MASTERING YOUR BERNINA®1/04/02 009DCC/1
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
MASTERING YOUR
009DCC
BERNINA®
OWNER’S WORKBOOK
Cover & Chain Stitch

MASTERING YOUR BERNINA®1/04/02 009DCC/2
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
SECTION A
Cover & Chain Stitch
Machine Set-Up
• Identifying the serger parts – Owner’s manual pg__
• Attaching the Foot Control and Power Cord – Owner's manual pg.____
• Assembling thread stand – Owner's manual pg.___
• Power Switch – Owner's manual pg.___
• Light Switch – Owner's manual pg.___
• Loopers – what are they? – Owner's manual pg.___
• The Looper Cover – Owner's manual pg.___
• Cover/Chain Stitch Foot
- Wider for better fabric feeding
- Floating toes level the foot for easier fabric feeding
- Closed holes with no thread outlet complete the threading path
Threads
Owner's manual pg.___
• Types to use
• The importance of quality threads
Needles
Owner's manual pg.___
• Always start with a new needle
• Match the needle to the fabric and thread – Owner's manual pg.___
• Change the needle often; using the needle inserter
• Loosening/re-tightening needle screws
Threading
Owner's manual pg.___
• Cone Holders and Spool Caps
- Holders used for large cones of serger thread
- Turn the cone upside down for the larger based cone threads.
- Caps used for “normal” sewing thread and decorative thread spools
• Raise the presser foot when threading
• Turn tension knobs to 1 when threading
• The threading paths – Owner's manual pg.___
• Use the road map inside the looper cover as a quick reference guide.
• Threading the first thread guide on all threads – Owner's manual pg.___. Lock thread into guide.
• Cover Stitch Threading Order –
- First – Cover Stitch Looper (Purple)
- Second – Right Needle (Green)
- Third – Left Needle (Yellow)

MASTERING YOUR BERNINA®1/04/02 009DCC/3
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
• Chain Stitch Threading Order –
- First – Chain Stitch Looper (Purple)
- Second – Left Needle (Yellow)
Test Sewing
Owner's manual pg.___
• Always start and end stitching on fabric.
• Lift the entire presser foot by the handle at the back.
• Place fabric under presser foot; lower presser foot.
• Turn the handwheel counterclockwise for the first stitch. Continue sewing; stop at the end of the fabric.
• When stitching is completed, turn the handwheel counterclockwise to lower the needles to their lowest
positions.
• Then turn the handwheel clockwise to raise the needles to their highest position; this releases the
needle threads from the looper.
• Raise the presser foot; remove work.
• Use the thread cutter to cut the thread chain.
Cleaning and Oiling
Owner's manual pg.___
• Clip all threads at the thread guide support.
• Raise presser foot.
• Turn all tension knobs to 1.
• Gently pull threads from serger. Always remove threads in the direction of sewing. If you encounter any
resistance, stop and rotate the handwheel slightly to release the threads from the loopers.
• Open the looper cover and side door.
• Using a vacuum cleaner adapter or a 1” cosmetic brush, remove all lint and fluff from the loopers and
feed dog areas of the machine.
• Following the oiling guide inside the looper cover, place a drop of oil on each of the two oiling points.
• Remove old needles and replace them with new.

MASTERING YOUR BERNINA®1/04/02 009DCC/4
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
COVER STITCH
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch using thread
colors to match the color-coded threading path on the serger (use blue thread for purple markings).
• Center the fabric under the presser foot. Lift the presser foot and place the fabric completely
under the foot.
• Turn the handwheel clockwise for the first stitch.
• Serge to the end of the fabric.
• At the end of the stitching, turn the handwheel counterclockwise until the needles are at their lowest
position. Then turn the handwheel clockwise until the needles are at their highest position to release
the threads from the looper.
• Raise the presser foot and carefully remove the work.
• Cut the thread using the thread cutter.
• Examine the serger stitch formation and compare it to the stitch graphic on page__ of the Owner's
manual.
• Read the tension adjustments information on page__ of the Owner's manual for information about
the stitch formation and correcting any stitch irregularities.
• Make any necessary tension adjustments and serge another row of stitching.
• Trim and mount the sample.
Fabric: Firm fabric, 3” x 6”
Needle: 80/12 Universal
Thread: 3 cones of serger thread
(yellow,green,blue)
Presser Foot: Coverstitch

MASTERING YOUR BERNINA®1/04/02 009DCC/5
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
MOCK FLAT FELLED SEAM
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch
using thread colors to match the color-coded threading path on the serger (use blue
for purple markings).
• Fold the fabric to form a ½” tuck lengthwise through the center of the fabric.
• Center the fabric under the presser foot. Lift the presser foot and place the fabric completely
under the foot, with the bulk of the fold to the left. Align the folded edge with the inside of the
right floating toe of the presser foot.
• Coverstitch, forming a tuck along the edge of the fabric. Serge to the end of the fabric.
• At the end of the stitching, turn the handwheel counterclockwise until the needles are at their
lowest position. Then turn the handwheel clockwise until the needles are at their highest
position to release the threads from the looper.
• Raise the presser foot and carefully remove the work. Cut the thread using the thread cutter.
• Trim and mount the sample.
Fabric: Medium weight cotton twill, 4” x 6”
Needle: 80/12 Universal
Thread: 3 cones of serger thread
Presser Foot: Coverstitch

MASTERING YOUR BERNINA®1/04/02 009DCC/6
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch
using thread colors to match the color-coded threading path on the serger (use blue
for purple markings).
• Fold up a 2” hem along the 6” edge of the fabric. Glue stick or pin in place.
• Using the markings on the stitch plate as a guide, place the fabric under the needles
with the fold to the right of the presser foot, with the right side of the fabric up and the
hem/wrong side down.
• Coverstitch the hem in place.
• Trim and mount the sample.
COVER STITCH HEM
Woven Fabric
Fabric: Medium weight cotton, 5” x 6”
Needle: 80/12Universal
Thread: 3 cones of serger thread
Presser Foot: Coverstitch

MASTERING YOUR BERNINA®1/04/02 009DCC/7
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
COVER STITCH HEM
Knit Fabric
Fabric: Cotton jersey, 5” x 6”
Needle: 80/12 Universal
Thread: 3 cones of serger thread
(yellow, green, blue)
Presser Foot: Coverstitch
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch
using thread colors to match the color-coded threading path on the serger (use blue
for purple markings).
• Fold up a 2” hem along the 6” edge of the fabric. Glue stick or pin in place.
• Using the markings on the stitch plate as a guide, place the fabric under the needles
with the fold to the right or the presser foot, with the right side of the fabric up and the
hem/wrong side down.
• Coverstitch the hem in place. There is no need to stretch the fabric while stitching, as the
cover stitch has natural stretch.
• Trim and mount the sample.

MASTERING YOUR BERNINA®1/04/02 009DCC/8
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
ATTACHING LACE
Fabric: Medium weight cotton, 3” x 6”
8” of 1” wide lace edging
Needle: 80/12Universal
Thread: 3 cones of serger thread
Presser Foot: Coverstitch
Owner’s manual pg.___
• Use spray starch or fabric stiffener to stabilize the fabric and lace.
• Position the lace on the right side of the fabric with the scalloped edge of the lace
even with the left side of the fabric.
• Place fabric and lace under the needles with the lace header positioned even with
the inside edge of the right floating toe.
• Coverstitch the lace to the fabric.
• Trim the fabric from beneath the lace.
• Trim and mount sample.

MASTERING YOUR BERNINA®1/04/02 009DCC/9
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
CHAIN STITCH SEAM
Fabric: 2 pieces of medium weight cotton, 3” x 6”
Needle: 80/12Universal
Thread: 2 cones of serger thread (yellow, blue)
Presser Foot: Coverstitch
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for chain stitch using thread
colors to match the color-coded threading path on the serger (use blue thread for purple markings).
• With right sides together, place the fabric under the needles. Align the the raw edges
with the 5/8” mark on the stitch plate.
• Turn the handwheel clockwise for the first stitch.
• Serge to the end of the fabric.
• At the end of the stitching, turn the handwheel counterclockwise until the needle is at its
lowest position. Then turn the handwheel clockwise until the needle is at its highest
position to release the thread from the looper.
• Following the instructions on page ___ of the Owner’s manual, raise the presser foot and
carefully remove the work.
• Cut the thread using the thread cutter.
• Examine the serger stitch formation and compare it to the stitch graphic on page__ of the
Owner's manual.
• Read the tension adjustments information on page__ of the Owner's manual for information
about the stitch formation and correcting any stitch irregularities.
• Make any necessary tension adjustments and serge another row of stitching.
• Trim and mount the sample.

MASTERING YOUR BERNINA®1/04/02 009DCC/10
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
ATTACHING BINDING
Fabric: Pre-quilted fabric, 3” x 6”
20” of wide prefolded bias binding
Needle: 80/12Universal
Thread: 2 or 3 cones of serger thread
Presser Foot: Coverstitch
Cover Stitch Option:
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch.
• Wrap the bias binding around one 6” side of the quilted fabric; secure in place with 505 temporary
spray adhesive.
• Place the fabric under the needles with the unstitched edge of the binding even with the inside of the
left floating toe, with the quilted fabric to the left.
• Coverstitch the binding to the quilted fabric.
Chain Stitch Option:
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch.
• Wrap the bias binding around one 6” side of the quilted fabric; secure in place with 505 temporary
spray adhesive.
• Place the fabric under the needles with the unstitched edge of the binding even with the inside of the
right floating toe, with the quilted fabric to the right.
• Coverstitch the binding to the quilted fabric.
• Trim and mount the sample.

MASTERING YOUR BERNINA®1/04/02 009DCC/11
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
CHAIN STITCH WITH DECORATIVE THREAD
Fabric: Medium weight cotton denim, 6” x 6”
Tear-away stabilizer, 6” x 6”
Needle: 80/12Universal
Thread: 1 cone of serger thread
3 cones of Isacord embroidery thread
1 cone of Yenmet metallic thread
Presser Foot: Coverstitch
Owner’s manual pg.___
• Following the instructions in the manual (page ___), thread the serger for cover stitch, threading the 3 strands
of Isacord embroidery thread together, treating them as one thread. Use a lower looper threader or dental floss
threader to thread them through the eye of the looper.
• Slightly loosen the tension on the chain stitch looper.
• Place the stabilizer against the wrong side of the denim. Place the denim right side down under the presser
foot; the stabilizer will be on top.
• Chainstitch a curved line
across the fabric.
• Turn the fabric over to see
the decorative stitching on
the right side.
• To increase the amount of
decorative thread that shows,
increase the stitch length to
3mm or 4mm. Changing stitch
length as you serge will vary
the decorative chain stitch effect.
Always use a stitch length of at
least 2.5mm.
• Stitch several more curved lines
across the fabric.
• Remove one spool of Isacord
embroidery thread and replace
it with Yenmet metallic thread.
Rethread the serger using 2
spools of Isacord embroidery
thread and 1 spool of Yenmet
metallic thread in the lower
looper.
• Loosen the chain stitch looper
tension slightly.
• Sew several additional rows of
decorative chain stitch.
• Trim and mount the sample.

MASTERING YOUR BERNINA®1/04/02 009DCC/12
BERNINA®009DCC
MASTERING
YOUR
BERNINA®
WISH LIST
Covers & Chains
Feet-ures- UnitM
Serger Technique Reference Book
Mettlerserger thread
 color________
 color________
 color________
Isacordembroidery thread
 color________
 color________
 color________
Yenmetmetallic thread
 color________
 color________
 color________
505temporary adhesivespray
Bias binding
Bias tape makers
BERNINA®IroningSystem
6” seam guide
Rotarycutter
BERNINA®cuttingmat
BERNINA®clear14” ruler
