COP-USA SDRDVR35-HSL User manual

Covert Smoke Digital Video Record Camera
Remote Control COLOR CCD Camera 3.7mm Pinhole Lens
* Non-Active Smoke Detector Camera
* Mpeg 4 Compression format
* Memory Full Overwrite Funtcion
* Motion Detection 32G SD Card capability
* Easy Access SD Card
* Records Video/Audio & Takes
* Remote Control
* Included 4GB SD Card
* DC 12V 300mA
VIDEO
Power DC 12V
MONITOR
VIDEO
DC 12V
* Specifications are subject to change without notice ** Designed in U.S.A.
100 Feet
Remote Control
SD Card Capacity Recording Time Photos
1GB 150Min(-/+ 10%) 23,200pcs (-/+ 10%)
2GB 300Min(-/+ 10%) 36,400pcs (-/+ 10%)
4GB 600Min(-/+ 10%) 92,800pcs (-/+ 10%)
Recording Time
ITEMS SDRDVR35-HSL
TYPE COLOR
PICK-UP DEVICE COLOR CCD IMAGE SENSOR
PICTURE ELEMENTS NTSC: 512Hx492V - PAL: 512Hx582V
HORIZONTAL RESOLUTION 540 TVL
MINI ILLUMINATION 0.001 LUX
HORIZ.SYNC FREQUENCY EIA/NTSC: 15.734Khz - CCIR/PAL: 15.625Khz
VERTICAL FREQUENCY EIA/NTSC: 60Hz - CCIR/PAL: 18.9375
CLOCK FREQUENCY EIA/NTSC: 19.0699 Mhz - CCIR: 18.9375
SCANNING SYSTEM 2:1 INTERLACE
S/N RATIO 46dB
ELECTRONIC SHUTTER 1/1000.000s
LENS PINHOLE LENS
VIDEO OUTPUT 1Vp-p, 75 Ohms
AUDIO OUTPUT 2Vp-p (Max)
GAMMA 0.45
ALARM
WEIGHT 100g
POWER SUPPLY DC 12V
POWER CONSUMPTION 300mA
STORAGE TEMPERATURE -30°C to +60°C
OPERATING TEMPERATURE -10°C to +45\°C
IR
MIC
Camera
SDRDVR35-HSL

Contents
1. SAFETY PRECAUTIONS ..........................................................................................................1
2. FEATURES..................................................................................................................................2
3. PACKAGE CONTENT................................................................................................................3
4. Smoke DVR Description..............................................................................................................4
4.1 SMOKE DVR LAYOUT .......................................................................................................4
4.2 CONNECTION OVERVIEW ...............................................................................................4
5. Operation......................................................................................................................................5
5.1 Power On................................................................................................................................5
5.2 Live Mode..............................................................................................................................5
5.3 Record Mode..........................................................................................................................6
5.4 Playback Mode.......................................................................................................................8
5.5 PC Playback...........................................................................................................................9
5.6 SD Card Maintenance............................................................................................................9
5.7 How to Download the Updated Software ..............................................................................9
6. MENU SETUP...........................................................................................................................10
6.1 Main Menu...........................................................................................................................10
6.2 Date/ Time............................................................................................................................11
6.3 Motion Detection .................................................................................................................11
6.4 Record Setup........................................................................................................................13
6.5 SD Card Options..................................................................................................................15
6.6 System Status.......................................................................................................................16
6.7 Power On Setup....................................................................................................................16
6.8 Factory Default.....................................................................................................................17
7. TROUBLE SHOOTING............................................................................................................18
9. SPECIFICATION.......................................................................................................................19
The author assumes no responsibility for any errors or omissions that may appear in this
document nor does the author make a commitment to update the information herein.
VER.: 1.0, CD
SDRDVR35-HSL

1. SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN!
CAUTION :
TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT OPEN COVERS (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
It is advised to read the Safety Precaution Guide through carefully before operating the
product, to prevent any possible danger.
WARNING: This symbol is intended to alert the user to the presence of un-insulated “dangerous voltage”.
CAUTION: This symbol is intended to alert the user to presence of important operating and
maintenance (Servicing) instructions in the literature accompanying the appliance.
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union
and other European countries with separate collection systems).
This symbol on the product or on its packaging indicates that this product shall not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you purchased the product.
Do not Plug and unplug the power cord, it may result product malfunction.
Do not install the product in an environment where the humidity is high.
Unless the product is waterproof or weatherproof, otherwise poor image quality may occur.
Do not drop the product or subject them to physical shocks.
Except for vandal-proof or shockproof product, otherwise malfunctions may occur.
Never keep the product to direct strong light.
It can damage the product.
Do not spill liquid of any kind on the product.
If it gets wet, wipe it dry immediately. Alcohol or beverage can contain minerals that corrode the
electronic components.
Do not install the product in extreme temperature conditions.
Use the camera under conditions where temperatures are between 5∘C(41∘F ) ~ 4 5 ∘C.(113∘F ) . B e e s p e c i a l l y
careful to provide ventilation when operating under high temperatures.
SDRDVR35-HSL

2. FEATURES
z The Mini DVR Module supports NTSC or PAL video system, and auto detects video loss.
z The Mini DVR Module is built-in with MPEG4-SP video and G.726 audio codec. It
supports 1 channel video and 1 channel audio recording and playback operation.
z Audio/ Video data are recorded directly on the SD card with FAT16/ 32 file system and
ASF file format. Simple data backup method to a PC.
z Audio/ Video data are recorded directly as ASF file format. You can view the data straight
from your PC, and playback those ASF files with popular media players.
z USB interface that enables data to be transfer to a PC.
z For 1 GB SD card, the record time is about 5 hours at Standard Quality for NTSC: 30 fps
@ 352 x 240 and PAL: 12 fps @ 640 x 480.
z The DVR supports: Manual, Motion Detection, Schedule, and Alarm Recording mode
with independent video size, quality, and frame rate set up.
z Schedule Record (Schedule Record Priority Order: Alarm/ Motion Detection/ Continuous)
and IR Illuminator can be setup to ON/ OFF and per hour.
z Support external alarm signal connection to enable alarm trigger recording.
z For motion detection, multiple detection blocks and appropriate motion trigger level
set-up.
z Support key lock function.
z Use anywhere, the device supports either DC power adaptor.
SDRDVR35-HSL

3. PACKAGE CONTENT
* 4G SD Card
* Remote Control
* 2 x AA Batteries
* SD Card Pick Up Tool
3.1 Remote Control Functions
1. Record Button: On/Off
2. ESC / STOPButton
3. Play / Pause Button
4. Directional Buttons
5. Menu / OK Button
SDRDVR35-HSL

4. Smoke DVR Description
4
.1 Smoke DVR Layout
4.2 Connection Overview
4.2.1 Put out SD Cards
4.2.2 A/V Connection:
SDRDVR35-HSL

5. OPERATION
5.1 Power On
1. To power-up, connect to a DC 12V power input connector.
NOTE 1: Each time after power-on, the system auto-detects its peripherals. When the REC LED
flashes indicate that the SD card is proceeding testing (complete boot time is several seconds)
When an image file error has been detected, the system will initiate auto repairing.
2. After power on, the system auto enters live monitoring. When the system is
currently under schedule recording, it auto enters record mode.
3. “” icon shown on the status line, indicates that SD card is operating normally.
4. When SD card is not inserted or problem occurs on the SD card. Rec indicator will
flash quickly. Please re-format before proceeding.
5. You can play while the SD card is “read only”, but you cannot record; and Rec
indicator will flash quickly.
6. After power-loss the system auto returns to the previous recording mode.
Do not withdraw the CF card while booting. It may destroy the data stored within the CF card.
5.2 Live Mode
Live mode is the default setup after system start-up.
cTime Display: System Date andTime.
2 Button Lock: Indicates all buttons are locked (buttons are ineffective).
3 Video Status: Indicates external camera connection.
SDRDVR35-HSL

4Record Status: Manual Record Parameter.
：Record Size, please refer to【7.4 Record Setup】for VIDEO SIZE
setup.
：Record Quality, please referto【7.4 Record Setup】for VIDEO QUALITY
setup.
：Audio Off Record, please refer to【7.4 Record Setup】for AUDIO
RECORD setup.
5SD Card Status:
：SD Card has not been inserted or malfunction.
：SD Card is proceeding file testing.
：SD Card is functioning normally.
：Overwrite record.
When SD card is not inserted, record and playback function is inapplicable, but
monitoring is applicable.
5.3 Record Mode
1. Start Record: 3 Types of recording mode.
(1) Manual Record: Suitable to record at anytime. Press《Rec》button, to enter
manual recording status (start recording). For more information, please refer to
【7.4 Manual Record & Schedule Record】.
(2) Motion Detection Record: Suitable to record, when there are severe image
changes. Motion detection triggers schedule recording, but it will only start
recording when the variation exceeds the alarm limitation value. For more
information, please refer to【7.3 Motion Detection】and【7.4 Manual Record &
Schedule Record】.
(3) Continuous Record: Suitable for few constant frame recording or on long-term
continuous recording. For more information, please refer to【7.4 Manual Record
& Schedule Record】.
(4) Alarm Record:Suitable for external alarm recording. When alarm schedule
been setup, alarm icon will be shown on the display status bar (alarm triggered
recording is setup).
2. Stop Record:
Manual Record Press《/∩》button/ Manual Power-Off/ Auto Power-Off when
System Power Shortage.
Schedule Record Enter《/II 》schedule recording, all kinds of recordings (Alarm/
Motion Detection/ Continuous) will be stopped.
To continue recording, please follow the methods below to restart recording.
Manual Record Repress《》button.
Schedule Record Stop playback and the system will auto re-check the record
schedule setup again.
SDRDVR35-HSL

3. Record Display:
1Record Status:
:Indicates recording is in progress.
2Record Mode:
：Manual Record ：Schedule Record
：Motion Detection Record ：Alarm Record
3Record Storage Mode Status:
：Continuous Record
% ：Remaining Storage Capacity
4 System recording is determined according to the recording priority order (Record Priority:
Manual/ Alarm/ Motion Detection/ Continuous).
5. Different recording modes may have different kinds of setups. Basic setup: video size,
recording frames, video quality, and audio recording. When different recording modes are
triggered, the system starts recording according to the different setup. This kind of design
provides flexibility to ensure efficient recording time and quality. Example: Work hour
from 8:00am to 6:00pm, setup「Schedule Record」to low video quality with less recording
frames to extend the recording time. And off work hour, setup 「Motion Detection
Record/ Alarm Record」to enable high video quality with the highest recording frames,
when an event occurs.
6. Video or audio may be recorded into the SD card (SD card is purchased separately).
Do not withdraw the SD card while recording. It may destroy the data stored within the SD card..
Power loss during recording results incomplete videos or errors.
Video loss during recording, the system stops recording, backups the files, and when
the videos are normal again, the system will continue recording.
SDRDVR35-HSL

5.4 Playback Mode
Selectable Playback format: Continuous Playback and Searching Playback.
(1) Normal Playback: Press《/》button to first playback the final recorded data, and then
according to the SD card file recording order.
1Playback Status:
`：Press《/》button once to playback, press it again to pause.
 ：Press《》or《》button to Fast Rewind or Fast Forward (Speed:
x2/ x4/ x8/ x16/ x32). Press《/》button to return to normal speed
playback.
II ：During playback, press《/》button to pause playback and press
again to return to playback status.
 ：During pause, press《》or《》button to step back one frame or
to step forward one frame and press《/》button to return to
normal speed playback.
Press《/∩》button to stop playback function and to return to live status.
(2) Search and Playback: Enter MENU and select【SEARCH AND PLAY】item.
1 File directory shows dates and the amount of contents under the directory. The
user may press《》or《》button to move the cursor up or down.
2 Current location page.
3 Event Record Status Icon:
SDRDVR35-HSL
