Bkav AI VIEW C300-0200 User manual

Qualcomm products contained herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated.
Full HD DOME
AI-BASED CAMERA

Model: C300-0200/C310-0200
INSTALLATION GUIDE

PRODUCT KIT
Camera
Installation guide Drilling position decal
3
Ø9 mm 3 Holes
CAMERA FRONT
TEMPLATE
Set 3 of screws and anchors Hex tool
Qualcomm products contained herein are products of Qualcomm Technologies,Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated.
Full HD DOME
AI-BASED CAMERA

4
TECHNICAL SPECIFICATION
Power supply
Protection standards IP66
C300-0200: DC 12V/1A - Maximum 5.4W
C310-0200: DC 12V/1A - Maximum 5.2W
Digital Zoom 8x
Focal length 4 mm
87.5° (H) - 104.9° (D) - 44.4° (V)Angle of view
Temperature: -10°C ~ 60°C (14°F - 140°F)
Operating temperature Humidity: 10% ~ 100%
Dimensions (L x W x H) L93.1 x W93.1 x H68 mm
Weight 0.36 Kg
Resolution, frame rate H.264/H.265
FHD 1920x1080, 30 fps

PRODUCT OVERVIEW
5
Reset
Audio in
Audio out
12 VDC power supply
RJ45 terminal block
Camera lens

6
INSTALLATION GUIDE
1 2
Step 1: Apply decal on the area where the camera needs to be installed and fix the plastic anchors. Tighten
the screws to fix the camera (figure 1).
Step 2: Insert the camera body on the camera mount and fix the camera with the protector by rotating
clockwise (figure 2).

INSTALLATION FOR SIGNAL CONNECTION
How to connect devices:
Model C300-0200/C310-0200: Use 12VDC and the network cable connected from the switch.
7
LAN
12VDC
RJ45

ADJUSTING THE CAMERA VIEWING ANGLE
65°
360°
8

9
PASSWORD SETTING
The IP address of camera is set to DHCP mode by default. For the camera enables the DHCP by default,
you need to use the AI View Scanner App to scan IP.
Note: To complete the installation steps for the camera, refer to the User Manual.
The system will ask you to reset the password on your initial access.
When the "Administrator password change" window appears, enter a new password.
For additional security, please do not repeat any characters in your password.
If you forget your password, you can hold the [RESET] button in 10 seconds to return the product to
its factory settings.
Note:
Special characters include: ~ ` ! @ # $ % ^ & * ( ) _ - = + | { } [ ] . ? /
For passwords using eight or nine characters, you need to use at least three of the following types of
characters: uppercase and lowercase letters, numbers, and special characters.
For passwords using 10 to 15 characters, you need to use at least two of the character types.
Administrator password change
New password
Confirm new password
For a new password with 8 to 9 digits, you must use at least 3 of the following:
uppercase/lowercase letters, numbers and special characters. For a password with 10 to 15
digits, you must use at least 2 types of those mentioned.
For higher security, you are not recommended to repeat the same characters or consecutive
keyboard inputs for your passwords.
If you lost your password, you can press the [RESET] button to initialize the product. So, don’t
lose your password by using a memo pad or memorizing it.
Special characters that are allowed: ~`!@#$%^*()_-+=|{}[].?/

10
SOFTWARE INSTALLATION
Login screen
When accessing the camera, a login window will appear.
Enter your user name and password to access the camera.
1. Enter "admin" in the <User name> box.
2. Enter your chosen password in <Password> box.
3. Click
User name
Password

SAFETY INFORMATION
Be sure to follow this advice to ensure the device works properly.
Installation instruction: Concrete, brick, column, wood... are all suitable. Make sure the wall is strong enough.
The torque forces of screws securing IP enclosure: 1.3 – 1.4Nm.
It is recommended to use shielded network cables (STP) during set-up.
It is recommended to use CAT5e or higher network cables.
Store the camera in a cool and dry environment.
Shield the camera from potential impact from heavy objects.
Do not install the camera on unstable pillars, brackets, surfaces, or walls.
Do not use chemicals or detergents to clean the camera or housing.
To clean, use a damp cloth.
Only use standard tools and accessories when installing the camera equipment. The manufacturer
recommends using the manufacturer's power supply equipment or a corresponding source for the
camera. Improper installation may cause damage to the product.
Contact Bkav's customer support or authorized Bkav agents if you experience any problems.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limit are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
a accordance with the instruction manual, may cause harmful interference to radio communications.
Operations of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Precautions
Use the original packaging, or equivalent, to avoid damaging the product during transportation.
Transportation:
11

12
For information about AI View product warranty and thereto related information, go to aiview.ai/warranty.
WARRANTY INFORMATION

Model: C300-0200/C310-0200
HƯỚNG DẪN LẮP ĐẶT

BỘ SẢN PHẨM ĐÓNG GÓI
Thiết bị camera
Sách hướng dẫn sử dụng Tờ decan dán định vị khoan
14
Ø9 mm 3 lỗ
Bộ 3 vít, nở lắp đặt Lục giác
Qualcomm products contained herein are products of Qualcomm Technologies,Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
The Made with Qualcomm Technologies logo is a trademark of Qualcomm Incorporated.
Full HD DOME
AI-BASED CAMERA
DECAL DÁN TƯỜNG
ĐỊNH VỊ LỖ KHOAN

15
THÔNG SỐ KỸ THUẬT
Nguồn
Tiêu chuẩn bảo vệ IP66
C300-0200: DC 12V/1A - Tối đa 5.4W
C310-0200: DC 12V/1A - Tối đa 5.2W
Zoom số 8x
Tiêu cự Lens 4 mm
87.5° (H) - 104.9° (D) - 44.4° (V)Góc nhìn
Nhiệt độ: -10°C ~ 60°C (14°F - 140°F)
Điều kiện hoạt động Độ ẩm: 10% ~ 100%
Kích thước (Dài x Rộng x Cao) D93.1 x R93.1 x C68 mm
Khối lượng 0.36 Kg
Độ phân giải, tốc độ khung hình H.264/H.265
FHD 1920x1080, 30 fps

TỔNG QUAN THIẾT BỊ
16
Reset
Đầu vào âm thanh
Đầu ra âm thanh
Nguồn 12 VDC
Cổng RJ45
Ống kính

17
HƯỚNG DẪN LẮP ĐẶT
Bước 1: Dán decan khu vực cần lắp camera và đặt nở. Siết chặt các vít định vị đế camera (hình 1).
Bước 2: Đưa thân camera vào đế camera và cố định bằng nắp bảo vệ xoay theo hướng kim đồng hồ (hình 2).
1 2

HƯỚNG DẪN KẾT NỐI TÍN HIỆU
Cách kết nối thiết bị:
Model C300-0200/C310-0200: Dùng nguồn 12VDC và dây mạng nối từ switch thường.
18
LAN
12VDC
RJ45

19
HƯỚNG DẪN XOAY GÓC NHÌN CAMERA
65°
360°

20
CÀI ĐẶT MẬT KHẨU
Địa chỉ IP của camera được đặt theo cơ chế cấp phát động IP (DHCP). Bạn cần sử dụng phần mềm AI View
Scanner để tìm kiếm IP của camera.
Lưu ý: Để hoàn thành các bước cài đặt cho camera bạn vui lòng xem tài liệu Hướng dẫn sử dụng WebUI.
Hệ thống sẽ yêu cầu bạn đặt lại mật khẩu cho sản phẩm vào lần đầu tiên truy cập.
Khi cửa sổ “Administrator password change” hiện lên, hãy nhập mật khẩu mới.
Để đảm bảo tính bảo mật, vui lòng không lặp lại các ký tự trong mật khẩu.
Nếu bạn quên mật khẩu, bạn có thể giữ nút RESET trong 10 giây để trở lại cài đặt mặc định của nhà
sản xuất.
Chú ý:
Những kí tự đặc biệt bao gồm: ~ ` ! @ # $ % ^ & * ( ) _ - = + | { } [ ] . ? /
Dành cho mật khẩu có từ 8 đến 9 kí tự, bạn cần dùng ít nhất 3 loại kí tự sau: kí tự chữ hoa/chữ thường,
số và kí tự đặc biệt.
Dành cho mật khẩu có từ 10 đến 15 kí tự, bạn cần sử dụng ít nhất 2 loại trong số đó.
Administrator password change
New password
Confirm new password
For a new password with 8 to 9 digits, you must use at least 3 of the following:
uppercase/lowercase letters, numbers and special characters. For a password with 10 to 15
digits, you must use at least 2 types of those mentioned.
For higher security, you are not recommended to repeat the same characters or consecutive
keyboard inputs for your passwords.
If you lost your password, you can press the [RESET] button to initialize the product. So, don’t
lose your password by using a memo pad or memorizing it.
Special characters that are allowed: ~`!@#$%^*()_-+=|{}[].?/
