INSTRUCTION MANUAL
PORTABLE DISHWASHER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BPD8W
BPD8B

Page 2

Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
product.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................4-5
Electrical Requirements.......................................................................................................................................................6
SET UP & USE
Installation Instructions........................................................................................................................................................ 7
Parts & Features........................................................................................................................................................................8
Operation & Use .................................................................................................................................................9-21
CLEANING & CARE......................................................................................................................................22-25
TROUBLE SHOOTING & WARRANTY
Before You Call For Service ..............................................................................................................................26
Customer Service..................................................................................................................................................26
Troubleshooting.............................................................................................................................................. 27-29
Limited Warranty ..................................................................................................................................................................30
Page 3

Page 4
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USE
2. Do not abuse, sit on, stand on or place any heavy objects on the
door or dish rack of the dishwasher when it is open. The appliance
could tip forward.
3. Do not operate your dishwasher unless all enclosure panels are
properly in place. Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
4. When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door
seal;
2) Warning: Knives and other utensils with sharp points must be
loaded in the basket with their points down or placed in a horizontal
position.
5. Check that the detergent receptacle is empty after completion of the
wash cycle.
6. Use only detergent and rinse additives designed for an automatic
dishwasher.
7. Never use soap, laundry detergent, or hand washing detergent in
your dishwasher. Keep these products out of the reach of children.
8. Keep children away from detergent and rinse aid. Keep children
away from the open door of the dishwasher, there could still be some
detergent left inside.
9. This appliance is not intended for use by persons (including children
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.)
10. Children should be supervised to ensure that they do not play in or
on a dishwasher.
11. Do not tamper with controls.
12. Do not wash plastic items unless they are marked “Dishwasher
Safe” or the equivalent. For plastic items not so marked, check the
manufacturer’s recommendations.
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following

Page 5
SAFETY INFORMATION
13. Dishwasher detergents are strongly alkaline, they can be extremely
dangerous if swallowed. Avoid contact with skin and eyes and keep
children away from the dishwasher when the door is open.
14. The door should not be left in the open position since this could
present a tripping hazards.
15. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
16. Remove the door to the washing compartment when removing an
old dishwasher from service or discarding it.
17. Dispose of packing materials properly.
18. Use the dishwasher only for its intended function.
19. During installation, the power supply must not be excessively or
dangerously bent or flattened. Do not tamper with controls.
20.The appliance is to be connected to the water mains using new hose
sets and that old hose-sets should not be reused.
21. The maximum number of place settings to be washed is 8.
22.The maximum permissible inlet water pressure is 14.5 psi (1 MPa).
23.The minimum permissible inlet water pressure is 5.8 psi (0.04 MPa).
24. Do not use this dishwasher outdoors.
25. This appliance must be properly installed in accordance with the
installation instructions before its use.
26. This appliance must be connected to a proper electrical outlet with
the correct electrical supply.
27. Disconnect electrical power and water intake hose to dishwasher
before cleaning and/or servicing.
28. Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the dishwasher turn on
all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the gas
is flammable, do not smoke or use an open flame during this time.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

Page 6
SAFETY INFORMATION
GROUNDING INSTRUCTIONS
ELECTRICAL REQUIREMENTS
In the event of malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock.
The appliance must be connected to a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
DANGER - Improper connection of the equipment grounding
conductor can result in a risk of electric shock. The conductor with
insulation having an outer surface that is green with or without yellow
stripes is the equipment grounding conductor. If repair or replacement
of the cord or plug is necessary, do not connect the equipment-
grounding conductor to a live terminal. Check with a qualified
electrician or service person if the grounding instructions are not
completely understood, or if in doubt as to whether the appliance is
properly grounded. Do not modify the plug connected to the appliance
– if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
FOR GROUNDED, CORD-CONNECTED APPLIANCE RATED LESS THAN
15A AND INTENDED FOR USE ON A NOMINAL 120V SUPPLY CIRCUIT
The appliance is for use on a nominal 120V circuit and should be
connected to a grounding outlet that looks like the one illustrated
below. The use of a temporary adaptor is not recommended.
Page 5
SAFETY INFORMATION
GROUNDING INSTRUCTIONS
ELECTRICAL REQUIREMENTS
In the event of malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock.
The appliance must be connected to a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged
into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
DANGER - Improper connection of the equipment grounding conductor
can result in a risk of electric shock. The conductor with insulation
having an outer surface that is green with or without yellow stripes is
the equipment grounding conductor. If repair or replacement of the
cord or plug is necessary, do not connect the equipment-grounding
conductor to a live terminal. Check with a qualified electrician or
service person if the grounding instructions are not completely
understood, or if in doubt as to whether the [tool/appliance] is properly
grounded. Do not modify the plug connected to the [tool/appliance] –
if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
FOR GROUNDED, CORD-CONNECTED [TOOL/APPLIANCE] RATED
LESS THAN 15A AND INTENDED FOR USE ON A NOMINAL 120V
SUPPLY CIRCUIT
The appliance is for use on a nominal 120V circuit and should be
connected to a grounding outlet that looks like the one illustrated
below. The use of a temporary adaptor is not recommended.

SET UP & USE
INSTALLATION INSTRUCTIONS
CAUTION: The installation of the pipes and electrical equipment should be done
by professionals.
The installation position of dishwasher should be near the existing inlet and drain
hoses and power cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain
hoses of the dishwasher.
Position the appliance in the desired location. The back should rest against the
wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is
equipped with water supply and drain hoses that can be positioned to the right or the
left to facilitate proper installation.
WARNING: DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH
THIS APPLIANCE.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE
GROUND CONNECTION FROM THE POWER CORD.
WARNING - RISK OF FIRE
It is important the plug fits tightly into the wall outlet. If the plug does not fit securely
and appears loose, it should not be used. Have a licensed electrician replace the
receptacle.
WARNING: Electrical Shock Hazard - Disconnect electrical power before
installing dishwasher.
Failure to do so can result in death or electrical shock.
Page 7
POWER SUPPLY CORD
1. Avoid the use of an extension cord because of potential safety hazards under
certain conditions. Have a qualified electrician or serviceman to install an
outlet near the appliance.
2. If it is absolutely necessary to use an extension cord, extreme care must be
exercised.
a) Use only a grounding type 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will accept the plug on the
appliance.
b) The marked electrical rating of the extension cord must equal to or greater
than the electrical rating of the appliance. The longer cord should be
arranged so that it will not drape over the counter top or table top where it
can be pulled on by children or tripped over unintentionally.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage
to the product or personal injury resulting from failure to observe the
electrical connection procedures.

Page 8
SET UP & USE
PARTS & FEATURES
Detergent &
Rinse Aid Dispenser
Lower spray arm
(interior bottom of
compartment)
Filter Assembly
Storage Hook
Quick Connect Assembly
(See next page for details)
Upper Rack
Upper
spray arm
Silverware Basket Lower Rack
4 casters (unlock the front two
casters to move the dishwasher)

Page 9
SET UP & USE
WATER CONNECTION
Your dishwasher comes equipped with a ‘quick connect’ assembly (includes inlet
and drain hose). The faucet adapter must be installed on the faucet before you can
connect the dishwasher. This adapter is included inside your dishwasher. The faucet
adapter is compatible with faucets inclusive of either male (outside) or female (inside)
threaded faucet connections.
Rear of Dishwasher
Inlet Port
Drain Outlet
Faucet
Adapter
Collar
1. Screw the faucet adapter onto (or into) the faucet tap. Check for leaks (use Teflon
tape to eliminate if necessary).
2. Connect the six-sided connection of the drain hose to the drain port connection
on the back of the dishwasher cabinet. Do not over-tighten (to avoid damage to
threads).
3. Connect the star-shaped connection of the inlet hose to the inlet port on the back
of the dishwasher cabinet. Do not over-tighten (to avoid damage to threads).
4. Connect the circular connection of the drain hose onto the longer (bottom) male
connection on the quick connect.
5. Connect the circular connection of the inlet hose onto the shorter (top) male
connection on the quick connect.
6. Attach the quick connect onto the faucet adapter, by pulling down the outer
locking collar on the quick connect, while pushing the quick connect upward onto
the faucet adapter.
7. When the quick connect snaps onto the faucet
adapter, release the locking collar. Verify the
connection is secure.
8. Slowly open the hot water line and check for
any sign of water leaks at all hose connections.
If leaks are located, immediately close the water
supply and repair the hose connections.
Inlet Connection
Drain Port
Connection
Inlet House
Connection
Drain House
Connection
Faucet
Adapter
Pressure
Relief
Button
(red)
Quick
Connect
WARNING: In order to avoid that there is more water staying in the inlet hose,
please close the faucet after using.

To Disconnect the Quick Connect Assembly
1. Turn o hot water.
2. Relieve water pressure from the quick connect assembly before disconnecting it
from the faucet by depressing the red pressure relief button.
3. Depress the locking collar and remove the quick connect from the faucet.
CONNECT THE DRAIN HOSE
Insert the end of the drain hose into the drain outlet located at the back of the unit.
The other end of the hose should be positioned using one of the following methods:
A. Over the edge of a wash basin. Secure the
guide to the side of the basin wall with a hook
tap with a piece of string to prevent the drain
hose from moving.
B. In a laundry tub. The laundry tub should not be
higher than 39 in. (100cm). Wash basins should
not be over 39 in. (100cm).
C. In a standpipe. The standpipe should not be
longer than 39 in. (100cm).
D. Insert the drain hose into a drain pipe with a
minimum diameter of 1.5 inches (4 cm).
39 in. Max
Hose
retainer
Tie
strap
tub
Standpipe
39 in. Max
32 in. Min
Laundry tub
Hose
retainer
Tie
strap
Page 10
SET UP & USE
NOTE: Avoid bending or crimping the drain hose. The free end of the hose must not
be immersed in water to avoid backflow. If you need a drain hose extension,
make sure to use a similar drain hose. It must not be longer than 13 feet (4
meters) otherwise the dishwasher will not drain properly.
MAX HEIGHT
39 in.
(100cm)
MIN diameter
1.5”(4cm)
Drain hose
A
B
C
D
Rear of Dishwasher
Water inlet
Drain outlet

Page 11
SET UP & USE
IMPORTANT!
1. Once you open the water supply line, (even if it is closed immediately thereafter),
the inlet hose will be pressurized.
2. To relieve water pressure from inside the inlet hose, (make sure the water line
(faucet) is closed): press and hold the red pressure relief button on the quick
connect until the flow of water stops.
NOTE: Hard water conditions will adversely aect the washing performance of
your dishwasher. Hard water conditions will also contribute to ‘lime’ (white
film substance) deposits and/or ‘scaling’ on the stainless steel surface of
the dishwasher tub and heater element, located in the sump underneath
the removable filter screen. To assist in minimizing these conditions, it is
recommended to periodically operate/rinse the inside of the dishwasher
(empty) using 1 cup of white vinegar at least once a week.
DISCONNECTING YOUR DISHWASHER
1. Shut o the water supply at the faucet.
2. Disconnect the power supply cord.
START OF DISHWASHER
The following things should be checked before starting the dishwasher:
1. The dishwasher is level and fixed properly.
2. The inlet valve is open.
3. There is a leakage at the connections of the connectors.
4. The wires are tightly connected.
5. The power is switched on.
6. The inlet and drain hoses are not knotted.
7. All packing materials and printings should no be taken out from the dishwasher.
WARNING: FAILURE TO RELIEVE WATER PRESSURE, BEFORE
DISCONNECTING THE QUICK-CONNECT FROM THE FAUCET, WILL
RESULT IN BACK-PRESSURE OVER-SPRAY. THE TEMPERATURE
OF INCOMING WATER CAN BE VERY HOT, AND BACK-PRESSURE
OVER-SPRAY COULD CAUSE SEVERE BURNS AND/OR SCALDING.
DANGER: DO NOT LET CHILDREN DISCONNECT THE DISHWASHER; CLOSE
SUPERVISION OF CHILDREN IS ALWAYS IMPORTANT AROUND
APPLIANCES.

Page 12
SET UP & USE
CONTROL PANEL
Power
Program
Hi Temp
Heated Dry
Control
Lock
Delay
Start /
Cancel
Press this button to turn on your dishwasher, the screen lights up.
Select the appropriate washing program, the selected program
indicator will be lit. After completing the program and function
selection, the Start / Cancel button to start.
When the “Hi Temp” function is selected, the temperature of the
water will be maintained at 140°F (60°C) max.
The “Heated Dry” function is selected. The water temperature is
at 158°F (70°C). (It can be used with all programs except glass.)
This option allows you to lock the buttons on the control panel,
so children cannot accidently start the dishwasher by pressing
the buttons on the panel. Only the Power button remains active.
To lock or unlock the buttons on the control panel, press and
hold the Hi Temp button + Heated button for 3 seconds simulta-
neously.
Press the Delay button to increase the delay start time. Delay a
cycle for up to 24 hours in one-hour increments. After setting
the delay time, press the Start / Cancel button to start.
1. To start the selected washing program.
2. Press the button for 3 seconds to cancel the program, when
the dishwasher is working.
3. Press the button for 3 seconds to cancel the delay start after
it has been programmed.

Page 13
SET UP & USE
Cycle
indicator
Screen
Press this button to turn on your dishwasher, the screen lights up.
Heavy
For heavily soiled items include pots and pans with dried on
food.
Normal
This is the standard program suitable for normally soiled loads,
such as pots, plates, glasses and lightly soiled pans.
ECO
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
Glass
For lightly soiled dishware and glass.
90 min
For normal/lightly soiled loads that need a quick wash and do
not need to be completely dry.
Rapid
A shorter wash for lightly soiled loads that do not need to be
completely dry.
Rinse Aid
If the “ ”indicator is lit, it means the dishwasher is low on dish-
washer rinse aid and requires a refill.
Water Faucet
If the indicator is lit, it means the water faucet is closed.
Time Display
Indicates remaining cycle time, delay start time and error codes.
For each cycle time the display will show the remaining time
counting down until it reaches 0:00 indicating the end of the
cycle. after 8 seconds the display will indicate END.

Page 14
SET UP & USE
RINSE AID DISPENSER
Rinse Aid improves drying, eliminating spots and streaks on your glasses and dishes.
It is automatically released during the final rinse to prevent water from forming
droplets. The rinse aid dispenser is located inside the door next to the detergent
dispenser.
WARNING: Only use branded rinse aid for dishwasher. Never fill the rinse aid
dispenser with any other substances. (Examples: Liquid Detergent or other soap).
This would damage the appliance.
REFILLING THE RINSE AID DISPENSER
When the Rinse Aid symbol is illuminated on the control panel, it indicates that the
rinse aid dispenser requires a refill.
If the rinse-aid warning light in the control panel in not illuminated, you can check the
amount of rinse-aid in the dispenser by the color of rinse aid indicator next to the cap.
When the rinse-aid dispenser is full, the circular indicator will be dark. As the rinse-aid
diminishes, the size of the dark circle decreases as shown below. You should never let
the rinse aid get below 1/4 full.
To fill the dispenser:
1. Remove the rinse aid reservoir cap by rotating it counterclockwise.
2. Carefully pour in the rinse-aid into its dispenser, while avoiding overflow.
3. Close the rinse aid reservoir cap by rotating it clockwise.
Note: clean any spilled or excessive rinse aid to avoid excessive foaming when the
dishwasher is in use.
The rinse aid dispenser has four settings. “1” selects the smallest amount or rinse aid,
while “4” releases the largest amount of rinse aid that is released during the rinse
cycle. The recommended setting is on “3”. If the dishes still are not drying properly
or are spotted, adjust the dial to a higher number. If there are sticky white stains or a
bluish film on glassware or silverware adjust the dial to a lower setting.
Rinse Aid Indicator
Rinse Aid
Reservoir Cap
Full 3/4 full 1/2 full 1/4 full Empty

Page 15
SET UP & USE
DETERGENT DISPENSER
The dispenser must be refilled before the start of each wash cycle. Follow the
dishwasher detergent manufacturer recommendation on the packaging.
Always add the detergent just before starting the dishwasher, otherwise it could get
damp and will not dissolve properly.
To fill the detergent dispenser press the release catch to oven the cover.
Add detergent to fill the larger compartment for the main wash cycle. For heavily
soiled dishes add some detergent into the smaller compartment as well for the
pre-wash cycle.
Close the cover and press the release catch until it locks into place.

Page 16
SET UP & USE
BEFORE LOADING YOUR DISHWASHER
RECOMMENDATIONS
Wash items which are identified as dishwasher-safe in your dishwasher.
For delicate items, select a program with the lowest possible temperature.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the program has ended.
ADJUSTING THE RACKS
The height of the upper rack can be easily adjusted to accommodate taller dishes in
either the upper or lower rack.
DO NOT WASH THE FOLLOWING
ITEMS IN A DISHWASHER
• Cutlery with wooden, horn china or
mother-of-pearl handles
• Plastic items that are not heat resistant
• Older cutlery with glued parts that is
not temperature resistant
• Bonded cutlery items or dishes
• Pewter or cooper items
• Crystal glass
• Steel items subject to rusting
• Wooden platters
• Items made from synthetic fibres
NOTE:
• Some types of glasses can become dull
after a large number of washes
• Silver and aluminium parts have a
tendency to discolor during washing
• Glazed patterns may fade if machine
washed frequently
To raise the rack when it
is in lower position, pull
it out and remove it.
Lower Position Upper Position
Align the rollers as
shown to reinsert and
push in .
The tines can be folded
to make room for larger
items. They can also be
removed when not in
use.

Page 17
SET UP & USE
Scrape o any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Load the dishwasher in following way:
• Place items such as cups, glasses, pots/pans, etc. face down.
• Curved items, or those with recesses, should be loaded at a slant so that water can
drain o.
• All utensils should be stacked securely and can not tip over.
• All utensils should be placed so that the spray arms can rotated freely during
washing.
• Load hollow items such as cups, glasses, pans etc. with the opening downwards so
that water cannot collect inside.
• Dishes and items of cutlery must not lie inside one another, or cover each other.
• To avoid damage to glasses, they must not touch.
• Load large items which are most dicult to clean into the bottom rack.
CAUTION: Long and/or sharp items of cutlery such as carving knives must be
positioned horizontally in the basket. Knives with long blades loaded
in an upright position are a potential hazard.
LOADING THE DISHWASHER
When loading dishes, pull out the upper rack suciently so you can load it without
striking the counter with dishes.
The upper rack is designed for small plates, mugs and glasses marked
“Recommended Loading”. If you have several small plates in is recommended that
you load them into the dishwasher in two half rows The front of each plate should
face the back of the plate in front of it, and the open sides of the plates at the center
of the dishwasher face each other.
Dinner plates, soup bowls, plates, pots, lids, casserole dishes, and plate should
be loaded in the bottom rack. Load large items such as pots and pans into the
dishwasher so their open sides face downwards
Silverware Basket
CAUTION: Long and/or sharp items of cutlery such as carving knives must be
positioned horizontally in the basket. Knives with long blades loaded
in an upright position are a potential hazard.
Top Rack
Recommended Loading
Bottom Rack

WARNING: DO NOT LET ANY ITEM EXTEND
THROUGH BOTTOM.
ALWAYS LOAD SHARP UTENSILS WITH
THE SHARP POINT DOWN!
Page 18
SET UP & USE
UNLOADING THE DISHWASHER
To prevent water dripping from the upper basket into the lower basket, we
recommend that you empty the lower basket first, followed by the upper basket.
WARNING: Items will be hot. To prevent injury do not take remove items from
the dishwasher until approximately 15 minutes after the wash
program has ended.
Teaspoons
3
Dinner forks
1
Serving forks
6
Serving spoons
5
Knives
4
Salad forks2

Page 19
SET UP & USE
WASH CYCLE TABLE
Program Cycle Selection
Information
Description of
Cycle
Detergent pre/
main
Running
time (min)
Energy
(Kwh)
Water
(I)
Rinse
Aid
Heavy
For the heaviest
soiled loads such
as pots, pans,
casserole dishes
and dishes that
have been sitting
with dried food
on them for a
while.
Pre-wash 1
Pre-wash 2
Main wash
(149°F)
Rinse 1
Rinse 2
Last
Rinse(154°F)
Drying
Pre-wash
compartment
for normal/
heavily
soiled + fill
main wash
compartment
165 0.76 19
Normal
For normal ly
soiled loads,
such as pots,
plates,glasses and
lightly soiled pans.
Standard daily
cycle.
Pre-wash 1
Pre-wash 2
Main wash
(113-140°F)
Rinse 1
Rinse 2
Last
Rinse(149°F)
Drying
Pre-wash
compartment
for normal/
heavily
soiled + fill
main wash
compartment
121-150 0.56-
0.64 9.7-
19
ECO
For lightly soiled
loads, such as
glasses, crystal
and fine china.
Pre-wash
Main wash
(122 °F)
Rinse 1
Rinse 2
Last Rinse
(143 °F)
Drying
Fill main wash
compartment 155 0.53 16
Glass
For lightly soiled
dishware and
glass.
Pre-wash
Main wash
(122 °F)
Rinse 1
Rinse 2
Last Rinse
(143 °F)
Drying
Fill main wash
compartment 125 0.60 16
90 min
A shorter wash
for normal/lightly
soiled loads that
do not need to be
completely dry.
Pre-wash
(122 °F)
Main wash
(140 °F)
Rinse
(131 °F)
Last Rinse
(154 °F)
* Quick
Drying
Pre-wash
compartment
for normal/
heavily
soiled + fill
main wash
compartment
90 0.83 13
Rapid
A shorter wash for
lightly soiled loads
that do not need
to be completely
dry.
Pre-wash
(131 °F)
Main wash
(140 °F)
Rinse
(131 °F)
Last Rinse
(136 °F)
* Quick
Drying
Fill main wash
compartment 60 0.56 13
Note:
* Quick Drying will not completely dry dishes due to the fast cycle time.

Page 20
SET UP & USE
STARTING A WASH CYCLE
1. Pullout the dishwasher racks, load the dishes and push the racks back in.
2. Add Detergent and Rinse Aid as needed.
3. Insert the plug into the socket. The power supply is 120V/60 Hz.
4. Make sure that the water supply is turned on to full pressure.
5. Close the door and press the POWER button to turn on the dishwasher
6. Choose a wash program and the corresponding indicator light will turn on.
7. Press the Start/Cancel button, the dishwasher begins to start.
NOTE: When you press the Start/Pause button to pause during washing, the display
time will stop blinking and the program will pause and remain this cycle till you
restart it again.
