Biostar P4 TSE-D2 Operating and installation instructions

P
P
P4
4
4T
T
TS
S
SE
E
E-
-
-D
D
D2
2
2
i
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in
a particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here of without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice
and we will not be responsible for any mistakes found in this user’s
manual. All the brand and product names are trademarks of their
respective companies.

C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
t
ii
LAYOUT OF P4TSE-D2 ..........................................................................1
COMPONENT INDEX.............................................................................2
ENGLISH...................................................................................................3
P4TSE-D2 Features....................................................................................................3
Package contents.......................................................................................................5
How to set up Jumper................................................................................................5
CPU Installation..........................................................................................................5
DDR DIMM Modules: DDRA1, DDRB1.......................................................................6
Installing DDR Module...............................................................................................7
Jumpers, Headers, Connectors & Slots...................................................................7
DEUTSCH................................................................................................14
Die Spezifikationen von P4TSE-D2.........................................................................14
Verpackungsinhalt ...................................................................................................16
Einstellung der Jumper ...........................................................................................16
Installation der CPU.................................................................................................16
DDR-DIMM-Modules: DDRA1, DDRB1 ....................................................................17
Installation von DDR-Modul.....................................................................................18
Jumpers, Headers, Anschlüsse & Slots.................................................................18
WARPSPEEDERTM ................................................................................26
Introduction ..............................................................................................................26
System Requirement................................................................................................26
Installation ................................................................................................................27
Usage ........................................................................................................................28
STUDIOFUN!TM (OPTIONAL).............................................................36
Introduction ..............................................................................................................36
Hardware Requirements..........................................................................................36
Installation and Usage.............................................................................................36
TROUBLE SHOOTING.........................................................................37
PROBLEMLÖSUNG..............................................................................38

1
Layout of P4TSE-D2
NOTE: ●represents the first pin.

2
Component Index
A. Power Source Selection for Keyboard and N. Communication Network Riser Slot (CNR1)
Mouse (JKBV1) O. System FAN Header (JSFAN1)
B. Power Source Selection for USB P. Front USB Header (JUSB2)
(JUSBV1) Q. Front USB Header (JUSB3)
C. Back Panel Connector R. Power Source Selection for USB
D. Power Source Selection for USB (JUSBV3_4)
(JUSBV2) S. Game Port Header (JGAME1)
E. ATX Power Connector (JATXPWR2) T. Front Panel Connector (JPANEL1)
F. ATX Power Connector (JATXPWR1) U. Serial ATA Connector (SATA1-2)
G. Front Audio Header (JAUDIO1) V. Case Open Connector (JCL1)
H. Accelerated Graphics Port Slot (AGP1) W. Clear CMOS Function (JCMOS1)
I. Digital Audio Connector (JSPDIF_OUT1) X. IDE Connectors (IDE1-2)
J. CD-ROM Audio-In Header (JCDIN2) Y. DDR DIMM Modules (DDRA1/ DDRB1)
K. CD-ROM Audio-In Header (JCDIN1) Z. Floppy Disk Connector (FDD1)
L. PCI BUS Slots (PCI 1-5) A1. CPU Fan Connector (JCFAN1)
M. Wake On LAN Header (WOL1) B1. Audio DJ Connector (JDJ1)

3
English
P4TSE-D2 Features
A. Hardware
CPU
Provides Socket-478.
Supports the Intel Pentium 4 processor to 3.2GHz.
Front Side Bus at 400/533/800MHz.
Supports Hyper-Threading Technology.
Supports Northwood CPU. (Willamette not supported)
Chipset
North Bridge: Intel 865PE.
South Bridge: Intel ICH5.
Main Memory
Supports one or two 64-bit wide DDR data channels with 1 DIMMs per-channel.
Available bandwidth up to 3.2GB/s(DDR400) for single-channel mode and 6.4GB/s
(DDR 400) in dual channel mode.
Supports 128-Mb, 256-Mb, 512-Mb DDR technologies.
Supports only x8, x16 DDR devices.( Does not support registered DIMMs and
ECC)
Supports four bank devices.
Maximum memory size is 2GB.
Super I/O
Chip: ITE IT8712.
Low Pin Count Interface.
Provides the most commonly used legacy Super I/O functionality.
Environment Control initiatives,
- H/W Monitor
- Fan Speed Controller
- ITE's "Smart Guardian" function
Slots
Five 32-bit PCI bus master slots.
One CNR slot.
One AGP 4X/8X slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 5, and Ultra DMA 33/66/100 Bus Master Mode.

4
LAN (optional)
Chip: RTL8100C/ RTL8110S(B).
Supports 10 Mb/s, 100 Mb/s and 1000Mb/s auto-negotiation operation.
Half/ Full duplex capability.
Supports ACPI, PCI power management.
On Board AC’97 Sound Codec
Chip: CMI9739A.
Compliant with AC’97 specification.
AC97 2.2 interface.
Supports 6 channels.
On Board Peripherals
a.Rearside
2 serial ports.
1 parallel port. (SPP/EPP/ECP mode)
Audio ports in vertical position.
1 RJ-45 LAN jack. (optional)
PS/2 mouse and PS/2 keyboard.
4 USB2.0 ports.
b.FrontSide
1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
4 USB2.0 ports.
1 front audio header.
1 S/PDIF header.
1 Audio DJ header.
Dimensions
ATX Form Factor: 20.3 X 30.5cm (W X L)
B. BIOS & Software
BIOS
Award legal BIOS.
APM1.2.
ACPI.
USB Function.
Software
Supports Warpspeeder™, 9th Touch™, WinFlasherTM, BootBlockerTM, FLASHER™
and StudioFun! ™ (optional).
Offers the highest performance for Windows 98 SE, Windows 2000, Windows Me,
Windows XP, SCO UNIX etc.

5
Package contents
HDD Cable X 1
FDD Cable X 1
User’s Manual X 1
Fully Setup Driver CD X 1
StudioFun! Application CD X 1 (optional)
USB 2.0 Cable X1 (optional)
S/PDIF Cable X 1 (optional)
Rear I/O Panel for ATX Case X 1
Serial ATA Cable X 1 (optional)
Serial ATA Power Switch Cable X 1 (optional)
How to set up Jumper
The illustration shows to how set up jumper. When the Jumper cap is placed on pins, the
jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The
illustration shows a 3-pin jumper whose pin1and 2 are “close” when jumper cap is placed
on these 2 pins.
Jumper open Jumper close Pin1-2 close
CPU Installation
Step1: Pull the lever sideways away from the socket and then raise the lever up to a
90-degree angle.
Step2: Look for the white dot/cut edge. The white dot/cut edge should point wards the
lever pivot. The CPU will fit only in the correct orientation.
Step3: Hold the CPU down firmly, and then close the lever to complete the installation.
Step4: Put the CPU Fan on the CPU and buckle it. Connect the CPU fan power cable to
the JCFAN1. This completes the installation.

6
Step1 Step2 Step3 Step4
CPU Fan Header: JCFAN1
Pin Assignment
1 Ground
2 +12V
1
3
JCFAN1 3 FAN RPM rate Sense
System Fan Header: JSFAN1
Pin Assignment
1 Ground
2 +12V
31
JSFAN1
3 FAN RPM rate Sense
DDR DIMM Modules: DDRA1, DDRB1
Dual Channel Guidelines
Matched DIMM configuration in each channel
!" Same Density (128MB, 256MB, 512MB, 1GB, etc.)
!" Same DRAM technology (128M-bit, 256M-bit, or 512M-bit)
!" Same DRAM bus width (x8 or x16)
!" Both either single-sided or dual-sided
Matched in both Channel A and Channel B memory channels
!" Populate symmetrical memory slots
Optimal platform performance with Dual Channel, DDR400, matched DIMMs
!" Fully loaded configurations can be single or double sided DIMMs

7
When not using DDR400, best performance obtained with
!" Symmetrical DIMM population and matched double-sided DIMMs
Dual Channel Configuration Table
• Dual Channel Configuration Table
DIMM Slot DDRA1 DDRB1 System Density
Fully Loaded Config 128MB -- 1GB 128MB -- 1GB 256MB -- 2GB
DRAM Access Time: 2.5V Unbuffered/ no registered (without ECC) DDR SDRAM
PC2100/ PC2700/ PC3200 Type required.
DRAM Type: 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)
Installing DDR Module
1. Unlock a DIMM slot by pressing the retaining clips
outward. Align a DIMM on the slot such that the
notch on the DIMM matches the break on the slot.
2. Insert the DIMM vertically and firmly into the slot
until the retaining chip snap back in place and the
DIMM is properly seated.
Jumpers, Headers, Connectors & Slots
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports 360K,
720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the
provided floppy drive ribbon cables.
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~5, Bus Master, and Ultra DMA 33/ 66/ 100 functionality. It has two HDD
connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.

8
Peripheral Component Interconnect Slots: PCI 1-5
This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral
Component Interconnect, and it is a bus standard for expansion cards. This PCI
slot is designated as 32 bits.
Accelerated Graphics Port Slot: AGP1
Your monitor will attach directly to that video card. This motherboard supports
video cards for PCI slots, but it is also equipped with an Accelerated Graphics Port
(AGP). An AGP card will take advantage of AGP technology for improved video
efficiency and performance, especially with 3D graphics.
Communication Network Riser Slot: CNR1
The CNR specification is an open Industry Standard Architecture, and it defines a
hardware scalable riser card interface, which supports modem only.
Serial ATA Connector: JSATA1/ JSATA2
The motherboard has a PCI to SATA Controller with 2 channels SATA interface, it
satisfies the SATA 1.0 spec and with transfer rate of 1.5Gb/s.
Serial ATA Connectors: SATA1/ SATA2
Pin Assignment Pin Assignment
1 Ground 2 TX+
3 TX- 4 Ground
5 RX- 6 RX+
1
23
4
56
7
SATA1/ SATA2 7 Ground
Case Open Connector: JCL1
Pin Assignment
1 Case Open Signal
1
JCL1 2 Ground
AUDIO DJ Connector: JDJ1
Pin Assignment Pin Assignment
1 SMBDATA 2 SMBCLK
3 INT_B 4 KEY
15
JDJ1 5 ATX_PWROK

9
Front Panel Connector: JPANEL1
Power Connectors: JATXPWR1/ JATXPWR2
PIN Assignment PIN Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS_ON
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 Standby Voltage
+5V 19 +5V
20
11
10
1
JATXPWR1
10 +12V 20 +5V
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Pin Assignment Function Pin Assignment Function
1 +5V 2 Sleep Control
3 NA 4 Ground Sleep
Button
5 NA 6 NA NA
7 Speaker
Speaker
Connector
8 Power LED (+)
9 HDD LED (+) 10 Power LED (+)
11 HDD LED (-) Hard Drive
LED 12 Power LED (-)
POWER
LED
13 Ground 14 Power Button
15 Reset Control Reset
Button 16 Ground Power-on
Button
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Ground
23 IRTX
IrDA
Connector
24 IRRX
IrDA
Connector
JPANEL1

10
PIN Assignment PIN Assignment
1 +12V 3 Ground
1
2
3
JATXPWR2 2 +12V 4 Ground
Power Source Selection for Keyboard/ Mouse: JKBV1
JKBV1 Assignment Description
1
3
Pin 1-2 close
+5V
+5V for keyboard and mouse
1
3
Pin 2-3 close
+5V Standby
Voltage
PS/2 Mouse and PS/2 Keyboard are
powered with +5V standby voltage
Note: In order to support this function “Power-on system via keyboard and
mouse”, “JKBV1” jumper cap should be placed on pin 2-3.
Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV3_4
JUSBV1/JUSBV2/
JUSBV3_4 Assignment Description
1 3
Pin 1-2 close
+5V
JUSBV1: 5V for USB at the JUSB1
connector port
JUSBV2: 5V for USB at the JRJ45USB1
coonector port
JUSBV3_4: 5V for USB at the JUSB2/3
connector ports
1 3
Pin 2-3 close
+5V Standby
Voltage JUSBV1: JUSB1 port powered with
standby voltage of 5V
JUSBV2: JRJ45USB1 port powered
with standby voltage of 5V
JUSBV3_4: JUSB2/3 ports powered
with standby voltage of 5V

11
Note: In order to support this function “Power-on system via USB device”,
“JUSBV1/JUSBV2/ JUSBV3_4” jumper cap should be placed on pin 2-3
respectively.
Clear CMOS Jumper: JCMOS1
JCMOS1 Assignment
1
3
Pin 1-2 Close
Normal Operation (default)
1
3
Pin 2-3 Close
Clear CMOS Data
※Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 Close”.
3. Wait for five seconds.
4. Set the jumper to “Pin 1-2 Close”.
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.
Game Header: JGAME1
1
216
15
JGAME1
Pin Assignment Pin Assignment
1 +5V 2 +5V
3 Joystick B Button 1 4 Joystick A Button 1
5 Joystick B Coordinate X 6 Joystick A Coordinate X
7 MIDI Output 8 Ground
9 Joystick B Coordinate Y 10 Ground
11 Joystick B Button 2 12 Joystick A Coordinate Y
13 MIDI Input 14 Joystick A Button 2
15 NA 16 +5V

12
CD-ROM Audio-In Header: JCDIN1/ JCDIN2
Pin Assignment
1 Left Channel Input
2 Ground
3 Ground
1
JCDIN1/ JCDIN2 4 Right Channel Input
Front Panel Audio Header: JAUDIO1
1
213 14
JAUDIO1
Pin Assignment Pin Assignment
1 Mic In/ Center 2 Ground
3 Mic Power/ Bass 4 Audio Power
5 Right Line Out/ Speaker Out
Right 6 Right Line Out/ Speaker Out Right
7 Reserved 8 Key
9 Left Line Out/ Speaker Out
Left 10 Left Line Out/ Speaker Out Left
11 Right Line In/ Rear Speaker
Right 12 Right Line In/ Rear Speaker Right
13 Left Line In/ Rear Speaker Left 14 Left Line In/ Rear Speaker Left
Digital Audio Connector: JSPDIF_OUT1
Pin Assignment
1 +5V
2 SPDIF_OUT
1
JSPDIF_OUT1 3 Ground
Wake On LAN Header: WOL1
Pin Assignment
1 +5V_SB
2 Ground
1
WOL1 3 Wake up

13
Front USB Header: JUSB2/3
Pin Assignment Pin Assignment
1 +5V(fused) 2 +5V(fused)
3 USB- 4 USB-
5 USB+ 6 USB+
7 Ground 8 Ground
2
1
10
9
JUSB2/3
9 KEY 10 NC
Back Panel Connectors
6 Channel Speakers
Speaker Out
Line In/ Rear Speaker
Mic In/ Center & Bass
PS/2
Keyboard
PS/2
Mouse Parallel Port
JPRNT1
JCOM1
JKBMS1
USB
COM1
JCOM2
COM2 USB
JRJ45USB1
MIC In
Speaker Out
Line In
JAUDIO
JUSB1
LAN
(optional)

14
Deutsch
Die Spezifikationen von P4TSE-D2
A. Hardware
CPU
Uterstützung für Sockel 478.
Unterstützung für den Intel Pentium®4 Prozessor bis zu 3.2GHz.
FSB mit 400/533/800MHz.
Uterstützung für die Hyper-Threading Technologie.
Unterstützung für Intel CPU Northwood. (Willamette wird nicht untergestützt)
Chipsatz
Die Northbridge: Intel 865PE.
Die Southbridge: Intel ICH5.
Hauptspeicher
Unterstützung für ein oder zwei 64-bit Breite DDR-Datenkanal mit ein oder zwei
DIMMs pro Kanal.
Verfügbare Bandbreite bis zu 3.2GB/s(DDR400) für Einzeln-Kanal-Modus.
Unterstützung für 128-MB, 256-Mb und 512-Mb DDR Technologie.
Unterstützung für x8, x16 DDR Geräte.( Registrierte DIMMs und doppelseitig X 16
DIMMs werden nicht untergestützt)
Vier DDR Speicherbänke.
Die maximale Speichergröße ist 2GB.
Super I/O
Chip: ITE IT8712.
Low Pin Count Interface.
Die meisten gemeinsamen vergebrauchten Super I/O Funktionen werden geliefert.
Umweltkontroll-Initiative:
- H/W Monitor
- Vetilator-Geschwindigkeit-Controller
- ITE's "Smart Guardian" Funktion
Steckplätze
Fünf 32-bit PCI-Bus-Slots.
Ein CNR-Slot.
Ein 4X/8X AGP-Slot.
Onboard-IDE
Unterstützung für vier IDE Diskettenlaufwerke.
Unterstützung für PIO Modus 5, und Ultra DMA 33/66/100 Bus Master Modus.

15
LAN (optional)
Chip: RTL8100C/ RTL8110S(B).
Unterstützung für 10Mb/s ,100 Mb/s und 1000Mb/s Auto-Negotiation.
Halb/Voll-Duplex Fähigkeit.
Unterstützung für ACPI, PCI Power Management.
Onboard AC’97 Sound Codec
Chip: CMI9739A.
Entspricht der Spezifikation von AC’97.
AC97 2.2 Interface.
Unterstützung für 6-Kanal.
Onboard-Peripheriegeräte
a.Rückwand
2 serielle Schnittstellen.
1 parallele Schnittstelle. (SPP/EPP/ECP-Modus)
Audio-Schnittstellen auf der vertikalen Postion i
1 RJ-45 LAN Buchse.(optional)
PS/2-Maus und PS/2-Tastatur.
4 USB2.0-Ports.
b.Vorderseite
1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB,
1.44MB und 2.88MB)
4 USB2.0-Ports.
1 Front Audio Header.
1 S/PDIF-Header.
1 Audio DJ Header.
Abmessungen
ATX Form-Factor: 20.3 X 30.5cm (W X L)
B. BIOS & Software
BIOS
Award legal BIOS.
APM1.2.
ACPI.
USB Funkion.
Software
Unterstützung für Warpspeeder™, 9th Touch™, WinFlasherTM, BootBlockerTM,
FLASHER™ und StudioFun! ™ (optional).
Unterstützung für die am meisten verbreiteten Betriebsysteme wie Windows 98SE,
Windows 2000, Windows ME, Windows XP and SCO UNIX usw..

16
Verpackungsinhalt
HDD Kable X 1
FDD Kable X 1
Benutzer Handbuch X1
Treiber CD für Installation X1
StudioFun! Anwendung CD X 1 (optional)
USB 2.0 Kable X1 (optional)
S/PDIF Kable X 1 (optional)
I/O-Rückwand für ATX Gehäuse X 1
Serial ATA Kable X 1 (optional)
Serial ATA Netzschalter Kable X 1(optional)
Einstellung der Jumper
Die Abbildung verdeutlicht, wie Jumper eingestellt werden. Pins werden durch die
Jumper-Kappe verdeckt, ist der Jumper ”geschlossen”. Keine Pins werden durch die
Jumper-Kappe verdeckt, ist der Jumper “geöffnet”. Die Abbiildung zeigt einen 3-Pin
Jumper dessen Pin1 und Pin2 ”geschlossen“ sind, bzw. es befindet sich eine
Jumper-Kappe auf diesen beiden Pins.
Jumper geschlossen Jumper geöffnet Pin1-2 geschlossen
Installation der CPU
Schritt 1: Ziehen Sie den Hebel seitlich vom Sockel weg. Heben Sie den Hebel
dann in 90-Grad-Winkel nach oben.
Schritt 2: Suchen Sie nach der scharfen Kante, die auf Drehpunkt des Hebels
weisen muss. Die CPU passt nur, wenn sie richtig ausgerichtet ist.
Schritt 3: Drücken Sie die CPU fest in den Sockel und schließen Sie den Hebel.
Schritt 4: Stecken Sie Ihren CPU-Lüfter auf die CPU. Schließen Sie die
Stromversorgungsstecker für CPU-Lüfter an JCFAN1 an. Dann beenden
Sie die Installation.

17
CPU-Lüfter Header: JCFAN1
Pin Beschreibung
1 Masse
2 +12V
1
3
JCFAN1 3 Lüfter Umdreh. pro Minute
Sensor
System-Lüfter Header: JSFAN1
Pin Beschreibung
1 Masse
2 +12V
31
JSFAN1
3 Lüfter Umdreh. pro Minute
Sensor
DDR-DIMM-Modules: DDRA1, DDRB1
Dual-Kanal Richtlinie
Entsprechende DIMM-Konfiguration für pro Kanal
!" Gleiches Dichte (128MB, 256MB, 512MB, 1GB, etc.)
!" Gleiche DRAM Technologie (128M-bit, 256M-bit, oder 512M-bit)
!" Gleiche DRAM Bus Weite (x8 or x16)
!" Ein von jenen ist einzelnseitig oder doppeltseitig
Entsprechend DIMM-Konfiguration für die beide Spreicherkanale (Kanal A und
Kanal B)
!" Stellen symmetrisch Spreicher-Slots
Schritt1 Schritt2 Schritt3 Schritt4

18
Optimale Plattform-Performance mit Dual-Kanal, DDR400, entsprechende DIMMs
!" Voll-Beladete Konfiguration: Einzeln- oder doppeltseitig DIMMs sind
möglich
!" When not using DDR400, best performance obtained with
!" Symmetrische DIMM-Population und entsprechende doppeltseitige DIMMs
Dual-Kanal Konfiguration Matrix
• Dual-Kanal Konfiguration Matrix
DIMM-Slot DDRA1 DDRB1 System Dichte
Voll-Beladete
Konfiguration
128MB --
1GB
128MB -- 1GB 256MB -- 2GB
DRAM-Zugriffszeit: 2.5V unbuffered/ nicht registrierter (ohne ECC) DDR SDRAM
PC2100/ PC2700/ PC3200 Typ erforderlich.
DRAM-Typ: 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin)
Installation von DDR-Modul
1. Öffnen Sie einen DIMM-Slots, indem Sie die
seitlich Chips nach außen drücken. Richten Sie
das DIMM-Modul so über dem Slot aus, dass das
Modul mit der Kerbe in den Slot passt.
2. Drücken Sie das DIMM-Modul in den Slot, bis die
seitlichen Clips zuschnappen und das Modul fest
sitzt.
Jumpers, Headers, Anschlüsse & Slots
Diskettenanschluss: FDD1
Das Motherboard enthält einen standardmäßigen Diskettenanschluss, der 360K-,
720K-, 1.2M-, 1.44M- und 2.88M-Disketten unterstützt. Dieser Anschluss
unterstützt die mitgelieferte Bandkabel des Diskettenlaufwerks.
Festplattenanschlüsse: IDE1 und IDE2
Das Mainboard hat einen 32-Bit Enhanced PCI IDE-Controller, der die Modi
PIO0~4, Bus Master sowie die Ultra DMA/33/66/100/133- Funktion zur Verfügung
stellt. Dieser ist mit zweii HDD-Anschlüssen versehen IDE1 (primär) und IDE2
