Biostar P4 TDG Operating and installation instructions

P
P
P4
4
4T
T
TD
D
DG
G
G
i
FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor’s approval in writing.
The content of this user’s is subject to be changed without notice and we
will not be responsible for any mistakes found in this user’s manual. All the
brand and product names are trademarks of their respective companies.

C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
ts
s
s
ii
ENGLISH.................................................................................................1
P4TDG Features .................................................................................................... 1
Package contents.................................................................................................. 1
Layout of P4TDG ................................................................................................... 2
CPU Installation..................................................................................................... 2
CPU Installation..................................................................................................... 3
DDR DIMM Modules: DDR1-2 ............................................................................... 4
Jumpers, Headers, Connectors & Slots.............................................................. 5
ESPAÑOL..............................................................................................10
Características del P4TDG ................................................................................. 10
Contenido del Paquete ....................................................................................... 10
Disposición del P4TDG........................................................................................11
Instalación de la CPU...........................................................................................11
Instalación de la CPU.......................................................................................... 12
Módulos DDR DIMM: DDR1-2............................................................................. 13
Conectores, Cabezales, Puentes y Ranuras..................................................... 14
TROUBLE SHOOTING..........................................................................19
SOLUCIÓN DE PROBLEMAS...............................................................20

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
1
English
P4TDG Features
 Use Intel 82845G/ 82801DB Chipset, Winbond W83627HF, LAN Chip
(optional).
 Contains on board I/O facilities, which include a serial port, a parallel port, a
VGA port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB
ports, a LAN port (optional) and a game port.
 Supports the Intel Pentium 4®(Socket 478) processor up to 2.2 GHz.
 Supports Ultra 100/66/33, BMIDE and PIO modes.
 Supports USB2.0 High Speed Device.
 Supports up to 2 GB for DDR 200/266 MHz unregister (Non-ECC) devices,
running at 400/533 MHz Front Side Bus frequency.
 Supports AGP 2.0 interface, 2X/4X Fast write protocol. (1.5V Only)
 Complies with PC Micro-ATX form factor specifications.
 Supports popular operating systems such as Windows 98SE, Windows NT,
Windows 2000, Windows ME, Windows XP, LINUX and SCO UNIX.
 Intel®AC’97 2.2 compatible.
 High S/N ratio meets PC 99 requirements.
 4CH DAC, applicable for leading motherboard chipsets.
 Line-in phonejack share with rear out.
Package contents
 HDD Cable X 1, FDD Cable X 1
 Flash Memory Writer for BIOS update X 1
 USB Cable X 2 (Optional)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
2
 Rear I/O Panel for Micro-ATX Case X 1 (Optional)
 Fully Setup Driver CD X 1
Layout of P4TDG
JATXPWR2
JKBMS1
JPRNT1
Socket 478
K/B
&
Mouse
JRJ45USB1
USB & LAN
DDR1
DDR2
JAUDIO1
PCI1
PCI2
PCI3
JATXPWR1
LAN
CHIP
JCDIN1
JCOM1
JVGA1
COM1
VGA1
JTAD1
JCDIN2
CNR1 WOL1
AGP1
JUSB3
JCMOS1
JPANEL1
JSFAN1
JDIMMVOLT
JCFAN1
JAUXPWR1
FDD1
IDE2 IDE1
Parallel Port
BAT1
INTEL
82845G
INTEL
82801DB
(ICH4)
Winbond
I/O FWH
BIOS
JMS1
JSD1
JSC1
JUSBV1
JKBV1
JUSB4
JUSBV2
JUSBV3_4
JGAME_USB1
GAME Port
SP-OUTMIC-IN LINE-IN
USBUSB

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
3
CPU Installation
1. Pull the lever sideways away from the socket then raise the lever up
to 90-degree angle.
2. Locate Pin A in the socket and lock for the white dot or cut edge in
the CPU. Match Pin A with the white dot/cut edge then insert the
CPU.
3. Press the lever down. Then Put the fan on the CPU and buckle it
and put the fan’s power port into the JCFAN1, then to complete the
installation.
CPU/ System Fan Headers: JCFAN1/ JSFAN1
CPU
JCFAN1
1
Ground
12V
Sense
JSFAN1
Ground
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
4
DDR DIMM Modules: DDR1-2
DRAM Access Time: 2.5V Unregister (Non-ECC) DDR 200/266 MHz
Type required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184
pin)
DIMM Socket
Location DDR Module Total Memory Size (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
* The list shown above for DRAM configuration is only for reference.
How to install a DIMM Module
1. The DIMM socket has a
“ Plastic Safety Tab”, and the
DIMM memory module has an
“Asymmetrical notch”, so the
DIMM memory module can only
fit into the slot in one direction.
2. Push the tabs out. Insert the
DIMM memory modules into the
socket at a 90-degree angle, then
push down vertically so that it will
fit into the place.
3. The Mounting Holes and plastic
tabs should fit over the edge and
hold the DIMM memory modules
in place.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
5
Jumpers, Headers, Connectors & Slots
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that
provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100
functionality. It has two HDD connectors IDE1 (primary) and IDE2
(secondary).
The IDE connectors can connect a master and a slave drive, so you can
connect up to four hard disk drives. The first hard drive should always be
connected to IDE1.
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that
supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This
connector supports the provided floppy drive ribbon cables.
Accelerated Graphics Port Slot: AGP1
Your monitor will attach directly to that video card. This motherboard
supports video cards for PCI slots, but it is also equipped with an
Accelerated Graphics Port (AGP). An AGP card will take advantage of
AGP technology for improved video efficiency and performance,
especially with 3D graphics.
Communication Network Riser Slot: CNR1
The CNR specification is an open Industry Standard Architecture, and it
defines a hardware scalable riser card interface, which supports audio,
network and modem only.
Peripheral Component Interconnect Slots: PCI1-3
This motherboard is equipped with 3 standard PCI slots. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for
expansion cards, which has, supplanted the older ISA bus standard in
most ports. This PCI slot is designated as 32 bits.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
6
Power Connectors: JATXPWR1/ JATXPWR2/
(JAUXPWR1=>Optional)
DIMM Power Selection Connector: JDIMMVOLT
Wake On LAN Header: WOL1
Front USB Header: JUSB3/(JUSB4=>Optional)
JATXPWR1
(ATX Main Power Conn.)
JATXPWR2
(ATX 12V Power Conn.)
JAUXPWR1
(AUX Power Conn.)
WOL1
1
5V_SB Wakeup
Ground
JUSB3/4
2
1
Pin1,2 ==> +5V
Pin3,4 ==> Data(-)
Pin5,6 ==> Data(+)
Pin7,8 ==> Ground
Pin9 ==> KEY
Pin10 ==> NA
1
2
JDIMMVOLT
Pin 1-2 off ==> 2.6V
Pin 3-4 off ==> 2.7V
Pin 5-6 off ==> 2.8V
Pin 7-8 off ==> 2.9V
(Default ==> 2.5V)
12
JDIMMVOLT
Jump On ==> 2.5V
Pin 1-2 on ==> 2.6V
Pin 3-4 on ==> 2.75V
Pin 5-6 on ==> 2.8V
Pin 7-8 on ==> 2.9V
(Default ==> 2.6V)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
7
5V/ 5VSB Selection for USB: JUSBV1/ (JUSBV2/3_4=>
Optional)
5V/ 5VSB Selection for Keyboard: JKBV1
Memory Stick Header: JMS1 (optional)
SD Memory Card Header: JSD1 (optional)
JMS1
Pin1 ==> Ground , Pin2 ==> MS1
Pin3 ==> 3.3V , Pin4 ==> MS2
Pin5 ==> MS3 , Pin6 ==> MS4
Pin7 ==> MS5 , Pin8 ==> MSCLK
Pin9 ==> MSPWCTL#
Pin10 ==> MSLED
1
JSD1
Pin1 ==> Ground , Pin2 ==> SD1
Pin3 ==> 3.3V , Pin4 ==> SD2
Pin5 ==> SD3 , Pin6 ==> SD4
Pin7 ==> S 5 , Pin8 ==> SDCLK
Pin9 ==> SDPWCTL#
Pin10 ==> SDLED
D
1
1
JUSBV1/2/3_4
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB
1
JKBV1
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
8
Smart Card Header: JSC1 (optional)
Front Panel Connector: JPANEL1
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
SPK ==> Speaker Conn.
HLED ==> Hard Driver LED
RST ==> Reset Button
IR ==> Infrared Conn.
SLP ==> Sleep Button
PWR_LED ==> Power LED
ON/ OFF ==> Power-on Button
JSC1
Pin1 ==> 5V , Pin2 ==> Ground
Pin3 ==> SCAPWRCTL#
Pin4 ==> SCAR5#
Pin5 ==> SCAC4 , Pin6 ==> SCALED
Pin7 ==> SCAIO , Pin8 ==> SCAC8
Pin9 ==> SCACLK
Pin10 ==> SCAPSNT
1
2

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
9
Audio Subsystem: JAUDIO1/ (JTAD1=>Optional)/
JCDIN1/ (JCDIN2=>Optional)
Back Panel Connectors
1
2
JAUDIO1
(Front Audio Header) JTAD1 => optional (TelephonyAudio Header)
1
11
JCDIN2 => optional
(CD-ROM Audio-In Header) JCDIN1 (CD-ROM Audio-In Header)
PS/2
Keyboard
PS/2
Mouse
COM1
Parallel
Game Port/
USB Ports (optional)
JPRNT1
JGAME1_USB1
JCOM1
JKBMS1
USB
LAN(Optional)
RJ45USB1
COM1 Speaker
Out Line In Mic
In
JVGA1
VGA1
PS/2
Keyboard
PS/2
Mouse
COM1
Parallel
Game Port/
USB Ports (optional)
JPRNT1
JGAME1_USB1
JCOM1
JKBMS1
USB
LAN(Optional)
RJ45USB1
COM1 Speaker
Out Line In Mic
In
JVGA1
VGA1
PS/2
Keyboard
PS/2
Mouse
COM1
Parallel Game Port
JPRNT1 JGAME1_USB1
JCOM1
JKBMS1
USB
LAN(Optional)
RJ45USB1
COM1 Speaker
Out Line In Mic
In
JVGA1
VGA1
(Normal Mode)
(Add USB Game Port Mode)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
10
Español
Características del P4TDG
 Usa Chipset Intel 82845G/ 82801DB, Winbond W83627HF, LAN Chip
(opcional).
 Contiene facilidades I/O integrados en la placa madre en el que incluye un
puerto serie, un puerto paralelo, un puerto VGA, un puerto de ratón PS/2,
un puerto de teclado PS/2, puertos de audio, puertos USB, un puerto LAN
(opcional) y un puerto de juego.
 Soporta procesador Intel Pentium 4®(Socket 478) hasta 2.2 GHz.
 Soporta Ultra 100/66/33, BMIDE y modos PIO.
 Soporta USB2.0 High Speed Device.
 Soporta dispositivos de hasta 2 GB para DDR 200/266 MHz (con ECC)
corriendo a 400/533 MHz frecuencia Front Side Bus.
 Soporta interface AGP 2.0, protocolo 2X/4X Fast write. (Solamente 1.5V)
 Compatible con el factor de forma de PC Micro-ATX especificados.
 Soporta sistemas operativos populares tales como Windows 98SE,
Windows NT, Windows 2000, Windows ME, Windows XP, LINUX y SCO
UNIX.
 Intel®AC’97 2.2 compatible.
 High S/N ratio comparte requerimientos PC 99.
 4CH DAC, aplicables para chipsets de principales placas madres.
 Entrada de línea phonejack compartido con el rear out.
Contenido del Paquete
 Cable HDD X 1, Cable FDD X 1
 Flash Memory Writer para actualización del BIOS X 1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
11
 Cable USB X 2 (Opcional)
 Panel trasero I/O para ATX X 1 (Opcional)
 Configuración completa del Driver CD X 1
Disposición del P4TDG
JATXPWR2
JKBMS1
JPRNT1
Socket 478
Teclado
&
Raton
JRJ45USB1
USB & LAN
DDR1
DDR2
JAUDIO1
PCI1
PCI2
PCI3
JATXPWR1
LAN
CHIP
JCDIN1
JCOM1
JVGA1
COM1
VGA1
JTAD1
JCDIN2
CNR1 WOL1
AGP1
JUSB3
JCMOS1
JPANEL1
JSFAN1
JDIMMVOLT
JCFAN1
JAUXPWR1
FDD1
IDE2 IDE1
Puerto Paralelo
BAT1
INTEL
82845G
INTEL
82801DB
(ICH4)
Winbond
I/O FWH
BIOS
JMS1
JSD1
JSC1
JUSBV1
JKBV1
JUSB4
JUSBV2
Puerto de Juego
Salida del Altavoz
Entrada del MIC Entrada
de Linea
USB 1USB 2
JUSBV3_4

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
12
Instalación de la CPU
1. Tire de la palanca del lado del zócalo, luego levante la palanca
hasta formar un ángulo de 90 grados.
2. Sitúe el contacto A del zócalo y busque el punto blanco o corte el
borde en la CPU. Empareje el contacto A con el punto blanco/
corte del borde, luego inserte la CPU.
3. Presione la palanca hacia abajo. Ponga el ventilador en la CPU y
abróchelo. Luego ponga el puerto de corriente del ventilador en el
JCFAN1. Y ya habrá completado su instalación.
CPU/ Cabezales del Sistema de Ventilación: JCFAN1/
JSFAN1
CPU
JCFAN1
1
Tierra
12V
Sense
JSFAN1
Tierra
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
13
Módulos DDR DIMM: DDR1-2
DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266 MHz Tipo
requerido.
DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM
(contacto 184)
Localización
del Zócalo
DIMM
Módulo DDR Total del Tamaño de
Memoria (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Máximo de
2GB
* La lista de arriba para la configuración DRAM es solamente para
referencia.
Cómo instalar un Módulo DIMM
1. El zócalo DIMM tiene una
lengüeta plástica de seguridad y
el módulo de memoria DIMM
tiene una muesca asimétrica, así
el módulo de memoria DIMM
puede caber solamente en la
ranura de una sóla dirección.
2. Tire la lengüeta hacia afuera.
Inserte los módulos de memoria
DIMM en el zócalo a los 90
grados, luego empuje hacia abajo
verticalmente de modo que
encaje en el lugar.
3. Los agujeros de montaje y las lengüetas plásticas deben caber por
sobre el borde y sostenga los módulos de memoria DIMM en el lugar.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
14
Conectores, Cabezales, Puentes y Ranuras
Conectores del Disco Duro: IDE1/ IDE2
La placa madre tiene un controlador de 32-bit PCI IDE que proporciona
Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100.
Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario).
El conector IDE puede conectar a un master y un drive esclavo, así
puede conectar hasta cuatro discos rígidos. El primer disco duro debe
estar siempre conectado al IDE1.
Conector de la Disquetera: FDD1
La placa madre proporciona un conector estándar del disquete (FDC)
que soporta 360K, 720K, 1.2M, 1.44M y 2.88M tipos de disquete. Éste
conector utiliza los cables de cinta proporcionados por el disquete.
Ranura del Puerto Acelerado para Gráficos: AGP1
Su monitor se fijará automáticamente a la tarjeta de video. Ésta placa
madre soporta tarjeta de video para ranuras PCI, pero también está
equipado con un Puerto Acelerado para Gráficos (AGP). La tarjeta AGP
tomará ventaja de la tecnología AGP para el mejoramiento de la eficacia
y funcionamiento del video, especialmente con gráficos 3D.
Ranura de la Banda de Suspensión de Comunicación y
Red: CNR1
CNR es una abierta Industria Estándar de Arquitectura, y define una
tarjeta de interface del hardware escalable en el que soporta solamente
audio, red y módem.
Ranuras de Interconexión del Componente Periférico:
PCI1-3
Ésta placa madre está equipado con 3 ranuras estándar PCI. PCI es la
sigla para Interconexión del Componente Periférico, y es una tarjeta de
expansión estándar en el que suplanta a la antigua estándar ISA bus en
su mayoría de las partes. Ésta ranura PCI está diseñado con 32 bits.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
15
Conectores de Corriente: JATXPWR1/ JATXPWR2/
(JAUXPWR1=>Opcional)
Conector de la Corriente de Selección DIMM:
JDIMMVOLT
Cabezal Wake On LAN: WOL1
Cabezal Frontal USB: JUSB3/(JUSB4=>Opcional)
JATXPWR1
(ATX Conector de Corriente Principal.)
JATXPWR2
(ATX 12V Conector de Corriente.)
JAUXPWR1
(AUX Conector de Corriente.)
WOL1
1
5V_SB Wake up
Tierra
JUSB3/4
2
1
Contacto1,2 ==> +5V
Contacto3,4 ==> Dato(-)
Contacto5,6 ==> Dato(+)
Contacto7,8 ==> Tierra
Contacto9 ==> KEY
Contacto10 ==> NA
1
2
JDIMMVOLT
Pin 1-2 off ==> 2.6V
Pin 3-4 off ==> 2.7V
Pin 5-6 off ==> 2.8V
Pin 7-8 off ==> 2.9V
(Default ==> 2.5V)
12
JDIMMVOLT
Puente Abierto ==> 2.5V
Contacto 1-2 encendido ==> 2.6V
Contacto 3-4 encendido ==> 2.75V
Contacto 5-6 encendido ==> 2.8V
Contacto 7-8 encendido ==> 2.9V
(Default ==> 2.6V)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
16
5V/ 5VSB Selección para USB: JUSBV1/ (JUSBV2/3_4
Opcional)
5V/ 5VSB Selección para Teclado: JKBV1
Cabezal Memory Stick: JMS1 (opcional)
Cabezal de la Tarjeta de Memoria SD: JSD1 (opcional)
1
JUSBV1/2/3_4
Contacto 1-2 encendido ==> 5V
Contacto 2-3 encendido ==> 5V_SB
1
JKBV1
Contacto 1-2 encendido ==> 5V
Contacto 2-3 encendido ==> 5V_SB
JMS1
Contacto1 ==> Tierra , Contacto2 ==> MS1
Contacto3 ==> 3.3V , Contacto4 ==> MS2
Contacto5 ==> MS3 , Contacto6 ==> MS4
Contacto7 ==> MS5 , Contacto8 ==> MSCLK
Contacto9 ==> MSPWCTL#
Contacto10 ==> MSLED
1
JSD1
Contacto1 ==> Tierra , Contacto2 ==> SD1
Contacto3 ==> 3.3V , Contacto4 ==> SD2
Contacto5 ==> SD3 , Contacto6 ==> SD4
Contacto7 ==> S 5 , Contacto8 ==> SDCLK
Contacto9 ==> SDPWCTL#
Contacto10 ==> SDLED
D
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
17
Cabezal Smart Card: JSC1 (opcional)
Conector del Panel Frontal: JPANEL1
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
SPK ==> Conector de Altavoces
HLED ==> LED del Disco Duro
RST ==> Boton de Reinicio
IR ==> Conector Infrarojo
SLP ==> Boton de Suspension
PWR_LED ==> Corriente LED
ON/ OFF ==> Boton de Encendido
JSC1
Contacto1 ==> 5V , Contacto2 ==> Tierra
Contacto3 ==> SCAPWRCTL#
Contacto4 ==> SCAR5#
Contacto5 ==> SCAC4 , Contacto6 ==> SCALED
Contacto7 ==> SCAIO , Contacto8 ==> SCAC8
Contacto9 ==> SCACLK
Contacto10 ==> SCAPSNT
1
2

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
18
Subsistema de Audio: JAUDIO1/ (JTAD1=>Opcional)/
JCDIN1/ (JCDIN2=>Opcional)
Conectores del Panel Trasero
1
2
JAUDIO1
(Cabezal de Audio Frontal) JTAD1 => opcional (Cabezal de Audio Telefonico)
1
11
JCDIN2 => opcional
(Cabezal de Entrada de Audio CD-ROM) JCDIN1 (Cabezal de Entrada de Audio CD-ROM)
COM1
Game Port/
USB Ports (optional)
JPRNT1
JGAME1_USB1
JCOM1
JKBMS1
USB
RJ45USB1
COM1
JVGA1
VGA1
COM1
Paralelo
Game Port/
USB Ports (optional)
JPRNT1
JGAME1_USB1
JCOM1
JKBMS1
USB
LAN(Opcional)
RJ45USB1
COM1
JVGA1
VGA1
Teclado
PS/2
Raton
PS/2
COM1
Paralelo Puerto de Juego
JPRNT1 JGAME1_USB1
JCOM1
JKBMS1
USB
LAN(Opcional)
RJ45USB1
COM1 Salida del
Altavoz Entrada de Linea
Entrada
del MIC
JVGA1
VGA1
(Modo Normal)
(Adicion del USB alModo del Puertode Juego)
Raton
PS/2
Teclado
PS/2 Salida del
Altavoz Entrada de Linea
Entrada
del MIC
