BERNHARDT 398-H04/FR4 User manual

ASSEMBLY INSTRUCTIONS FOR
398-H04/FR4 5/0 UPH BED
398-H05/FR5 6/6 UPH BED
398-H06/FR6 6/0 UPH BED
Thank you for purchasing Bernhardt Furniture. Be sure to check all packing materials carefully to
Please read all instructions carefully before starting the assembly process. Some parts are large and
heavy and require at least two people to assemble, to prevent possible injury and/or damage to furniture.
PARTS LIST
NO. DRAWING QTY. DESCRIPTION
A
B
C
D
E
C
1
2
3
5
B
A
4
HEADBOARD
FOOTBOARD
SIDERAIL
SLAT
SUPPORT LEG
1 PC
1 PC
2 Pcs
5 Pcs
10 Pcs
NO. DRAWING SIZE QTY. DESCRIPTION
1
2
3
4
5
6
Open Wrench
Hex Nut
Lock Washer
Flat Washer
T hreaded Rod
Screw
M12
5/16"
5/16"
5/16"
M4 x 1 1/4''
ASSEMBLY INSTRUCTIONS
1. Stand Headboard and Footboard in upright position and attach Threaded Rod (5) into all attachment locations.
2. Carefully slide Siderails (C) onto Threaded Rods on Headboard and Footboard. Place Flat Washer (4), Lock
Washer (3) and Hex Nut (2) onto Threaded Rod in Siderail cavity.
Tighten Hex Nuts using Open Wrench (1).
3.
.
1 PC
8 Pcs
5/16" x 3 1/2''
8 Pcs
8 Pcs
8 Pcs
10 Pcs
ensure proper assembly.
See diagram. 2 holes for Threaded Rods are located on each end of Headboard and Footboard.
Pg 1/2

ASSEMBLY INSTRUCTIONS
1. Attach Support Legs (E) to underside of Slats (D) .
2. Place Slats (D) on Siderails (C), tighten Screw (6) with Phillips Screw Driver.
3. Level bed as needed with adjustable floor glides.
6
E
D
D
LEVELER
PARTS LIST
NO. DRAWING SIZE QTY. DESCRIPTION
1
2
3
4
5
6
Open Wrench
Hex Nut
Lock Washer
Flat Washer
T hreaded Rod
Screw
M12
5/16"
5/16"
5/16"
M4 x 1 1/4''
1 PC
8 Pcs
5/16" x 3 1/2''
8 Pcs
8 Pcs
8 Pcs
10 Pcs
NO. DRAWING QTY. DESCRIPTION
A
B
C
D
E
HEADBOARD
FOOTBOARD
SIDERAIL
SLAT
SUPPORT LEG
1 PC
1 PC
2 Pcs
5 Pcs
10 Pcs
NOTE: Philips Screw Driver (Not Included) required for slat assembly.
Pg 2/2
ASSEMBLY INSTRUCTIONS FOR
398-H04/FR4 5/0 UPH BED
398-H05/FR5 6/6 UPH BED
398-H06/FR6 6/0 UPH BED
