BK RESOURCES DW-2-1 Installation instructions

DRAWER WARMER MANUAL
INSTALLATION & OPERATING MANUAL

DRAWER WARMER MANUAL
2www.bk-resources.com | [e-mail]
WARNING
Improper installation, adjustment, alteration, ser-
vice or maintenance can cause
property damage, injury or death. Read the installa-
tion, operation and maintenance
instructions thoroughly before installing or servic-
ing this equipment.
FOR YOUR SAFTEY
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of
this or any other appliance.
Do not operate this equipment unless you have read and
understand the content of
this manual! This manual contains important safety in-
formation concerning the
maintenance, use and operation of this product. Keep
this manual in a safe location
for future reference.

DRAWER WARMER MANUAL
3
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
General information:
1. Always clean equipment thoroughly before rst use.
(See general cleaning instructions)
2. Check rating label for your model designation and electrical rating.
3. For best results, use stainless steel countertops.
4. All dimensions in parenthesis in centimeters unless noted.
General operation instructions:
1. All foodservice equipment should be operated by trained personnel.
2. Do not allow your customers to come in contact with any surface labeled ”CAUTION HOT”.
3. Where applicable: Never pour cold water into dry heated units.
4. Where applicable: Do not cook, warm or hold food directly in liner pans (well pans).
Always use steam table pans/inset, etc.
5. Never hold perishable food below 150°F(66°C).
2. SAFETY INFORMATION
Warmer drawers are designed, built and sold for commercial use and should be operated by trained
personnel only. Clearly post all CAUTIONS, WARNINGS and OPERATING INSTRUCTIONS near each unit to
insure proper operation and to reduce the chance of personal injury and/or equipment damage.
Always disconnect power before serving the Warmer Drawer. Surfaces will remain hot after power has been
turned o. Allow unit to cool before cleaning or servicing. Never clean the Warmer Drawer by immersing it
in water. The warmer drawer is not protected against water jets, DO NOT CLEAN WARMER DRAWER WITH A
WATER JET. Always clean equipment before rst use.
3. SPECIFICATIONS
Cordset conguration:
120V: NEMA5-15P plug, 6 foot, 3 wire grounded cord.
208/240V: NEMA6-20P Plug,6 foot, 3 wire ground cord.
If the supply cord is damaged, the manufacturer or an authorized service agent or a similarly qualied person
must replace it to avoid a hazard or voiding the warranty.

DRAWER WARMER MANUAL
4www.bk-resources.com | [e-mail]
4. WARNING
IN THE EVENT OF A POWER FAILURE , DO NOT ATTEMPT TO OPERATE THIS DEVICE.
WARNING:
ELECTRICAL SHOCK HAZARD. FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL COULD RESULT IN
SERIOUS INJURY OR DEATH.
1. Plug unit into a properly grounded electrical receptacle of the correct voltage,size and plug conguration.
If plug and receptacle do not match, contact a qualied electrician to determine and install proper voltage
and size electrical receptacle.
2. DO NOT submerge or saturate with water. Unit is not waterproof. Do not operate if unit has been
submerged or saturated with water.
3. Do not pull unit by power cord.
4. Do not use an extension cord with this appliance.
5. Check with a qualied electrician if you are unsure as to whether the appliance is properly grounded.
6. Turn OFF power switch, unplug power cord,and allow unit to cool before performing any cleaning,
adjustments or maintenance.
7. Unit is not waterproof. Locate unit indoors where the ambient air temperature is a minimum of 70°F(21°C).
8. Do not steam clean or use excessive water on the unit.
9. This unit is not“jet -proof”construction. Do not use jet-clean spray to clean this unit.
10. Discontinue use if power cord is frayed or worn.
11. Do not attempt to repair or replace a damaged power cord. The cord must be replaced by an
authorized agent or a person with similar qualications.
This unit must be serviced by qualied personnel only. Service by unqualied personnel may lead
to electric shock or burn.
CAUTION:
Some exterior surfaces on the unit will get hot. Use caution when touching these areas.
Use caution when opening drawer. Hot air escapes when drawer is open.
NOTE:
DO NOT lay unit on front or back side. Damage to unit could occur.

DRAWER WARMER MANUAL
5
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
FIRE HAZARD:
1. Locate unit a minimum of 1”(25mm)from combustible walls and materials. If safe
distances are not maintained,discoloration or combustion could occur.
2. Do not use harsh chemicals such as bleach(or cleaners containing bleach), oven cleaners, or ammable
cleaning solutions to clean this unit.
5. OPERATION
1. Initial heating of unit may generate smoke or fumes and must be done in well ventilated area.
2. Set the thermostat control knob to desired setting and preheat each drawer for 30 minutes.
3. Place food product directly in stainless steel drawer pans or use any combination of full or fractional pans
up to 6”(152mm)deep.
4. Set front vent knob to desired position for maintaining food product moisture.
5. Perforated pans may be used with damp towel or small amount of hot water in the drawer pan to prevent
food “dry out”.
CAUTION: Use no more than 1 quart(1 liter) for wet operation.
6. If too much moisture accumulates around drawer front or vent, reduce temperature setting or move vent
knob to “Dry”position.
Part Number Electric Dimensions # of Drawers Shipping Weight
DW-1-1 120V,450W,3.75A 10 3/8”x 27 3/4”x 20 5/8”
(263mmx704mmx524mm) 1 103.60 Ibs (47kgs)
DW-2-1 120V,900W,7.50A 19 3/4”x 27 3/4”x 20 5/8”
(501mmx704mmx524mm) 2 152.50 Ibs(69kgs)
DW-3-1 120V,1350W,11.25A 29 1/4”x 27 3/4”x20 5/8”
(740mmx704mmx524mm) 3 203.50 Ibs(92kgs)
PRODUCT TEMP SETTING VENT
ROLLS, BREAD 160°-180°F(71°-82°C) MOIST
VEGETABLE 170°-180°F(77°-82°C) MOIST
MEATS 170°-180°F(77°-82°C) MOIST
STANDARD DRAWER WARMERS
Make sure food product has been heated to proper food-safe temperature before placing in the
unit. Failure to heat food product properly may result in serious health risks. This unit is for holding
preheated food product only.
NOTE: Temperature and vent settings
will require adjustment according
to type and quantity of food, and
number of times drawer is
opened during operation.

DRAWER WARMER MANUAL
6www.bk-resources.com | [e-mail]
6. CLEANING
General Cleaning Instructions:
1. Never clean any electrical unit by immersing it in water. Turn o before surface cleaning.
2. Always clean equipment thoroughly before rst use. Clean unit daily except where noted on charts:
Use warm, soapy water. Mild cleansers and PLASTIC souring pads may be used to remove baked-on food and
water scale.
3. Turn o electrical units before cleaning or servicing. All service should be performed by authorized service
agency.
Daily cleaning:
1. Follow general cleaning instructions (above).
2. Remove any inset pans and drawer pans. Wash thoroughly in the sink or dishwasher.
3. Remove drawers: Remove pans and pan inserts, extend drawer and lift up on the front to clear the drawer
stop. Low drawer and pull straight out.
Preventative Care:
To prevent stainless steel break-down, follow these steps:
1. Never use any metal tools,scrapers, les, wire brushes, or scouring pads(except for stainless steel
scouring pads.)
2. Never use steel wool which will leave behind particles that will rust.
3. Never use acid-based or chloride-containing cleaning solutions-which will break down the protective lm.
4. Never rub in a circular motion. Always rub gently in the direction of the steal grain.
5. Never leave food products or salt on the surface. Many food are acidic. Salt contains chloride.

DRAWER WARMER MANUAL
7
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
7. TROUBLESHOOTING GUIDE
Always ask and check the following:
1. Is the unit connected to a live power source of the proper voltage?
2. Check the circuit breaker.
3. Is power switch”ON” and pilot light glowing?
4. Check the rating label. Is the unit connected to the correct power source?
SYMPTOMS POSSIBLE CAUSES REMEDY
Warmer not operating
Warmer not connected to power source Connect cabinet to power source.
No Power Check circuit breaker and/or check CFCI
switch on outlet
CFCI or Ground Fault Circuit Indicator
tripped.
Moisture problem Dry moisture problems
Shorted element Contact authorized service provider
Pinched/damaged wire Contact authorized service provider
Damaged power cord Contact authorized service provider
Warmer is connected to power
source, thermostat is turned on
but warmer not heating
Defective: Heating element, thermometer,
thermostat etc. Contact authorized service provider

DRAWER WARMER MANUAL
8www.bk-resources.com | [e-mail]
MODEL:
WWaarrmmeerr DDrraawweerr
9.WIRING DIAGRAM
10
8. Wiring Diagram

DRAWER WARMER MANUAL
9
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
MODEL:
WWaarrmmeerr DDrraawweerr
ENDWB EXPLODED VIEW
ENDWB-2
13
9. DW-X-1 PARTS LIST

DRAWER WARMER MANUAL
10 www.bk-resources.com | [e-mail]
MODEL:
WWaarrmmeerr DDrraawweerr
ENDWB PARTS LIST
PARTS（QTY）ENDWB-1 ENDWB-2 ENDWB-3
ITEM P/N DESCRIPTION
120 208 240 120 208 240 120 208 240
VOLTS VOLTS VOLTS
1 DWB1-010001 Body Assembly 1 1 1
DWB2-010001 Body Assembly 2 2 2
DWB3-010001 Body Assembly 3 3 3
2 DW-010321 Element Bracket 1 1 1 2 2 2 3 3 3
3 DWFRGB-120 Heating Elements 1 2 3
DWFRGB-208 Heating Elements 1 2 3
DWFRGB-240 Heating Elements 1 2 3
4 DW-030001 Pan 1 1 1 2 2 2 3 3 3
5 DW-020301 Center Pan Support
Assemby 1 1 1 2 2 2 3 3 3
6
DW-020201
Drawer Face Assembly
1
1
1
2
2
2
3
3
3
7
DW-020401
Drawer Handle
1
1
1
2
2
2
3
3
3
8
N/S
Drawer Vent Knob
1
1
1
2
2
2
3
3
3
9
DW-020701
Gasket
1
1
1
2
2
2
3
3
3
10 DW-020101 Drawer Inner Frame
Weldment 1 1 1 2 2 2 3 3 3
11
DW-020501
Guard Bearing
2
2
2
4
4
4
6
6
6
12
DW-020601
Slide Bearing
6
6
6
12
12
12
18
18
18
14
N/S
Thermostat 250V 105℃
1
1
1
2
2
2
3
3
3
15
N/S
Knob
1
1
1
2
2
2
3
3
3
16 N/S Mechanical Temperature
Indicator(0~120 ℃)
1 1 1 2 2 2 3 3 3
17
N/S
Power Indicator Light
1
1
1
2
2
2
3
3
3
18
N/S
Control Panel
1
1
1
1
1
1
1
1
1
19
N/S
Cord+Plug NEMS(5-15)
1
1
1
N/S
Cord+Plug NEMS(6-20)
1
1
1
1
1
1
20
N/S
Cabel Bushing
1
1
1
1
1
1
1
1
1
21
DWB1-010301
Front Plate
1
1
1
DWB2-010301
Front Plate
1
1
1
DWB3-010301
Front Plate
1
1
1
22
N/S
Screw 1/4-20X1.25"
6
6
6
12
12
12
18
18
18
23
N/S
Screw 1/4-20X0.75"
2
2
2
4
4
4
6
6
6
24 N/S Nylon Lock Nut 1/4-20" 8 8 8 16 16 16 24 24 24
14
Parts (Qty) DW-1-1 DW-2-1 DW-3-1
10. DW-X-1 PARTS LIST

DRAWER WARMER MANUAL
11
4A Do-It Drive, Altamont, IL 62411 | P: 888-310-4393 | F: 618-483-9898 | F: 888-310-4394
MODEL:
WWaarrmmeerr DDrraawweerr
11.Component Supply
1
1
.
.
S
S
t
t
a
a
i
i
n
n
l
l
e
e
s
s
s
s
S
S
t
t
e
e
e
e
l
l
P
P
a
a
n
n
s
s
f
f
o
o
r
r
R
R
e
e
p
p
l
l
a
a
c
c
e
e
m
m
e
e
n
n
t
t
2
2
.
.
F
F
o
o
n
n
t
t
P
P
l
l
a
a
t
t
e
e
f
f
o
o
r
r
R
R
e
e
p
p
l
l
a
a
c
c
e
e
-
-
B
B
u
u
i
i
l
l
d
d
i
i
n
n
D
D
e
e
s
s
i
i
g
g
n
n
33..CCaasstteerrss ffoorr OOppttiioonn ttoo RReeppllaaccee LLeeggss
5x1-1/4 Thread Stem Casters
Hangzhou Evernew Machinery&Equipment Co.,Ltd
Room 1304,T1 Office Building Raffles Center,#228 Xinye Road,Jianggan District,Hangzhou,China
Tel:[phone]; Fax:[phone]
19

8” Stainless Steel
Deck Mount Faucet
bk-resources.com
120 Frontage Road • Altamont, IL 62411
888-310-4393 • www.bk-resources.com
Additional Product Categories
HAND SINKSPLUMBING
COMPARTMENT SINKS
DISH TABLES
GREASE TRAPS
UNDERBAR EQUIPMENT
STAINLESS STEEL TABLES
DROP IN SINKS
SHELVING
8” Stainless Steel
Deck Mount Faucet
EVO-8DM- -G
8” Stainless Steel
Deck Mount Faucet
8” Stainless Steel
Deck Mount Faucet
Model: EVO-8DM
• Highly Engineered Stainless Steel Design
• Accepts Wrist Blade Handles
• Interchangeable Spouts
• 1/4 Turn Ceramic Cartridges
• Lifetime Warranty
• Lead Free
For a complete product oering, go to
© BK Resources 2017© BK Resources 2017
bk-resources.com
888-310-4393
Certified to
NSF/ANSI/CAN 61-G & 372
Made in Taiwan
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
LIFETIME
LUTION
V
LUTION
V
LUTION
V
LUTION
V
8” Stainless Steel
Deck Mount Faucet
bk-resources.com
120 Frontage Road • Altamont, IL 62411
888-310-4393 • www.bk-resources.com
Additional Product Categories
HAND SINKSPLUMBING
COMPARTMENT SINKS
DISH TABLES
GREASE TRAPS
UNDERBAR EQUIPMENT
STAINLESS STEEL TABLES
DROP IN SINKS
SHELVING
8” Stainless Steel
Deck Mount Faucet
EVO-8DM- -G
8” Stainless Steel
Deck Mount Faucet
8” Stainless Steel
Deck Mount Faucet
Model: EVO-8DM
• Highly Engineered Stainless Steel Design
• Accepts Wrist Blade Handles
• Interchangeable Spouts
• 1/4 Turn Ceramic Cartridges
• Lifetime Warranty
• Lead Free
For a complete product oering, go to
© BK Resources 2017© BK Resources 2017
bk-resources.com
888-310-4393
Certified to
NSF/ANSI/CAN 61-G & 372
Made in Taiwan
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
LIFETIME
LUTION
V
LUTION
V
LUTION
V
LUTION
V
Drawer Warmer Manual
8” Stainless Steel
Deck Mount Faucet
bk-resources.com
120 Frontage Road • Altamont, IL 62411
888-310-4393 • www.bk-resources.com
Additional Product Categories
HAND SINKSPLUMBING
COMPARTMENT SINKS
DISH TABLES
GREASE TRAPS
UNDERBAR EQUIPMENT
STAINLESS STEEL TABLES
DROP IN SINKS
SHELVING
8” Stainless Steel
Deck Mount Faucet
EVO-8DM- -G
8” Stainless Steel
Deck Mount Faucet
8” Stainless Steel
Deck Mount Faucet
Model: EVO-8DM
• Highly Engineered Stainless Steel Design
• Accepts Wrist Blade Handles
• Interchangeable Spouts
• 1/4 Turn Ceramic Cartridges
• Lifetime Warranty
• Lead Free
For a complete product oering, go to
© BK Resources 2017© BK Resources 2017
bk-resources.com
888-310-4393
Certified to
NSF/ANSI/CAN 61-G & 372
Made in Taiwan
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
LIFETIME
LUTION
V
LUTION
V
LUTION
V
LUTION
V
8” Stainless Steel
Deck Mount Faucet
bk-resources.com
120 Frontage Road • Altamont, IL 62411
888-310-4393 • www.bk-resources.com
Additional Product Categories
HAND SINKSPLUMBING
COMPARTMENT SINKS
DISH TABLES
GREASE TRAPS
UNDERBAR EQUIPMENT
STAINLESS STEEL TABLES
DROP IN SINKS
SHELVING
8” Stainless Steel
Deck Mount Faucet
EVO-8DM- -G
8” Stainless Steel
Deck Mount Faucet
8” Stainless Steel
Deck Mount Faucet
Model: EVO-8DM
• Highly Engineered Stainless Steel Design
• Accepts Wrist Blade Handles
• Interchangeable Spouts
• 1/4 Turn Ceramic Cartridges
• Lifetime Warranty
• Lead Free
For a complete product oering, go to
© BK Resources 2017© BK Resources 2017
bk-resources.com
888-310-4393
Certified to
NSF/ANSI/CAN 61-G & 372
Made in Taiwan
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
LIFETIME
LUTION
V
LUTION
V
LUTION
V
LUTION
V
8” Stainless Steel
Deck Mount Faucet
bk-resources.com
120 Frontage Road • Altamont, IL 62411
888-310-4393 • www.bk-resources.com
Additional Product Categories
HAND SINKSPLUMBING
COMPARTMENT SINKS
DISH TABLES
GREASE TRAPS
UNDERBAR EQUIPMENT
STAINLESS STEEL TABLES
DROP IN SINKS
SHELVING
8” Stainless Steel
Deck Mount Faucet
EVO-8DM- -G
8” Stainless Steel
Deck Mount Faucet
8” Stainless Steel
Deck Mount Faucet
Model: EVO-8DM
• Highly Engineered Stainless Steel Design
• Accepts Wrist Blade Handles
• Interchangeable Spouts
• 1/4 Turn Ceramic Cartridges
• Lifetime Warranty
• Lead Free
For a complete product oering, go to
© BK Resources 2017© BK Resources 2017
bk-resources.com
888-310-4393
Certified to
NSF/ANSI/CAN 61-G & 372
Made in Taiwan
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
LIFETIME
LUTION
V
LUTION
V
LUTION
V
LUTION
V
See our other products!
