Biodom C15 User manual

Biodom C15 | instructions for use, maintenance and installation | February 2019
__________
PELLET BOILER
BIODOM C15
Instructions for use, maintenance and installation
__________

2
GENERAL INFORMATION
BUYER:
NAME AND SURNAME:
STREET AND HOUSE NO.:
CITY:
PHONE NO/GSM: __________________E-MAIL:
DATE OF SALE:
INVOICE NUMBER:
PRODUCT TYPE:
SERIAL NUMBER:
DURATION OF WARRANTY: 2 YEARS
STAMP AND SIGNATURE:
INSTALLATION OF DEVICES
DATE OF INSTALLATION:
NAME OF THE INSTALLATION COMPANY:
STREET AND HOUSE NO.:
CITY:
PHONE NO./GSM:
E-MAIL:
NAME AND SURNAME OF INSTALLER:
SERIAL NUMBER:
STAMP AND SIGNATURE OF INSTALLER:
(FILLS IN AN INSTALLATION COMPANY)

3
COMMISSIONING OF THE DEVICE
DATE OF COMMISSIONING:
AUTHORIZED COMPANY NAME:
STREET AND HOUSE NO.:
CITY:
PHONE NO.:
NAME AND SURNAME OF SERVISER:
STAMP AND SIGNATURE OF SERVISER:
(FILLS IN AN AUTHORIZED SERVICE COMPANY)

4
WARRANTY CARD No. (No. of boiler):_____________________
BUYER:
NAME AND SURNAME:
STREET AND HOUSE NO.:
CITY:
PHONE NO/GSM: __________________E-MAIL:
DATE OF SALE:
INVOICE NUMBER:
PRODUCT TYPE:
SERIAL NUMBER:
INSTALLATION OF DEVICES
DATE OF INSTALLATION:
NAME OF THE INSTALLATION COMPANY:
STREET AND HOUSE NO.:
CITY:
PHONE NO./GSM:
E-MAIL:
NAME AND SURNAME OF INSTALLER:
SERIAL NUMBER:
STAMP AND SIGNATURE OF SERVISER:
(FILLS IN AN AUTHORIZED SERVICE COMPANY)
COMPLETED FORM RETURN TO BIODOM

5
DIFFERENCES :
(FILLS IN AN INSTALLATION COMPANY)
COMPLETED FORM RETURN TO BIODOM

6
WARRANTY CARD No. (no. of boiler):_____________________
BUYER:
NAME AND SURNAME:
STREET AND HOUSE NO.:
CITY:
PHONE NO./GSM: __________________E-MAIL:
DATE OF SALE:
INVOICE NUMBER:
PRODUCT TYPE:
SERIAL NUMBER:
INSTALLATION OF DEVICES
DATE OF INSTALLATION:
NAME OF THE INSTALLATION COMPANY:
STREET AND HOUSE NO.:
CITY:
PHONE NO./GSM:
E-MAIL:
NAME AND SURNAME OF INSTALLER:
SERIAL NUMBER:
STAMP AND SIGNATURE OF INSTALLER:

7
DIFFERENCES :

8
INSTRUCTIONS FOR CONNECTING, OPERATION, AND MAINTENANCE OF THE STOVE
Heating devices (in this manual they are called “stoves") by Company Biodom (in this manual titled
Biodom) are assembled and tested in accordance with the safety and applicable measures, and
regulations of the European Community.
This manual is intended for users of the stoves, contractors who install the stoves, operators and
workers for stove maintenance that is shown on the front page of the manual.
If you do not understand something in this manual, please contact our professional services or an
authorized service center. In doing so, always specify the number of the chapter where there is some
ambiguity.
Printing, translation and reproduction, even in part, of this manual is subject to licensing by Biodom,
which means that Biodom must approve these actions. Technical information, figures, and
specifications in this manual must not be given to a third party.
WARNING:
IMPORTANT: Connecting the appliance to the electrical installation must be carried out by qualified
and authorized persons in accordance with applicable regulations.
This appliance is not intended for use by persons (including children) with reduced physical, motor,
and mental capabilities, or to persons with a limited knowledge and experience in the absence of
the person responsible for their safety or care.
DOUBLE COMBUSTION SYSTEM
The flame obtained by proper combustion of the pellet in the stove emits the same amount of carbon
dioxide (CO2), which would be freed as a result of the natural decay of wood.
The amount of carbon dioxide (CO2) obtained through combustion or decomposition of plant mass
corresponds to the amount of carbon dioxide (CO2) which the plant mass is able to obtain from the
environment and to transform it into air and carbon of the plants during its entire lifetime.
The use of non-renewable fossil fuels (coal, oil, gas), contrary to what happens with the wood, releases
into the atmosphere huge amounts of carbon dioxide (CO2), that have been gathering up for millions
of years, creating a greenhouse effect. The use of wood as fuel is therefore perfectly balanced with the
environment, because the wood as a renewable fuel is in ecological harmony with nature.
Using the principle of clean combustion, we fully achieve these objectives, and so Biodom has directed
its development and all activities towards fulfilling this goal.
What do we consider clean combustion and how does it work?
Controlling and adjusting the primary air and injecting the secondary air causes secondary combustion,
or the so-called post-combustion, which provides a secondary flame that is by its nature lighter and
stronger than the primary flame. The addition of a new oxygen (inserted through the air) allows further
combustion of gases that are not completely burned. This significantly increases the thermal efficiency
and reduces harmful emissions of carbon monoxide (CO), because the incomplete combustion is
minimized. These are the basic characteristics of these stoves and other products of Biodom.

Biodom C15 | instructions for use, maintenance and installation | February 2019
INDEX
1. WARNINGS ............................................................................................................ 12
2. TECHNICAL CHARACTERISTICS................................................................................ 15
3. DIMENSIONS OF BOILER BIODOM C15 ................................................................... 16
4. PURPOSE OF INSTRUCTIONS FOR USE .................................................................... 16
4.1. UPDATES ...............................................................................................................................16
5. RESPONSIBILITY OF MANUFACTURER..................................................................... 17
5.1. BASIC PREVENTIVELY REQUIRED STANDARDS.......................................................................17
5.2. TRANSPORTATION AND HANDLING OF PELLET BOILER.........................................................18
5.3. RESPONSIBILITY OF INSTALLER .............................................................................................18
6. INSTALLATION ........................................................................................................ 19
6.1. PLACEMENT..........................................................................................................................19
6.2. EXTRACTION OF SMOKE GASES ............................................................................................23
6.3. INSULATION AND DIAMETER OF HOLES IN THE ROOF..........................................................25
6.4. INLET AIR ..............................................................................................................................25
6.5. ELECTRICAL CONNECTION ....................................................................................................26
7. BOILER COMMISSIONING....................................................................................... 28
8. SAFETY WARNINGS ................................................................................................ 28
8.1. SAFETY WARNINGS FOR MAINTENANCE STAFF ....................................................................28
8.2. SAFETY WARNINGS FOR USER ..............................................................................................29
9. INSTRUCTIONS FOR SAFE IGNITION AND CLEANING OF BOILER.............................. 30
9.1. REGULAR MAINTENANCE AND CLEANING OF BOILER ..........................................................30
9.2. CONTROL AND PARTS REQUIRING MAINTENANCE...............................................................33
9.3. ADDITIONAL MAINTENANCE ................................................................................................34
10. IMPORTANT SAFETY INFORMATION ....................................................................... 34
11. PELLET QUALITY IS VERY IMPORTANT..................................................................... 35
11.1. STORING PELLETS .................................................................................................................36
12. DESCRIPTION AND OPERATION OF CONTROL DEVICE ............................................. 37
12.1. BOILER DURING OPERATION.................................................................................................40

Biodom C15 | instructions for use, maintenance and installation | February 2019
10
12.2. BOILER SHUTDOWN..............................................................................................................40
12.3. BOILER ACTIVATION..............................................................................................................40
12.4. TIME PROGRAMME SETTING................................................................................................41
12.5. INDICATIONS AND MESSAGES ON DISPLAY...........................................................................44
13. MENU .................................................................................................................... 46
14. SCHEME OF ELECTRONIC CONTROL PANEL OF THE BOILER ..................................... 48
14.1. HYDRAULIC SCHEME.............................................................................................................49
15. ALARM STATUSES................................................................................................... 50
16. INFORMATION REGARDING DESTRUCTION AND DISPOSAL OF BOILER ....................... 57
17. INSTRUCTIONS FOR FIRST START-UP ........................................................................... 58
17. WARRANTY CONDITIONS....................................................................................... 61

Biodom C15 | instructions for use, maintenance and installation | February 2019
11
-Instructions for use, maintenance and installation-

Biodom C15 | instructions for use, maintenance and installation | February 2019
12
WARNINGS
ATTENTION
DISCARD ALL PACKAGING OUT OF REACH OF CHILDREN. DANGER OF SUFFOCATION WITH BAG, FOIL,
POLYSTYRENE ETC.
ATTENTION
Smoke gas discharge MUST NOT BE CONNECTED TO:
•Flue pipe, used by other combustion devices (boilers, stoves, fireplaces etc.);
•Air extraction systems (hoods, air extraction fans etc.).
ATTENTION
Installation of draught closing valves is prohibited!
Flue connection Ø 80 mm from pellet boiler to flue pipe should be:
no more than 12 m long (in case of longer connection, dimension of connection pipe must increase to
Ø 130 mm);
each 90° joint requires a 1 m shorter flue connection;
each joint must be fitted with doors for cleaning;
connections between pipes must be sealed
ATTENTION
If there is too much resistance in extraction system (many joints, improper end fitting, bottlenecks
etc.), extraction of smoke gases is not provided for. Therefore, connection pipes and joints must be
increased to a greater dimension – Ø 130 mm. If the flue does not ensure appropriate extraction of
smoke gases, it can also come do improper operation and, consequently, to alarm from boiler
BIODOM. It is advisable that the flue is inspected by an expert before installing boiler BIODOM.
ATTENTION
Never turn off the boiler by pulling the electrical cable from the socket, while fire is still burning in the
boiler. This could damage the boiler and seriously jeopardize its functioning

Biodom C15 | instructions for use, maintenance and installation | February 2019
13
ATTENTION
Extraction of smoke gases must be earthed in accordance with regulations in force. (Earthing
connection is required by law). Earthing must be independent of combustion unit.
ATTENTION
When the boiler installation is finished, it is mandatory to perform measurements of smoke gases
discharge.
ATTENTION
The pellet boiler operates by creating negative pressure in the combustion chamber. Therefore, ensure
that the extraction of smoke gases is thermally sealed.
Upon first start-up (minimum operation of boiler – 1 hour), paint evaporates fumes, which have
unpleasant odour. Therefore, ventilate the room afterwards.
ATTENTION
DURING PELLET BOILER OPERATION, CHILDREN ARE PROHIBITED TO COME NEAR OR PLAY WITH IT!
ATTENTION
Be careful that the sealant rope under the edge of combustion chamber is not damaged. If the
sealant rope is damaged, contact an authorized service centre.
ATTENTION
Ensure that the pellet boiler and ashes in it are cool before cleaning.
ATTENTION
In the event of fire in the flue pipe, all persons and animals must leave the area, then immediately
disconnect power supply from the main switch or socket (if it is possible without risk) and call the fire
department.

Biodom C15 | instructions for use, maintenance and installation | February 2019
14
ATTENTION
Do not use fine cut wood to ensure operation and safety of the boiler.
ATTENTION
Do not use the pellet boiler as an incinerator.
ATTENTION
Persons with back injuries and pregnant women should avoid lifting pellet bags.
ATTENTION
The manufacture shall in no way be held liable for damages arising from the use of poor quality pellets,
as well as for poor functioning of the boiler due to poor quality of used pellets.
ATTENTION
Pellets should be in accordance with DIN 51731, DIN plus, Ö-Norm M-7135 or other comparable
European standards.
ATTENTION
PELLETS SHOULD NOT BE STORED NEAR THE PELLET BOILER. Keep them at least 50 cm away.

Biodom C15 | instructions for use, maintenance and installation | February 2019
15
TECHNICAL CHARACTERISTICS
Minimal
Nominal
Thermal power
4,97 kW
17,13 kW
Efficiency
90,6 %
93,83 %
Pellet consumption per hour
1,13 kg/h
3,77 kg/h
Burning time with 1 filling of container (approx.)
39,8 h
12 h
Average temperature of smoke gases
58 °C
117,1 °C
Mass flow of smoke gases
0,0039
0,0084
Fuel
Pellets C1
boiler class according to EN 303-5:2012
5
Flue connection
Ø80 mm
Water volume in boiler
42 l
Boiler water temperature
65 °C – 80 °C
Highest boiler water temperature
90 °C
Minimum return water temperature
50 °C
Maximum permitted work pressure
2,5 bar
Boiler resistance ΔT = 20 °C
32 mbar
Firebox volume
30,6 l
Weight
215 kg
Pellet container
~ 55 kg
Flue draught
0,10 (± 0,05) mbar
Voltage 220 V
Current at maximum electrical consumption during boiler operation 1,80 A
frequency 50 Hz
Maximum consumption of power during boiler operation 98,91 W
Maximum consumption of power during boiler ignition 293 W
Safety level IP20
Boiler operates with two fans
Boiler operates only in manner of negative pressure combustion

Biodom C15 | instructions for use, maintenance and installation | February 2019
16
Boiler operates without condensation conditions
Noise does not exceed 60 dB
CO emissions at 13% O2 40,49 /
OGC emissions at 13% O2 2,6 /
Ash at 13% O2 12,6 /
DIMENSIONS OF BOILER BIODOM C15
PURPOSE OF INSTRUCTIONS FOR USE
The purpose of instructions for use is that the user takes all necessary measures and prepares all
required equipment to ensure safe and proper use of combustion device.
4.1. UPDATES
These instructions reflect the state of the product at the moment the boiler is produced.
Instructions are not applicable for products, which are already present on the market with correspond-
ing technical documentation and cannot be considered as insufficient or inadequate after any modifi-
cation, adaptation or application of new technologies on newer products.
The content of this booklet must be carefully read and heeded to. All of the information, contained in
this booklet, is necessary for correct installation, use and maintenance of you boiler.
The instructions must be stored carefully and safely. Instructions for use, maintenance and installation
are a component part of pellet boiler.

Biodom C15 | instructions for use, maintenance and installation | February 2019
17
If the pellet boiler changes ownership to another person, this person must also receive these
instructions for use, together with the boiler.
If the instructions get lost, request for a new copy of instructions from the manufacturer, authorized
reseller or repairman.
RESPONSIBILITY OF MANUFACTURER
In providing these instructions, Company Biodom rejects any civil or penal liability, direct or indirect,
due to:
•accidents caused by non-compliance with standards and specifications from these instructions;
•accidents caused by prohibited or incorrect use by the user;
•accidents caused by modifications and repairs not authorized by manufacturer Company
Biodom;
•poor maintenance;
•unforeseeable events;
•accidents caused by use of non-original or improper spare parts.
The installer is fully responsible for installation.
5.1. BASIC PREVENTIVELY REQUIRED STANDARDS
Product Biodom C15 is manufactured in accordance with the following standards:
DIRECTIVE EC ON MACHINERY (2006/42/EC);
DIRECTIVE EC ON LOW-VOLTAGE EQUIPMENT (2014/35/ES);
DIRECTIVE EC ON ELECTROMAGNETIC COMPATIBILITY (2014/30/ES);
Harmonized standards:
•EN 303-5:2012
•EN 60335-1:2012+A11:2014
•EN 60335-2-102:2006+A1:2010
•EN 55014-1:2008/A2:2012
•EN 55014-2:1998/A1:2002/A2:2009
•EN 61000-3-2:2015
•EN 61000-3:2014/EC:2016

Biodom C15 | instructions for use, maintenance and installation | February 2019
18
5.2. TRANSPORTATION AND HANDLING OF PELLET BOILER
When moving the boiler, pay attention to your safety.
Before transport and handling of the boiler, which must be performed in complete safety, make sure
that the lifting capacity of transport equipment suffices. Avoid sudden and/or abrupt movement of
boiler.
ATTENTION
DISCARD ALL PACKAGING OUT OF REACH OF CHILDREN. DANGER OF SUFFOCATION WITH
BAG, FOIL, POLYSTYRENE ETC.
5.3. RESPONSIBILITY OF INSTALLER
It is the responsibility of the installer to check adequacy of installation and pipeline, ensure air intake
for combustion, ensures regulated distances and all other solutions, required for installation of the
pellet boiler.
It is the responsibility of the installer to ensure compliance with local legislation in force in the place of
pellet boiler installation.
Use of the pellet boiler must conform with instructions, provided in Instructions for use, maintenance
and installation, and all safety standards, specified by local legislation in the place of pellet boiler
installation.
Standard UNI 10683 defines duties of installer. The installer must check:
•type of device to be installed;
•adequacy of space for installation of unit, reflected by minimum required size of the space, in
which the pellet boiler will be installed;
•instructions of the manufacturer about heating device, regarding requirements of smoke gases
outlet;
•flue pipe internal diameter, the material it is made of, is it straight or even and that there are
no obstructions;
•height and, if required, vertical extension of flue pipe;
•existence and suitability of flue pipe cover resistance;
•possibility of outside air intake;
•possibility of simultaneous use of generator for connection with other equipment.
If the results of all above provided checks are positive, installation may proceed. Carefully heed to
instructions provided by the manufacturer, as well as safety and fire prevention standards in force.
After the first start-up of the boiler, perform a minimum 30-minute test of operation to check all
required demands.
When the installation is complete, the installer must provide the customer with the following:
•instructions for use, maintenance and installation from the manufacturer (if not included in
the unit);

Biodom C15 | instructions for use, maintenance and installation | February 2019
19
•required documentation in accordance with standards in force;
•perform training of customer for operation and regular maintenance and cleaning of the
device.
INSTALLATION
Responsibility for installation work in the space is entirely upon the customer.
Before proceeding with installation, the installer must comply with all required legal safety standards,
especially:
•check that norms regarding pellet boiler installation meet local, national and European norms;
•heed to requirements set forth in this document;
•check that pipes and air intake are compliant with the type of installation;
•do not make temporary electrical connections by using unsuitable cables;
•check earthing of electrical system;
•always use individual safety equipment and all legally required protection;
•always allow sufficient space for maintenance work;
•acquire consent of chimney sweep for connection of boiler to flue;
•perform measurement of smoke gases outlet after finished installation.
6.1. PLACEMENT
It is advisable to remove pellet boiler packaging only when it is in the place of installation.
If the adjacent walls and/or flooring are made of material that is not heat resistant, suitable protection
must be provided using insulating, non-combustible material.
For protection of flooring, made of flammable material, we advise installing a metal plate with
thickness 3 to 4 mm under the boiler, which protrudes at least 30 cm out from the front of the pellet
boiler.
Pellet boiler must be installed in accordance with drawing that defines distances from walls (figure 1).

Biodom C15 | instructions for use, maintenance and installation | February 2019
20
