Blue Star PRO LINE PL30240 Instruction and safety manual

© Copyright 2012 Prizer –Painter Stoves Works “REV 1 – 6/14/2012”
INSTALLATION, USE AND CARE MANUAL
FOR PROFESSIONAL VENTILLATION FOR
THE HOME
IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE MAKING
ANY CONNECTIONS.
8. TO AVOID RISK OF FIRE , ELECTRIC SHOCK, OR INJURY TO PERSONS, TURN OFF THE ELECTRIC-
ITY TO THE HOOD FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING.
This product is intended for domestic use only!
P/N 750306 Page 1

TABLE OF CONTENTS
Table of Contents ................................................................................................................................... 2
Safety Instructions............................................................................................................................... 3-4
Introduction ............................................................................................................................................ 5
Welcome ................................................................................................................................................ 6
Handling & Unpacking .......................................................................................................................... 7
Packing list for your Vent Hood ....................................................................................................... 8-9
Pro Line Hoods ......................................................................................................................... 8
Pyramid Style Hoods ............................................................................................................... 9
Low Profile and Re-Circulating hoods .................................................................................. 10
Installation of Pro Line Series
Dimensions…………. .. ……………………………………………………………………11
Site Preparation …………………………………………………………………………….. 12
The Correct Height …………………………………………………………………………...13
Duct Information ……………………………………………………………………………..14
Blower Installation …………………………………………………………………………...15
Custom Duct Installation ……………………………………………………………………..16
Installation of Pyramid Style
Dimensions ............................................................................................................................. 17
Site Preparation .................................................................................................................... 18
The Correct Height ................................................................................................................ 19
Duct Information ................................................................................................................... 20
Blower Installation ................................................................................................................ 21
Flue Installation ..................................................................................................................... 22
Installation of Low Profile Series
Dimensions ............................................................................................................................. 23
Site Preparation .................................................................................................................... 24
The Correct Height ................................................................................................................ 25
Duct Information and Wiring ................................................................................................ 26
Installation of Low Profile Re-Circulating Series
Dimensions ............................................................................................................................. 27
Site Preparation .................................................................................................................... 28
The Correct Height and Wiring ............................................................................................. 29
Cleaning and Maintenance ................................................................................................................. 30
Warranty.......................................................................................................................................... 31-32
Performance Checklist .................................................................................................................... 33-34
P/N 750306 Page 2

IMPORTANT!—PLEASE READ AND FOLLOW
1. THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION.
2. DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER’S WARRANTY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
3. THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RE-
TAIN THEM FOR FUTURE REFERENCE.
4. PLEASE OBSERVE ALL LOCAL AND NATIONAL BUILDING CODES AND ORDINANCES. IF NO LO-
CAL CODES ARE APPLICABLE, PLEASE FOLLOW ALL WIRING REQUIREMENTS IN ACCORDANCE
WITH THE NATIONAL ELECTRICAL CODE, ANSI/NFPA 70 EDITION.
5. PLEASE CHECK WITH A QUALIFIED AND TRAINED INSTALLER OR YOUR LOCAL CODES FOR ANY
MAKE UP AIR REQUIREMENTS.
6. THIS HOOD IS FOR RESIDENTIAL USE ONLY AND IS NOT DESIGNED FOR INSTALLATION OVER A
COMMERCIAL PRODUCT.
7. MAKE SURE ALL POWER IS TURNED OFF AT THE MAIN BREAKER OR FUSE BOX BEFORE SERVIC-
ING OR MAKING ANY CONNECTIONS.
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
 USE THIS UNIT IN THE MANNER INTENDED
BY THE MANUFACTURER, IF YOU HAVE
ANY QUESTIONS PLEASE CALL 800-449-8691
 BEFORE CLEANING OR SERVICING UNIT,
SWITCH POWER OFF TO THE UNIT AT THE
SERVICE PANEL AND LOCK OUT THE SER-
VICE PANEL. IF THE SERVICE PANEL CAN-
NOT BE LOCKED OUT, PLEASE AFIX A
WARNING DEVICE PROMINENTLY, SUCH AS
A TAG, TO THE SERVICE PANEL.
WARNING! WARNING!
P/N 750306 Page 3
TO REDUCE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
 INSTALLATION WORK AND ELECTRICAL
WORK MUST BE PERFORMED BY QUALIFIED
INDIVIDUALS IN ACCORDANCE WITH ALL
APPLICABLE CODES AND STANDARDS, IN-
CLUDING ALL FIRE RATED CONSTRUCTION
 DO NOT DAMAGE ANY EXISTING ELECTRI-
CAL OR HIDDEN UTILITIES WHEN DRILL-
ING , CUTTING AND/OR REMOVING A WALL,
CEILING OR FLOOR
 DUCTED FANS MUST VENT OUTDOORS
 SUFFICIENT AIR IS REQUIRED TO PROPERLY
EXHAUST GASES THROUGH THE FLUE OF
NATURAL AND LIQUID PROPANE FUELED
COOKING EQUIPMENT TO AVOID ANY BACK
DRAFTING. FOLLOW ALL LOCAL AND NA-
TIONAL CODES AND STANDARDS FOR
PROPER AIR REQUIREMENTS.
 USE ONLY METAL DUCTWORK
 NEVER VENT DUCTED EXHAUST AIR INTO
ANOTHER ROOM OR GARAGE. TO REDUCE
THE RISK OF FIRE AND TO PROPERLY VENT
EXHAUST AIR, DUCT MUST VENT OUT-
DOORS
WARNING!
TO REDUCE THE RISK OF A RANGETOP GREASE
FIRE:
 NEVER LEAVE THE APPLIANCE UNAT-
TENDED DURING USE. BOIL-OVERS MAY
OCCUR, CAUSING SPILLS WHICH MAY IG-
NITE.
 DO NOT USE WATER ON GREASE FIRES.
NEVER PICK UP A FLAMING PAN. IT IS REC-
OMMENDED YOU PURCHASE A MULTI-
PURPOSE DRY CHEMICAL OR FOAM-TYPE
FIRE EXTINGUISHER FOR YOUR HOME.
STORE IT IN CLOSE PROXIMITY TO YOUR
APPLIANCES.

TO REDUCE THE RISK OF A RANGETOP GREASE FIRE (CONTINUED):
 IF YOU ARE FLAMING LIQUOR OR OTHER SPIRITS, AND YOUR APPLIANCE IS INSTALLED UNDER
A VENT HOOD, TURN THE FAN OFF. THE DRAFT CREATED COULD CAUSE THE FLAMES TO
SPREAD OUT OF CONTROL.
 FOR YOUR SAFETY, NEVER USE YOUR APPLIANCE OR ANY OTHER COOKING APPLIANCE AS A
SPACE HEATER TO WARM OR HEAT THE ROOM.
 USE ONLY DRY POTHOLDERS. MOIST OR DAMP POTHOLDERS ON HOT SURFACES MAY RESULT
IN STEAM BURNS. DO NOT ALLOW POTHOLDERS TO TOUCH HOT BURNER AREAS. DO NOT USE
A TOWEL OR OTHER BULKY MATERIAL AS A POTHOLDER.
 TO REDUCE THE RISK OF BURNS, IGNITION OF FLAMMABLE MATERIALS, AND SPILLAGE, THE
HANDLE OF ANY POT OR PAN SHOULD BE POSITIONED SO THAT IT DOES NOT EXTEND OVER
ADJACENT BURNERS OR THE FRONT OF THE APPLIANCE.
 CLEAN VENTILATING FANS AND GREASE BAFFLES OFTEN. GREASE SHOULD NOT BE ALLOWED
TO ACCUMULATE .
WARNING!
WARNING!
TO REDUCE RISK OF INJURY TO PERSONS DUE TO A GREASE FIRE:
 SMOTHER THE FLAMES WITH A CLOSE FITTING LID, COOKIE SHEET OR METAL TRAY, THEN
TURN OFF THE BURNER. TAKE CARE TO AVOID AND PREVENT BURNS. IF FLAMES DO NOT EX-
TINGUISH, EVACUATE THE PREMISES AND CALL THE FIRE DEPARTMENT
 NEVER HANDLE OR PICK UP A FLAMING PAN.
 DO NOT USE WATER, INCLUDING WET DISHCLOTHS, OR TOWELS. A VIOLENT STEAM EXPLO-
SION MAY ENSUE
 DO NOT TURN ON HOOD TO EVACUATE SMOKE. TURN OFF HOOD
 USE AN EXTINGUISHER ONLY IF:
 YOU HAVE A CLASS ABC EXTINGUISHER AND YOU CAN OPERATE IT
 THE FIRE IS SMALL AND CONTAINED WHERE IT STARTED
 THE FIRE DEPARTMENT HAS BEEN NOTIFIED
 YOU CAN FIGHT THE FIRE WITH YOUR BACK TOWARDS AN UNOBSTRUCTED EXIT
WARNING!
P/N 750306 Page 4
 THIS PRODUCT IS FOR GENERAL VENTILATION APPLICATIONS. DO NOT USE TO EXHAUST HAZ-
ARDOUS, FLAMMABLE, OR EXPLOSIVE MATERIALS
 PRIOR TO CLEANING OR SERVICING THE UNIT, SWITCH POWER OFF AT THE SERVICE PANEL
AND LOCK OUT THE PANEL. IF THE PANEL CANNOT BE LOCKED OUT, AFFIX A PROMINENT
WARNING TAG TO THE SERVICE PANEL.
 DO NOT USE PORCELAIN OR ABRASIVE CLEANERS ON THIS PRODUCT. THIS MAY RESULT IN
COSMETIC DAMAGE TO THE SURFACE LIKE SCRATCHES AND/OR DISCOLORIZATION
 ALL BRASS TRIM PIECES REQUIRE SPECIAL CLEANING. DO NOT USE ABRASIVE CLEANERS OR
FURNITURE POLISH. THIS WILL RESULT IN DISCOLORIZATION TO THE BRASS SURFACE

Since 1880, we have been dedicated to quality! We believe that our success can only be measured
by the continuing success of our customers. We achieve customer satisfaction by ensuring that
each of our employees understands, meets and exceeds customer expectations. We establish and
maintain an environment that encourages all employees to pursue continuous improvement in qual-
ity and productivity.
Our quality policy is monitored by the highest levels of management.
We hope you enjoy your new appliance and we THANK YOU again for believing in our product
as much as we do.
The staff and team at Prizer Stove Works !
LOW PROFILE HOOD RECIRCULATING LOW PROFILE HOOD
PRO LINE HOOD PYRAMID HOOD
P/N 750306 Page 5
