Genelec HT320BC User manual

The Genelec HT320BC is a three-way
active loudspeaker designed for medium
sized high quality Home Theater systems.
The HT320BC is a dedicated, magneti-
cally shielded center channel version of
the matching HT315B, offering a compact
solution where space is insufficient for
the standard enclosure. Designed as an
active loudspeaker system, it contains a
loudspeaker cabinet with multiple drivers
and a separate 3U RAM5 amplifier unit
containing power amplifiers, active cross-
over filters and protection circuitry. Neutrik
Speakon connectors are provided to facili-
tate wiring and system connection at cus-
tomer facilities. The loudspeaker performs
best when flush-mounted into a solid wall
structure.
The unique Directivity Control Wave-
guide™ (DCW™) Technology developed
by Genelec provides extremely stable and
accurate imaging and frequency balance
even in difficult acoustic environments. It
also results in perfect phase and delay
uniformity at the crossover frequency. Fur-
thermore, versatile and precise crossover
controls allow for accurate matching of
the loudspeaker system to different room
acoustic conditions.
Every amplifier is calibrated individu-
ally with its designated loudspeaker unit
before packing. This eliminates the effects
of component tolerances and ensures
consistent quality and long term reliability.
The low frequencies are repro-
duced by two long throw 250 mm (10”)
bass drivers featuring a -3 dB point at
33 Hz. The HT320BC model shares the
same midrange and high frequency driver
layout with the HT315B, consisting of a
Genelec proprietary 130 mm (5”) mid-
range cone driver and a 25 mm (1”) metal
dome HF driver loaded by the proprietary
Directivity Control Waveguide™. All driv-
ers are magnetically shielded to minimize
stray magnetic field and interference.
The amplifier unit contains an active
crossover. This is the ideal method for
dividing the input signal between the driver
units, allowing the overall response of the
system to be optimized to an extent impos-
sible with a passive system. Variable input
sensitivity and XLR line level input con-
nector provide easy connection and accu-
rate level matching to the preamplifier or
decoder.
The RAM5 amplifier unit of the
HT312BC has a 400 W amplifier for the
low frequency driver and 120 W amplifiers
each for midrange and treble drivers. The
amplifiers are designed to operate at very
low THD and IM distortion values and are
capable of driving a stereo system to peak
output levels in excess of 123 dB SPL at 2
m with music material.
The RAM5 amplifier incorporates spe-
cial circuitry for driver overload and ampli-
fier thermal protection, as well as an
“Autostart” function for automatic switch-
ing between “Standby” and “On” power
modes. The power mode can also be
changed with a 12 V trigger voltage or
external switch or relay type remote con-
trol. An LED indicator on the DCW™ plate
displays the system status. “Autostart” and
“Remote control” functions can be enabled
or disabled as required.
Contact your local Genelec dealer for an
audition and see Genelec’s Home Theater
website www.genelec-ht.com for more
information on Genelec’s Home Theater
loudspeaker line.
Genelec HT320BC
Three-Way Active Loudspeaker
Data Sheet
HT320BC
HT320BC Data Sheet
Genelec Document BBA0069001a. Copyright Genelec Oy 11.2008. All data subject to change without prior notice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email [email protected]
In the U.S. please contact:
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, U.S.A.
Phone +1 508 652 0900
Fax +1 508 652 0909
Email [email protected]
www.genelec.com
In Sweden please contact
Genelec Sverige
Ellipsvägen 10B
P.O. Box 5521, S-141 05 Huddinge
Phone +46 8 449 5220
Fax +46 8 708 7071
Email [email protected]
system specifications
Ht320Bc
Lower cut-off frequency, -3 dB
Upper cut-off frequency, -3 dB
Free field frequency response
of system
≤ 33 Hz
≥ 20 kHz
35 Hz - 20 kHz (±2.5 dB)
Maximum short term sine wave
acoustic output on axis in half space,
averaged from 100 Hz to 3 kHz
@ 1 m ≥120 dB SPL
Maximum long term RMS acoustic
output in same conditions with IEC-
weighted noise (limited by driver unit
protection circuit)
@ 1 m ≥116 dB SPL
Maximum peak acoustic output per
pair with music material
@ 2 m ≥124 dB
Self generated noise level in free field
@ 2 m on axis
≤15 dBA
Harmonic distortion at 95 dB SPL at
1m on axis:
freq. 50...100 Hz <1%
freq. >100 Hz <0.5%
Drivers
Bass
Midrange
Treble
All drivers are magnetically shielded
2 x 250 mm (10”) cone
130 mm (5") cone
25 mm (1") metal dome
Weight
Loudspeaker
Amplifier
60 kg (130 lb)
15 kg (33 lb)
Loudspeaker dimensions
Height
Width
Depth*
Amplifier dimensions
Height
Width
Depth*
350 mm (13 3/4”)
950 mm (37 3/8”)
453 mm (17 7/8”)
133 mm (5 1/4”) (3 U)
483 mm (19”)
380 mm (15”)*
* Note that the cable connectors require additional
100 mm (4”) of space behind the loudspeaker cabinet
and the amplifier.
Ht320Bc
Input connector XLR female pin 1 gnd
pin 2 +
pin 3 -
Input impedance 10 kOhm
Input level for 100 dB SPL
output @1m
variable from +6 to -6 dBu
Input level for maximum short term
output
variable from +26 to +14 dBu for 120 dB SPL @1m
Subsonic filter 18 dB/octave
below 33 Hz
Ultrasonic filter 12 dB/octave above 25 kHz
Crossover frequency
Bass/Mid
Mid/Treble
410 Hz
3 kHz
Crossover acoustical slopes 24 - 32 dB/octave
Crossover level control operating
range in 1 dB steps
Bass
Mid
Treble
from 0 to -6 dB
from 0 to -6 dB
from 0 to -6 dB
Bass roll-off control in 2 dB steps from 0 to -8 dB @ 33 Hz
Bass tilt control in 2 dB steps from 0 to -8 dB @ 80 Hz
The 'CAL' position is with all tone controls set to 'off'
and input sensitivity control to maximum.
Ht320Bc
Bass amplifier short term output power 400 W (4 Ohm load))
Midrange amplifier short term output
power with an 8 Ohm load
120 W
Treble amplifier short term output
power with an 8 Ohm load
120 W
Long term output power is limited by driver unit protec-
tion circuitry.
Slew rate 80 V/µs
Amplifier system distortion at nominal
output
THD
SMPTE-IM
CCIF-IM
DIM 100
≤0.05%
≤0.05%
≤0.05%
≤0.05%
Signal to Noise ratio, referred to full
output
Bass
Midrange
Treble
≥100 dB
≥100 dB
≥100 dB
Mains voltage 100/200V or 115/230V
Voltage operating range nominal ±10%
Power consumption
Idle
Full output
60 W
500 W
Autostart Signal sensing Standby/On switching
Remote control Remote controlled Standby/On switching by 12 V
trigger or external switch
amplifier section
crossover section
In China please contact:
Beijing Genelec Audio Co. Ltd.
Jianwai SOHO, Tower 12, Room 3304
39 East 3rd Ring Road
Chaoyang District
Beijing 100022, China
Phone +86 10 5869 7915, Fax +86 10 5869 7914
