BLACKMORE BJP-1516BT User manual

Samson
Electronics Inc.
3400 E. Slauson
Ave. Maywood,
CA 90270 Ph:
323.585.6393
Fax: [phone]
Web: http://www.blackmoremobile.com
BJP-1516BT Rechargeable and Amplified PA Speaker
Introduction:
The BJP-1516BT is a rechargeable and amplified PA loudspeaker with integrated music player, a ¼”
MIC input, collapsible luggage style carrying handle, built in caster wheels and LED accent lighting.
This model boasts a rechargeable lead acid battery, an auxiliary power supply capable of operating
off of 12V DC and a standard AC power connection making this unit extremely versatile. It comes
with an integrated music player that can play mp3 files from SD cards or USB drives, Bluetooth
connectivity for wireless music streaming and FM Radio.
Features:
•3 power modes: AC plug, Rechargeable Battery, 12V DC
•Music Player with SD Card and USB inputs
•Bluetooth Connectivity
•FM Radio
•LED Accent lighting
•Wireless remote control
•Wired Microphone included
•15” Subwoofer, titanium dome tweeter, 1000W
•Weight: 30 lbs
Caution:
• Please read All Operating Instructions before using this product
• Avoid electrical shock, DO NOT OPEN THIS UNIT, THERE ARE NO REPLACEABLE PARTS INSIDE. Please refer
to your warranty information for service.
• Do not Expose this product to Moisture, Water, Rain or Snow. Keep away from direct heat sources. Damaged
items will not be accepted for warranty
• Do not clean this unit with solvents or chemicals
• Insure that all volume and gain controls are set to “0”when connecting source units

1. 2. 3. 4. 5. 6.
7.
8.
9.
16.
10.
11.
17.
12.
13.
14.
18. 15.
20.
19.

Func tio ns:
1. Mode: Press to scroll between Bluetooth, MP3, line in and FM mode
2. Previous track/FM station: Press this to go back 1 track on the mp3 player or back 1 FM
station
3. Play/Pause/Scan: Press to start an MP3 track or to pause it. Press to scan and program FM
stations in FM mode.
4. Next track/FM station: Press this to go forward 1 track on the mp3 player or forward 1 FM
station
5. Repeat/Shuffle: Press to repeat a track, shuffle all tracks, or repeat all tracks
6. Equalizer: press and repeat to scroll between EQ Presets that provide different
tone settings for music playback.
7. USB input: This is a full size USB2.0 female input. It has a read capacity of 4GB. Music files
must be formatted as MP3 to be played via USB.
8. Master Volume control: This controls the overall volume of the speaker and supersedes all
volume controls.
9. AUX Audio in: 3.5mm AUX audio input for external audio sources
10. Master Bass control: This controls the amount of bass frequencies produced by the
speakers.
11. Master Treble control: This controls the amount of treble frequencies produced by the
speakers.
12. MIC Echo: Use to adjust the amount of echo effect produced on the MIC Signal
13. MIC volume control: This controls the amount of signal received by the microphone.
14. Battery Status Indicator
15. MIC input: ¼” Jack. Can be used with a wide range of professional microphones
and equipment.
16. Master Power Switch: This turns the unit on or off.
17. LED illumination switch: Use this to turn the LED illumination on or off.
18. 12V DC power input.
19.
20. LED Screen that displays track and mode information.
21. Guitar input: ¼” MIC and Guitar Input. Can be used to amplify a wide range of
instruments.
22. MIC input: ¼” Jack. Can be used with a wide range of professional microphones
and equipment.
23. AC Power Input

Operation:
Setup:
1. Ensure that the unit is connected to the appropriate power source using the provided power cable.
2. Plug in the power cable and choose your input method.
3. Ensure that the master volume is turned to the “0”position before connecting any audio source.
4. Place the speaker in a location that is away from any direct heat source, moisture, or extreme humidity.
Playback:
1. Using a USB storage device: The player can accept thumb drives and storage devices in USB 2.0 or less
format. Files can be played back formatted as MP3 only. The USB connection can read devices up to 4GB.
2. Using a SD card: The player can accept standard SD cards formatted as MP3 only. The TF Card input can read
devices up to 4GB.
3. Using Bluetooth: Ensure that your audio source has bluetooth enabled/discoverable, next turn your speaker
on and select bluetooth mode. Search for available Bluetooth devices on your source unit and select BJP-
198BT. Once connected you can play audio from your device when the unit is in Bluetooth Mode.
4. Using Microphones: Ensure that the Microphone volume is set to “0”. Connect your microphone to the ¼”
Jacks. Ensure that your microphone is turned on. Adjust the volume control to desired volume.
5. Using line in: Ensure that you are in line in source mode. Ensure that your line in source gain control is not
set to 0 and that your source unit volume is not set to 0.
Maintenance and care:
• Store and use in a dry environment away from direct heat sources and moisture.
• Do not clean with solvents or detergents. Only use a mildly damp cloth to dust or clean.
• Use on a flat stable surface. This unit will vibrate when played at high volume and will shift position.
Please use caution when placing this on any surface
• Use only the correct power source and cable provided
• Maintain all gain controls at correct levels. Excessive gain controls coupled with high volume can
damage the speaker drivers.
• Collapse all antennas and disconnect all cables before moving the unit.
Troubleshooting:
• Music files not read: Ensure that your music files are encoded as MP3 Audio Files.
• No Sound: Please ensure that all volume and gain controls are not in the “0”position and that all
source units are on and producing volume. Check volume controls at source units
• Bluetooth not connecting: Ensure that the Bluetooth devise you are connecting has Bluetooth on
and is discoverable.
• No Power: please ensure that your power connection is fully engaged and connected to a non
surging power source.
• Sound is distorted: Please ensure that your source volume and input gains on the speaker are even
and balanced. Also check that your connecting cables from source units are not damaged or broken.
• No sound from Microphone: Ensure that the MIC gain control is not set to “0”ensure that the
microphone is turned on and that all connecting cables are fully engaged and working properly.
If you are still having technical issues with your product and could use some assistance please contact us at
[e-mail]

How to protect and maintain the battery of your
Blackmore Portable speaker
(not all models have a rechargeable battery)
Your Blackmore Speaker comes with a non spill able lead acid battery preinstalled. There are no user serviceable
parts on your speaker. However, the battery’s life depends on how you charge and maintain it. Below are several
crucial points you must follow in order to preserve the life and performance of your battery and protect your factory
warranty.
1. Allow a full charge before use.
2. Do not over charge your battery. Disconnect from power source once battery is full.
3. Do not allow your battery to fully drain.
Step one:
When you first plug your speaker into a power source (12V or AC) you begin to charge your unit for the first time. It
is important to allow a complete charge before you disconnect from a power source or use the speaker for the first
time. Allowing a full charge before use ensures that all the cells in your battery are activated. Full cell activation
only happens during initial charge.
Step two:
Ensure that you disconnect the power source from the battery once it is fully charged. Over charging the
battery will cause the cells in the battery to break down and deteriorate.
All rechargeable Blackmore Speakers have a battery status indicator that shows when the battery is fully charged.
Step three:
Never allow the battery on your unit to drain completely. Draining the battery completely will also cause the cells
within the battery to lose their conductivity. You can tell when your battery is running low by the battery status
indicator or by your speaker producing a gradual lower volume.
Following these steps will ensure that your battery performs and lasts the full life of your speaker. Not following
these steps will void our warranty.

FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body
