Big Dipper LP009 User manual

Model:LP009
d001
P000
L000
E000
soud
r000
g000
b000
U000
Y000
F000
1
2
3
4
5
6
7
8
9
10
11
地址码，（001—512）B、C键加减地址 码数值
七彩跳变，（00—255）B、C键修改跳变速度
七彩渐变，（00—255）B、C键修渐变速度
七彩脉变，（00—255）B、C键修改脉变速度
七彩声控变化
红色选色，（000—255）B、C键修改亮度
绿色选色，（000—255）B、C键修改亮度
蓝色选色，（000—255）B、C键修改亮度
白色选色，（000—255）B、C键修改亮度
黄色选色，（000—255）B、C键修改亮度
频闪，（000—255）B、C键修改闪烁频率
序号 显示 功能说明 ( )所有的功能选定后再按一次D键保存确认即可
操作说明：按功能键A会循环出11种不同的功能效果，数码管小数点前面的数字代表当前功能
（参照功能表）。小数点后面的数字代表该功能对应的参数。
按B或C键即可修改其参数值。按D键确认即可。
序号 说 明 功能
R、G、B、W, Y总调光，线性调光，由暗到亮
频闪由慢到快
0—50：频闪和线性调光；51－ －100：跳变；101—150：渐变；
151—200：脉变；201—255：声控
对应第3通道功能的速度，由慢到快
R调光，线性调光，由暗到亮
G调光，线性调光，由暗到亮
B调光，线性调光，由暗到亮
W调光，线性调光，由暗到亮
Y调光，线性调光，由暗到亮
第1通道
第2通道
第3通道
第4通道
第5通道
第6通道
第7通道
第8通道
第9通道
总调光
频闪
功能选择
功能速度
R调光
G调光
B调光
W调光
Y调光
DMX512 通道说明
L P009
54x3W
50,000小时
100-240V/50-60HZ
180W
自走/声控/DMX/主从联机
9
七彩变色,频闪
255*255*295mm
2.25KG /3KG
电源线
型号
光源
光源寿命
电源
额定功率
控制模式
DMX通道
效果
尺寸
净重/毛重
标配
按键说明 A键：功能键 B键：加 C键：减 D键：保存

Bi g Dippe r
R
LED Par Light User's Manual
Attention
Safety Tips
1.Please read these operating instructions carefully to familiarize you with basic operations of this unit
BEFORE USE.
2.Without permitted, it is prohibited to spread the contents of this manual to others.
3.This manual is only to provide related information, and the contents of this manual will be changed at
any time without notice.
4.Unless the instructions have already stated, please do not freely modified the unit.
Big Dipper Laser Science And Technology Co., Ltd
1. Before installation and maintenance, please confirm the power is OFF. make sure that the ventilation
around the unit is good.
2.The lighting is designed for indoor demonstration, please do not use this product in a wet environment
for long-term.
3.The use and maintenance of this unit should avoid contact with water. when using it outdoor, please take
waterproofing measures.
4.Personnel, who to take the installation, operation and maintenance, must be familiar with the lighting
performance. Most of the damage is resulted from unfamiliar with its performance.
5.Please do not face up to the luminous unit for a long time, so as not to cause discomfort to your eyes.
6.Please often wipe the unit with a clean cloth.
Safety guide
Safety guide
Operation Instructions
DMX Address,(001-512) B、C button to plus or minus the numerical code.
colorful jump, (00-255) the button B and C for adjusting the change speed.
colorful fade, (00-255) the button B、C to adjust the change speed.
colorful vein banding, (00-255) the button B、C to adjust the change speed.
colorful sound-active.
Red-selecting, (000-255) Button B、C to adjust the brightness.
Green-selecting, (000-255) Button B、C to adjust the brightness.
Blue-selecting, (000-255) Button B、C to adjust the brightness.
White-selecting, (000-255) Button B、C to adjust the brightness.
Amber-selecting, (000-255) Button B、C to adjust the brightness.
Strobe, (000-255) Button B、C to adjust flicker frequency.
Model:LP009(With Amber)
Iten NO. Display
Instruction of buttons
Button A: Function button; Button B: to increase; Button C: to decrease; Button D: to save
Operation Instructions: Press Button A will active 11 kinds of different functions. The digit in
front of decimal point on the nixie tube indicates the present function. The digit behind the
decimal point indicates the function corresponds to the parameter.
d001
P000
L000
E000
soud
r000
g000
b000
U000
Y000
F000
1
2
3
4
5
6
7
8
9
10
11
Description (all the funtions needed, want to active, should press Button “D” to save.)
Item NO. Function Instruction
（Last radix point flickers on digital display board when has DMX signal）
R-Dimming
0-50:strobe and linear dimming; 51-100: jump-change;
101-150: fade change; 151-200: vein banding; 201-255: Sound
R G B W A total dimming, linear dimming, from dark to bright
Strobe speed from slow to fast
Corresponding CH 3 function speed, from slow to fast
Red color dimming, linear dimming, from dark to bright
Green color dimming, linear dimming, from dark to bright
BLue color dimming, linear dimming, from dark to bright
White color dimming, linear dimming, from dark to bright
Yellow color dimming, linear dimming, from dark to bright
Function-selecting
Dimming
Strobe
A-Dimming
W-Dimming
B-Dimming
G-Dimming
Function speed
CH 1
CH 9
CH 8
CH 7
CH 6
CH 5
CH 2
CH 4
CH 3
DMX Control
Operating Instructions
Safety guide
L P009(Amber)
54x3W(R12 G12 B12 W12 A6)
50,000hours
100-240V/50-60HZ
180W
9
colorful change, strobe
255*255*295mm
2.25KG /3KG
Power Cable
Model
Light source
Source lifetime
Power supply
Rating power
DMX channel
Effect
Dimensions
N.W./G.W.
Standard configurationPlay mode Auto/Sound/DMX/Master-slave
Technical Specification
