the lift is to be installed and check for cracked or defective
concrete.
4. Lift is designed for INDOOR INSTALLATION ONLY.
Outdoor installation is prohibited. Always follow warnings
illustrated on equipment labels.
SECTION 2
(FLOOR REQUIREMENTS)
This lift must be installed on a solid level concrete
floor with no more than 3-degrees of slope. Failure
to do so could cause personal injury or death.
A level oor is suggested for proper use, installation
and level lifting. If a oor is of questionable slope, con-
sider a survey of the site and/or the possibility of pouring
a new level concrete slab.
t DO NOT install or use this lift on any asphalt surface
or any surface other than concrete.
t DO NOT install or use this lift on expansion seams
or on cracked or defective concrete.
t DO NOT install or use this lift on a second / elevated
oor without rst consulting building architect.
t DO NOT install or use this lift in extremely damp
environments.
t DO NOT install this lift outside. It is only approved for
indoor installations.
t Refer to ANSI/ALI ALIS Standard (R2015) Safety
Requirements for Installation and Service for more
information about safely installing your Lift.
ALL MODELS MUST BE INSTALLED ON CONCRETE
ONLY CONFORMING TO THE MINIMUM
REQUIREMENTS SHOWN ABOVE. NEW CONCRETE
MUST BE ADEQUATELY CURED BY AT LEAST
28 DAYS MINIMUM.
OUR LIFTS ARE SHIPPED WITHOUT OIL.
ADD OIL TO POWER UNIT TANK BEFORE USE.
LIFT MODEL CONCRETE REQUIREMENTS
PCL-18B 5” Min Thickness

8
When removing the lift from shipping angles, pay close attention as the columns can slide and can cause injury. Be
careful when cutting steel banding material as items may become loose and fall causing personal harm or injury.
Prior to removing the pallets make sure the posts are held securely by a fork lift or some other heavy lifting device.
PCL-18B PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Column Assembly 4
Carriage Assembly 4
Fork Arm Weldment 8
Displacement Sensor Cover 4
Control Box Assembly 4
Motor Cover Assembly 4
Parts Box (Packing List Enclosed) 4
Hydraulic Jack 4
Hydraulic Power Unit 4
Displacement Sensor
Cover
Control Box
Assembly
Hydraulic Jack
Motor Cover
Assembly
Carriage
Assembly
Column
Assembly
Fork Arm
Weldment

9
PCL-18B
Maximum Column Capacity Each Column 18,000 Lbs. / 8,165 Kg
Conguration Sold in sets of 2, 4 or 6 columns
Min. Column Height 97.5” / 2,572 mm
Maximum Lifting Height 71.5” / 1,889 mm
Length Lifting Fork 13.6” / 360 mm
Overall Length / Depth 47.5” / 1,206 mm
Width Inside Lifting Fork / Min. 9.5” / 241 mm
Width Inside Lifting Fork / Max. 22.7” / 576 mm
Overall Width 44” / 1,160 mm
Turning Circle 40” / 1,016 mm
Column Weight Each 1450 lbs. / 657 kg.
Lifting Speed 85 Seconds
Motor / 2HP * 208-240 V 50/60 Hz, 3 Phase
* Special Voltages Available Upon Request
The design, material and specications are subject to change without notice.
SECTION 3
(LAYOUT)

10
CLEARANCES
LIFT HEIGHT CLEARANCE NOTE: There must be a 148” MIN distance from ground to the nearest
overhead obstruction to clear the lift at full rise.

11
SECTION 4
(HYDRAULIC JACKING SYSTEM)
The PCL-18B employs a Hydraulic Jacking Dolly
System to move and position the Columns. The operation
of the Dolly System is similar to that of a pallet Jack.
(Fig. 4.1 & 4.2)
Moving the Columns
ENSURE THE DOORS OF THE ELECTRIC CONTROL
BOXES ARE CLOSED TO AVOID GETTING HANDS
PINCHED OR CRUSHED BY THE HANDLE BAR.
ALL LIFTING COLUMNS MUST BE LOWERED TO
THE GROUND BEFORE LIFTING OF ANY VEHICLE.
Fig. 4.2
Fig. 4.1 NEVER ATTEMPT TO MOVE A COLUMN WITH A
VEHICLE LOADED ON THE ARM FORKS.
DO NOT OPERATE THE LIFT WITH THE
HYDRAULIC JACK IN THE RAISED POSITION.
DO NOT STOP THE JACKING DOLLY ON SLOPE
1. Position the Release Handle in the Lowest position.
2. Pump the Handle Bar down and up several times to
raise the Column off the ground 1- 1.5” (25-38mm).
3. Position the Release Handle in the middle position.
4. Move the Column Assembly by pushing or pulling on
the Handle Bar.
5. When the Column is in the desired location, pull up
on the Release Handle and the Column will lower to the
ground.

12
SECTION 5
(ELECTRICAL CONNECTIONS)
• ALL WIRING MUST BE PERFORMED BY A LICENSED ELECTRICIAN.
• DO NOT PERFORM ANY MAINTENANCE OR INSTALLATION OF ANY
COMPONENTS WITHOUT FIRST ENSURING THAT ELECTRICAL POWER
HAS BEEN DISCONNECTED AT THE SOURCE OR PANEL AND CANNOT
BE RE-ENERGIZED UNTIL ALL MAINTENANCE AND/OR
INSTALLATION PROCEDURES ARE COMPLETED.
• DO NOT RUN POWER UNIT WITHOUT OIL. DAMAGE TO POWER UNIT
PUMP CAN OCCUR. THE POWER UNIT MUST BE KEPT DRY. DAMAGE
TO POWER UNIT CAUSED BY WATER OR OTHER LIQUIDS SUCH AS
DETERGENTS, ACID ETC., IS NOT COVERED UNDER WARRANTY.
OPERATE LIFT ONLY BETWEEN TEMPERATURES OF 41 °- 104° F.
IMPROPER ELECTRICAL HOOK-UP CAN DAMAGE MOTOR AND WILL NOT
BE COVERED UNDER WARRANTY. PROTECT EACH CIRCUIT WITH TIME
DELAY FUSE OR CIRCUIT BREAKER. FOR 208-230 VOLT, THREE PHASE,
USE A 30 AMP FUSE. WHEN SELECTING A PLUG MAKE SURE YOU SELECT A
PLUG MADE FOR 30 AMP, 220 VAC, 3 PHASE POWER.
24VDC
380-460 VAC

13
SECTION 6
(COMMUNICATION CABLE
CONNECTION AND POSITIONING
PROCEDURE) 1. Position each column as shown below. Column A
“Master Column” should be located closest to the power
supply. (See Fig 6.1)
2. Route and connect the Communication Cables
according to the pictures and diagrams below. Pull back
on Locking Tab to lock Communication Cable to the
Column connectors. (See Fig. 6.2 - 6.4)
Fig. 6.2 Fig. 6.3 Fig. 6.4
Fig. 6.1
MAIN POWER SWITCH MUST BE OFF BEFORE
CONNECTING OR DISCONNECTING ANY OF
THE COMMUNICATION CABLES. FAILURE TO
FOLLOW PROPER PROCEDURE CAN RESULT IN
DAMAGE TO THE ENTIRE CONTROL SYSTEM.

14
PCL-18B COLUMN CONFIGURATION

15
SECTION 7
CONTROL PANELS
The PCL-18B includes one Master Column (Column A) and Slave Columns (Columns B, C and D). Each Column has a
control panel that can operate in SINGLE Mode, the main Column and the one directly across from it in PAIR Mode or
all 4 Columns at once in TEAM Mode.
Master Column Control Panel
1. Door Lock - Prevents unauthorized
access to the circuitry of the PCL-18B
system. Make sure door is securely
closed and locked while the lift is in
operation or the columns are being
moved. Be sure if the keys are removed
that they are kept in a safe place.
2. UP Control - Initiates de lift rise
sequence.
3. DOWN Control - Initiates the lift
lowering sequence.
4. PARK Control - Initiates the lift
locking (parking) sequence. Each lift
column will slowly settle onto the
mechanical stops.
5,6,7. TEAM, SINGLE or PAIR LIGHTS
Shows which lift columns will operate
as group, tandem or individually.
8. MODE Control - Commands
specic lift columns to operate as
single, team and/or pair modes.
9. SPEED Control - Selects the
parking or lowering speeds.
10. STANDBY/TURTLE - Choose this
command for a slower “turtle” speed
and a safe controlled descent.
11. READY/RABBIT - Select the faster
“rabbit” speed for a rapid controlled
descent.
12. VISUAL/AUDIBLE ALARM - When
the Main Power switch is moved to the
“ON” position, this light will illuminate
and the alarm will sound and ash. This
alarm will activate whenever the lift is
in motion or a fault is detected in the
system.
13. EMERGENCY STOP BUTTON - Each Column has an Emergency
Stop Button. Press this button on any of the Columns when you need to
stop operation immediately. To Reset, twist button clockwise. The button
will pop back out.
14. MAIN POWER SWITCH - Controls power to all of the
Columns. When this switch is in the “OFF” position, the lift system is
powered off and not operable. When this switch is in the “ON” position,
the lift system is powered on and prepared for operation.
15. FAULT / RESET - If for any reason the lift operation exceeds a
specied out of level tolerance treshold, all lift columns will stop and
display the error as: FAULT 1: Out of Tolerance; FAULT 2: No Motion;
FAULT 3: Safety Release; FAULT 4: String Pot.
To clear the error, an ofending lift will be put in SINGLE mode and raised
or lowered accordingly to reduce the difference in lift heights.
16. CALIBRATION BUTTON - Press and hold this button and in ve
seconds the calibration procedure will be completed.

16
Columns B, C, D
Column A
1 2 5 6 7
8
9 10 11
12 13 14
15
16 17 18 19
3
4
MASTER COLUMN CONTROL PANEL
SLAVE COLUMN CONTROL PANELS
The Columns B,C and Dhave many of
the same features as that of the Column A
Control Panel with the following exceptions:
-There is no Power Switch
-There is no Calibration Button
-There is no Main Power Supply Cord to
connect to the wall.
1. Door Lock
2. UP Control
3. DOWN Control
4. PARK Control
5. TEAM Light
6. SINGLE Light
7. PAIR Light
8. MODE Control
9. SPEED Control
10. STANDBY/TURTLE Light
11. READY/RABBIT Light
12. VISUAL/AUDIBLE Alarm
13. EMERGENCY STOP Button
14. MAIN POWER Switch
15. FAULT/RESET button
16. FAULT 1 - Out of Tolerance Light
17. FAULT 2 - No Motion Light
18. FAULT 3 - Safety Release Light
19. FAULT 4 - String Pot Light
20. CALIBRATION Button

17
SECTION 8
(INITIAL START-UP AND PLC SYSTEM OVERVIEW)
1. Make sure the power unit reservoirs are full with four
(4) gallons of 10-WT hydraulic oil or Dexron-III automatic
transmission uid each.
2. Apply light axle grease to the inside of the posts where
the slide blocks glide.
3. Once electrical power is connected to Column A and
the communication cables routed to the other Columns,
turn the Main Power Switch to the “ON” position. (See
Fig. 8.1)
If any of the Column heights are higher than the other one
press the “DOWN” button. If the heights still do not match
correctly see Maintenance section for calibration
instructions.
5. Pressing MODE allows the operator to control he
movement of the entire system in Team mode (See Fig
8.2), Columns A and B in Pair mode or Column A by itself
in Single Mode
6. Pressing SPEED allows the operator to change the
speed at which the lift will lower when the DOWN button is
pressed. Rabbit mode (See Fig. 8.3) allows for a quicker
descent while Turtle mode (See Fig 8.4) allows for a
slower, more precise descent.
7. Pressing CALIBRATE SYSTEM (Column A Control
Panel only) will set the current height of the lift carriages
as the 0 point or ground level. (See Fig 8.5)
ENSURE ALL OF THE COLUMNS ARE IN THE
LOWERED POSITION AND NOT RESTING ON A
RAISED HYDRAULIC JACKING DOLLY.
Fig. 8.1
Fig. 8.2
Rabbit Mode
Turtle Mode
Fig. 8.3
Fig. 8.4
Fig. 8.5

18
SECTION 9
(TESTING PROCEDURES)
Single Column Test
(Repeat these procedures on each Column in Single
Mode.)
Lifting Test
1. After setting the Operation Mode to SINGLE on the
control panel, raise the lift unloaded by pressing and
holding the “UP” button to check if the carriage rises
normally.
If the Carriage raises slowly or jerks, the Cylinder may
have to be bled to release any trapped air in the hydraulic
system. If not, go to Step 3.
2. Raise the carriage above about 5”\127mm and
loosen the Cylinder Bleed Screw on the top of the
Cylinder one full turn or until air or oil ows out. DO NOT
completely remove bleed screws. Retighten after trapped
air has escaped. (See Fig 9.1)
Safety and Lowering Test
3. With the Carriage above 21”/533mm press and hold
the “PARK” button that became available when the lift
passed the indicated height. The lift will lower onto the
nearest safety lock. Continue holding the “PARK” button
and then check that the Carriage is securely on the safety
lock before continuing.
NOTE: When the PCL-18B is not loaded with a vehicle
the SPEED should be set to Rabbit mode or a fault
condition may be detected.
4. Press and hold the “DOWN” button. The carriage will
start to move up to clear the safeties and then down to the
to the ground or until the “DOWN” button is released.
Emergency Button Test
5. Test the Emergency Stop Button by hitting the
Emergency Stop Button while the lift is rising or lowering.
The lift should immediately stop. To Reset, twist button
clockwise. The button will pop back out.
Multiple Column Test
Repeat the Lift Test, Safety Test, Lowering Test, and
Emergency Stop Button Test procedure for each of the
other Columns in the other Operation Modes: Pair and
Team.
Remember:
-Pair mode will control the Column directly across
from the Column control panel being operated.
-Team mode will control the entire system.
POST-INSTALLATION CHECK-OFF
√ Columns properly lowered and stable.
√ Wheel and Arm Pins properly attached.
√ Electric power supply confirmed.
√ Safety Locks functioning properly.
√ Check for hydraulic leaks.
√ Oil level.
√ Lubrication of critical components.
√ Check for overhead obstructions.
√ All Screws, Bolts, and Pins securely fastened.
√ Surrounding area clean.
√ Operation, Maintenance and Safety Manuals
on site.
√ Perform an Operational Test with a typical
vehicle.
DO NOT completely remove
Bleed Screw. One full turn
should purge trapped air.
Cylinder Bleed
Screw
Fig. 9.1

19
SECTION 10
(Operation Instructions)
OWNER/EMPLOYER RESPONSIBILITIES
The Owner/Employer:
• Shall ensure that lift operators are qualied and that they
are trained in the safe use and operation of the lift using
the manufacturer’s operating instructions; ALI/SM01-1, ALI
Lifting it Right safety manual; ALI/ST-90 ALI Safety Tips
card; ANSI/ALI ALOIM-2000, American National Standard
for Automotive Lifts-Safety Requirements for Operation,
Inspection and Maintenance; ALI/WL Series, ALI Uniform
Warning Label Decals/Placards; and in the case of frame
engaging lifts, ALI/LP-GUIDE, Vehicle Lifting Points/Quick
Reference Guide for Frame Engaging Lifts.
•Shall establish procedures to periodically inspect the
lift in accordance with the lift manufacturer’s instructions
or ANSI/ALI ALOIM-2000, American National Standard
for Automotive Lifts-Safety Requirements for Operation,
Inspection and Maintenance; and The Employer shall
ensure that lift inspectors are qualied and that they are
adequately trained in the inspection of the lift.
•Shall establish procedures to periodically maintain the
lift in accordance with the lift manufacturer’s instructions
or ANSI/ALI ALOIM-2000, American National Standard
for Automotive Lifts-Safety Requirements for Operation,
Inspection and Maintenance; and The Employer shall
ensure that lift maintenance personnel are qualied and
that they are adequately trained in the maintenance of the
lift.
• Shall maintain the periodic inspection and maintenance
records recommended by the manufacturer or ANSI/ALI
ALOIM-2000, American National Standard for Automotive
Lifts-Safety Requirements for Operation, Inspection and
Maintenance.
•Shall display the lift manufacturer’s operating
instructions; ALI/SM 93-1, ALI Lifting It Right safety
manual; ALI/ST-90 ALI Safety Tips card; ANSI/ALI AL-
OIM-2000, American National Standard for Automotive
Lifts-Safety Requirements for Operation, Inspection and
Maintenance; and in the case of frame engaging lifts, ALI/
LP-GUIDE, Vehicle Lifting Points/Quick Reference Guide
for Frame Engaging Lifts; in a conspicuous location in the
lift area convenient to the operator.
• Shall provide necessary lockout/tagout means for energy
sources per ANSI Z244.1-1982 (R1993), Safety
Requirements for the Lockout/Tagout of Energy Sources,
before beginning any lift repairs.
•Shall not modify the lift in any manner without the prior
written consent of the manufacturer.

20
LIFT OPERATION SAFETY
• DAILY inspect your lift. Never operate if it malfunctions
or if it has broken/damaged parts. Use only qualied lift
service staff and genuine BendPak parts to make repairs.
• THOROUGHLY train all employees in use and care of
lift, using manufacturer’s instructions and “Lifting It Right”
and “Safety Tips” supplied with the lift.
• NEVER allow unauthorized or untrained persons to
position vehicle or operate lift.
• PROHIBIT unauthorized persons from being in shop
area while lift is in use.
• DO NOT permit anyone on lift or inside vehicle when it is
either being raised or lowered.
• ALWAYS keep area around lift free of tools, debris,
grease and oil.
• NEVER overload lift. Capacity of lift is shown on name-
plate affixed to the lift.
• DO NOT stand in front of the vehicle while it is being
positioned in lift bay.
• DO NOT hit or run over lift arms, legs or cables. This
could damage lift or vehicle. Before driving vehicle into
position, move Columns to provide unobstructed access
to lift area.
• ALWAYS load vehicle on lift carefully. Position the lift
arms to contact at the vehicle’s wheels. Raise lift until the
wheels are 2”/50mm off ground. Check arms for secure
contact with wheels. Raise lift to desired working height.
• DO NOT block open or override self-closing lift controls;
they are designed to return to the “Off” or Neutral position
when released.
• DO NOT remove or disable arm restraints.
• ALWAYS remain clear of lift when raising or lowering
vehicles.
• ALWAYS use safety stands when removing or installing
heavy components.
• DO NOT go under raised vehicle if safety locks are not
engaged.
• NEVER LEAVE LIFT IN ELEVATED CONDITION
unless all Safety Locks are engaged.
• AVOID excessive rocking of vehicle while on lift.
• ALWAYS CLEAR AREA if vehicle is in danger of falling.
• ALWAYS REMOVE tool trays, stands, etc. before
lowering lift.
•ALWAYS POSITION the Columns to provide an
unobstructed exit before removing vehicle from lift area.
• DO NOT raise or lower the lift with persons or
equipment under the vehicle at any time.
• All vehicle tires need to be inspected and properly
inated according to vehicle manufactures specications.
• DO NOT lift any vehicle with any of the tires under
inated , at, or with any damage or wear that could
compromise the load bearing capability of the tire.
• Ensure that all steerable wheels are pointed straight
and are parallel to the vehicle body.
• Ensure there is a minimum of 6”/152mm clearance
above the top of the vehicle.
• NEVER attempt to override any fault condition.
• DO NOT operate the lift with any fault condition present.
• ALWAYS lower all columns onto the ground after
positioning or for storage.
• DO NOT apply a horizontal force or load to any raised
vehicle that exceeds more than 20% of the vehicles gross
weight during any repair procedures.
• Protect the communication cables from damage from
sharp objects. DO NOT drive over communication cables.
• Calibration procedure should be repeated bi-weekly
and/or for any control module replacement, system
calibration related fault, removal or replacement of any
sensors, valves, coils, motors or pumps.
• NEVER calibrate lift whole columns are in an elevated
position.
• Read and comply with all safety guidelines and
recommendations.
TO RAISE LIFT
1. Perform the Lift Testing Procedure as outlined in
Section 9 before lifting any vehicle.
2. Position the Vehicle on solid concrete surface.
3. Conrm that the vehicles tires are all properly inated.
Verify the gross vehicle’s weight does not exceed
the total capacity of the lifting system.
