Beta Three R Series User manual

R12
UM- R 1 2 - 2 0 0 9 0 6 2 9 v e r A
User Manual
R Series Dual 12 LH"
Medium Line Array System

1
1. Read the instruction manual first before using this product.
2. Please keep this manual for future reference
3. Pay attention to all warnings.
4. Obey all operating instructions.
5. Do not expose this product to rain or moisture.
6. Clean this equipment with a dry cloth.
7. Do not block any ventilation openings. Install according to manufacturer's instructions .
8. Do not install this product near any heat source, such as a, heater, burner, or any other equipment with heat radiation .
9. Only use spare parts supplied by the manufacturer.
10. Pay attention to the safety symbol on the outside of the cover.
SAFETY INSTRUCTIONS
PLEASE READTHIS MANUAL FIRST
Thank you for a buying product. Read this manual first as it will help you operate the system properly. Please keep this manual
for future reference. β
WARNING:
Thisproduct mustbeinstalledbyprofessionals.Whenusing hangingbracketsorrigging otherthan those supplied with
theproduct,pleaseensuretheycomplywith the local safetycodes.
Theexclamationpoint withinanequilateraltriangleis intendedtoalertyoutothe presenceof important
operatingand servicinginstructions.
ATTENTION: Don't refit the system or spare parts without being authorized as this will void the warranty.
WARNING: Don't place naked flames (such as candles) close to the equipment.

2
R12
4
5
3
3
3
3
4
5
4
4
6
6
6
7
PushTerminals
Nl4 Connection
System Connection Example
INSTALLATION
Installation Guidance
TECHNICAL SPECIFICATIONS
Specifications
Frequency Response And Impedance Curve
Dimensions
PRODUCT INTRODUCTION
Main Features
Product Description
Applications
CONNECTION
CONTENT
Product information updated without
notification, please visit www.elderaudio.com for the
latest update.
may be
CONTENT
R Series Medium Line Array System

R12
3
R12
The phase reversal cabinet design greatly reduce the
disturbance to low frequencies and thus enhance the
sound quality.
Main Features
PRODUCT INTRODUCTION
Double 12 LF Speaker"
Double 12 LF drivers inverted low frequency speaker."
Thesoundproducedby R12iscleanpowerfulandelastic.
Frequency Response 45 Hz 300 Hz (-3dB).
Sensitivity 92 dB, Max Sound Level 122 dB.
RMS Power 900W, Peak Power 3600w.
Product Description
and structure design as well as advanced paint spraying
techniques. It is combined of two 12 LF speakers. The"
100mm flat aluminum andTIL material bracket enable full
heat radiation.The RMS of the speaker can reach 900W
and short term peak power can reach 3600W.
Thedesignofparallelmagnetic circuitcan reducethe odd
harmonic in the LF speaker to the fullest extent.
The cabinet of R12 is made of 18mm thick plywood with
stretching resistance up to 4500N.The wedge structure
frees the cabinet from any nails. The paint on the surface
has high resistance to abrasion.The inverted bass design
which provides best sound quality is used in R12. Also the
phase reversal tube is improved to reduce the wind
speed. Thus sound quality is improved by reducing the
disturbance to the low frequencies.
Thanks to the Q235 material and the powder spraying
techniques, the grill of R12 has high intensity and high salt
mistresistance.Intheatmosphereof5%sodiumhydroxide,
it has salt mist resistance duration of 96 hours. In actual
application itcankeep itselfrustfreefor5 years.The inner
side of the grill is padded with cottons to protect it from
rains.
R12is mainly appliedin meetingrooms, largemultifunction
halls, auditorium, churches and mobile performance.The
sound characteristics of R12 can be defined as clear full"
and without any compromises on the massiness."
Applications
Religion Place
Auditorium
Multi-function hall
All kinds of living performance
Assembly room
Special designed connection accessories and hangs to
combinetheapplicationof R6and R12.Easyassembling.
The cabinet adopts new paints and advanced spraying
techniqueswhichgreatlyenhancethesurfaceresistance.
R Series Medium Line Array System
R12 is a low frequency speaker with brand new shape

CHA
BRIDGE IN
CHB
SIGN AL GND
SIGNAL +
SIGNAL -
BRID GE
PARALLEL
STEREO ON
OFF
50HZ
25HZ
ON
OFF
CHB O UTPUT
CHA O UTPUT
POWER
CABLE
FUSE
-
B
+
-
A
+
-
+
5HZ
CAUTION
BRIDGE
OUT PUT ASSI GNMEN T:
BRI DGE MON O OUTPU T:
CHA :
PIN 1+ : SI GNAL GND
CHA:
PIN 1+ :
PIN 1 - :
PIN 2+ :
PIN 2 - :
CHA SIGNAL
CHA GND
CHB SI GNAL
CHB GN D
CHB: PIN 1+ :
PIN 1 - :
PIN 2+ :
PIN 2 - :
CHB SI GNAL
CHB GN D
PIN2 + :
!
Ser ial no:
Special design for big power！
RISK OF ELECTRIC SHOCK
DO NOT OPEN
MODE LF FILTE R GROUND
CLIPLIMITER
INPUT
PIN1 :
PIN2 :
PIN3 :
1
2
1
2
3
4
1+
1-
+
-
LOW
1+ 1- INPUT
R12
INPUT
OUTPUT
No.:
ELD ER AUDIO M ANUFACTURE CO. , LTD
1+ 1- : INPUT
1+
2+
1-
2-
R12
War ranty does not
coverdamagecaused
by incorrect installation,
operation or overload.
R12 R12
+
-
LOW
SENSITIVITY(1W/1m)
IMPEDANCE
NET WEIGHT
92dB
4Ω
50kg
POWER(RMS)
FREQUENCY 45Hz-300Hz
900W
Two NL4 connectors are available for amplifier connections. Paralelled connector is very convenient for another speaker
connection.
Speakon
1. Connect 2. Disconnect
System Connection Reference
NL4Wiring Connection
CONNECTION
Warning:Please make sure the speaker impedance and polarity match the amplifiers.
R Series Medium Line Array System

(1) Open the package; take out R6, R12 and the accessories.
(2) Install four U-rings into one flying frame.
(3) Demount the ball-catch bolt from the pulling plate of R6,
place R12 pulling plate lockpin into the slot of R6 pulling
plate with holes against each other; put the ball-catch
bolt back.
(4) Insert connecting rod into R6 rear and angle-adjustment
slot of R12 on the bottom, adjust angle according to
practical needs.
(5) Install one or multiple sets of R6 by sequence onto the
bottom of the previous R6.
COMPACT LINE ARRAY SOUND REINFORCEMENT SYSTEM
5
R12
4 inch wheel
4-YXPJ-112 with baking
4-YXPJ-113 without baking
Wheel bracket｣1-AZPJ-85)
INSTALLATION
Installation Guidance
M8 locknut
Flying Frame
R12 pulling plate
R6 pulling plate
components
R6 rear connecting
rod components
R6 rear connecting
rod on the top
R6 rear connecting
rod at the bottom
Method of angle adjustment:
When the angle of hole against the connecting rod
Warning: Make sure the mounting accessories safety
factor not less than 5:1 or meet the local standard
during installation.
o
hole is 0 , insert the bolt, the vertical binding angle
of two cabinets is 0°.
R Series Medium Line Array System

6
R12
Sensitivity (dB)
20
60
70
80
90
100
110
50
Frequency Response
Impedance
18
6.5
4
50 100 200 500 2k 5k 10k 20k
1k
30
12
TECHNICAL SPECIFICATIONS
Specifications SpeakerTesting Method
1. Frequency Response
Use pink noise to test the speaker in the anechoic chamber, adjust the
leveltomakethespeakerworkatitsratedimpedanceandsetthe output
power at 1W, then test the frequency response 1m away from the
speaker.
2. Sensitivity
Use full range Pink noise which has been modified using an EQ
curve to test the speaker in the anechoic chamber, increasing the
signal to make the speaker work at its rated impedance and set the
power output at 1W, then test the sensitivity 1m away from the
speaker.
3. MAX.SPL
Use full range Pink noise which has been modified using an EQ
curve to test the speaker in the anechoic chamber , increase the
signal to make the speaker work at its maximum power output
level, then test the SPL1m away from the speaker.
4. Rated Power
Use pink noise to the IEC#268-5 standard to test the speaker,
increase the signal for a continuous period of 100 hours, the
rated Power is the power when the speaker will show no visible
or measurable damage.
Technical Specifications
45Hz-300Hz
92dB
900W (RMS)
1800W (MUSIC)
3600W (PEAK)
4 ohms
NL4×2
122dB/128dB(PEAK)
35Hz-600Hz
2×12" LF Drivers
Wedge Cabinet，18mm Plywood
Special rigging brackets
and connection accessories
Polyurethane-based painting.
Steel grille is coated by dots to
provide strong ultra-Weatherability.
Passive PaintWooden Full
Range Speaker
4
50kg(110 lb)
55kg(121 lb)
784×670×870mm
(30.9×26.4×34.3in)
2×Wooden Handles
730×630×508mm
(28.7×24.8×20.0in)
LF Driver:
1
2
3
Carry:
Packing Dimension(WxDxH):
Sensitivity(1W@1M):
Frequency Response(-3dB:
Dimension(WxDxH):
Maximum. Spl(1m):
Frequency Response(-10dB):
Product:
Power:
Rated Impedance:
Cabinet:
Installation:
Connector:
NetWeight:
GrossWeight:
Optional Accessories:
Paint:
Flight Frame
R Series Medium Line Array System

7
R12
文件（图）名
产品名称
客户/品牌/型号
版本
第8页共10页
文件（图）号
ELDER/β3/R12
英文说明书
专业音箱
516mm
[20.32in]
630mm
[24.80in]
312mm
[12.83in]
83mm
[3.26in]
730mm
[28.74in]
720mm
[28.35in]
508mm
[20.00in]
Front view
Back view
Side view
TECHNICAL SPECIFICATIONS
Dimensions
R Series Medium Line Array System

Notes:
文件（图）名
产品名称
客户/品牌/型号
版本
第9页共10页
文件（图）号
ELDER/β3/R12
英文说明书
专业音箱

文件（图）名
产品名称
客户/品牌/型号
版本
第10页共10页
文件（图）号
ELDER/β3/R12
英文说明书
专业音箱
