BMW Motorrad C 400 X Installation and maintenance manual

RIDER'S MANUAL
C 400 X
BMW
MOTORRAD
MAKE LIFE A RIDE

Vehicle data
Model
Vehicle identification number
Color number
First registration
License plate
Retailer data
Contact in Service
Ms./Mr
Phone number
Retailer's address/Phone (company stamp)

YOUR BMW.
We are pleased that you have chosen a BMW Motorrad vehicle
and welcome you to the family of BMW riders. Familiarize your-
self with your new vehicle so that you can ride safely and confi-
dently in all traffic situations.
About these operating instructions
Read these operating instructions before starting your new BMW.
It contains important notes about operating the vehicle that will
enable you to make full use of the technical assets of your BMW.
You will also obtain preventive maintenance and care instructions,
which are beneficial to operating and road safety and help retain
the value of your vehicle as much as possible.
If you should decide to sell your BMW one day, please remember
to hand over these operating instructions as well. They are an
important part of your vehicle.
We wish you many miles of safe and enjoyable riding with your
BMW
BMW Motorrad.

01 GENERAL
INSTRUCTIONS 2
Overview 4
Abbreviations and sym-
bols 4
Equipment 5
Technical data 5
Notice concerning cur-
rent status 6
Additional sources of
information 6
Certificates and operat-
ing permits 6
Data memory 6
02 OVERVIEWS 12
General view, left side 14
General view, right
side 15
Underneath the seat 16
Multifunction switch,
left 17
Multifunction switch,
right 18
Cockpit 19
Cockpit 20
Instrument cluster 21
Instrument cluster with
connectivity 22
03 DISPLAYS 24
Indicator and warning
lights 26
Multifunction display 27
Indicator lights 28
Service display 37
Oil level indicator 38
Ambient temperature 38
Indicator and warning
lights with connectivity 40
TFT display in Pure
view 41
TFT display in the
View menu 42
Indicator lights with
connectivity 43
04 OPERATION 60
Ignition switch/steer-
ing lock 62
Ignition with Key-
less Ride 63
Emergency on/off
switch (kill switch) 67
Lights 67
Hazard warning lights 68
Turn indicators 69
Multifunction display 70
SETUP 72
General settings on the
multifunction display 74
Heated grips 76
Seat heating 77
Seat 78
Storage compartments 79

05 TFT DISPLAY 82
General notes 84
Principle 85
Pure and Urban views 91
General settings 91
Onboard computer 93
Bluetooth 94
My Vehicle 97
Navigation 99
Media 101
Phone 101
Display software ver-
sion 102
Display license infor-
mation 102
06 ANTI-THEFT
ALARM SYSTEM 104
Overview 106
Activation 106
Alarm function 109
Deactivation 110
Programming 111
07 SETTING 112
Mirrors 114
Headlights 114
Spring preload 114
08 RIDING 116
Safety instructions 118
Observe checklist 120
Starting 121
Riding 123
Breaking in 123
Brakes 124
Parking the Scooter 125
Refueling 126
Refueling 128
Version 1 128
Version 2 129
Open fuel filler cap
emergency release 130
Close fuel filler cap
emergency release 130
Securing the vehicle
for transport 130
09 TECHNOLOGY IN
DETAIL 134
General notes 136
Antilock Brake Sys-
tem (ABS) 136
Automatic Stability
Control (ASC) 138
10 MAINTENANCE 140
General notes 142
Standard tool kit 142
Front-wheel stand 143
Engine oil 144
Brake system 146
Coolant 150
Tires 151
Rims and tires 152
Wheels 153
Fuses 165
Light sources 167
Battery 167

Trim panel compo-
nents 173
Diagnostic socket 175
11 ACCESSORIES 178
General notes 180
Power socket 180
USB charging socket 181
Topcase 182
Navigation system 184
12 CARE 188
Care products 190
Washing your motor-
cycle 190
Cleaning sensitive
vehicle parts 191
Paint care 192
Protective wax coat-
ing 192
Storing the Scooter 192
Putting the scooter
into operation 193
13 TECHNICAL DATA 194
Troubleshooting chart 196
Screw connections 199
Fuel 201
Engine oil 201
Engine 202
Clutch 202
Transmission 202
Rear-wheel drive 202
Frame 203
Chassis 203
Brakes 203
Wheels and tires 204
Electrical system 205
Anti-theft alarm sys-
tem 206
Keyless Ride 206
Dimensions 207
Weights 207
Performance data 208
14 SERVICE 210
Reporting safety de-
fects 212
BMW Motorrad
Service 213
BMW Motorrad
Service Manual 213
BMW Motorrad Mo-
bility Services 214
Maintenance proce-
dures 214
Maintenance sched-
ule 216
Maintenance confir-
mations 217
Service confirmations 234

APPENDIX 236
Certificate for elec-
tronic immobilizer 237
Certificate for Key-
less Ride 239
Declaration of con-
formity for anti-theft
alarm 243
Certificate for TFT
instrument cluster 248
INDEX 252

GENERAL
INSTRUCTIONS
01

OVERVIEW 4
ABBREVIATIONS AND SYMBOLS 4
EQUIPMENT 5
TECHNICAL DATA 5
NOTICE CONCERNING CURRENT STATUS 6
ADDITIONAL SOURCES OF INFORMATION 6
CERTIFICATES AND OPERATING PERMITS 6
DATA MEMORY 6

4 GENERAL INSTRUCTIONS
OVERVIEW
Chapter 2 of this Rider's Man-
ual will provide you with an ini-
tial overview of your Scooter.
All maintenance and repair
work carried out on your ve-
hicle will be documented in
Chapter 14. Documentation
of the maintenance work per-
formed is a prerequisite for
generous treatment of claims.
If you ever decide to sell your
Scooter, please remember to
include this Rider's Manual; it is
an important part of the vehi-
cle.
ABBREVIATIONS AND SYM-
BOLS
CAUTION Hazard with
low risk. Failure to avoid
this hazard can result in minor
or moderate injury.
WARNING Hazard with
moderate risk. Failure to
avoid this hazard can result in
death or serious injury.
DANGER Hazard with
high risk. Failure to avoid
this hazard results in death or
serious injury.
ATTENTION Special
instructions and pre-
cautionary measures. Non-
compliance can cause damage
to the vehicle or accessories
and warranty claims may be
denied as a result.
NOTICE Special infor-
mation on operating and
inspecting your motorcycle as
well as maintenance and ad-
justment procedures.
Instruction.
Result of an activity.
Reference to a page
with more detailed
information.
Indicates the end of
accessory or equip-
ment-dependent infor-
mation.
Tightening torque.
Technical data.
NV National-market ver-
sion.
OE Optional equipment.
BMW Motorrad op-
tional equipment is
already completely in-
stalled during motor-
cycle production.

5
OA Optional accessories.
BMW Motorrad
optional accessories
can be purchased
and retrofitted at
your authorized
BMW Motorrad
retailer.
EWS Electronic immobilizer.
DWA Anti-theft alarm.
ABS Anti-Lock Brake Sys-
tem.
ASC Automatic Stability
Control.
CVT Continuously variable
transmission.
Transmission with a
continuously variable
gear ratio
EQUIPMENT
When you ordered your
Scooter, you chose various
custom equipment items.
This Rider's Manual describes
optional equipment (OE)
offered by BMW and selected
optional accessories (OA). This
explains why the manual may
also contain descriptions of
equipment which you have
not ordered. Please note, too,
that your vehicle might not be
exactly as illustrated in this
manual on account of country-
specific differences.
If your Scooter was supplied
with equipment not described
in this rider's manual, you will
find these features described in
a separate manual.
TECHNICAL DATA
All dimensions, weights and
performance data contained
in these operating instructions
refer to the German Institute
for Standardization i.e. DIN
(Deutsches Institut für Nor-
mung e. V.) and comply with
their tolerance specifications.
The technical data and spec-
ifications in these operating
instructions serve as points of
reference. The vehicle-specific
data may vary, for instance due
to the selected optional equip-
ment, national-market version
or country-specific measuring
procedures. Detailed values can
be obtained from the registra-
tion documents or requested
from your BMW Motorrad re-
tailer or other qualified service
partner or specialist workshop.
The information on the vehicle
documents always takes prece-
dence over the information in
these operating instructions.

6 GENERAL INSTRUCTIONS
NOTICE CONCERNING CUR-
RENT STATUS
The high safety and quality
standards of BMW Scooters
are maintained by consistent,
ongoing development efforts
embracing their design, equip-
ment, and accessories. For this
reason, some aspects of your
vehicle may vary from the de-
scriptions in this rider's man-
ual. In addition, BMW Motorrad
cannot guarantee the total ab-
sence of errors. We hope you
will appreciate that no claims
can be recognized based on
the data, illustrations or de-
scriptions in this manual.
ADDITIONAL SOURCES OF
INFORMATION
BMW Motorrad retailer
Your BMW Motorrad retailer is
always happy to answer any of
your questions.
Internet
The Operating Instructions for
your motorcycle, the operating
and installation instructions for
optional accessories and gen-
eral BMW Motorrad informa-
tion related to the technology
or other features are available
at bmw-motorrad.com/manu-
als.
CERTIFICATES AND OPERAT-
ING PERMITS
The certificates for the vehi-
cle and the official operating
permits for possible acces-
sories are available at bmw-
motorrad.com/certification.
DATA MEMORY
General information
Control units are installed in
the vehicle. Control units pro-
cess data received from vehicle
sensors, self-generated data or
data exchanged between con-
trol units, for example. Some
control units are required for
safe vehicle operation or pro-
vide riding assistance, such as
driver assistance systems. Con-
trol units also make comfort
and infotainment functions pos-
sible.
Information about the stored
or exchanged data can be ob-
tained from the vehicle manu-
facturer, such as in the form of
a separate booklet.
Personal references
Every vehicle is marked with
a unique vehicle identifica-
tion number. Depending on
the country, the vehicle owner
can be identified using the
vehicle identification number

7
and license plate and with the
help of the relevant authorities.
There are also other ways to
trace data obtained from the
vehicle back to the driver or
vehicle owner, such as via the
ConnectedDrive Account that
was used.
Data privacy laws
In accordance with applicable
data privacy laws, vehicle users
have certain rights over the ve-
hicle manufacturer or company
that collects or processes per-
sonal data.
Vehicle users have the right to
obtain comprehensive informa-
tion without charge from the
locations that store the vehicle
user's personal data.
These locations may be:
The vehicle manufacturer
Qualified service partners
Specialist workshops
Service providers
Vehicle users may request in-
formation about the type of
personal data that is stored, the
purpose for which the data will
be used and the source of the
data. This information can only
be obtained by a registered
owner or a person with written
proof authorizing use of the ve-
hicle.
The right to information also
includes information related
to data transmitted to other
companies or locations.
The vehicle manufacturer's
website contains the appro-
priate privacy policy notices.
The privacy policy notices con-
tain information on the right
to delete or correct data. The
vehicle manufacturer also pro-
vides the manufacturer contact
information and the contact in-
formation of the data security
officer.
The vehicle owner can have
a BMW Motorrad retailer or
other qualified service partner
or specialist workshop read out
the data stored in the vehicle
for a fee if required.
The vehicle data is read out via
the vehicle's legally mandated
socket for onboard diagnosis
(OBD).
Legal requirements for the
disclosure of data
The vehicle manufacture is re-
quired by the law applicable in
this context to provide authori-
ties with the data stored by the
manufacturer. Providing this
data within the scope required
is on a case-by-case basis, for
instance to clarify a criminal of-
fense.

8 GENERAL INSTRUCTIONS
Government agencies are au-
thorized by the law applicable
in this context to read out the
data from the vehicle them-
selves in individual cases.
Operating data in the vehicle
Control units process data so
that the vehicle can run.
Examples of this include:
Status messages from the ve-
hicle and its individual com-
ponents, such as wheel RPM,
wheel speed and deceleration
Environmental conditions,
such as temperature
The data is processed only in
the vehicle itself and is usu-
ally temporary. The data is not
stored beyond the period in
which the vehicle is operating.
Electronic components such
as control units contain com-
ponents for storing technical
information. This may be infor-
mation about the vehicle's con-
dition, component load, events
or faults stored temporarily or
permanently.
This information generally doc-
uments the condition of a com-
ponent, module, system or the
surrounding area; for example:
Operating conditions of sys-
tem components, such as fill
levels and tire pressure
Malfunctions and faults in key
system components, such as
lights and brakes
Vehicle responses in specific
riding situations, such as the
activation of driving stability
control systems
Information about events
causing damage to the vehicle
The data is necessary for pro-
viding control unit functions. In
addition, it is used by the vehi-
cle manufacturer to detect and
eliminate malfunctions as well
as to optimize vehicle func-
tions.
The majority of this data is
temporary and is processed
only within the vehicle itself.
Only a small amount of event-
driven data is stored in the
event data recorder and fault
memory.
When a vehicle is serviced,
such as for repairs, servicing
processes, warranty cases and
quality assurance measures,
this technical information can
be read out from the vehicle
together with the vehicle iden-
tification number.
The information can be read
out by a BMW Motorrad re-

9
tailer or other qualified service
partner or specialist workshop.
The vehicle's legally mandated
socket for onboard diagnosis
(OBD) is used to read out the
data.
The data is collected, pro-
cessed and used by the
respective retailer network
locations. The data documents
the vehicle's technical states
and helps with fault finding,
compliance with warranty
obligations and quality
improvements.
The manufacturer also has
product monitoring obligations
arising from product liability
law. The vehicle manufacturer
requires technical data from
the vehicle in order to fulfill
these obligations. The data
from the vehicle can also be
used to verify customer war-
ranty and guarantee claims.
The fault memory and event
data recorder in the vehicle can
be reset by a BMW Motorrad
retailer or other qualified
service partner or specialist
workshop as part of a repair or
servicing.
Data input and data transfer
in the vehicle
General information
Depending on the equipment,
comfort settings and individual-
ized settings in the vehicle can
be saved and changed or reset
at any time.
Examples of this include:
Windshield position settings
Chassis and suspension ad-
justment settings
It is possible to introduce data
into the vehicle entertainment
and communication system via
a smartphone, for instance.
Depending on the individual
equipment, this includes:
Multimedia data, such as mu-
sic for playback
Address book data for use in
conjunction with a commu-
nication system or integrated
navigation system
Entered navigation destina-
tions
Data about the use of Inter-
net services. This data can
be stored locally in the ve-
hicle or is on a device con-
nected to the vehicle, such
as a smartphone, USB stick
or MP3 player. If this data is
saved in the vehicle, it can be
deleted at any time.

10 GENERAL INSTRUCTIONS
This data is transmitted to third
parties only upon personal re-
quest as part of the use of on-
line services. The data trans-
mitted depends on the selected
settings when using the ser-
vices.
Integrating mobile end de-
vices
Depending on the equipment,
mobile end devices connected
to the vehicle, such as smart-
phones, are controlled using
the vehicle's operating ele-
ments.
This enables audio and visual
output from mobile end de-
vices through the multimedia
system. At the same time, cer-
tain information is transmitted
to the mobile end device. This
includes for instance position
data and other general vehicle
data, depending on the type of
integration, and makes it pos-
sible to optimize the use of se-
lected apps, such as those for
navigation or audio playback.
The way the data is processed
further is determined by the
provider of the particular app
used. The range of possible
settings depends on the par-
ticular app and the operating
system of the mobile end de-
vice.
Services
General information
If the vehicle has a mobile
phone connection, this
connection makes it possible
to exchange data between
the vehicle and other systems.
The mobile phone connection
is made possible through
the vehicle's transmitter and
receiver or via personally
integrated mobile end devices
such as smartphones. Online
functions, as they are called, are
used over this mobile phone
connection. These include on-
line services and apps provided
by the vehicle manufacturer or
other providers.
Vehicle manufacturer ser-
vices
In the case of the vehicle man-
ufacturer's online services, the
particular functions are de-
scribed at the appropriate lo-
cation, such as in the operating
instructions or on manufactur-
er's website. The relevant legal
information on data privacy is
also provided there. Personal
data may be used in order to
provide online services. The
data is exchanged over a se-
cure connection, i.e. with the
vehicle manufacturer's IT sys-

11
tems which are intended for
this purpose.
Any collection, processing and
use of personal data that goes
beyond the provision of ser-
vices take place only as per-
mitted by law, on the basis of
a contractual agreement or as
a result of consent. It is also
possible to have the entire data
connection activated or deacti-
vated. This is not the case for
legally prescribed functions.
Services of other providers
When using the online services
of other providers, these ser-
vices are subject to the respon-
sibility and the data protection
and usage conditions of the re-
spective provider. The vehicle
manufacturer has no control
over the content exchanged
via these services. Informa-
tion about the type, scope and
purpose of collecting and us-
ing personal data as part of
third-party services can be
obtained from the particular
service provider.

OVERVIEWS
02

GENERAL VIEW, LEFT SIDE 14
GENERAL VIEW, RIGHT SIDE 15
UNDERNEATH THE SEAT 16
MULTIFUNCTION SWITCH, LEFT 17
MULTIFUNCTION SWITCH, RIGHT 18
COCKPIT 19
COCKPIT 20
INSTRUMENT CLUSTER 21
INSTRUMENT CLUSTER WITH CONNECTIVITY 22

14 OVERVIEWS
GENERAL VIEW, LEFT SIDE
1Brake fluid expansion tank
for the rear wheel brake
( 149)
2Under the battery cover:
Battery ( 167)
Fuses ( 165)
Data link connector
( 175)
3Spring preload setting
( 114)
4Fuel filler opening
( 126) ( 128)
5Coolant expansion tank
(under left fairing side
panel) ( 151)
