Description of the appliance
1. Water hardness adjustment
2. Levelling spacers
3. Upper basket stop
4. alt container
5. Large filter
6. Detergent dispenser
7. Control panel
8. Rating plate
9. Rinse aid dispenser
10. Central filter
11. Lower spray arm
12. Upper spray arm
13. Upper basket
14. Worktop
1
2
3
4
5
6
7
8
9
10
11
12
13
14
IN68

3
The control panel
1. MAIN ON indicator light
2. On/Off push button
3. Programme guide
4. Door handle
5. Programme marker
6. Programme selector dial
7. Programme sequence indicator
As the programme progresses, the programme
selector dial turns, to sho the phase in the ash
programme the appliance has reached.
Pre ash / Rinse and hold
Wash
Cold rinse
Hot rinse
Drying

3
Washing programmes
Programme Degree of soil
and
type of load
Require
push
button
tarting
position of
the programme
selector
Recommended
quantity of
detergent
wash prewash
Heavy soil.
Crockery, cutlery, pots
and pans.
Normal soil
Crockery and cutlery
Any.
Partial load (to be
completed later in the
day).
Cycle description
*POWER
WA H
NORMAL
WA H
** QUICK
WA H
RIN E
&
HOLD
Cold pre ash
Main ash up to 65°C
2 cold rinses
1 hot rinse
Drying
Main ash up to 65°C
2 cold rinses
1 hot rinse
Drying
1 cold rinse (to avoid
food scraps from
sticking together).
*Testing programme for EN 50242 (see "Hints for Test Centres").
** This is a special programme for quick ashing a full load of lightly soiled dishes, glasses and crockery (except pots)
so that you may re-use them promptly.
25 g 5 g
30 g /
30 g /
//
1On/Off
On/Off
On/Off
On/Off
2
3
Light soil.
Crockery and cutlery. Main ash up to 65°C
1 cold rinse
1 hot rinse
4

5
1. Check the filters
Ensure they are clean and properly positioned
(see "Maintenance and cleaning" Instruction book -
Part 1).
2. Check that there is rinse aid and
salt
(See Instruction book - Part 1).
3. Load the dishes
Remove any scraps of food.
Pull the lo er basket out and arrange the
saucepans, plates and cutlery in it.
Pull the upper basket out and arrange the plates,
saucers, glasses and cups etc. in it.
Slide the baskets back into the machine.
4. Ensure that the spray arms can
rotate freely.
5. Measure out detergent
Add the required amount of detergent into the
dispenser according to the "Washing programmes"
chart.
Close the detergent dispenser lid.
6. Close the dishwasher door
7. et the programme
Turn the programme selector dial clock ise until
the programme marker on the knob
corresponds ith the number of the programme you
ish to select.
8. tart the programme
Depress the On/Off push button.
The "Mains On" indicator light ill come on
and the machine ill start.
If you ish to interrupt the ashing programme at
any time press this button again.
9. At the end of the washing
programme
At the end of the programme the dish asher ill
automatically stop.
The “Mains On” indicator light remains on until the
On/Off push button is depressed.
10. witch off the dishwasher
S itch off the dish asher by pressing the On/Off
push button.
Wait 15/20 minutes before opening the
dish ashers’s door; in this ay you ill avoid
burning yourself hen removing the dishes and
avoid also the damage of the nearby furniture
caused by the escape of steam.
Empty the lo er basket first and then the upper one;
this ill avoid ater dripping from the upper basket
onto the dishes in the lo er one.
When the washing programme has finished, it
is recommended that the dishwasher is
unplugged and the water tap turned off.
In general it is not advisable to open the door
while the machine is working; if the door is
opened however, a safety device ensures that
the machine stops.
Important!
Care must be taken if the door is opened during
the hot phase or immediately after a
programme has finished, as steam may escape.
Operating sequence

6
Loading your appliance
Before placing dishes in the machine, remove any scraps of
food, to avoid clogging the filters and consequently reducing
the performance.
Do not load very small items which can fall
through the baskets.
The lower basket
The lo er basket is designed to take saucepans, lids,
plates, salad bo ls, cutlery etc.
Serving dishes and large lids should be arranged around the
edge of the basket, ensuring that the upper spray arm can
turn freely.
The cutlery basket
Long bladed knives stored in an upright position
are a potential hazard.
Long and/or sharp items of cutlery such as
carving knives must be positioned horizontally in
the upper basket.
Take care when loading or unloading sharp items
such as knives.
Cutlery should be placed in the removable cutlery basket
ith the handles facing do n ards.
If the handles protrude from the bottom of the basket,
obstructing the lo er spray arm, load the cutlery ith the
handles facing up ards.
Mix spoons ith other cutlery to prevent them from sticking
together.
For best results e recommend to use the cutlery grid
provided (if the size and dimensions of the cutlery allo it).
UI49
UI19
Using your appliance
UI71

7
The upper basket
The upper basket is designed for plates (dessert plates,
saucers, dinner plates of up to 25 cm in diameter), salad
bo ls, cups and glasses.
Arrange items on and underneath the fold-do n cup racks
so that ater can reach all surfaces.
Light items (plastic bo ls etc.) should be loaded in the
upper basket and arranged so they do not move.
In case that plates are loaded in the
upper basket:
load them starting from the rear positions of the basket;
tilting them slightly forwards and avoiding the front
positions near the door.
Before closing the door, ensure that the spray
arms can rotate freely.
Adjusting the height of the upper
basket
If ashing very large plates (over 27 cm and up to 32 cm
in diameter) you can load them in the lo er basket after
moving the upper basket to the higher position.
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper basket
out ards and slide the basket out.
2. Refit the basket in the higher position and replace the
stops (A) in their original position.
When the top basket is in the higher position it
will only take plates up to 20 cm in diameter
and you will not be able to use the raised cup
racks.
After loading your machine always close the
door, as an open door can be a hazard.
US64
A
RC01
US71

8
Fitting under a counter
(kitchen worktop or sink)
By removing the machine’s orktop, you can install it
under a close fitting sink unit or a pre-existing top,
providing the dimensions of the recess correspond to
those sho n in the picture.
Proceed as follows:
- Remove the machine’s orktop by unscre ing the
t o rear retaining scre s, pull from the front and
slide out the rear slots, lifting the orktop.
Insert the machine after adjusting height and levelling ith
the adjustable feet. When inserting the machine, ensure
that the ater inlet and drain hoses are not kinked or
squashed.
Levelling
Good levelling is essential for correct closure and sealing
of the door.
When the appliance is correctly levelled, the door ill not
catch on the levelling spacers on either side of the
cabinet.
If the door does not close correctly, loosen or tighten the
adjustable feet until the machine is perfectly level.
820
570 - 600
600
IN05
IN06
IN07

9
Before starting any test it is necessary to fill completely ith salt the salt container and ith rinse aid the rinse aid dispenser
Hints for test centres
Test standard: EN 50242
Reference programme: POWER WASH
Load: 12 standard place settings
Rinse aid selector: position 5
Detergent dosage: 25 g in the dispenser
5 g on the dispenser lid
Arrangement upper basket Arrangement lo er basket
Arrangement cutlery basket
Dimensions Width 60 cm
Height ith orktop 85 cm
Height ithout orktop 82 cm
Max depth 60 cm
Max depth ith open door 115.2 cm
Electrical connection Voltage 220/240 V - 50 Hz
Motor rating during ash 200 W
Po er of heating element 2100 W
Overall po er 2300 W
Water supply pressure Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
Capacity 12 place settings
Technical specifications
