Triple BEAST Quick Start Guide
Safety Instructions
This Quick Start Guide is only intended for a temporary test setup with the standard
configuration (4.2A motors, 48V power supply, mechanical reference switches). Be sure to
read the manual completely before mounting the motors on a machine tool or using other
accessories. Have the connection of the power supply unit to the 230V mains supply
carried out by a specialist if you are not trained to do so yourself. Check all connections
carefully before switching on. If you do not understand something, please ask the dealer
where you purchased the product or Benezan-Electronics. No liability is accepted for damage to property or
injury resulting from failure to observe the manual and the statutory regulations. Protect the unit from flying
chips, dust and cooling water. Damage caused by metal chips or moisture will void the warranty.
Commissioning
1. Set the DIP switches on the TripleBeast to the correct motor current.
This is easiest to do if the device is not yet built into a housing. The
adjacent picture shows the setting when you use three identical motors
with 4.2A. Please refer to the printed table or the manual for settings
for other motors.
2. Connect the power supply unit to the mains connection via a main
switch. The main switch must switch off both poles (N and L). Make sure that both the power supply unit
and the control unit housing are connected to the protective conductor.
3. Connect power supply output (48V) and motors according to the following wiring diagram. Make sure that
the polarity of the power supply connection is correct. If you do not use an extra 24V supply, the 48V must
be fed to both supply terminals X1 and "Motor Supply".
4. If the motor cables are shielded (recommended), connect them to the bare 2.8mm flat plugs between the
black terminals. These are conductively connected to the power supply ground and the heat sink.
5. Connect the reference/limit switches (if necessary) and the emergency stop switch. Exclusively for test
purposes on freely rotating motors without mechanical connection to the machine, the emergency stop
M
M
M
Netzteil
48V =
Not-Halt
Referenz/
Endschalter
Verbraucher
L
N
