P4SDP Features
 Use Sis 645DX/ Sis 962 Chipset, ITE IT8705, LAN Chip- VT6103
(optional).
 Contains on board I/O facilities, which include two serial ports, a parallel
port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a
LAN port (optional) and a game port.
 Supports the Intel Pentium® 4 processor (Socket-478).
 Supports Ultra 133/100/66/33, BMIDE and PIO modes.
 Supports USB2.0, 6 ports, High Speed Device, 2 ports in rear panel and 4
ports in front panel.
 Supports up to 2 DDR 200/266/333 MHz (without ECC) devices, running at
533 MHz Front Side Bus frequency.
 Supports a maximun memory size up to 2 GB.
 Supports one CNR Slot (Type B only), one AGP Slot, and five 32-bit PCI
Bus slots.
 Complies with PC ATX form factor specifications.
 Supports popular operating systems such as Windows 98, Windows 2000,
Windows ME, Windows XP, LINUX and SCO UNIX.
 Intel®AC’97 2.2 compatible.
 High S/N ratio meets PC 99 requirements.
 6CH DAC, applicable for leading motherboard chipsets.
 Line-in phonejack share with rear out.
 Supports front audio pin head functions.
 Supports 3 ports of IEEE 1394 function.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
2
Package contents
 HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1
 Flash Memory Writer for BIOS update X 1
 USB Cable X 2 (Optional)
 Rear I/O Panel for ATX Case X 1 (Optional)
Layout of P4SDP
DDR 1
DDR 2
SIS 645DX
Socket 478
JAUDIO1
1
2
K/B
&
Mouse
JKBMS1
PCI3
CNR1
BAT1
JCFAN1
JUSB1
AGP1
JCDIN1
JGAME1
GAME Port
SP-OUTLINE-INMIC-IN
JATXPWR2
PCI1
PCI2
PCI4
Codec
1
H/W
AUDIO
Chip
(optional)
JUSBV2
IDE1 JCMOS1
SIS 962
PRIMARY IDE CONN.
JSFAN1
PCI5
1
JPANEL1
FDD1
JWOL1
1
2
23
24
1
SECONDARY IDE CONN.
FLOPPY DISK CONN.
IDE2
JUSB2
2
1
BIOS
13
14
JUSBLAN1
JPRNT1
JCOM1
JCOM2
COM1
Parallel Port
JATXPWR1
ITE I/O
J1394A2
2
J1394A1
2
J1394A3
2
1394A
Chip
10 210
JUSBV1
LAN Chip

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
3
CPU Installation
1. Pull the lever sideways away from the socket then raise the lever up
to 90-degree angle.
2. Locate Pin A in the socket and lock for the white dot or cut edge in
the CPU. Match Pin A with the white dot/cut edge then insert the
CPU.
3. Press the lever down. Then Put the fan on the CPU and buckle it
and put the fan’s power port into the JCFAN1, then to complete the
installation.
CPU/ System Fan Headers: JCFAN1/ JSFAN1
CPU
JCFAN1
Ground
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
4
DDR DIMM Modules: DDR1-2
DRAM Access Time: 2.5V Unbuffered DDR 200/266/333 MHz Type
required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184
pin)
DIMM Socket
Location DDR Module Total Memory Size (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
* The list shown above for DRAM configuration is only for reference.
How to install a DIMM Module
1. The DIMM socket has a
“ Plastic Safety Tab”, and the
DIMM memory module has an
“Asymmetrical notch”, so the
DIMM memory module can only
fit into the slot in one direction.
2. Push the tabs out. Insert the
DIMM memory modules into the
socket at a 90-degree angle, then
push down vertically so that it will
fit into the place.
3. The Mounting Holes and plastic
tabs should fit over the edge and
hold the DIMM memory modules
in place.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
5
Jumpers, Headers, Connectors & Slots
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that
provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100/ 133
functionality. It has two HDD connectors IDE1 (primary) and IDE2
(secondary).
The IDE connectors can connect a master and a slave drive, so you can
connect up to four hard disk drives. The first hard drive should always be
connected to IDE1.
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that
supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This
connector supports the provided floppy drive ribbon cables.
Communication Network Riser Slot: CNR1
The CNR specification is an open Industry Standard Architecture, and it
defines a hardware scalable riser card interface, which supports audio,
network and modem only.
Peripheral Component Interconnect Slots: PCI1-5
This motherboard is equipped with 5 standard PCI slots. PCI stands for
Peripheral Component Interconnect, and it is a bus standard for
expansion cards, which has, supplanted the older ISA bus standard in
most ports. This PCI slot is designated as 32 bits.
AGP (Accelerated Graphics Port) Slot: AGP1
Your monitor will attach directly to that video card. This motherboard
supports video cards for PCI slots, but it is also equipped with an
Accelerated Graphics Port. An AGP card will take advantage of AGP
technology for improved video efficiency and performance, especially
with 3D graphics.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
6
Power Connectors: JATXPWR1/ JATXPWR2
Wake On LAN Header: WOL1
Front USB Header: JUSB1/ JUSB2
JATXPWR1
(ATX Main Power Connector)
JATXPWR2
(ATX 12V Power Connector)
WOL1
1
5V_SBWake up
Ground
JUSB1/2
2
1Pin1,2 ==> +5V
Pin3,4 ==> Data(-)
Pin5,6 ==> Data(+)
Pin7,8 ==> Ground
Pin9 ==> KEY
Pin10 ==> NA

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
7
5V/ 5VSB Selection for USB: JUSBV1/ 2
Front Panel Connector: JPANEL1
Audio Subsystem: JAUDIO1/ JCDIN1
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
SPK ==> Speaker Conn.
HLED ==> Hard Driver LED
RST ==> Reset Button
IR ==> Infrared Conn.
SLP ==> Sleep Button
PWR_LED ==> Power LED
ON/ OFF ==> Power-on Button
(+) (-)
(+) (-)(+)
1
JUSBV1/ 2
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
8
Clear CMOS Jumper: JCMOS1
Front 1394A Header: J1394A1/ J1394A2/ J1394A3
1
JCMOS1
Pin 1-2 on ==> Normal Operation
(default)
Pin 2-3 on ==> Clear CMOS Data
Pin1 ==> Mic In Pin2 ==> Ground
Pin3 ==> Mic Power Pin4 ==> Audio Power
Pin5 ==> RT Line Out Pin6 ==> RT Line Out
Pin7 ==> Reserved Pin8 ==> KEY
Pin9 ==> LFT Line Out Pin10 ==> LFT Line Out
Pin11==> RT Line In Pin12 ==> RT Line In
Pin13 ==> LFT Line In Pin14 ==> LFT Line In
JAUDIO1
1
213
14
J1394A1/A2/A3
2
1Pin1,2 ==> A+/A-
Pin3,4 ==> Ground
Pin5,6 ==> B+/ B-
Pin7,8 ==> +12V
Pin9 ==> KEY
Pin10 ==> GND

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
9
Back Panel Connectors
PS/2
Keyboard
PS/2
Mouse
COM1
Parallel Game Port
JPRNT1 JGAME1
JCOM1
JKBMS1
USB
LAN(Optional)
JUSBLAN1
Speaker
Out Line In Mic
In
COM2
JCOM2

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
10
Español
Características del P4SDP
 Usa Chipset SIS 645DX/ SIS 962, ITE IT8705, LAN Chip- VT6103
(opcional).
 Contiene facilidades I/O integrados en la placa madre en el que incluye
dos puertos en serie, un puerto paralelo, un puerto para ratón PS/2, un
puerto para teclado PS/2, puertos de audio, puertos USB, puerto LAN
(opcional) y un puerto para juegos.
 Soporta procesador Intel Pentium 4®(Socket 478).
 Soporta Ultra 133/100/66/33, BMIDE y modo PIO.
 Soporta Dispositivo High Speed USB2.0, 6 puertos, 2 puertos en el panel
trasero y 4 puertos en el panel frontal.
 Soporta hasta 2 dispositivos DDR 200/266/333 MHz (no incluye ECC),
corriendo a 533 MHz frecuencia Front Side Bus.
 Soporta una memoria máxima de hasta 2 GB.
 Soporta una ranura CNR (solamente de tipo B), una ranura AGP y cinco
ranuras PCI Bus de 32-bit.
 Compatible con la forma de factor de tamaño PC ATX.
 Soporta sistemas operativos populares tales como Windows 98, Windows
2000, Windows ME, Windows XP, LINUX y SCO UNIX.
 Intel®AC’97 2.2 compatible.
 High S/N ratio meets PC 99 requirements.
 6CH DAC, applicable a los chipsets de la place madre.
 Entrada de Línea compartido con el rear out.
 Soporta funciones del cabezal de contactos del audio frontal.
 Soporta 3 puertos de la función IEEE 1394.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
11
Contenido del Paquete
 Cable HDD X 1, Cable FDD X 1, Completo Setup Driver CD X 1
 Memoria Flash Writer para actualización del BIOS X 1
 Cable USB X 2 (Opcional)
 Panel trasero I/O para caja ATX X 1 (Opcional)
Disposición del P4SDP
DDR 1
DDR 2
SIS 645DX
Socket 478
JAUDIO1
1
2
Teclado
&
Raton
JKBMS1
PCI3
CNR1
BAT1
JCFAN1
JUSB1
AGP1
JCDIN1
JGAME1
Puerto de Juego
Salida del Altavoz
Entrada de Linea
Entrada del MIC
JATXPWR2
PCI1
PCI2
PCI4
Codec
1
Chip del
H/W
AUDIO
(opcional)
JUSBV2
IDE1 JCMOS1
SIS 962
JSFAN1
PCI5
1
JPANEL1
FDD1
JWOL1
1
2
23
24
1
IDE2
JUSB2
2
1
BIOS
13
14
JUSBLAN1
JPRNT1
JCOM1
JCOM2
COM1
Puerto Paralelo
JATXPWR1
ITE I/O
J1394A2
2
J1394A1
2
J1394A3
2
1394A
Chip
10 210
JUSBV1
LAN Chip

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
12
Instalación de la CPU
1. Tire de la palanca del lado del zócalo, luego levante la palanca
hasta un ángulo de 90 grados.
2. Sitúe el contacto A del zócalo y busque el punto blanco o corte el
borde en la CPU. Empareje el contacto A con el punto blanco/
corte del borde, luego inserte la CPU.
3. Presione la palanca para abajo. Ponga el ventilador en la CPU y
abróchelo. Luego ponga el puerto de corriente del ventilador en el
JCFAN1. Y ya habrá completado su instalación.
CPU/ Cabezales del Sistemas de Ventilación: JCFAN1/
JSFAN1
CPU
JCFAN1
Tierra
12V
Sense
1

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
13
Módulos DDR DIMM: DDR1-2
DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266/333 MHz
Tipo requerido.
DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184
Contactos)
Localización
del Zócalo
DIMM
Módulo DDR Total del
Tamaño de
Memoria (MB)
DDR 1 64MB/128MB/256MB/512MB/1GB
*1
DDR 2 64MB/128MB/256MB/512MB/1GB
*1
Máxima es
2GB
* La lista de arriba para la configuarción DRAM es solamente para
referencia.
Cómo instalar un módulo DIMM
1. El zócalo DIMM tiene una
lengüeta plástica de seguridad y
el módulo de memoria DIMM
tiene una muesca asimétrica, así
el módulo de memoria DIMM
puede caber solamente en la
ranura de una sóla dirección.
2. Tire la lengüeta hacia afuera.
Inserte los módulos de memoria
DIMM en el zócalo a los 90
grados, luego empuje hacia abajo
verticalmente de modo que
encaje en el lugar.
3. Los agujeros de montaje y las
lengüetas plásticas deben caber
por sobre el borde y sostenga los
módulos de memoria DIMM en el lugar.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
14
Conectores, Cabezales, Puentes y Ranuras
Conectores del Disco Duro: IDE1/ IDE2
La placa madre tiene un controlador de 32-bit PCI IDE que proporciona
Modo PIO 0~4, Bus Master, y funcionalida Ultra DMA / 33/ 66/ 100.
Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario).
El conector IDE puede conectar a un master y un drive esclavo, así
puede conectar hasta cuatro discos rígidos. El primer disco duro debe
estar siempre conectado al IDE1.
Conector para el Disquete: FDD1
La placa madre proporciona un conector estándar del disquete (FDC)
que soporta 360K, 720K, 1.2M, 1.44M y 2.88M tipos de disquete. Éste
conector utiliza los cables de cinta proporcionados por el disquete.
Ranura de Canalización de la Red de Comunicación:
CNR1
La especificación CNR es una abierta Industria Estándar de Arquitectura,
y define una tarjeta hardware escalable de interface en el que soporta
audio, red y módem.
Ranura de Interconexión del Componente Periférico:
PCI1-5
Ésta placa madre está equipado con 5 ranuras PCI. PCI es la sigla para
Interconexión del Componente Periférico, y es un estándar bus para la
tarjeta de expansión en el que reemplaza, en su mayoría de las partes,
al antiguo estándar ISA bus. Las ranuras de PCI están desiñados con
32 bits.
Accelerated Graphics Port Slot: AGP1
Su monitor se fijará directamente a la tarjeta de video. Ésta placa madre
soporta tarjetas de video para ranuras PCI, y también está equipado con
un Puerto Acelerado para Gráficos. Ésta tarjeta AGP tomará ventaja de
la tecnología del AGP para el mejoramiento de la eficiencia y
funcionamiento del video, especialmente con gráficos 3D.

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
15
Conectores de Encendido: JATXPWR1/ JATXPWR2
Cabezal Wake On LAN: WOL1
Cabezal Frontal USB: JUSB1/ JUSB2
5V/ 5VSB Selección para USB: JUSBV1/ 2
JATXPWR1
(ATX Conector de Corriente Principal)
JATXPWR2
(ATX 12V Conector de Corriente)
WOL1
1
5V_SBWake up
Tierra
JUSB1/2
Contacto1,2 ==> +5V
Contacto3,4 ==> Dato(-)
Contacto5,6 ==> Dato(+)
Contacto7,8 ==> Tierra
Contacto9 ==> KEY
Contacto10 ==> NA
2
1
1
JUSBV1/ 2
Contacto 1-2 on ==> 5V
Contacto 2-3 on ==> 5V_SB

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
16
Conector del Panel Frontal: JPANEL1
Subsistema de Audio: JAUDIO1/ JCDIN1
SPK ==> Conector de Altavoz
HLED ==> LED del Disco Duro
RST ==> Boton de Reinicio
IR ==> Conector Infrarojo
SLP ==> Boton de Suspension
PWR_LED ==> Corriente LED
ON/ OFF ==> Boton de Encendido
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
1
2
JAUDIO1
(Front Audio Header)
1
JCDIN1
(CD-ROM Audio-In Header)
1
2
JAUDIO1
(Cabezal de Audio Frontal)
1
JCDIN1
(Cabezal de Entrada de Audio
CD-ROM)
13
14

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
17
Puente de Borrar CMOS: JCMOS1
Cabezal Frontal 1394A: J1394A1/ J1394A2/ J1394A3
Pin1 ==> Entrada del Mic Pin2 ==> Tierra
Pin3 ==> Corriente del Mic Pin4 ==> Corriente del Audio
Pin5 ==> RT Salida de Linea Pin6 ==> RT Salida de Linea
Pin7 ==> Reservado Pin8 ==> KEY
Pin9 ==> LFT Salida de Linea Pin10 ==> LFT Salida de Linea
Pin11 ==> RT Entrada de Linea Pin12 ==> RT Entrada de Linea
Pin13 ==> LFT Entrada de Linea Pin14 ==> LFT Entrada de Linea
JAUDIO1
1
213 14
1
JCMOS1
Contacto 1-2 on ==> Operacion Normal
(default)
Contacto 2-3 on ==> Borrar Datos CMOS
J1394A1/A2/ A3
2
1Contacto1,2 ==> A+/A-
Contacto3,4 ==> Tierra
Contacto5,6 ==> B+/ B-
Contacto7,8 ==> +12V
Contacto9 ==> KEY
Contacto10 ==> GND

M
M
Mo
o
ot
t
th
h
he
e
er
r
rb
b
bo
o
oa
a
ar
r
rd
d
d
D D
De
e
es
s
sc
c
cr
r
ri
iip p
pt
t
ti
iio o
on
n
n
18
Conectores del Panel Trasero
Teclado
PS/2
Raton
PS/2 Paralelo Puerto de Juego
JPRNT1 JGAME1
JCOM1
JKBMS1
USB
LAN(Opcional)
JUSBLAN1
COM1 Salida del
Altavoz Entrada de Linea Entrada de
Mic
JCOM2
COM2
