Black BLK-CDS205NS User manual

1BLK-CDS205NS_CQ
11/20/12
3. If the lens assembly has an auto-iris feature, plug the lens cable to the lens connector on the back
of the camera.
Installing the camera
1. Install the camera mounting bracket using the instructions provided with the bracket.
2. Attach the camera to the mounting bracket.
3. Route a video/power extension cable between the camera and a video monitor and power
source.
4. Apply power to the camera. NOTE: When connecting 12 Vdc power, observe the polarity marked
on the power input connector.
5. While observing video from the camera on the monitor, aim the camera at your surveillance
target.
6. Adjust the lens focus and zoom if controls are provided. If you installed a xed lens to the camera,
you can adjust the focus by:
a. Loosing the set screw on the side of the camera (see photo above).
b. Slowly rotate the mounting ring until the best focus is achieved.
c. Tighten the set screw.
OSD Camera Menu
The OSD (On Screen Display) camera menu appears over the video image from the camera. It is
controlled by the joystick on the back panel of the camera.
UP
LEFT
DOWN
Press in to
“Enter”
RIGHT
In general, the joystick can rock up or down to move the cursor between parameters in the OSD menu
list, or left or right to change the selected parameter value. Press the joystick in (toward the camera) to
open a submenu or start an operation.
To use the OSD conguration menus, connect a video monitor to the camera, then press the joystick
in (“Enter”). The CAMERA MENU will open. The OSD CAMERA MENU provides links to submenus.
Submenu links are indicated by the 8 icon at the end of the line. Selecting the 8 icon parameter on
submenus and pressing the joystick in (“Enter”) returns to the previous menu.
OSD Menus
• LENS: Select Manual, Video or DC (default).
• EXPOSURE
—Shutter: You can set the shutter to auto or manual
mode: Options are: Auto, 1/60, FLK, 1/250, 1/500,
1/1000, 1/2000, 1/4000, 1/5000, 1/10,000 and
1/100,000
—Brightness: You can adjust brightness level 0
(dark) to 255 (bright)
—AGC: You can select auto gain level. O / Low /
Middle/High
—DWDR: The DWDR feature employs intelligent light
level control to compensate for strong backlight
conditions. DWDR: OFF / ON
• White Balance: You can choose from one of the
following modes. ATW1 / ATW2 / AWC SET / MANUAL
(INDOOR / OUTDOOR / MANUAL)
—ATW1: Automatically adjusts color for the available
lighting temperature range: 2500 °K to 9500 K.
—ATW2: Automatically adjusts color for the available
lighting temperature range: 2300 K to 10000 K.
BLK-CDS205NS 600 TVL DWDR
CS Mount Camera
Quick Installation Guide
This document guides you through the basic steps to install your BLK-CDS205NS camera. The camera
is designed for CS type lenses, and C-type lenses with an adapter. The lens is not included The camera
features:
• Ultra-compact box size with CS mounting
• 1/3” Sony® SuperHAD II CCD
• Resolution > 600 TVL
• Sensitivity 0.1 lux (F1.2, 50 IRE, 30 fps)
• Adaptive 2D digital noise reduction
• Programmable OSD
BLK-CDS205NS camera with lens (lens not included)
Precautions
• Please read this manual carefully before installing the camera.
• Precision components are contained in this camera. Avoid strong shocks or vibrations during
installation and maintenance. Do not connect the power until you have completed the installation.
• Obey all local electrical wiring regulations when using this unit.
• Do not use abrasive or corrosive materials for cleaning. Use only a soft cloth for cleaning.
• To prevent damage to the lens and sensor, do not point the camera directly into the sun or toward
a strong light source.
• Operate the camera only within the recommended temperature and humidity ranges.
• Ensure that the power supply meets the current requirements of the camera and that the supply
voltage is inside the tolerances of the camera.
• Ensure that the mounting hardware is adequate to support the weight of camera and lens.
• Do not dismantle or service the camera. Refer it to qualied service personnel for repair.
Connections
All connections to the camera are make at the back panel.


y


 Video out connector (75Ω BNC): Connect
to a monitor, DVR, etc.
 IRIS: Lens connector for auto-Iris lens.
 Joystick: Used for conguring OSD menus
 Power input: 12 Vdc or 24 Vac.
y LED power indicator: Illuminated when
power is applied.
Attaching the lens
1. Remove the protective cap covering the camera image sensor.
2. Attach the lens assembly to the camera by screwing it clockwise onto the camera mounting ring
until it is fully seated.
Camera Body
Mounting Ring
Lens
Set Screw
Connector for CS bracket (top and bottom)

2© 2012 Observint Technologies, Inc. All rights reserved.
WHITE BALANCE (continued)
—AWC SET: It is a xed white balance mode that may be automatically readjusted only by
pressing SET Button in
—OUTDOOR: Set color temperature for Outdoor light (5400 K)
—INDOOR: Set color temperature for Indoor light (3200 K)
—MANUAL: Color can be corrected when the user increases or decreases red gain or blue gain.
—RED GAIN: Adjust red gain value 0 ~ 255
—BLUE GAIN: Adjust blue gain value 0 ~ 255
• BACKLIGHT: Select OFF, BLC, HLC.
BLC mode:
—AREA SEL: Select AREA1, AREA2
—AREA STATE: Select OFF / ON
—GAIN: Select 0 ~ 255 steps
—HEIGHT: Select 0 ~ 15 steps
—WIDTH: Select 0 ~ 15 steps
—LEFT/RIGHT: Select 0 ~ 15 steps
—TOP/BOTTOM: Select 0 ~ 15 steps
HLC: High Light Compensation.
—Level: 0-255 steps.
—Mode: All Day, Night Only
• Day& Night Level: Select AUTO / COLOR / B/W /
D&N AUTO mode:
—D -> N LEVEL: 0 ~ 255 steps
—D -> N DELAY: 1 ~ 30 SEC
—N -> D LEVEL: 0 ~ 255 steps
—N -> D DELAY: 1 ~ 30 SEC
Color: D&N color mode only
D&N B/W mode:
—BURST: OFF / ON
—IR SMART: OFF / ON. This option controls the
IR LED output level to compensate for object
distance. The IR smart options is used for objects
in an area of the image
—IR LEVEL: HIGH / LOW
• DPC (Dead Pixel Compensation): When used, the
camera will remove defective pixels from an image.
• SPECIAL
—CAM TITLE: Select camera title menu (text edit).
—MOTION: Select camera title menu (text edit)
»AREA SEL: Select AREA1, AREA2, AREA3,
AREA4
»AREA STATE: Select OFF / ON
»HEIGHT: Select 0 ~ 15 steps
»WIDTH: Select 0 ~ 15 steps
»LEFT/RIGHT: Select 0 ~ 15 steps
»TOP/BOTTOM: Select 0 ~ 15 steps
» DEGREE: Select 0 ~ 255 steps
»VIEW: OFF / ON
—PRIVACY: You can cover an area of the screen.
»AREA SEL: Select AREA1, AREA2, AREA3, AREA4
»HEIGHT: Select 0 ~ 255 steps
»WIDTH: Select 0 ~ 255 steps
»LEFT/RIGHT: Select 0 ~ 255 steps
»TOP/BOTTOM: Select 0 ~ 255 steps
»COLOR: Select 0 ~ 15 steps
—PARKLINE: You can insert a line on the screen.
»LT: You can adjust the top left area on screen. (0 ~ 195 steps)
»LB: You can adjust the bottom left area on screen. (0 ~ 194 steps)
»RT: You can adjust the top right area on screen. (0 ~ 194 steps)
»RB: You can adjust the bottom right area on screen. (0 ~ 194 steps)
»F: You can adjust the front area on screen. (0 ~ 68 steps)
»N: You can adjust the near area on screen. (0 ~ 68 steps)
»T: You can adjust the parking line thickness. (0 ~ 15 steps)
—IMAGE ADJUST: You can adjust camera image.
»2DNR: (on-screen Digital Noise Reduction)
(OFF/ON)
»MIRROR: (reverse camera image horizontally)
(OFF/ON)
»FONT COLOR:
FONT: 16 colors (O ~ 15 steps)
ID & TITLE: O ~ 15 steps
»CONTRAST: You can adjust contrast on screen. (0 ~ 255 steps)
»SHARPNESS: You can adjust camera image for clarity. (0 ~ 31 steps)
»DISPLAY: You can adjust camera output for the display type. (CRT / LCD / USER)
CRT (cathode ray tube).
PED LEVEL: 0 ~ 63 steps
COLOR GAIN: 0 ~ 255 steps
LCD (liquid crystal display)
GAMMA: 0.05 ~ 1.00 steps
PED LEVEL: 0 ~ 63 steps
COLOR GAIN: 0 ~ 255 steps
USER
GAMMA: 0.05 ~ 1.00 steps
PED LEVEL: 0 ~ 63 steps
COLOR GAIN: 0 ~ 255 steps
»NEG.IMAGE: You can invert a color image, or a black and white image. (OFF/ON)
—LANGUAGE: Select language. (ENGLISH / CHINESE)
—VERSION: Factory version number.
• RESET: Set the camera options to the factory default
settings.
Specications
CCD Sensor 1/3” Sony Super HAD II CCD
Eective Pixels 768 x 494
Performance Resolution > 620 TVL
Sensitivity 0.1 lux (Color), 50 IRE
S/N Ratio 52 dB
Day / Night Software Controlled
Lens Type DC / manual
Mount CS (C with adaptor)
Functions OSD English / Chinese
Shutter 1/60~1/120,000
Flickerless On / O
Wide Extended Range O / Low / Medium / High
AGC Adjustable
Electronic shutter O/On 1/200,000 second maximum
Sync Internal
Camera ID Number O / On 1 .. 255
Camera Name O / On, 8 alphanumeric characters
White Balance ATW / push / manual
2D Adaptive DNR O / Low / Middle / High
Gamma 0.45 / 0.7 / 1.0
Chroma Gain Adjustable
Motion Detection 4 areas, O / On, Position and Sensitivity adjustable
Privacy masking 4 areas, O / On, Color and Position adjustable
Image functions Sharpness, Mirror
Input / output Video Output CVBS 1.0 Vp-p, 75 Ω
Programming Interface Joystick
Power Power Supply 12 Vdc -10 % to +15 %, 24 Vac ± 20 %
Power Consumption 2.1 W maximum
Physical Dimensions (l x w x h) 2.87” x 1.57” x 1.57” (73 mm x 40 mm x 40 mm)
Weight 7.76 oz (220 g)
Mounting 2 x ¼” BSW
Environ-
mental
Operating Temp 14 °F ~ 122 °F (-10 °C ~ 50 °C)
Operating Humidity < 90 % non-condensing

3© 2011 Digiop, Inc. All rights reserved.
