12” PORTABLE
PARTY SPEAKER
Model # BB2714
Instruction Manual
Instrucciones en español incluidas

Thank you for purchasing the Billboard® Wireless Speaker. For best
use of this device we recommend carefully reading this user manual
and keeping it for your records
About your Powered Speaker
1. Your Billboard powered speaker has a built-in amplier and line mixer to control the
devices that are connected to it. Therefore you do not need a separate amplier or mixer
in order to use it. The amplier is properly balanced for the output of the speakers.
2. Your Billboard powered speaker also includes a lithium ion or lead-acid battery. This will
allow you to use your speaker without any AC power for long periods of time. The battery
life will vary based on how loud you play your speaker and what type of devices are played
though it as well. It can range from 2 hours to as much as 60 hours for some models.
Please make sure to read the separate section regarding lithium ion and lead-acid batteries
to better understand them
3. Your Billboard powered speaker can play many devices through it’s many inputs.
Check the inputscarefully on your model to better understand what is compatible with
your speaker
Powering up your speaker
1. Plug the micro USB plug into your speaker’s micro USB charging port (#16)
2. Plug the USB side of your cable into your computer or laptop’s USB charging port, or into
a standard USB charger (not included)
3. Make certain that your computer or laptop is powered on, or the USB charger is plugged in to
begin charging.
4. The Charging indicator LED light (#17) should illuminate RED when charging and then
turn to GREEN when the battery is fully charged.
FOR MAXIMUM BATTERY LIFE, IT IS IMPORTANT TO
FULLY CHARGE YOUR BATTERY PRIOR TO USE.
5. Move the power switch (#18) to the ON position. The LED display (#1) should activate.
6. Adjust the volume control (#14) to the MIN position before connecting a device.
7. You’re now ready to connect your device!
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER ON
THIS SPEAKER. THERE ARE NO USER-SERVICEABLE PARTS INSIDE. REFER ALL
SERVICING TO A QUALIFIED TECHNICIAN
To prevent re or electric shock, do not expose this equipment to rain or
moisture. Do not store or operate this product near any liquids, heat sources
such as radiators, heat registers. Clean only with a dry cloth. Users should
exhibit extra safety when this symbol appears in this instruction manual and
follow all precautions as they are stated.
WARNING!

PANEL LAYOUT & FUNCTIONS
1. LED display.
2. POWER/INPUT button.
3. Brightness of LED light mode button
4. EQ sound eect mode button
5. VOLUME-/+&MENU PUSH:
Master volume adjustment&Menu
selection button & PUSH knob enter menu.
6. LINE IN.
7. USB: USB Payer/Power Bank 5V 1A output
8. MIC: Microphone signal input.
9. Previous song .
10. Play/Pause (In FM mode,hold for
3 seconds the device will enter into
automatic scan).
11. Next song.
12.LED CHARGE STATUS:
RED = Charging
GREEN = Fully charged
13.DC 9V external input
BASIC OPERATION
1. POWER/INPUT button: long press POWER/INPUT button for about 3 seconds,
the machine displays“HI”and then “bLUE”to start; long press POWER/INPUT
button for about 3 seconds and the machine turns o. During working state, short
press POWER/INPUT button to select the mode, the sequence is USB (when USB
device is connected), FM, LINE, BT.
2. VOLUME-MENU PUSH: adjust volume; PUSH knob enter menu: turn left and right to
adjust the volume from 0 to 30. To press and then turn left and right, you can adjust the
Treble and Bass volume, Microphone volume, and switch 12 kinds of Light Modes.
3. PLAY/PAUSE: to play or pause the music. During FM state, long press PLAY/
PAUSE to automatically search radio and save.
4. PREVIOUS/NEXT: to switch the song and radio.
5.EQ Button: Press EQ button on the top panel to select EQ modes: Pop, Classical,
Jazz and Rock.
6.Brightness of LED light mode: The product has LED light brightness adjust function,
press LIGHT to choose the eect.
7. USB: USB Player/Power Bank 5V 1A output.
FM Operation
Lightly press Power/Input button to switch to FM mode, long press PLAY/PAUSE
button to automatically scan radio station, by pressing PREVIOUS or NEXT you
can select a previous or next song.
Bluetooth:
Press the POWER/INPUT button on the panel control to select Bluetooth mode.
Simultaneously open the Bluetooth setting on your phone, tablet or any other
Bluetooth enabled audio device and select“RM-212”. The unit and device will
then connect via Bluetooth.To control the device via your phone, tablet etc please
download the App“Speaker Pro”. Once the unit and device are connected via Bluetooth,
open the“Speaker Pro”App on your phone, tablet etc and press the Bluetooth button. This
will enable you to control the following ve modes on the device from your phone: Music,
Light, USB Card, Bluetooth and Equalizer. To cancel the app, press the exit button.
EQ
1
2
3
4
5
8
6
7
9
10
11
13
12
DC 9V

To control the device via your phone, please nd and install the app
“ Speaker Pro “. Open the App“Speaker Pro” on your phone, there are 8
function icons on the main page :
1. Bluetooth Music play
2. USB card play
3. Light control colour, brightness and light ash mode
4. FM Radio
5. Control Bluetooth connect
6. Line In input - mute
7. Equalizer,volume adjustment for
music, Microphone and quitar input.
1
2
3
4
5
6
7
(1) Bluetooth Music play
Press to enter into Bluetooth Music play page, Press“Pick songs to play”
to Pick Song page to choose the song you want to play, press “Done”to return
to Bluetooth Music play page, also you can operate pause, play, backward,
forward& volume adjustment, repeat, random play. Press“Back” to return to
the main page.
(2)USB card play
When inserting a USB into the speaker, press to enter the USB Card play
page. To choose a song and play music on the USB card, press“Play” to enter
into the play control page ,where you can operate pause, play, backward,
forward & volume adjustment. Press“List” to return to USB list page, press
“Back”to return to the main page.
(3) Light control colours, brightness and colour change mode
Press to enter into Light Control page, you can select any colour to show
the light colour on the speaker, as well as adjust the brightness of the light. To
go back to main page, press““ in the left corner.
Press“Proles” to enter into Light Eect mode page, you can choose from a
total of 12 pre-set light eect modes. To return to Light Control page, press
“Light” in the left corner.
1 2 3

(4) FM Mode
Press to enter into FM radio mode, press SCAN to enter into radio
program automatic scan. Press for radio program manual scan,
Top and bottom trimming, Turn the TUNER button radio station can be
adjusted. Slide around to adjust radio frequency between 87.5MHz~108.0MHz.
(5) Bluetooth connection
Press to enter into Bluetooth Control connection page, then click
“Speaker Pro BLE”to connect to the speaker.
(6)Line In input - mute
Press to enter into Line IN input page, press to mute music, press
insert a line continue play. Press“Back”to main page.
(7) Equalizer regulation
Press to enter into Sound Set page, and then turn volume or bass or treble
to adjust the volume. There are 4 pre-set EQ modes: dance, Classical, Jazz and
Rock.You can also press G-Eq to access the graphic equalier to set up your
preferred equalize specication.
765
4

LIMITED WARRANTY
ESI Cases & Accessories, Inc., warrants to the rst consumer purchaser
that this product, when shipped in its original container to the original
purchaser will be free from defective workmanship and materials for one
year and agrees that it will, at its option, either repair the defect and re-
place the defective product or part thereof at no charge to the purchaser
for parts or labor for the time periods described.
This warranty does not apply to any appearance items of the product
nor to the additional excluded item(s) set forth below nor at any product
the exterior of which has been damaged or defaced which design or
construction. The limited warranty described herein is in addition to an
applicable law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD FROM THE
DATE OF ORIGINAL PURCHASE SET FORTH BELOW.
Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. Neither the sales
personnel of the seller nor any other person is authorized to make any
warranties other than those described herein or to extend the duration of
any warranties beyond the time period described herein on the behalf of
ESI Cases & Accessories, Inc.
The warranties described herein shall be the sole and exclusive
warranties granted by ESI Cases & Accessories, Inc. and shall be the sole
and exclusive remedy available to the purchaser corrections of defects,
in the manner and for the period of time described herein, shall
constitute complete fulllment of all liabilities and responsibilities of ESI
Cases & Accessories, Inc. to the purchaser with respect to the product and
shall constitute full satisfaction of all claims, whether based on contract
negligence, strict liabilities and responsibilities of ESI Cases & Accessories,
Inc. be liable or in any way responsible, for any incidental of consequen-
tial damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO
HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.

Return Instructions
If your speaker malfunctions during the warranty period of one calendar year (90
days for battery), contact our customer service department at [phone] to
obtain troubleshooting information. If troubleshooting assistance fails to remedy
the problem, you will receive a return authorization # and instructions for sending
your unit to our Service Center. Your return authorization number must be clearly
visible and placed on the outside of box when the unit is returned.
Enclose a copy of your original proof of purchase showing the original purchase
date, along with detailed information describing the exact nature of your prob-
lem. Be sure to include your complete name, address, email address, daytime and
evening contact numbers. In addition, please send a check or money order made
payable to“ESI Cases & Accessories.” for return freight amount (given to you by our
service agents). All of the above must be included with your return, or your pack-
age will not be eligible for service under our warranty. The customer is responsible
for packing the speaker in it’s original carton or equivalent, and for insuring, and
shipping the unit to our service center. Please make sure to pack all accessories
included with your speaker so that we can properly identify any issues. All freight
cost to return the unit to ESI Cases & Accessories., are the responsibility of the
customer. If your speaker is under warranty, then ESI Cases & Accessories. will at its
sole discretion, exchange or repair the speaker without charge for parts and labor.
The customer is responsible for return freight and should include a check or mon-
ey order payable to“ESI Cases & Accessories.” with your return for the return freight
amount. Any shipments received without a Return Authorization number will be
refused. For more details please contact our customer service department.
Send product:
ESI Cases & Accessories
44 East 32nd Street
New York, NY 10016
Tech Support: [phone]
[e-mail]

FCC Information
This device complies with Part 15 of the FCC rules.Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received; including interference that may cause
undesired operation.Federal Communications Commission (FCC) StatementThis
Equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver
.•Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected
.•Consult the dealer or an experienced radio/TV/technician for help.
Warning: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the equipment.
Tested to comply with FCC standard.FOR HOME OR OFFICE USE.
Warning:This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This device and its antenna(s) must not be co-located or
conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
© 2020 Billboard IP Holdings, LLC. All rights reserved. Billboard®,the Billboard logo,
HOT 100 and associated characters,trademarks and design elements are owned and
licensed by Billboard IP Holdings, LLC.
Bluetooth is a registered trademark of Bluetooth SIG
All other trademarks are property of their respective companies.
