BLACK DECKER AC028A2CA User manual

Customer Care Line:
UsA 1-800-842-1289
Accessories/Parts (UsA)
1-800-842-1289
MICROWAVE OVEnS
InS RUC
TIOn MAnUA L
T T l
Model
❍ 0 00W10
AC 28A2CA

PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
(a) Do not attempt to operate this oven with the door open since
operation can result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allows soil or
cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particular important that
the oven door close properly and that there is no damage to the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACE
(d) The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
open door
S
ly
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
Rated Input Power(Grill):
Rated Input Power(Convection):
AC028A2CA
1500W
Approx.18.5kg
28 L
1150W
315mm
508520 326mm
1000W
1500W
120V~60Hz
2

WARNING -
1. Read all instructions before using the
appliance.
2. Read and follow the specific:
EXCESSIVE MICROWAVE ENERGY"
found on page 2.
combustible materials are placed inside the oven to facilitate cooking.
only to properly grounded outlet. See
found on page
accordance with the provided installation
instructions.
To reduce the risk of burns, electric shock, fire, injury to persons or exposure
to excessive microwave energy:
3. This appliance must be grounded. Connect
"PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
"GROUNDING INSTRUCTIONS"
4. Install or locate this appliance only in
5. Some products such as whole eggs and sealed containers - for example, closed glass
jars - are able to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as described in the manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
supervision is necessary when used
by children.
7. As with any appliance, close
damaged cord or plug, if it is not
working
properly, or if it has been
damaged or dropped.
8. Do not operate this appliance if it has a
by qualified service personnel.
Contact nearest
authorized service
facility for examination, repair, or
adjustment.
9. This appliance should be serviced only
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near water - for
example,
near a kitchen sink, in a wet
basement, near a swimming pool, or
similar location.
1 . Do not immerse cord or plug in water.2
1 . Keep cord away from heated surface.
14. Do not let cord hang over edge of
table or counter.
3
15. When cleaning surfaces of door and oven that comes together on closing the door,
16. To reduce the risk of fire in the oven cavity:
1). Do not overcook food. Carefully attend appliance when paper, plastic, or other
2). Remove wire twist-ties from paper or plastic bag before placing bag in oven.
3). If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, shut off power at the fuse or circuit breaker panel.
4). Do not use the cavity for storage purposes. Do not leave paper products, cooking
utensils, or food in the cavity when not in use.
point without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
IMPORTANT SAFETY INSTRUCTIONS
precautions should be followed, including
When using electrical appliances basic safety
following:the
use only mild, nonabrasive soaps, or detergent applied with a sponge or soft cloth.
or
4.
3

stand in the microwave oven for a short time
before removing the container. spoon or other utensil into the container.
This appliance must be grounded. In the event of an electrical short circuit, grounding
of electric shock by providing an escape wire for the
appliance is equipped with a cord having a
plugged into an outlet that is properly installed and grounded.
GROUNDING INSTRUCTIONS
THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN
THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Do not use straight-sided containers with narrow necks.
4) After heating, allow the container to
5) Use extreme care when inserting a
grounding wire with a grounding plug.
reduces the risk electric current. This
The plug
WARNING - Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely or if doubt exists as to whether the appliance is properly grounded.
extension cord, use only a 3-wire extension cord that has a
The marked rating of the extension cord shall be equal to or greater than the electrical
appliance.
understood,
If it is necessary to use an
3-blade grounded plug, and 3-slot receptacle that will accept the plug on the appliance.
rating of the
Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death.
disassemble this appliance.
DANGER -
Do not
Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug into an outlet until
appliance is properly installed and grounded.
WARNING -
SA E THESE INSTRUCTIONS
must be
V
18. Oversized food or oversized metal utensils should not be inserted in a microwave/
toaster oven as they may create a fire or risk of electric shock.
19. Do not clean with metal scouring pads. Pieces can burn off the pad and touch
electrical parts involving arisk of electric shock.
20. Do not use paper products when appliance is operated in the toaster mode.
21. Do not store any materials, other than manufacturer's recommended accessories, in
this oven when not in use.
22. Do not cover racks or any other part of the oven with metal foil. This will cause over-
heating of the oven.
4

1. Operation of the microwave oven may cause interference to your radio, TV
or similar
2. When there is interference, it may be reduced or eliminated by taking the
following
1) Clean door and sealing surface of the oven
2) Reorient the receiving antenna of radio or television.
3) Relocate the microwave oven with respect to the receiver.
4) Move the microwave oven away from the receiver.
5) Plug the microwave oven into a different outlet so that microwave oven
are on different branch circuits.
RADIO INTERFERENCE
equipment.
measures:
and receiver
1. A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
3. If a long cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.
-
5

Personal Injury Hazard
Tightly-closed could explode. Closed containers should be opened and plastic
pierced before cooking.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the
2. Cook on maximum power for 1 minute.
3. Carefully feel the . If the empty is
warm, do not use it for microwave
4. Do not exceed 1 minute cooking time.
UTENSILS
See the instructions on "Materials you can use in microwave oven or to be avoided in
There may be certain non-metallic that are not safe to use for microwaving. If
utensil in question following the procedure below.
CAUTION -
pouches should be
microwave oven."
in doubt, you can test the
utensil in question.
cooking.
Materials you can use in microwave oven
Remarks
Follow manufacturer* instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer* instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Dinnerware
6
containers
container
containers
.container
Container

Materials you can use in microwave oven
Remarks
Microwave-safe only. Follow the manufacturer* instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Plastic
Plastic wrap
Materials to be in microwave oven
Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
7
Material
AVOIDED
Item

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
Grill Rack( Cannot be used in microwave
function and must be placed on the glass tray )
Grill tray( Cannot be used in microwave
function and must be placed on the grill rack)
8
F
G
A
C B
ED

Installation
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
The accessible surface
may be hot during
operation.
9

OPERATION
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
When the microwave oven is electrified,the oven will display "0:00", buzzer will ring
once.
2) Turn " " to adjust the hour figures, the input time should be within -- (12-hour).
3) Press " ", the minute figures will
5) Press " " to finish clock setting. ":" will flash.
Note: 1) If the clock is not set, it will not function when powered.
2) During the process of clock setting, if you press " ", the oven
will go back to the previous status automatically.
1) Press " "
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
2. Kitchen Timer
1) Press " " once, the screen will display "00:00".
2) Turn " " to enter the correct timer.(The maximum cooking time is 95 minutes.)
3) Press " START/+30SEC. " to confirm setting.
4) When the kitchen time is reached, the buzzer will ring 5 times.
If the clock be set(12-hour system), the screen will display the current time.
Note: (1) The kitchen time is different from 12-hour system,Kitchen Timer is a timer.
1.Clock Setting
CLOCKTIMER/
CLOCKTIMER/
CLOCKTIMER/
CLOCKTIMER/
twice
1) Press the "
Press " " or turn " to select the
power from 100% to 10%. "PL10", "PL9", "PL8", "PL7", "PL6", "PL5",
START/+30SEC. " to confirm.
Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
START/+30SEC. " to start cooking.
microwave
3. Microwave Cooking
repeatedly "
flash.
START/+30SEC. " to confirm.The "PL10" will light.2) Press "
3)
4) Press "
5)
6) Press "
, the hour figures will flash.
1 12
(2) During the kitchen timer, any program cannot be set.
"PL4", "PL3", "PL2", "PL1" will display in order.
10
MICRO./GRILL/CONVEC./COMBO " once and "PL10" will flash.
MICRO./GRILL/CONVEC./COMBO
STOP/CANCEL

NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
Microwave Power Chart
2) Press " " or turn " " to select the grill
Stop pressing/turning when "G-1" flash.
3) Press " " to confirm.The "G-1" will light.
4)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5) Press " START/+30SEC. " to start cooking.
4. Grill Cooking
repeafedly
1) Press the "
2) Press " " or turn " " to select combination
mode. Stop pressing/turning when "G-2","G-3","C-1" display.
3) Press " START/+30SEC. " to confirm.
4)Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5) Press "START/+30SEC. " to start cooking.
5. Combination Cooking
repeafedly
1) Press the " .
START/+30SEC.
function.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
Note:If half the grill time passes, the oven sounds twice, and this is normal. In order
to have a better effect of grilling food, you should turn the food over,
close the door, and then press" " to continue cooking.
If no operation, the oven will continue working.
START/+30SEC.
11
display
MICRO./GRILL/CONVEC./COMBO" once and "PL10" will flash.
MICRO./GRILL/CONVEC./COMBO
MICRO./GRILL/CONVEC./COMBO" once and "PL10" will
MICRO./GRILL/CONVEC./COMBO

urn " " to
START/+30SEC. " to confirm the temperature.
START/+30SEC. " to start preheating.When the
preheating temperature arrives, the buzzer will sound twice to remind you to
put the food into the oven. And the preheated temperature is displayed and flash.
Turn " " to adjust the cooking time. (The maximum setting time is 95 minutes.)
START/+30SEC. " key to start cooking.
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
Note:the temperature can be chosen from 100 to 425
the convection temperature.
select
6. Convection Cooking(With preheating funtion)
7. Convection Cooking( Without pre-heating function)
1) Press the " " once and "PL10" will flash.
2) Press " " or turn " " to select convection
function. Stop pressing/turning when "100" flash.
3) Press " START/+30SEC. " to confirm.
repeatedly
T
4)
5) Press the "
6) Press the "
7) Put the food into the oven and close the door.
8) Press the "
urn " " to
START/+30SEC. " to confirm the temperature.
(The maximum setting time is 95 minutes.)
START/+30SEC. " key to start cooking.
Note:the temperature can be chosen from 100 to 425
the convection temperature.
select
1) Press the " " once and "PL10" will flash.
3) Press " START/+30SEC. " to confirm.
T
4)
5) Press the "
6)Turn " " to adjust the cooking time.
7) Press the "
2) Press " " or turn " " to select convection
function. Stop pressing/turning when "100" flash.
repeatedly
Note: Combination instructions
12
Microwave
Display Convection
Function Grill
Combi.1
Combi.2
Combi.3 C-1
G-2
G-3
℉ ℉
℉ ℉
MICRO./GRILL/CONVEC./COMBO
MICRO./GRILL/CONVEC./COMBO
MICRO./GRILL/CONVEC./COMBO
MICRO./GRILL/CONVEC./COMBO

Note: Auto menu and preheating cannot be set as one of the multi-stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80%
microwave power for 7 minutes. The steps are as following:
1) Press " " twice, the screen will display "d
2) Turn " " to adjust the defrost time of 5 minutes;
3) Press"
START/+30SEC." to confirm;
START/+30SEC." to start cooking.
/COMB " once and "PL10" will flash;
8.Multi-Stage Cooking
1) In waiting state, press " " key to cook with 100% power
seconds. Each press on the same key can increase 30 seconds. The
2) During microwave,grill,convection and combination states, press ""
key to increase 30 seconds' cooking time.
Note: this function cannot work under weight defrost
9. Speedy Cooking
START/+30SEC." to confirm;
4) Press "
5) Turn " " to choose 80% microwave power till "PL8" display;
6) Press "
7) Turn " " to adjust the cooking time of 7 minutes;
8) Press "
cooking
or low temp control.
level for 30
maximum cooking
time is 95 minutes.
EF2";
,auto menu
10. Auto Menu
1) In waiting state, turn " " right to choose the function wanted,
"A3"...."A12" will be displayed.More menu options on the next page.
2) Press " " to confirm the menu you need.
3) Turn " " to choose the weight of menu,and "Oz" indicator will light.
4) Press " " to start cooking.
and "A1","A2",
Note: 1)Cake menu is under convection cooking with -warm-up function,
and you should preheat first following the auto menu operation, when the oven
reaches the temperature, it will stop cooking and sound to remind opening
the door to put cake in, then press " " to start cooking.
2) When roast chicken is selected and 2/3 of the time has passed, it will ring twice to tell you
over the food. You can just leave it continue. For better result,
the door, and then press" "to continue cooking.
to turn turn the food over, close
3℉
13
Up to 2 stages of cooking can be set. If one stage is defrosting, defrosting is automatically placed
in the first stage. After the cooking at each stage, the buzzer will sound and start the next cooking.
At
the end of the first stage of cooking, the buzzer sounds 1 time to start the second stage of
cooking.The cooking settings for each stage are the same as the single stage. )
O
.
MICRO
WEIGHT/TIME DEFROST
START/+30SEC.
START/+30SEC.
START/+30SEC.
START/+30SEC.
START/+30SEC.
START/+30SEC.
./GRILL/CONVEC
00

14
Please do not put the cake into the oven at
the beginning. The oven needs to be
preheated to first. After several
minutes, the buzzer beeps twice to
remind you to put the cake into the oven.
After putting the cake in the oven,
please press start again. The timer will
count down, and the cake will be cooked
perfectly.
Roast Chicken During the cooking process,
the oven beep twice to remind
you to turn the food over.
030

12. Defrost by Time
11. Defrost by W.T.
1) Press " " key twice, the oven will display "
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " " key to start defrosting.
1) Press " " key once,the oven will display "
3) Press " " key to start defrosting.
2) Turn " " to select the weight of food.At the same time, "Oz" will lights,
The weight should be 4-100 Oz.
1) Press the " " key once, "H1" will flash.
2) to choose the menu from H1 to H9. And "H1", "H2", "H3"..."H9" will display.
" to start cooking.
Turn " "
3) Press "
13. Air Fry
MenuNoNo.
H1
H2
H3
H4
H5
H6
H7
H8
H9
Frozen French fries
Frozen Potato croquettes
Frozen Calamari
Frozen Onion rings
Frozen Chicken nuggets
Steak
Shrimps
Vegetable
dEF1",.
dEF2".
Chicken wings
Power
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
425
without preheat
℉
15
START/+30SEC.
START/+30SEC.
START/+30SEC.
WEIGHT/TIME DEFROST
WEIGHT/TIME DEFROST
AIR FRY

1) Press the " " key, the screen will display "C1".
2)
" to start cooking.
14. Crispy Grill
Press " orrepeatedly
"turn " " to select grill mode.
Stop prssing/turning when "C1", "C2", "C3" or "C4" displays.
3) Press " " to confirm.
4)Turn " " to select the cooking weight.
5) Press "
Weight
C4(pie/tart)
Crispy grill
C1
Cordon bleu
(fresh mini pizza)
C2(lasagna)
C3(bread)
Power
15% microwave power
Note: All the food should be placed on the grill tray, and the grill tray must be placed on
the grill rack.
7.00 Oz
10.5 Oz
14.00 Oz
18.00 Oz
21.00 Oz
+ 85% grill power
7.00 Oz
10.5 Oz
14.00 Oz
18.00 Oz
21.00 Oz
15% microwave power
+ 85% grill power
3.50 Oz
7.00 Oz
10.5 Oz
15% microwave power
+ 85% grill power
7.00 Oz
10.5 Oz
14.00 Oz
18.00 Oz
425
with preheat
℉
16
START/+30SEC.
START/+30SEC.
CRISPY BROWN
CRISPY BROWN

1) Press the " " key , the screen will display "L1".
"L1", "L2", "L3", "L4" or "L5" will flash.
3) Press " " to confirm.
4) Turn " " to select the cooking temperature.
15. Low Temp Control
16. Deodorization
Press the " " key to start deodorizing .
L1(Slow 12h
Display
L2(Keep warm)
L3(Food dry)
L4(Yogurt/ferment)
Cooking time
(Max)
√√
√ √ √ 95min
√ √ √ √ √ √
√12h
√ √ √ √ √ √ √ 95min
" to confirm.
Turn " " to adjust the cooking time.
" to start cooking.
5) Press "
6)
7) Press "
cook)
L5(Warming box)
" repeafedly or2) Press the " rn
"" tu
to select cooking mode .
In waiting state, turn " " left to choose cooking time directly then press
" " key to cook with 100% microwave power. This program can be set
as the first stage of multi-stage cook.
17. Speedy Microwave Cooking
12h
℉
105 ℉ 120 ℉ ℉ ℉ ℉ ℉ ℉
18. Lock-out Function for Children
Lock: In waiting state, press " " for 3 seconds, there will be a long "beep"
denoting entering into the children-lock state and the lock indicator will light. will display
current time or 0:00.
Lock quitting: In locked state, press " " for 3 seconds, there will be a long "beep"
denoting that the lock is released, and the lock indicator will disapear.
17
140 160 175 195 210 230
Screen
START/+30SEC.
START/+30SEC.
START/+30SEC.
START/+30SEC.
STOP/CANCEL
STOP/CANCEL
DEODORIZATION
LOW TEMP. CONTROL
LOW TEMP. CONTROL

1) The buzzer will sound once when turning the knob at the beginning;
2) " " must be pressed to continue cooking if the door is opened
during cooking;
3) Once the cooking program has been set ,if " " is not pressed
4) The buzzer sounds once by efficient press, inefficient press will be no responce.
5) The buzzer will sound five times to remind you when cooking is finished.
1) During cooking state, press " " to check the current time. The time will be
2) In cooking state, press "the current
displayed for 3 seconds.
CLOCKTIMER/
"
20. Inquiring Function
In waiting state, press " " and hold, then press " " within 3
seconds, the buzzer will sound once and the oven will enter mute mode. Any operation
and the oven will exit mute mode.
21. Mute Function
19. Specification
power will be
cannot make the buzzer sound.
In waiting state, press " " and hold, then press " " within 3
seconds, the buzzer will sound once
Enter ECO mode: In waiting state, press " " briefly, the screen will be off.
ECO Function
Press any key.Exit ECO mode:
22.
18
displayed for 3 seconds.
Enter mute function:
Exit mute function:
within 5 minutes the current time will be displayed and the program cancelled.
STOP/CANCEL
STOP/CANCEL
STOP/CANCEL START/+30SEC.
START/+30SEC.
MICRO./GRILL/CONVEC./COMBO
START/+30SEC.
START/+30SEC.

Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE
Oven will not start
POSSIBLE CAUSE POSSIBLE REMEDY
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were
used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were
used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suit ble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is
not suitable. Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
MAINTENANCE
a
19
PN:16170000A78150
