Better BT0323 User manual

DVD/VCD/CD/MP3/MP4/SD/USB PLAYER, BLUETOOTH WITH FM/AM TUNER
BT0323
Operating Instructions

1
Safety Precautions
Safety Precautions .........................................1
Panel Controls................................................2
Remote Controls......................................... 3-4
General Operation ..................................... 4-5
iPhone Operation............................................6
Radio Mode ....................................................7
USB/SD/MMC/MP3 Mode ..............................8
Disc Mode................................................. 8-10
Bluetooth Mode .......................................11-12
Track Playback ....................................... 13-14
DVD Setup.............................................. 15-16
Electrical Connections..................................17
Anti-Theft System.........................................18
Installation Guide..........................................19
Troubleshooting............................................20
Specications ...............................................21
Contents
Note:
• Playingadefectiveordustydisccancause
dropouts in sound.
• Holddiscsasillustrated.
• Donottouchtheunlabeledside.
• Donotattach anyseal,labelordata
protection sheet to either side of a disc.
• Donot exposea disctodirectsunlightor
excessiveheat.
• Wipea dirtydisc fromthe centeroutward
withacleaningcloth.
• Never use solvents such as benzine or
alcohol.
• Thisunitcannotplay3-inch(8cm)discs.
• Neverinserta3-inchdisccontained inthe
adapter or an irregularly shaped disc.
The unit may not be able to eject it.
Precautions
• Useonly ina 12-voltDC negative-ground
electrical system.
• Whenreplacingthefuse,besuretouseone
withanidenticalamperagerating.Using
afusewithahigheramperagerating may
cause serious damage to the unit.
• Donotattempt todisassembletheunit.
Laser beams from the optical pickup are
dangerous to the eyes.
• Makesurethatpinsorotherforeignobjects
do not get inside the unit; they may cause
malfunctions,orcreatesafetyhazardssuch
aselectricalshockorlaserbeamexposure.
• Ifyouhaveparkedthecarforalongtimein
hotorcoldweather,waituntilthetemperature
in the car becomes normal before operating
the unit.
• Keepthevolumeatalevelatwhichyoucan
hearoutsidewarningsound(hornssirens,etc.).
• Donotopencoversanddonotrepairthemby
yourself.Consultthedealeroranexperienced
technician for help.
• In addition to ordinary CDs, this unit can
playbackCD-RorCD-RW,MP3.
Toprovideacleardemonstrationand an
alternativeforeasyunderstanding ofthe
operationofthisunit, graphicillustrationis
used.
However,thisillustration isnotnecessarily
printed as the actual image found on the unit.

2
Panel Controls
Power on/off: Press to turn on/off the unit.
1. Disc eject
2.-Poweron/off(pressmorethan2seconds)
- Mute
3. -Tofastsearchwithinatrack/skiptonextor
 previoustrack
- Track seek
4.-Aux
- I-MODE
 -BTMUSIC(inBluetoothmode)
- Tuner
 -Disc(whendiscinserted)
-USB(whenUSBinserted)
-Card(whenSD/MMCinserted)
5. Panel open
6. -Radio station auto preset
- Press to tune in a preset station.
- Holdformorethan2secondstostorestation.
10. Radio local/distant
11.AUXIN
12. USB connector
13. Disc slot
14. Remote sensor
15.-Rotatethecontroltoadjustvolumelevel
- Audio mode select.
- Press more than 2 seconds to enter into
menu mode.
16.-BandSwitch:
FM1 - FM2 - FM3 - AM1 - AM2
 -REDial/Answer/Transferthecall
(Bluetoothmode)
 -Hangupthecall
7. SD/MMCcardslot(locatedbehindthefront
panel)
8.-Shortpresstoswitchtoclockdisplay,
pressagaintoexit.
- Long press to enter clock setting.
9.1button:Play/Pause
2button:scanplay
3button:Trackrepeatplay
4button:Trackrandomplay
5button:-VideosystemNTSC\PAL\AUTO
-Selectfolderdown
6button:-DVDaudio/VCDaudioL/R/ST
- Select folder up
*1-6Radiopreset:

3
Remote Controls
Power on/off: Press to turn on/
off the unit.
Replacing the lithium battery of
remote control unit.
Whentherangeofoperationofthecard
remotecontrolbecomesshort ornofunction,
replacethelithiumbatterywithanewone.
Make sure the battery polarity replacement is
correct.
1.Pulloutthebatteryholderwhilepressingthe
stopper.
2.Insertthebutton-typelithiumbatterywith
the(+)markfacingupward.Insertthebattery
holder into the remote control.
1 2
(CR 2025)
1.Zoom(DVD/VCDonly)
2.Title(DVDonly)
3.Poweron/off
4. Setup
5. Menu cursor
6. Enter
7. Program
8. Digit area
9. -Shortpresstoselectaudiomenu,and
 rotatetheknobtoadjustlevel.
 -Longpresstoenterintosettingmenu,
then each press changes the mode.
10. Volume
11. Mute
12. - Radio tune
- Track skip/seek
13.Subtitle(DVDonly)
14.-Aux
- I-MODE
 -BTMUSIC(inBluetoothmode)
- Tuner
 -Disc(whendiscinserted)
 -USB(whenUSBinserted)
 -Card(whenSD/MMCinserted)
15. Repeat
16. Repeat A-B
17. Stop/Return
18. Play/Pause
19. Goto search
20. - DVD menu
 -PBC(forVCD2.0orup)
21.-OSD:Onscreendisplay
 -AMS:Radiopresetscan/Radioauto
preset
22. - DVD audio
- VCD audio L/R/ST
23.-Shortpresstoswitchtoclockdisplay,
 pressagaintoexit.
- Long press to enter clock setting.
 -Returntopreviousmenu(Settingmenu)
24.-Angle(DVDonly)
 -Hangupthecall
25.-VideosystemNTSC\PAL\AUTO
 -Radioband(inRadiomode)
 -REDial/Answer/Transferthecall
 (Bluetoothmode)

4
Remote Controls
Remote control operating range
Theremotecontrolcanoperatewithina
distance of 3~5m.
Warning
• Storethebatterywherechildrencannot
reach.Ifachildaccidentallyswallowsthe
battery,consultadoctorimmediately.
• Donotrecharge,short,disassembleorheat
thebatteryordisposeitinare.
• Donotleavethebatterywith othermetallic
materials.Otherwise,the battery may start
togiveoffheat,crackorcatchre.
• Whenthrowingaway orsaving thebattery,
wrapitintapeandinsulate.
General Operation
Switching on and off
1. Press to turn on the unit.
2. Press SRC once or more to select your
desiredfunction:Aux(Aux-in),I-MODE,BT
MUSIC,Tuner(Radio),DISC,USB,CARD.
3. Long press againtopoweroff.
4.When you switch off the system or car
ignition,thesettings,tuner presetsandthe
volumelevelwillberetainedintheunit's
memory.
Clock Display
Press DISP on the panel or on the remote
controltodisplayclocktime,andpressDISP
againtoexit.
Clock Setting
1. Press DISPmorethan2seconds,hour
displayblinks, then rotatetheknob to set
hour.
2. Press the VOLknobtoconrm,andminute
displayblinks,thenrotatetheVOL knob to
set minute.
3. Press DISPagaintoexit.
Audio Setting
Press the VOL knobtoselectaudiosetting,
and rotate the knob to adjust.
- VOL
DisplayshowsthevolumelevelVOLandnum-
ber from 0 to 40.
- BAS
DisplayshowstheBASSlevel.
BASSrange:-7to+7.
- MID
DisplayshowstheMiddlelevel.
Middlerange:-7to+7.
- TRE
DisplayshowstheTREBLElevel.
TREBLErange:-7to+7.
- BAL
DisplayshowstheBALANCElevel.
BALANCE range:12L(full left)to12R (full
right).
L=leftspeaker,R=rightspeaker.
- FAD
DisplayshowstheFADERlevel.
FADERrange:12R(full rear)to12F(full
front).
R=rearspeaker,F=frontspeaker.

5
General Operation
Menu Setting
Press the VOL knob more than 2 seconds
toenterintomenumode,theneachpress
changes the mode.
- EQ Mode
TheEqualizerfunctionappliespresetsound
effects to the unit’s audio output signal. Rotate
theknobtoselectEQsoundeffect:
FLAT-CLASSIC-ROCK-POP-JAZZ-USER
Withtheequalizerfunctionactivated,ifbassor
trebleisadjusted,theEQModewill revertto
“Off”.Whentheequalizerfunctionisactivated,
themostrecentlyselectedbass/treblelevels
cannotbeadjusted.When theequalizer
functionisnotactive,theunitwillreturntothe
mostrecentlyselectedbassandtreblelevels.
- LOUD ON/ OFF
When listening tomusicat low volumes,this
featurewillselectivelyboostcertainbassand
treble frequencies.
- BEEP ON/ OFF
Thebeeptonefeatureallowstheselection of
an audible beep tone to be heard each time
the menu is accessed.
- SUBW ON/ OFF
Rotatetheknobtochoosesubwoofer-outon
or off.
- 12 /24 HOURS Mode
12 HOURS MODE:
The clock displays in the type of 12 hours such
as 11:18 AM.
24 HOURS MODE:
The clock displays in the type of 24 hours such
as 20:18.
- MONO/STEREO
Selectable when the current source is Radio
mode.
Thisoptionallowsyoutoselect radio FM
mono/stereo.
- AREA SET
Thisoptionallowsyoutoselecttheappropriate
frequency spacing for your area.
Rotate the knob to choose USA or Europe.
- SWC SET
Rotatetheknobtoselecta SWCcontrol
button:POWER-MUTE-SOURE-VOLUP-
VOLDN-SEEKUP-SEEKDN-BAND
- AUTO ON/OFF
Whenyouturntheuniton,thebuilt-inbluetooth
willsendconnectionorderautomaticallyifyou
havesetthe‘AUTO’to‘ON’.

6
iPhone Operation
Accessing iPhone mode
Press the SRCbuttononthefrontpanelorremotecontroltoswitchtotheI-MODE source.
Audio
Pausing play
Press the [ 1 ] button on the front panel or the [ ] button on the remote control to pause play.
Selecting a track
Track-up
1. Press the [ ] button to move to the beginning of the next track.
2. Each time you press the [ ] button, the track advances to the beginning of the next track.
Track-down
1. Press the [ ] button to move back to the beginning of the current track.
2. Press the [ ] button twice to move back to the beginning of the previous track.
Receive
After iPhone connected, if there is a call incoming, Press [ 1 ] button to receive. Press [ 1 ] button again to hang up.
SIRI ( only for iPhone 4S and higher version )
1. Press the knob to turn on the SIRI function.
2. Press the [ 1] button to turn off the SIRI function.

7
Radio Mode
Selecting a Band
Press BAND once or more to select FM1 -
FM2 - FM3 - AM1 - AM2.
Displayshowswaveband,frequency,and
preset station number if already stored.
Selecting a Station
Press the or tuning button to tune to
another station.
Tuning
- AUTO SEEK
Press the or buttonstoseekthenext/
previousstationautomatically.
- MANUAL SEEK
Press and hold the or buttons to enter
manual tuning mode. Press the buttons again
tomovetheradiofrequencynumberup or
downonestep.
Note:
• Duringmanual seeking,ifthepause
betweentwooperatingstepsis longerthan
5seconds,whenyoucontinuetopress the
or buttons, theunit willenter auto
seeking.
• Duringmanualseeking,whenyoupressand
hold the or buttons,theunitwillseek
continuously.
Preset Mode
Sixnumberedpresetbuttonsstoreandrecall
stations for each band. The stored stations
(1-6)forthecurrentbandcanbeviewedon
the screen.
Storing Stations
- Auto storing
1.Selectaband(ifneeded).
2. Press AMS briefly to search all stations in
the band,the6strongestavailablestation
willbeautomaticallysavedinthepreset
button(numbers1-6).
- Manual storing
1.Selectaband(ifneeded),thenselecta
station.
2.Pressand hold a preset button (numbers
1-6)onthefrontpanelorremotecontrol.
Recalling a Station
1.Selectaband(ifneeded).
2.Pressapresetbutton(numbers1-6)onthe
front panel or remote control to select the
corresponding stored station.

8
USB/SD/MMC/MP3 Mode
Accessing Disc Mode
If a disc is already in the disc slot but is not
playing,presstheSRC button on the front
panelorontheremotecontroltoswitchtothe
DISCsource.ToplaylesfromanSDorUSB
that is already inserted, choose the CARD
or USB source. The disc playback screen is
indicatedbelow:
Disc Mode
1. Source Indicator
2. Current Track/Total Track
3.NameoftheSongDisplay
4. Audio Folder
5. Picture Folder
6. Video Folder
2
4
5
6
1 3
1. Loading SD/MMC Card
Insert the SD/MMC card into the slot.
 Theunitwillplaythemusicautomaticallyandthe LCDwillshow
CARD.
2. Take out SD/MMC Card
 PushSRCbuttonandswitchtononCARDmode,slightlypressSD/
MMCcard,takeoutthecardwhenitwaspoppedout.
3. Loading USB equipment
 Opentherubbercap,inserttheUSBintotheconnectorandtheunit
playthemusicintheUSBstorerautomatically,and theLCD will
showUSB.
4. Take out USB equipment
 PushtheSRCbuttonandswitchtononUSBmode,thentakeoffthe
USBstorer,closetherubbercap.
USB/SD/MMC Notes
USBfunctions(ashmemorytype)MP3musicplay.
1. SD/MMC card support.
2.USBashmemory2in1(SD/MMC)support.
3. Support FAT 16 & FAT 32
4.Filename:32byte/dirname:32byte/tagname:32byte.
5.Tag(id3tagver2.0)
Title/artist/album:32bytesupport.
6. Multi card reader not support.
7. USB 1.1 support.
Not all kinds of USB devices are compatible with the unit.

9
Insert a Disc
Insertthediscintotheslot, andthe unitwill
change to disc mode automatically.
Note:
• Pleaseconrmwhetherthereisadiscin
the unit before you insert another one.
• Theunitwillexitcurrentplayingsourceand
enterDVDmodewhenonediscisinserted.
Eject the Disc
Press to eject the disc.
Note:
• Afterejectingthedisc,theunitrevertsto
radio mode.
• Youcanejectadiscwiththeunitpowered
off. The unit remains off after the disc is
ejected.
Disc Playback
1.Whendisc inserted, display shows LOAD.
ForMP3ordiscwithmixedfiles,reading
timemayexceed1minute.
2.ERRORwillbedisplayediferrorfoundin
disc operation.
3.ForVCD/CD,VCDorCDiconwillappear
on the display.
4.WhileMP3/WMAlesplayback,MP3/WMA
iconwillappearonthedisplay.
5.ForDVD,DVDiconwillappearonthe
display and TITLE appears. Press ENTER
or to play.
File Type Supported
Audio le: MP3(*.mp3), WMA(*.wma)
Video le:
MP4 (*.avi, DIVX3.11/4.0/5.0/6.0)
MPEG 2 (*.vob)
MPEG 1 (*.dat)
Picture le: JPEG (*.jpg)
MP3 le:
ISO9660orISO9660+Jolietformat- Max.
30 characters.
Max. nested directory is 8 levels.
The max. album number is 99.
The max. length of each track is 99 minutes
59 seconds.
Supported sampling frequency for MP3 disc:
8KHz to 48KHz (44.1KHz preferably).
Supported bit-rates of MP3 disc are: 32 - 320
kbps (128 kbps preferably).
Disc and File NOT Supported
*.AAC, *.DLF, *.M3U, *.PLS, MP3 PRO files
and files with DRM.
Open session discs.
Audio/Picture/Video File Playback
WhenAUDIO/PICTURE/VIDEO leisplayed,
Category/Folder/Filelistwillbedisplayedon
thescreen,andle/foldernamebeing played
willbedisplayedontop.Currentselecteditem
willbehighlighted.
Category Select
Use / to select AUDIO
VIDEO
Press ENTERtoconrm.
Folder Select
Use / to enter folder list and use / to
selectdesiredfolder,pressENTERtoconrm.
File Select
Use / to enter file list and use / to
selectdesiredle,pressENTER to play back.
ForPICTURE,press  to slide show the
pictures,pressPROG to select picture
showingstyle.
ForMUSIC,press willenterpoweron logo,
then press to return.
Disc Mode

10
Note:
MP3andWMA(WindowsMediaAudio)music
lesaredigitalaudiolesthatarecompressed
toallowmorefiles tobe stored.Thisunit
canplayMP3/WMAandvideodirectlyfrom
filescontainedonaCD-R/RW,DVD-ROM,
DVD+RW, DVD-RW,DVD+R,DVD-Rand
DVD-VIDEO, oran SD card orUSBDevice.
Manytypesofsoftware areavailable forcon-
vertingaudiofilesinto MP3/WMA formats.
NeroorRoxioEasy CDCreatorarerecom-
mended.ThisunitcanplayMP3(MPEG1,2,
2.5AudioLayer3).However,theMP3record-
ing media and accepted formats are limited.
Entering ID3 Tag
ThisunitsupportsID3tagversion2.0.
Forcharactercodes,refertothetabletothe
below.
Entering File and Folder Names
Namesusingthecode listcharactersarethe
only file names and folder names that can
be entered and displayed. Using any other
characterwillcausethe leand foldernames
tobedisplayedincorrectly.Theunitrecognizes
andplaysonlyfiles withthe MP3/WMA
extension.
Note:
Alenameenteredwithcharactersnotonthe
code list may not play correctly.
Electronic Shock Protection
• 10secondsforCD-DA(CDA)
• >45secondsforMP3recorded at44.1kHz,
128kbps
• >90secondsforWMArecordedat44.1kHz,
128kbps
Bit Rates
The unit supports bit rates from 32 - 320 kbps.
MP3 Playing Order
When selected for play, files and folders
(FolderSearch,FileSearchorFolderSelect)
areaccessedinthe orderinwhichtheywere
writtentothemedia.Asa result,the orderin
whichtheyareexpectedtobeplayedmay
notmatchtheorderinwhichtheyareactually
played. You may be able to set the order in
whichMP3/WMAfilesareto beplayed by
assigningfilenamesbeginningwithplay
sequence numbers such as "01" to "99". For
example,amediumwith thefollowing folder/
lehierarchyissubject toFolderSearch,File
SearchorFolderSelectasshownbelow.
()
0

1

2♪①
♪②

5
♪⑧
♪⑦

6

7♪⑨
♪③

3

4
♪④
♪⑤
♪⑥
Layer1 Layer 2 Layer 3 Layer 4 Layer5
○Root Folder
Folder
♪File
Theplayerwillonlyrecognizethreefolder
levelsanddoesnotdisplayfolderscontaining
onlyotherfolders.In theexampleabove,the
unitwilldisplayfolders 3,4, 6,and 8,butnot
2 and 7 since they do not contain any tracks
directly.Folder5isnotrecognizedatallsince
itisatthefourthlevel.
Disc Mode

11
Bluetooth Mode
Note:
Foryoursafety,avoidtalkingonthephoneas
muchaspossiblewhiledriving.
Bluetoothis awireless transmissionway
for short distance. The built-in Bluetooth
canconnectwiththemobilephoneshaving
Bluetooth function.
Afterconnecting,youcancontrolyour mobile
phone through the unit.
Pairing
Use this function to establish a connection
betweentheunitandyourmobilephone.
1. Press and hold SRCbuttonuntil“PAIRING”
appears on the LCD.
2. Turn on Bluetooth function of your mobile
phone,keepphonewithin 3metersto
the unit and start to search for Bluetooth
devices.
3. After the name of the Bluetooth module
“BETTER” appears on the pairing list of your
mobilephone,selectit.Atthistime,apairing
code is required. Enter the pairing code
(“1234”bydefault)andtheBluetoothpairing
willprocessautomatically.Some mobile
phones may instruct you to select connect
ordisconnect,pleaseselectconnecting.
Exit Pairing
After pair successfully, ifyouwantto
disconnect,pressandholdSRC button until
“PAIR OUT“ appears on the LCD.
Make a Call
Afterpairsuccessfully, pressSRC button
repeatedly to select BT MUSICsource,press
button to dial the last number you called.
Receive
1. After pair successfully, if there is a call
incoming,theunitswitchtoBTMUSICmode
automatically.
2. Press to receive.
3. Press to hang up.
Voice Transfer
During talking, press button to transfer audio
from the unit to your mobile phone.
Note:
Some mobile phones will transfer audio from
the unit to themselves once the incoming call
is answered.
BT Audio
(if the mobile phone has the A2DP & AVRCP
functions)
Afterpairsuccessfully,open the audio player
and set the transmission mode to Bluetooth.
The audio will be transferred from the mobile
phone to the unit. Some mobile phones may
hint that to connect with the unit. After found
the Bluetooth device name “BLUETOOTH” on
mobile phone, you should select to connect
it, and then input the pairing code (“1234” by
default). When music playback, touch to
play/pause, and press / key on the
front panel or remote control to previous/next
track (if the options are available).

12
Bluetooth Mode
Auto Connect
Press the knobtoentermainmenu,andselect
[AUTOON]or[AUTOOFF]inthemenu.
AUTO OFF: After paired OK, if the distance
between mobile phone and the unit is over 10
metres, the connection will exit. The Bluetooth
technology will not automatically establish a
connection.
AUTO ON: After paired OK, if the distance
between mobile phone and the unit is over 10
metres, the connection will exit. The Bluetooth
technology will automatically establish a
connection between the unit and the registered
mobile phone when the transmission distance
is 10 metres or shorter.
Whether the automatic connection is ON or
OFF, when power is off then on again, the unit
Bluetooth will connect the mobile phone (if the
Bluetooth function turning on) which is paired
OK last time.
Note:
1.Toconnectautomaticallyas shownabove,
the unit must connect the mobile phone
successfully before.
2.Theunitwilltrytoconnectthemobilephone
pairedwhenon,mostmobilephone will
connectautomatically,some needconnect
manuallyduetodifferentsoftwaresetting.
Music Mode
A2DP
A2DP is short for Advanced Audio Distribution
Profile. The mobile phones supporting this
function can transmit stereo audio, whereas
the ones not supporting this function can
transmit mono audio only.
AVRCP
AVRCP is short for Audio/Video Remote
Control Prole. The mobile phones supporting
this function can control the playback of a
Bluetooth audio player.
In the mode of the music player working, if you
want to make a phone call, disconnect A2DP,
otherwise the LCD will display “BUSY“ when
you dialing out.
General Notes for Bluetooth
1.ForN7X,N9X,PHILIPS,SonyEricssion,
SAMSUNGmobilephones,duringourtest,
after the mobile phones appear connection
successful,theunitstillappearwaiting for
pairing.Atthistimeyoumustndtheunit’s
Bluetoothmodulename“BLUETOOTH”on
the pairing list on your mobile phone and
selectconnectinginthesubmenu,thenthe
unitwillappearpairOK.Otherwise,thereis
novoicecomingoutwhencommunicating,
though the mobile phone has already
displayedpairOK.Somemobilephones,
suchasPHILIPS,whenitplaybacksA2DP,
youmustfindtheunit“BLUETOOTH”in
thephone’smenuandreconnect(check
yourmobilephonewhetherhastheA2DP&
AVRCPfunctions).
2.Whenpairing,sometypesofmobilephone
hintthathowtooperate,forexample,when
youmakeaphonecallbytheunit,ifthe
mobilephonevoicedosn’tbetransferred
totheunit,novoicecomes out.The
SAMSUNGmobilephonehints thatvoice
shouldbetransferredtoBluetoothdevice.
3.Dependingon themobile phone,ifprivate
modeisselected,when youmakeaphone
callbytheunit,orreceive,the voicewould
be transferred to the mobile phone. But
sometime the Bluetooth maybe disconnect
tillthecommunicationends,thenconnects
your mobile phone to the unit automtically.
Some mobile phones maybe need pair
again.
4.For mobile phone, the Bluetooth device
name must be primary symbols or numbers.
Otherwise,someunpredictableissues
mayoccurduringtheBluetoothdevices
connecting and making phone call.
5.After pairedOK,ifnosoundproduced,
pleasecheckwhetherthe Bluetoothstereo
audioonthephoneswitchedON.

13
Track Playback
Select Desired Track
- Press or toskiptothenexttrack.
- Use 1-9and0, 10+buttonson theremote
control to select desired track number.
Fast Forward/Backward During
Playback
Press or for more than 2 seconds once
ormoretoselectX2,X4, X8,X20 tofast
backwardorforwardtrackduringplayback.
-Duringthefastforwardorbackward
operation,press brieytoplaybackagain.
-Duringthefastforwardorbackward
operation,thevolumewillbemuted.
Intro (for CD/VCD only)
Youcanplaythebeginningofevery trackfor
10 seconds in sequence.
1.Duringplayback,pressINT once.
 SCANON/OFFwillappearonthedisplay.
2. Press INT again to select the current track.
Random Rrack Playback (for CD/
VCD/MP3 Only)
You can play all the tracks in random order.
1.Duringplayback,pressRDM once or more.
 -RDMiconwillappearonthedisplay.
2. Press RDM again to select normal playback.
Repeat
Duringplayback,pressREPEAT or RPT once
or more.
- RPTiconwillappearonthedisplay.
- ForVCD/CD:DisplayappearsRPTONE
RPT ALL RPT OFF
- For DVD:DisplayappearsRPTCHAPTER
RPT TITLE RPT OFF
- ForFiledisc:DisplayappearsRPTONE
RPT DIR RPT ALL RPT OFF
Note:Ifyoudo notselect RPTon,whenthe
entirediscorTITLEplaybackhasfinished,
thesystemwillstop.Ifnoothercontrol,after5
minutestheunitwillturnintostandbymode.
Repeat A B
Select desired passage to repeat playback.
- Press A B once to select starting point.
DisplayshowsREPEATA.
- Press A B again to select ending point.
 DisplayshowsREPEATA  B,  a nd
selected passage start to replay.
- Press A Bonceagaintoexit.
 DisplayshowsA BCANCEL.
Pause
- Duringplayback,press to paus e
playback.
- Thesoundwillbemuted.
- Display"PAUSE"intheTV screen,display
and blink "PAUSE" on the panel display.
Press again to continue playback.
PBC - Playback Control (for VCD only)
1.IfyouinsertaVCDwithPBC,playback
starts from the beginning of the 1st track
automatically.
2. Press MENU PBC toshowmenu,use
/ or digit button to select desired track.
Press toreturn to poweronlogo. Press
MENU PBCagaintoexitmenu.
On the remote
control

14
DVD Subtitle Select
Press SUB.T to select the subtitle language
toshowiftheDVDhasmultiplelanguage
subtitles.
DVD Title Select
Press TITLEtodisplaytitleorchapterlist,use
/ or / cursorordigitnumbertoselect,
press ENTER to play.
DVD Angle Select
Press ANGLEtoselectdifferentangletoview
iftheDVDhasmultiple-angleviews.
Zoom
Press ZOOMbutton,thepicturewillbe
zoomedaccordingly.
Track Playback
GOTO
Goto desired track/chapter or time point
directly.
Press GOTObuttonon theremotecontrol,
track or DVD Title/Chapter and time display on
top of the screen. Current item is highlighted.
Use / to select desired item. Use digit
button to select number. Press ENTER to
conrm.
Program
- Press PROG to enter program list. Use
/ or / cursor and digit button to enter
number.
 ForDVDandFiledisc,selecttitleand
chapter number.
 ForVCDandCD,selecttracknumber.
- Press  toplay,ormove thecursor to
select "PLAY" and press ENTER to play.
- Ifyouwanttodeletethelist,movethecursor
to"CLEAR",pressENTER to delete all the
list set before.
- Press PROGagaintoexitprogramplay.
DVD Audio Select
Press AUDIO or R/L to select audio language
to listen if the DVD has multiple audio
languages.
VCD Audio Select
Press R/L to select audio channel to listen.
PROGRAM
PROGRAM

15
Press SETUP to display setup menu on the
screen.
Use toselectsetupitems:
SYSTEM - LANGUAGE - VIDEO
DVD System Setup
Use , to select and ENTERtoconrm.
- TV SYSTEM: NTSC/PAL/AUTO
Select the TV system in the setting menu.
- TV TYPE: 4:3PS/4:3LB/16:9
SelectTVtypetowatchwidescreenmovies.
4:3PanScan:For4:3TV,leftandrightedges
willbecut.
4:3LetterBox:For4:3TV,blackbarswillap-
pear on top and bottom.
16:9:For16:9widescreenTV.
DVD Setup
- PASSWORD
1. Press number button " 0000 " on the remote
control,thenpresstheENTER button to
conrm.
2.Pressthedesired4-digitpassword,andthen
press ENTERbuttontoconrm.
3.Recordthepasswordandkeepitinasafe
place for future reference.
If you forget the password, please
enter 0000 to reset a new password.
The password: 0000
- RATING:
1 KID SAFE/2 G/3 PG/4 PG13/5 PG-R/6 R/7
NC-17/8 ADULT
Theratingofthediscisfrom1to8:
(1)withthemostlimitswhenplaying.
(8)withtheleastlimitswhenplaying.
Originalsetting:8
Note:
The rating can be selected only under the
passwordunlockedstatus,and thelimitscan
beworkedonlyunderthepasswordlocked
status.
- DOWNMIX:
LT(/RT)/STEREO/VSS
Select composite audio output from 2 channel
speaker system.
- DEFAULT: RESTORE
Ifthisitemisselected,theunitwillreturnto
original setting.
DVD Language Setup
Use , to select and ENTERtoconrm.
- OSD LANGUAGE
Selectonelanguagethatyouarefamiliarwith
to display system menu.
- AUDIO LANG
Select one dialogue language that you are
familiarwithwhenplayingbackDVDdiscs.
Note:
If the DVD disc has the audio file in the
selectedlanguage,thedialogues youlistened
towillbeintheselectedlanguage.
IftheDVDdiscdoesnotcontaintheaudiole
intheselectedlanguage,thedialoguesyou
listenedtowillbeinthedefaultlanguage.

16
You can change the language by pressing
[AUDIO] key of the remote controller.
- SUBTITLE LANG
Selectonelanguagethatyouarefamiliarwith
to display DVD subtitles.
If the DVD disc has the subtitle file in the
selectedlanguage,thesubtitle willbe
displayed in the selected language.
If the DVD disc does not contain the subtitle
leintheselectedlanguage,thesubtitlewillbe
displayed in the default language.
- MENU LANG
Selectonelanguagethatyouarefamiliarwith
to display DVD menu.
Note:
IftheDVDdisc hastheselectedlanguage,
theDVDMENU/TITLEwillbedisplayedinthe
selected language.
If the DVD disc does not contain the selected
language,the DVDMENU/TITLEwillbe
displayed in the default language.
DVD Video Setup
Use , to select and ENTERtoconrm.
- BRIGHTNESS
Setthebrightnessofthevideooutputwith
from 0 to 12.
- CONTRAST
Setthecontrastof thevideooutputwith
from 0 to 12.
- HUE
Setthehueofthevideooutputwith from -6
to+6.
- SATURATION
Setthesaturationofthevideooutputwith
from 0 to 12.
- SHARPNESS
Setthesharpnessofthevideooutputwith
from 0 to 8.
DVD Setup

17
Electrical Connections
Wiring Diagram

18
Anti-Theft System
Thisunitisequippedwithaip-downdetachable
panel.
Panelcanbedetachedandtakenwithyou,
helping to deter theft.
Removing the Panel
1.Switchoffthepoweroftheunit.
2. Press buttontoipdownthepanel.
3. At an angle hold the panel to pull it out.
4. Place the panel into the case and take it
withyouwhenyouleavethecar.
Installing the Panel
1.Holdthe paneland ensurethepanelfaces
towardyou,andsettheright sideof the
panel in the panel bracket.
2. Press the left side of the panel until it locks.
Removing the Unit
1.Removethepanelandthetrimplate.
2.Insertbothremovalkeysintoholeonthe
front of the set until they lock.
3. Pull out the unit.

19
Installation Guide
Important:Removethesetwoscrewsbeforeinstallation.Otherwise,theplayerwillnotwork.
1. Inset mounting collar into the dashboard, and bend the mounting tabs out with a screw-
driver.
 Makesurethatlocklever isushwiththemountingcollar(notprojectingoutward).
2. Secure the rear of the unit.
 Afterxingmountingboltandpowerconnector,xtherearoftheunittothecarbodybyrubber
cushion.
3. Insert trim plate.
Installation Procedures
Firstcompletetheelectricalconnections,and
then check for correctness.
Reset
Press buttontoflipdownthepanel.Then
press the RESETbuttonwithapointedobject
to reset the unit to the original status.
Note:PresstheRESETbuttonwillerasethe
clock and stored stations.
Installation Opening
This unit can be installed in any dashboard
havinganopeningasshownbelow.
The dashboard should be 4.75mm - 5.56mm
thick in order to be able to support the unit.
Mounting bolt
rubber cushion
Transport
screws
53mm
183mm
