Bertazzoni DW18S2IPV User manual

DW18S2IPV
DISHWASHER 18" STANDARD TUB PANEL READY
V TIER
Energy Star rated panel-ready standard tub dishwasher
able to fit up to 8 place settings.
Customizable and effective washing and drying with 6
washing cycles, 5 washing options and ActiveDry
system.
NSF-certified Sanitize option elevates washing
temperature to 155°F for perfect and sanitized cleaning,
eliminating 99.9% of all common household bacteria.
Dual pump system and triple-stage metal filter
ensures consistent cleaning results.
Optionally choose Professional or Master Series handle
kit to match your cooking and refrigeration appliances.
PRODUCT FEATURES
Style Panel ready for custom cabinet door,
standard tub
Interior finish Stainless steel
User interface Concealed loop button control
Display White LED
Place settings 8
Racks 2: height adjustable not loaded middle
rack and folding tines lower rack
Silverware basket Yes - removable
Delayed start Yes - 1-19h
Wash cycles 6 - auto,crystal and china,pots and
pans,quick,regular,rinse and hold
Wash options 5 - extra dry,delay start,1 half load
mode,sanitize,scrub
Spray arms 2
Drying system ActiveDry
Heating element Concealed
Filter Triple stage metal filter
Overflow protection device Yes
TECHNICAL SPECIFICATIONS
Approvals ADA Compliant,CEC,NSF,UL
Energy star Yes - tier 1 - 239.0 kwh/yr
Sound rating 51 dB(A)
Electrical requirements 120 V , 60 HZ, 1400 W, 12 A
Packaging dimensions H: 33 11/16'' - W: 20 1/16'' - D: 26
9/16''
Weight Net: 66.1 lbs - Gross: 70.6 lbs
Warranty 2 years parts & labor
ACCESSORIES
HK18PRODWX Handle kit - Professional series
HK18MASDWX Handle kit - Master series
bertazzoni.comversion: 1

DW18S2IPV
DISHWASHER 18" STANDARD TUB PANEL READY
V TIER
21 5/8"
550
2" (50)
21 5/8"
550
17 5/8"
(448)
17 5/8"
(448)
min 3 1/8" (80)
max 5 1/8" (130)
3 15/16" (100) + 2" (50) feet adjustment
WATER
DRAIN
WATER
INLET
POWER
647
25 1/2"
4 1/8"
(105)*
1 3/16"- 3 1/8"
(30-80)*
820-870
32 1/4"-34 1/4"
45 2/3"
1160
32 1/2"-34 3/8"
824-874
18" (457)*
17 3/4" (450)**
or
25"
(635)***
EWEW
EWEW
3 15/16
"
100
2"
50
* with vertical side trims installed
** without vertical side trims
ELECTRICAL & WATER CONNECTION CUSTOM PANEL
INSTALLATION REQUIREMENTS
FRONT VIEW
A properly-grounded,
horizontally-mounted electrical
receptacle should be installed
according to this drawing.
To connect the water mains to
the water inlet valve thread, use
a 3/8” water inlet hose and 3/4”
metal adapter with a length of
60” (1524) (not supplied).
Connections placement must be located on either side of the cutout.
TOP VIEW
Follow local codes & ordinances for drain requirements. Install a waste line with
an air gap (not supplied) or, alternatively, at least 30” (762) high drain loop to
prevent backow. Drain hose is 74” (1880) long. Drain hose must be connected at
minimum 20” (508) from the oor.
W
E
17 3/8"- 17 9-16"
442-446
25 1/
21
/4"-28
"
647-717
Dimensions in parentheses are millimeters unless otherwise specied.
Door tension can be adjusted to
accommodate custom panel weights
from 7 lb (3 kg) to 13 lb (6 kg).
Suggested panel thickness is 3/4” (20).
PRODUCT DIMENSIONS
CUTOUT DIMENSIONS
SIDE VIEW
SIDE VIEW
FRONT VIEW
FRONT VIEW
TOP VIEW
***Cabinet depth shown includes kitchen cabinet front
panel. For a ush installation, a minimum inset depth
of 22 1/2” (570) is required with a custom door panel
thickness of 3/4” (20).
TOP VIEW
Drain hose and toe kick
are provided with the unit
* including a 3/4” (20) thick custom panel
For complete installation details refer to the installation manual at us.bertazzoni.com or ca.bertazzoni.com
Disclaimer: while every effort has been made to ensure the accuracy of the information contained in this document, Fratelli Bertazzoni reserves the right to change it at any time without notice.
For detailed installation instructions, consult the installation manual. Fratelli Bertazzoni, Bertazzoni and the winged wheel brand icon are registered trademarks of Bertazzoni Spa. bertazzoni.comversion: 1
