Blomberg WM 98400 SX Instruction Manual

WM 98400 SX
WM 98200 SX
Owner’s Guide & Installation Instructions
To prevent accidents and machine damage, read these
instructions before installation or use. Use the washer only as
instructed in this owner’s guide and installation instructions
included with your washer. Keep this guide for future reference
Front-Loading Automatic Washer
2820524382_EN / 01-06-15.(10:26)Document Number
As an ENERGY STAR® partner,
BLOMBERG has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.

2 / English
Front-Loading Automatic Washer
Please read this guide first!
Dear Customer,
We hope that your product which has been manufactured in modern
facilities and passed through a strict quality control procedure will give
you the best results.
Therefore, we advise you to read through this document carefully
before using your product and keep it for future reference.
This guide will…
…help you use your washer in a fast and safe way.
• Please read the guide before installing and starting your washer.
• Particularly follow the instructions related to safety.
• Keep this guide within easy reach. You may need it in the future.
• Please read all additional documents supplied with this washer.
Please note that this owner’s guide & installation instructions may be
applicable for several other models. Differences between models will
be identified in the guide.

Owner’s Guide & Installation Instructions
3 / English
Explanation of symbols
Throughout this guide the following symbols are used:
CCAUTION
• Important information or useful hints about usage.
AWARNING
• Warning for hazardous situations with regard to life and property.
BWARNING
• Warning for electrical shock
If you have questions, call:
Call Center (toll free number)
1-800-459-9848 (USA)
or send e-mail to:
[e-mail]
For the list of dealers/retailers, distributors and authorized service
agents, visit:http://www.blombergappliances.com
Please fill in the information below for future reference.
Model no.:
Serial no.:
Purchase date:

4 / English
Front-Loading Automatic Washer
TABLE OF CONTENTS
1 Your Washer 6
Overview .......................................................6
Specifications ....................................................7
2 Important Safety Instructions 8
3 Installation Instructions 13
The Right Location of Installation ....................................13
Installation Clearances ............................................14
Allowable Clearances for Undercounter Installation.......................15
Allowable Clearances for Closet Installation ............................16
Stacked Installation ..............................................16
Removing packaging reinforcement ..................................16
Removing shipping bolts ..........................................17
Leveling the washer ..............................................18
Electrical Connection .............................................18
Power supply and circuit ..........................................20
Water Supply Connection ..........................................21
Drainage.......................................................23
Installation Checklist ..............................................24
Transportation ..................................................24
Disposal Information..............................................25
Appliance Disposal ...............................................25
4 Operating Instructions 26
First Use.......................................................26
Laundry Tips ...................................................27
Preparing the laundry .............................................28
Loading the washer ..............................................29
Detergent Use ..................................................30
Detergent Quantity ...............................................31
Detergent Dispenser..............................................32
(II) Main Wash Detergent Compartment ...............................33
Liquid Fabric Softener Compartment .................................34
Using liquid detergents ............................................34
(I) Liquid Chlorine Bleach Compartment ...............................35
Water Consumption ..............................................35

Owner’s Guide & Installation Instructions
5 / English
TABLE OF CONTENTS
5 Selecting a Program and Operating Your Washer 36
Control panel ...................................................36
Programs .....................................................37
Program selection ...............................................40
Program and consumption table.....................................42
Temperature selection ............................................45
Spin speed selection .............................................46
Rinse Hold .....................................................46
Auxiliary function selection .........................................47
End Time ......................................................49
Changing the selections after program has started .......................50
Child Lock .....................................................51
6 Preparation 52
Starting the program .............................................52
Door locking system..............................................53
Adding or taking out laundry........................................53
Cancelling the program ...........................................54
Re-spinning the laundry ...........................................54
End of program .................................................55
Energy saving mode..............................................55
7 User maintenance instructions 56
Cleaning detergent dispenser .......................................56
Cleaning the door seal ............................................57
Cleaning the drum ...............................................57
Cleaning the outer cabinet and control panel ...........................58
Cleaning the water inlet strainers ....................................58
Cleaning the drain pump filter ......................................59
Descaling the washer .............................................61
8 Troubleshooting 62
9 WARRANTY STATEMENT FOR THE BLOMBERG CLOTHES
WASHERS 75
10 HOW TO GET SERVICE 76

6 / English
Front-Loading Automatic Washer
1Your Washer
1
2
3
4
5
6
7
8
Overview
1- Power cable
2- Top panel
3- Control panel
4- Drain hose
5- Loading door
6- Filter cap
7- Adjustable feet
8- Detergent drawer

Owner’s Guide & Installation Instructions
7 / English
Your Washer
Specifications
Specifications of this appliance may change without notice to improve
the quality of the product. Figures in this guide are schematic and
may not match your product exactly.
Values stated on the washer labels or in the documentation
accompanying it are obtained in laboratory in accordance with the
relevant standards. Depending on operational and environmental
conditions of the appliance, these values may vary.
Front Loading Automatic Washer
Models WM 98400 SX WM 98200 SX
Height (in) / (cm) 33.1 / 84 33.1 / 84
Width (in) / (cm) 23.6 / 60 23.6 / 60
Depth (in) / (cm) 24.6 / 62,5 24.6 / 62,5
Net Weight (lbs) / (kg) 165.6 / 75 165.6 / 75
Electricity (V/Hz.) 208-240 / 60 208-240 / 60
Total Current (A) 10 10
Total Power (W) 2000-2350 2000-2350
Spinning cycle (rpm max.) 1400 1400
Water pressure (psi) / (bar) (15-145) / (1-10) (15-145) / (1-10)
Drain height (ft.) / (m.) 4.9 / 1.5 4.9 / 1.5
Wash capacity (cu. Ft.) 2.52 2.52
Dry Load Capacity (lbs)/(kg) 22.26 / 10.1 22.26 / 10.1

8 / English
Front-Loading Automatic Washer
2Important Safety Instructions
BWARNING
• To reduce the risk of fire, electric shock or injury to persons while
using your appliance follow basic safety precautions, including
the following:
• Read all instructions before using the washer.
• Do not wash articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents,
or other flammable or explosive substances (acetone, alcohol,
kerosene, some liquid household cleaners, some spot removers,
turpentine, waxes and wax removers) as they give off vapors that
could ignite or explode.
• Do not add gasoline, dry-cleaning solvents, or other flammable or
explosive substances to the wash water. These substances give off
vapors that could ignite or explode.
• Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using a washing machine, turn
on all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the
gas is flammable, do not smoke or use an open flame this time.
• Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
• Before the appliance is removed from service or discarded, remove
the door and the power cord / main plug to prevent accidents.
• Do not reach into the appliance if the drum is moving. Wait until the
drum has completely stopped before opening the door.
• Do not install or store this appliance where it will be exposed to the
weather and direct sunlight.
• Do not tamper with controls.

Owner’s Guide & Installation Instructions
9 / English
Important Safety Instructions
• Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in the user-maintenance
instructions or in published user-repair instructions that you
understand and have the skills to carry out.
• This appliance must only be used for the purpose of washing,
rinsing and spinning machine-washable items using laundry
additives that are suitable for use in washers . The appliance
manufacturer cannot be held responsible for damage caused by
improper or unintended use of the appliance.
• Only detergents, softeners and additives suitable for use in
HE (High-efficiency) washers may be used. Always follow the
instructions and information given by the laundry detergent
manufacturers when using these products.
• Always follow the fabric care instructions of garment manufacturers.
• Do not touch the door glass while washing at high temperatures.
Danger of burning!
• Do not sit on top of the washer.
• Do not climb onto the washer.
• Destroy the shipping carton, plastic bag and other packing
materials after the washer is unpacked. Keep children away from
these packing materials. Danger of suffocation from plastic sheets
and cartons!
• Do not mix chlorine bleach with ammonia or acids such as vinegar
and/or rust remover when washing. This mixture can produce
hazardous fume which may cause death.
• Do not operate this appliance if it is damaged, malfunctioning,
partially disassembled, or has missing or broken parts, including a
damaged cord or plug.

10 / English
Front-Loading Automatic Washer
Important Safety Instructions
• Store laundry detergents and additives in a cool, dry place out
of children’s reach due to danger of chemical poisoning and skin
irritation. Follow the manufacturers’ instructions when using laundry
products.
• Do not machine wash fiberglass materials. Small particles can stick
to fabrics washed in following cycles and may lead to skin irritation.
• Do not wash items stained with vegetable oil, cooking oil or
petroleum. These items may contain some flammable oils after
laundering and the fabric may smoke or catch fire by itself.
• Be sure to unplug the power cable before attempting maintenance
or cleaning of your appliance to minimize the risk of electric shock.
Always unplug the cable by grasping the plug, not the cord.
• Do not use wet hands when plugging/unplugging the power cable.
• Check the water inlet and drain hose connections regularly for any
leakage. Hoses should be replaced every 5 years.
• Do not leave the washer door open to prevent children hurt
themselves by hanging on the door or going inside the drum.
• Be careful when the appliance is draining hot water. Danger of
burning!
• At the end of a washing day, turn off the water faucets to prevent
any leakage that may occur due to a faulty condition of the
appliance.
• Check the appliance and inlet hose connections for water leakage
after each use. If there is leakage, turn off the appliance and water
faucets and call service.
• Do not machine wash items having large or heavy metal parts such
as buttons or buckles. These items could severely damage the
appliance.
• Always be sure to empty all foreign materials from the pockets of
your clothing as small items such as coins, pins etc. could severely
damage the appliance.
• Do not install and operate the appliance in places exposed to
temperatures below freezing. Frozen water may cause severe
damage by bursting hoses and pump.

Owner’s Guide & Installation Instructions
11 / English
Important Safety Instructions
• Make sure that shipping bolts are removed before you operate the
washer. If service is required as a result of not removing the bolts, it
will not be covered by the warranty.
• Make sure that the wash drum is empty before you load the washer.
• Do not store and use any flammable and combustible substances
such as lint, paper and chemicals near the appliance.
• Always follow the manufacturer’s instructions when you are using
a descaling agent. Be sure that descaling agent contains rust-
protective materials and rinse the washer a few times thoroughly
after the descaling process (See, Descaling the washer).
• Install and operate the washer on a solid floor to prevent vibration or
movement. It is not recommended to install and operate the washer
on wooden floor or on a carpet.
• The rated voltage of your washer is 208/240V, so it should not be
directly connected to the wall power of 110/120V. A special junction
box will be provided and used for the wall power connection
(See, Installation Instructions for Grounding Instructions and
Requirements).
• If an abnormal sound is heard during the washer operation, refer to
the “Troubleshooting” of this guide.
• Call service for checking any possible damage or fault if the
appliance is dropped or bumped.
• The end of drain hose should not contact the discharge water in
any way as this might cause siphoning of water.
• Always leave the property after checking that the wash cycle is
completed and the washer is turned off.
• Damaged or worn power cords and plugs must only be replaced by
a Blomberg Service technician.
• Never use an extension cord or adapter to connect the appliance to
the electrical power due to the risk of electric shock and/or fire.
• All broken and faulty components, panels and parts must only be
replaced with original Blomberg spare parts by a Blomberg Service
technician.
• Do not force the washer door open when it is locked. The door

12 / English
Front-Loading Automatic Washer
Important Safety Instructions
must be closed any time during the program cycle.
• Do not use fabric softeners or products to reduce static unless
recommended by the manufacturers of the fabric softener product.
• Check the drain pump filter occasionally to remove coins, buttons
and such small objects.
• Always drain off the water completely before cleaning the pump
filter, before transporting the washer, when there is a danger of frost
and when there is a power failure (For emergency draining, See
User maintenance instructions).
• Always be sure that the washer has been properly installed by
licensed personnel, water and electrical connections and grounding
conform to all relevant codes and requirements.
• This manual does not cover every possible condition and situation
that may occur. Use common sense and caution when installing,
operating, and maintaining any appliance.
AWARNING
• This product may ccontain chemicals known to the state of
California to cause cancer or birth defects or other reproductive
harm.
SAVE THESE INSTRUCTIONS
Always follow the instructions on this user guide. If you aren’t sure
how to perform them, please call Customer Service for assistance
and scheduling service.

Owner’s Guide & Installation Instructions
13 / English
3Installation Instructions
Read this first !
This washer can be individually installed in free-standing and built-in
installations. You can also install your washer with your dryer as a
free-standing or built-in pair. Before you install your appliance, read
the following instructions completely and carefully:
• Save these instructions for future reference.
• This appliance must be properly installed and grounded by qualified
and skilled technicians in accordance with all local codes and
ordinances and the latest edition of the National Electrical Code,
ANSI/NFPA 70.
• Proper installation of this appliance is the responsibility of the
owner and failure due to improper installation is not covered by the
warranty.
The Right Location of Installation
You can install your washer in a basement, closet or in a laundry
room if the location has proper drainage, plumbing and power supply
system. Always follow these instructions for installation:
• Do not install or store this appliance where it will be exposed to
the weather, rain, damp places, water and direct sunlight. The
ambient temperature must be higher than 60°F (15.6°C) for proper
operation. Installation location must have the proper ventilation.
• Do not store and use any flammable and combustible substances
such as lint, paper, curtains, gasoline, coal and liquid or vapor
chemicals near the appliance.
• Install and operate the washer on a strong solid concrete floor to
prevent vibration, noise or movement in case of load unbalance.
The floor must have sufficient load carrying capacity and the washer
must be leveled properly before the operation.
• It is not recommended to install and operate the washer on a
wooden floor or soft floor. If you have to install your washer on a
wooden or frame construction floor, the floor must be reinforced
properly and the washer must be located in the corner of the room
if possible.

14 / English
Front-Loading Automatic Washer
Installation Instructions
• Never place your washer on a carpet. This prevents air circulation.
The electrical components of the machine may overheat and cause
damage.
• Do not stand appliance on the power cable.
• Do not install and operate your washer in ambient temperatures
lower than 32˚F (0˚C). Controls may stop working properly in such
condition.
• If there is danger of frost, drain all remaining water in pump and
hoses since it may freeze and cause damage by bursting them (see
“Cleaning the drain pump filter”).
Installation Clearances
CCAUTION
• The installation location must be large enough for the washer door
to be fully opened for loading.
• The installation location must be large enough for ease of
operation, maintenance and service.
• Ensure there is min 1/2” of clearance on each side of the washer
to allow slight sideways movement during washing and spin
drying.

Owner’s Guide & Installation Instructions
15 / English
Installation Instructions
Allowable Clearances for Undercounter Installation
The dimensions are for the recommended spacing. Counter depth
should be 23.5-24.5”(60-62 cm).
Custom undercounter installation – Washer only
Minimum counter width should be 50” (127 cm) for a pair of Blomberg
washer & dryer.
Custom undercounter installation – Washer & Dryer
50”
(127 cm)

16 / English
Front-Loading Automatic Washer
Installation Instructions
Allowable Clearances for Closet Installation
When installed in closet (washer only/washer dryer stacked) :
Sides, Rear, Front 1/2 in. (1.27 cm), Top= 1 in. (2.54 cm)
Closet door ventilation requirement: A louver having minimum 23 in2
(148 cm2) air opening located at 3 in (7.62 cm) from the bottom of
closet door.
Stacked Installation
You can stack your Blomberg washer and dryer (model no.: DHP
24412 W / DHP 24400 W) by using a special stacking kit (Part
No.2985300200). If necessary, consult your dealer or technical
service for supplying the stack kit. In stacked closet installation,
following configuration is necessary:
A louver having minimum 23 in2(148 cm2) air opening located at 3
in (7.62 cm) height from the bottom of closet door (for washer) & A
louver of minimum 46 in2(297 cm2) air opening located at 3 in (7.62
cm) distance from the top of closet door (for dryer).
Removing packaging reinforcement
Tilt the washer to remove the packaging reinforcement. Remove the
packaging reinforcement by pulling the ribbon.

Owner’s Guide & Installation Instructions
17 / English
Installation Instructions
Removing shipping bolts
BWARNING
• Shipping bolts must be removed before operating the washer!
Otherwise, the appliance will be damaged seriously!
1.Loosen all the bolts with a spanner wrench until they rotate freely
(“C”)
2.Remove the shipping bolts by turning them gently.
3.Bolt hole covers (supplied in the bag with the owner’s guide)
are fitted into the holes on the rear panel with a special lock
mechanism. To fit the cover, first insert it into the hole and then
rotate it counterclockwise with a screwdriver until it is locked. To
unlock, apply the procedure in reverse.
CCAUTION
• Keep the shipping bolts in a safe place to reuse when the clothes
washer needs to be moved again in the future.
• Never move the appliance without shipping bolts properly fixed in
place!

18 / English
Front-Loading Automatic Washer
Installation Instructions
Leveling the washer
BWARNING
• Do not use any tools to loosen the lock nuts. Otherwise, they
can be damaged.
1.Manually (by hand) loosen the lock nuts on the feet.
2.Adjust them until the washer stands level and firmly.
3.Important: Tighten all lock nuts up again.
Electrical Connection
Grounding Instructions
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This appliance
is equipped with a cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with all
local codes and ordinances and the latest edition of the National
Electrical Code, ANSI/NFPA 70.
BWARNING
• Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualified electrician
or serviceman if you are in doubt as to whether the appliance is
properly grounded.
• Do not modify the plug provided with the appliance – if it will
not fit the outlet, have a proper outlet installed by a qualified
electrician.

Owner’s Guide & Installation Instructions
19 / English
Installation Instructions
BWARNING
• Be sure that the power cord is always accessible by the user
after the appliance is installed.
• Never use an extension cord or adapter to connect the appliance
to the electrical power due to the risk of electric shock and/or
fire.
• It is the personal responsibility and obligation of the appliance
owner to provide a proper and grounded outlet installed by a
qualified electrician.
• Never use a damaged power cord since there is a risk of electric
shock and/or fire.
• The damaged power cord must be replaced by a qualified
electrician as soon as possible.
• Do not use wet hands when plugging/unplugging the power
cable.
• Electrical supply voltage must conform to the voltage
specifications (208-240V, 60Hz) located on the appliance. For
this purpose, a junction box (as seen in picture below) must be
obtained. Junction box is supplied with Blomberg Clothes Dryer
(model no.: DHP 24412 W / DHP 24401 W) and it works as a
voltage converter from 110/120V to 208/240V between the wall
power and appliance.
• Only one appliance must be connected to a properly grounded
individual branch circuit outlet.
• Be sure to unplug the power cable before attempting
maintenance or cleaning of your appliance to minimize the risk of
electric shock. Always unplug the cable by grasping the plug, not
the cord.
• Do not use wet hands when plugging/unplugging the power
cable.

20 / English
Front-Loading Automatic Washer
Installation Instructions
Power supply and circuit
Connect the clothes washer to the junction box supplied. Junction
box must be connected to an earthed outlet protected by a fuse of
suitable capacity.
Important:
• Wall power connection should comply with national regulations.
• The voltage and maximum total current are specified in the section
“Specifications”.
• The appliance must not be directly connected to the wall power in
case of absence of junction box.
• Connection via extension cords or multi-plugs should not be made.
BWARNING
• A damaged power cable must be replaced by a qualified
electrician.
• The appliance must not be operated unless it is repaired! There
is the risk of electric shock!
15 Amp. Fuse or circuit breaker, 208-240 volt, 60 Hz, grounded,
alternating current
Properly grounded 3-prong receptacle and junction box to be located
so the power supply cords are accessible when the washer is in
installed position.
