Caution
Technical Specifications
Dimensions
Parts/Setup
Operation/Safety

2
Caution
Ensure no obstacles are in the column's path. Ensure
the column is not touching any walls. Ensure all cords
are appropriate length to accommodate the change in
height.
Warning
Pinch Point
Keep hands and
fingers clear.
Keep children away from electric height-adjustable lifting columns, control units, and handsets.
There is a risk of injury and electric shock.
Keep all electrical components away from liquids.
Do not sit or stand on the lifting column. Do not crawl or lie under the lifting column.
Do not place any objects taller than 12" underneath the lifting column.

3
Technical Specifications
Duty Cycle 10% Max. 2 mins on, 18 mins off
Height Range
Weight Capacity 225lbs
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VDC
Stroke 16.5"
Speed 0.5"/sec
Material Aluminum Alloy
Certification UL
12” - 28.5”
Temperature Rating 5C to 40C

4
Dimensions
Wireless Remote
Control Box
Bottom
Top COM
5.50"
2.20"
10.71"
11.61"
11.61"
11.61"
11.61"
10.71"
0.80"
Ø 0.21"
Ø 0.21"
Wired Remote
6.13"
6.13"
3.44"
1.57"
0.80"
3.44"
0.65"
0.23"
0.10"
0.10"
0.40"
0.34"
0.24"
1.89" 1.52"
0.65"
0.84"
0.80"
0.18" 2.83"
3.94"
2.38"
1.59"
0.80"
Ø0.43"
1.49"
0.65"
0.23"
12.19"

5
Parts
Control Box AC Power Cord
Setup
Lifting Column
Wired Remote Wireless Remote
FLT-11
FLT-11 Control Box
Wireless
Remote
Wired
Remote
Extension Cable

6
Operation Procedure
Safety Features
This column comes with a built-in self-locking feature, where when left idle for 10 seconds, the
column will lock and will be unresponsive to controls.
If the LED light is red, this will indicate you must unlock the column in order to lower the lift. Press
and hold the DOWN button for 5 seconds on either remote to unlock the lifting column for full
control.
Anti-collision sensor: When retracting the lifting column, the control box will detect any
obstructing objects. Once detected, the column will stop and rise slightly.
Overcurrent Protection: While in motion, the controller will detect a current spike. When sensing
a current spike of 6.5A, the lifting column with stop to prevent any overloading errors.
Use the wired or wireless remote for full up and down motion control. The non-momentary buttons
allow the user to press the buttons for both up and down control. Pressing any button while in
motion will stop the column.
Pairing the wireless remote
Press the UP and DOWN buttons on the wireless remote while simultaneously pressing the
button on the side of the control box for 10 seconds. The control box will emit a single beep to
confirm the pairing procedure has started. After 10 seconds, the wireless remote is now ready for
use.
LED Light: A green light will indicate the column is in normal operation. A red light will indicate
that the column is locked. Please see the unlocking procedure below.
