Black & Decker DINING-IN TO3290XSD User manual

TM
DIGITAL
COUNTERTOP OVEN
HORNO PARA
MOSTRADOR DIGITAL
FOUR NUMÉRIQUE
POUR LE COMPTOIR
use and care manual
manual de uso y cuidado
guide d’utilisation ed d’entretien
TO3290XSD
DINING-IN™

2
CONTENTS
CAUTION
THIS OVEN GETS HOT.
WHEN IN USE, ALWAYS USE OVEN MITTS OR
POT HOLDERS WHEN TOUCHING ANY OUTER
OR INNER SURFACE OF THE OVEN.
Important Safeguards ............................................... 3
Getting to Know Your Countertop Oven ................................ 5
How to Use........................................................ 6
Operating Your Oven................................................ 7
Function Chart.....................................................11
Single Serve Chocolate Chip Cake Recipe! ..............................12
Care and Cleaning ..................................................13
Warranty and Customer Service Information ............................14

3
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS.
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury, including the following:
• READ ALL INSTRUCTIONS
BEFORE USING.
• Do not touch hot surfaces. Use
handles or knobs.
• To protect against electrical
shock, do not immerse cord,
plug, or appliance in water or
other liquid.
• Close supervision is necessary
when any appliance is used by or
near children.
• Unplug from outlet when not in
use and before cleaning. Allow
time to cool before putting on or
taking off parts.
• Do not operate any appliance
with a damaged cord or plug,
or if the appliance malfunctions
or has been damaged in any
manner. Contact consumer
support at the toll-free number
listed in the warranty section.
• The use of accessory
attachments not recommended
by the appliance manufacturer
may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge
of table or counter, or touch
hot surfaces.
• Do not place on or near a hot
gas or electric burner, or in a
heated oven.
• Extreme caution must
be used when moving an
appliance containing hot oil or
other hot liquids.
• To disconnect, press Stop/Start
button at the bottom of the
control panel ( ), then unplug
from wall outlet.
• Do not use appliance for other
than intended use.
• Use caution when removing tray
or disposing of hot grease.
• Do not clean oven with metal
scouring pads. Pieces can break
off the pad and touch electrical
parts, causing risk of electric
shock.
• Do not attempt to clean the
heating elements.
• Oversized foods or metal utensils
must not be inserted in a toaster
oven, as they may create fire or
risk of electric shock.
• A fire may occur if the toaster
oven is covered or touching
flammable materials including
curtains, draperies, walls, and the
like, when in operation. Do not
store any item on top of the unit
while in operation.
• Do not store any material,
other than manufacturer’s
recommended accessories, in
this oven when not in use.
• Do not place any of the following
materials in the oven: paper,
cardboard, plastic, and other
items not constructed of oven
safe metal and glass pans.
• Do not cover crumb tray or any
part of this oven with metal foil.
This will cause overheating in
the oven.

4
GROUNDED PLUG
As a safety feature, this product is equipped with a grounded plug, which will only
fit into a three-prong outlet. Do not attempt to defeat this safety feature. Improper
connection of the grounding conductor may result in the risk of electric shock. Consult
a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt
to remove the outer cover. There are no user-serviceable parts inside. Repair should
be done only by authorized service personnel.
ELECTRICAL CORD
1. A short power-supply cord is provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
2. If a long detachable power-supply cord or extension cord is used:
a) The marked electrical rating of the power cord or extension cord should be at
least as great as the electrical rating of the appliance.
b) The extension cord should be a grounding-type 3-wire cord.
c) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over
unintentionally.
Note: If the power cord is damaged, please contact the warranty department listed
in these instructions.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
• This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instructions concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised to
ensure that they do not play with
the appliance.
• The appliance is not intended
to be operated by means of
an external timer or separate
remote-control system.
• Do not leave unattended while
in operation. Food ignition may
occur. If this happens, unplug the
unit, but DO NOT open door. To
reduce the risk of fire, keep oven
interior completely clean and free
of food residues, oil, grease and
other combustible materials.

5
Product may vary slightly
from what is illustrated.
1. Slide out crumb tray
(Part# TO3250-04)
2. Baking pan
(Part# TO3250-05)
3. Slide rack
(Part# TO3250-06)
4. 3 rack positions
5. Easy view glass door
6. Door handle
7. Digital Display
8. Convection + Bake
9. Toast
10. Broil
11. Bagel
12. Reheat
13. Pizza
14. Frozen Snacks
15. Temperature
16. Timer + Toast Shade
17. Start-Stop
GETTING TO KNOW YOUR
COUNTERTOP OVEN
1
2
4
6
5
3
7
8
910
12
11
13 14
16
17
15

6
HOW TO USE
This appliance is intended for household use only.
Getting Started
• Remove all packing material, any stickers, and the plastic band around
the power plug.
• Remove and save literature.
• Please go to www.prodprotect.com/applica to register your warranty.
• Wash all removable parts as instructed in Care & Cleaning Section.
• Select a location where this unit is to be used, allowing enough space from
the back of the unit and wall to allow heat flow without damage to cabinets
and walls.
Important information about your oven
1. This oven gets hot. When in use, always use oven mitts or potholders when
touching any outer or inner surface of the oven.
2. When using the oven for the first time, you may notice smoke or a slight odor
during the first few minutes. This is normal.
3. Be sure food or baking dish does not come within 11/2 inches (3.81cm) of the top
heating elements.
4. Food should not extend beyond the edges of the baking pan/drip tray to avoid
drippings from falling onto the heating elements.
5. The heating elements will cycle on and off to maintain even heat distribution.
6. After the cooking cycle is completed, the main display will stay illuminated for
a short time if not unplugged.
Changing to and from Celsius and Fahrenheit
Press and hold the Up and Down temperature arrows ( ) simultaneously. The
display will show either a °C for Celsius or °F for Fahrenheit.

7
1. Plug into outlet.
2. Display light will illuminate and all function lights will light up momentarily.
3. When turned on, the oven will either default to factory settings or to the last
setting used. (see Function Chart on page 11)
4. Choose the desired function and proceed with detailed function information
below.
Convection Baking Function |
Display will blink until desired temperature setting is met. Timer will not start
until the oven is preheated.
1. Press the Convection Baking function button ( ). The blue light will
illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 10)
3. If needed, press the temperature buttons ( ) to select the desired
temperature. Up arrow for a higher temperature, and down for a lower
temperature.
4. If needed, press the timer buttons ( ) to select the desired time. Up arrow
for a longer time period, and Down for a shorter time period. Select Stay On
( ) by pressing the Down arrow past Zero. The Stay On icon ( ) will
show in the display panel.
5. Press the Start/Stop button (I/0) to begin heating the oven. Display will blink
while oven is preheating.
6. Once it’s preheated there will be an audible beep and the display will stop blinking;
Place the food in the oven on the middle or low rack position to begin baking.
Note: Use a metal, oven-tempered glass, or ceramic baking dish.
7. If using the oven timer, there will be an audible beep once the baking cycle is
complete and the oven will stop heating. If not using the timer, press the Start/
Stop Button (I/0) once cooking cycle is complete.
8. Unplug the appliance when not in use.
OPERATING YOUR OVEN

8
Broil Function |
No preheat needed for this function.
1. Press the broil function button ( ). The blue light will illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 11)
3. If needed, press the temperature buttons ( ) to select the desired
temperature.
4. If needed, press the time buttons ( ) to select the desired time. Up arrow
for a longer time period, and Down for a shorter time period.
5. Press the Start/Stop button (I/0) to begin broiling.
6. Place the food in the oven on the top rack position.
Be sure food or baking dish does not come within 1 1/2 inches (3.81cm) of the
top heating elements.
Note: Place food directly on rack with baking pan in place.
7. There will be an audible beep once the broil cycle
is complete and the oven will stop heating.
8. Unplug the appliance when not in use.
Toast Function |
No preheat needed for this function.
1. Press the Toast function button ( ). The blue light will illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 11)
3. If needed, press the time/toast shade buttons ( ) to select the desired
shade. Up arrow for a darker shade, and Down for a lighter shade.
Note: Shades 1-7 are available, 1 being the lightest and 7 being the darkest.
4. Place food directly on rack in the middle rack position and then press the
Start/Stop button (I/0) to begin toasting.
5. There will be an audible beep once the toasting cycle is complete and the oven
will stop heating.
6. Unplug the appliance when not in use.
OPERATING YOUR OVEN

9
Bagel Function |
No preheat needed for this function.
1. Press the Bagel function button ( ). The blue light will illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 11)
3. If needed, press the time/toast shade button ( ) to select the desired
shade. Up arrow for a darker shade, and Down for a lighter shade.
Note: Shades 1-7 are available, 1 being the lightest and 7 being the darkest.
4. Place food directly on rack in the middle rack position and press the Start/Stop
button (I/0) to begin toasting.
5. There will be an audible beep once the toasting cycle is complete and the oven
will stop heating.
6. Unplug the appliance when not in use.
Reheat Function |
No preheat needed for this function.
1. Press the Reheat function button ( ). The blue light will illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 11)
3. If needed, press the temperature button ( ) to select the desired
temperature. Up arrow for a higher temperature, and Down for a lower
temperature.
4. If needed, press the time buttons ( ) to select the desired time. Up arrow
for a longer time period, and Down for a shorter time period. Select Stay On
by pressing the Down arrow past Zero. The Stay On icon ( ) will show in
the display panel.
5. Place food on middle or low rack and press the Start/Stop button (I/0) to
begin reheating the food.
Note: Use a metal, oven-tempered glass, or ceramic baking dish.
6. If using the oven timer, there will be an audible beep once the cycle is complete
and the oven will stop heating. If not using the timer, press the Start/Stop
Button (I/0) once cycle is complete.
7. Unplug the appliance when not in use.
OPERATING YOUR OVEN

10
Frozen Snacks |
Display will blink until desired temperature setting is met. Timer will not start until the
oven is preheated.
1. Press the Frozen Snacks function button ( ). The blue light will illuminate.
2. When turned on, the oven will either default to factory settings or to the last
setting used. (see Function Chart on page 11)
3. If needed, press the temperature button ( ) to select the desired
temperature. Up arrow for a higher temperature, and Down for a lower
temperature.
4. If needed, press the time buttons ( ) to select the desired time. Up
arrow for a longer time period, and Down for a shorter time period.
5. Press the Start/Stop button (I/0) to begin heating the oven. Display will blink
while oven is preheating.
6. Once it’s preheated there will be an audible beep and the display will stop
blinking; Place the food in the oven on the middle or low rack position to begin
baking.
Note: Use a metal, oven-tempered glass, or ceramic baking dish placed on the
middle or low rack position.
7. There will be an audible beep once the frozen snack cycle is complete and the
oven will stop heating.
8. Unplug appliance when not in use
OPERATING YOUR OVEN
Pizza |
Display will blink until desired temperature setting is met. Timer will not start until the
oven is preheated.
1. Press the Pizza function button ( ). The blue light will illuminate.
2. The oven will either default to factory function settings or to the last setting
used. (see Function Chart on page 11)
3. If needed, press the temperature button ( ) to select the desired temperature.
Up arrow for a higher temperature, and Down for a lower temperature.
4. If needed, press the time buttons ( ) to select the desired time. Up arrow for
a longer time period, and Down for a shorter time period.
5. Press the Start/Stop button (I/0) to begin heating the oven. Display will blink
while oven is preheating.
6. Once it’s preheated there will be an audible beep and the display will stop
blinking. Place the food in the oven, directly on the rack, in the middle or
low rack position to begin baking.
7. There will be an audible beep once the pizza cycle is complete and the oven
will stop heating.
8. Unplug appliance when not in use.
