Black Ridge PS-14 User manual

AIR REGULATOR WITH
FILTER &LUBRICATOR
PLU 161643


PLU 161683


Manufactured and packaged for SUPER CHEAP AUTO PTY LTD ABN 64 085 395 124
751 Gympie Road, Lawnton, Queensland 4501, Australia
12
Month
Warranty

1 2
WARRANTY
This product is guaranteed against defects for a period of 12 months from date of
purchase. This warranty is provided by Super Cheap Auto Pty Ltd ACN 085 395
124 (Supercheap Auto) of 751 Gympie Rd Lawnton QLD 4501 Ph [phone].
Supercheap Auto will offer a repair, replacement product or store credit if the product
is assessed as being defective during the warranty period.
To claim under this warranty, take this product to the Front Service Desk of your nearest
Supercheap Auto store. For store locations, visit www.supercheapauto.com.au (AUS)
or www.supercheapauto.co.nz (NZ). You will need your receipt or proof of purchase.
Additional information may be requested of you to process your claim. Should you not
be able to provide proof of purchase with a receipt or a bank statement, identification
showing your name, address and signature may be required to process your claim.
This product may need to be sent to the manufacturer to assess the defect before
determining any claim. Faults or defects caused by product modification, misuse and
abuse, normal wear and tear or failure to follow user instructions are not covered under
this warranty.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Any expenses incurred relating to the return of this product to store will normally have
to be paid by you. For more information contact your nearest Supercheap Auto store.
The benefits to the consumer given by this warranty are in addition to other rights and
remedies of the Australian Consumer Law in relation to the goods and services to
which this warranty relates.
IllustratIon
technIcal data
Model: PS-14
Type of Feed: Gravity
Standard Nozzle and Needle: 0.2mm
Additional Nozzles and Needles: 0.3mm, 0.5mm
Control: Push-button
Fluid Cup Capacity: 7ml
Operating Air Pressure: 15-50 PSI (1-3.5 BAR)
Air Inlet: 1/8”
WarnIng
• Familiarise yourself with the applications, limitations and hazards of this spray gun.
• Keep this product in good working condition. Take immediate action to repair
or replace damaged parts.
• Use genuine parts only. Unapproved parts may be dangerous.
• Use the spray gun only for its intended purpose.
• Keep your work area clean to avoid injury.
• Use appropriate safety equipment (breathing mask, protective glasses, etc).
TO PREVENT SERIOUS INJURY
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE

3 4
• Keep proper footing and balance at all times. If necessary, secure the work
piece in a clamp or vice.
• Keep the spray gun pointed away from your body and from other people in
the work place. Do not direct paint or air at yourself or others.
• Ensure that the spray gun is disconnected from the air supply before
servicing, changing accessories and when not in use.
• do not allow smoking or open flames in the work area.
• do not carry the spray gun by the hose.
• do not tamper with, or adjust, the safety valve.
• do not use whilst tired or under the influence of drugs, alcohol or
intoxicating medication.
aPPlIcatIons
• Commercial, illustrations, photo retouching, hobby and crafts.
asseMBlY
• Screw one side of the air hose onto the air hose connection of the air brush
and the other end onto the air supply.
• Use the air hose adaptor to connect the air hose to the compressor if
necessary.
oPeratIon
• Fill the cup with fluid after thinning appropriately.
• Hold the air brush lightly in your hand.
• By pressing the main lever down, a stream of air emerges. Then draw it
backward gradually for colour atomisation.
• The spray pattern is in determined by the distance between the work surface
and the air brush.
• For fine line spraying, remove the needle cover and hold the air brush near the
work surface.
• To achieve a consistent output of material the airbrush is equipped with a
“needle stop adjustment screw”. This allows you to draw back the paint flow
to a preset amount which in turn will deliver an even flow for the entire stroke.
Simply adjust the screw to your desired output and test on a piece of scrap
material. Fine tune until the desired flow is achieved and you are set to go.
note: We recommend you spray on an old newspaper or other material to get
the “feel” of your air brush before approaching your work piece.
cleanIng and MaIntenance
note: To achieve the best results when spraying it is always best to start with
the air brush clean and totally free from old paint deposits, dirt, etc. Therefore,
the air brush should be thoroughly cleaned immediately after each operation.
WarnIng: Turn off air and paint to the air brush and release pressure by
triggering the air brush before disassembling, cleaning or servicing. If unsure,
please take the air brush to a qualified technician for repair.
• Empty the fluid cup and wash with thinners (or water depending on the
application).
• Refill with solvent (or water depending on the application), then block the
needle cover with a finger and spray.
• The air flows backward into the nozzle to clean the paint remaining in the air
brush.
