BMW Motorrad

G 450 X

The new BMW G 450 X Sport Enduro is a unique motorcycle that completely rede²nes enduro riding. That’s because it’s been designed from the

ground up to deliver the sort of traction dreams are made of, with a brand new single-cylinder engine and a revolutionary patented swing-arm design.

After extensive testing, the G 450 X is ready, willing and able to take on the toughest competition around.

UNSTOPPABLE – THE NEW G 450 X.

Our engineers set the bar high when designing the new G 450 X,

and resolved to build a motorcycle that would meet the ver y highest

standards in off-road racing. The result is a truly revolutionary frame

design, with a swing-arm pivot point that shares its axle line with the

drive sprocket. This ensures that the length of the drive chain – and

as a result, the ef²ciency of the transmission – is not affected by the

compression and rebound of the suspension.

It also saves space, meaning there is room for a swing-arm that is

signi²cantly longer than on other bikes with a comparable wheelbase,

for maximum ground contact and traction on any surface. This design

also allows the engine to be placed further back, which means the

vehicle’s mass is now more concentrated around its center of gravity.

By angling the engine for wards, additional space is created for long,

straight intake pipes that help the G 450 X to meet the latest emission

regulations without compromising on performance.

The motorcycle’s innovative, patented technology has been extensively

tested in competition, with experienced professional racers such as Joël

Smets, Kari Tiainen, Simo Kirssi and Andreas Lettenbichler providing

valuable feedback used to ²ne-tune its setup. This incredible motorcycle

is now available for anyone to buy, and is ready to tackle the toughest

courses the off-road world can throw at it.

TECHNICAL DETAILS:

BMW G 450 X DESIGN CONCEPT

The frame of the BMW G 450 X is a completely new design. It is made

up of exceptionally thin stainless steel tubing with very few bends. The

down tubes run in a straight line directly from the swing-arm mounting to

the steering head, while the top tubes connect the steering head to the

suspension strut. This keeps down the amount of materials used, and

offers maximum strength and stiffness with minimum weight. As a result,

the motorcycle handles impeccably, is highly manoeuvrable and offers

excellent directional stability. This new layout also frees up extra space

for the radiator, which is now a single component, removing the need

for additional hoses and so further reducing overall weight. However,

what makes the chassis truly unique is the way in which the swing-arm

and drive sprocket now pivot about the same point. The swing-arm is

mounted on a steel axle that passes through the transmission output

shaft, meaning that the length of the drive chain remains constant,

whatever the suspension travel. The tension in the chain remains

constant, and the pinion, chain and chain ring wear considerably less

than in conventional systems. This coaxial swing-arm mounting also

lessens the impact of load changes on the drive train. And the swing-arm

itself can be 1.2 inches (30 millimeters) without extending the overall

wheelbase, meaning that better ground contact is maintained in all

situations and power is put down more effectively onto the ground.

Being unstoppable means doing things better than the rest. The design of the swing-arm is nothing short

of revolutionary: for the ²rst time ever on a production motorcycle, its pivot point shares an axle line with the

drive sprocket. As a result, the compression and rebound of the suspension do not alter the length of the

chain, and so do not impair the ef²ciency of the drive train.

It also means that the length of the swing-arm can be signi²cantly increased, without needing

to extend the wheelbase, and that the engine can be positioned further to the rear. These two

factors greatly increase traction and ground contact in off-road riding. As a further unique innovation,

the frame is made almost entirely of straight tubing, offering exceptional rigidity. All these design

innovations offer bene²ts that you’ll feel right away – and never want to be without again.

UNSTOPPABLE TRACTION.

COMES FROM REVOLUTIONARY

FRAME/SWING-ARM DESIGN.

TECHNICAL DETAILS:

FRAME AND PATENTED

SWING-ARM DESIGN

The key to unstoppable performance is an unbeatable engine – an engine like the ultra-modern DOHC single-cylinder unit found

in the G 450 X. Because it is angled forwards, the air intakes are straight and long, ensuring the engine receives all the air it needs

to deliver punchy yet supremely controllable responses right across the rev range. In addition, the innovative

positioning of the clutch directly on the crankshaft minimizes the amount of torque it has to handle, and as a

result its size and weight can be signi²cantly reduced.

UNSTOPPABLE TRACTION.

COMES FROM AN OUTSTANDING ENGINE.

The 449-cc single-cylinder engine found in the BMW G 450 X produces

41 horsepower at 7,000 rpm and 31.7 lb/ft of torque at 6,500 rpm.

It features a catalytic converter which is homologated for on-road use*

and offers all the power you need for an incredible riding experience.

Should you wish to further increase performance however, simply

insert a small engine chip and you can boost output to 52 horsepower

at 9,000 rpm, and torque to 32,5 lb/ft at 7,800 rpm (original silencer

with catalytic converter must be replaced with Sport silencer so this

Full Power Mode is for off-road use only). The short-cylinder, four-stroke

DOHC engine is another BMW innovation: while the inlet valves of the

compact four-valve cylinder head are actuated via rocker arms, a bucket

tappet is employed for the outlet valve. Digital engine management

and two sequential throttle valves also further improve performance,

and ensure that the engine reacts precisely to throttle inputs. Unlike on

most motorcycles, the clutch is now mounted directly on the crankshaft

and can thus be more compact, as its increased revolutions reduce the

amount of torque it needs to transfer. Furthermore, the engine is angled

forwards, optimizing weight distribution and allowing straighter – and

therefore more ef²cient – intake pipes. The air ²lter is made of a smooth

foam ³eece and can be changed quickly and effortlessly. Finally, the

standard silencer with catalytic converter can easily be swapped for

an AkrapoviĖ®titanium slip-on system for competition riding (optional,

not homologated for on-road use).

* At this tim e, 49-state roa d-legal onl y; Californ ia road-lega l model will be in troduced at a la ter date.

TECHNICAL DETAILS:

ENGINE

To be truly unstoppable, you need outstanding grip, which means maximum ground contact at all speeds and

on all surfaces. The front of the G 450 X features a fully adjustable Marzocchi upside-down fork with 11.8 inches

(300 millimeters) of travel, which effortlessly handles even the bumpiest terrain. At the rear is a fully adjustable Öhlins monoshock suspension system, also

fully adjustable and with 12.6 inches (320 millimeters) of travel. All this sophisticated engineering has been introduced with one aim and one aim only –

making you and your machine unstoppable.

UNSTOPPABLE TRACTION.

COMES FROM A SUPERB CHASSIS.

The rear wheel of the BMW G 450 X measures 18 inches in diameter

and is held in place by a robust aluminum double swing-arm. An Öhlins

suspension strut is attached to this via bolted aluminum brackets, offering

12.6 inches (320 millimeters) of travel, and fully adjustable compression

and rebound damping. The spring preload can also be adjusted, via ring

nuts. The 21-inch front wheel features an upside-down Marzocchi fork

and 1.7 inches (45 millimeters) stanchion tubes. This too is fully adjustable

for both compression and rebound damping, and travel here is 11.8 inches

(300 millimeters). Stopping power is provided by a Brembo brake

system, with a double-piston ³oating caliper at the front, and a single-

piston ³oating caliper at the rear. The diameter of the front brake disc is

10.2 inches (260 millimeters), while that at the rear measures 8.6 inches

(220 millimeters). To protect the G 450 X in the most challenging off-road

conditions, the motorcycle also features a shatterproof lightweight plastic

bash plate, which has already proven its worth in competition riding.

TECHNICAL DETAILS:

CHASSIS

Being unstoppable means being in complete control. And that takes more than the right combination of frame,

engine and chassis. Whether you’re travelling uphill or down, sitting or standing, it is vital that you, the rider,

are always in a comfortable position. The G 450 X is an exceptionally well-balanced machine, with a slim body, and a long, ³at seat.

And to give you maximum freedom of movement and a low center of gravity, the fuel tank is located underneath the rider seat.

UNSTOPPABLE TRACTION.

COMES FROM A PERFECT RIDING POSITION.

The design of the BMW G 450 X is at once instantly recognizable as a

BMW machine and highly ergonomic. From the steering head to the back

of the seat, the bike is unusually narrow, offering the rider exceptional

freedom of movement. The fuel tank is located beneath the seat, so it

never gets in the rider’s way, and this makes a major difference when

standing (the ²ller cap is integrated into the seat). The airbox is positioned

relatively high up, underneath the front part of the seat, so it is ver y well

protected from dust and when riding through water. The single-section

seat is made of special moulded foam – there is no cover, substructure

or base, saving further weight. The motorcycle’s wide foot pegs are

extremely practical and offer excellent grip for feet due to their serrated

edges, while the double-butted aluminum Magura handlebars can be

adjusted by up to 0.8 inches (20 millimeters), ensuring exceptional control

and comfort.

TECHNICAL DETAILS:

RIDING POSITION

ALUMINUM BASH PLATE

Made of high-strength aluminum, this bash plate of fers

additional protection during extreme riding. The thinness

of the materials employed means it does not af fect the

G 450 X’s slimline pro²le.

G 450 X IN DETAIL:

ACCESSORIES

OVERVIEW.

SMALL SPOILER ATTACHMENTS

FOR ALUMINUM HAND

PROTECTORS

Plastic de³ectors of fer further protection around the hand

area. They are screwed onto the aluminum hand guards.

LOW SEAT, BLACK

Reducing the seat height by 0.8 inches (20 millimeters)

offers shorter riders better control of their machine when

riding off-road.

ALUMINUM HAND PROTECTORS

These closed-loop hand protectors guard the hands and

control levers when riding off-road, and in the event of a fall

or light impact. They consist of aluminum bars with aluminum

guards screwed onto them.

MX HAND PROTECTORS

These plastic hand protectors are open at the outside and

offer effective protection for the hands and control levers

during off-road riding.

REAR BAG

MOUNTING RAIL FOR REAR BAG

Additional storage for small items, tools or a ²rst-aid kit.

Made of hard-wearing, water-resistant material, the rear

bag is ideally suited to off-road riding. It is fastened to

the aluminum mounting rail.

SLIP-ON RACING SILENCER (NOT

HOMOLOGATED FOR ON-ROAD USE)

Featuring the same design as the standard silencer, the racing

edition is considerably lighter than the standard component

(by 2.2 lbs.), due to the absence of the catalytic converter. It can

easily be ²tted in place of the standard silencer, and no further

modi²cations are required. ( When ²tted with the racing silencer,

the G 450 X is not homologated for on-road use)

AKRAPOVIC®TITANIUM RACING

EXHAUST MANIFOLD (NOT

HOMOLOGATED FOR ON-ROAD USE)

AKRAPOVIC®TITANIUM SLIP-ON

RACING SILENCER (NOT HOMOLOGATED

FOR ON-ROAD USE)

Designed in conjunction with the experts at Akrapovic®, these

high-quality competition components improve performance and

signi²cantly reduce weight (by 4.4 lbs. compared with standard

components). Exceptionally well made, with racy styling and a rich

throaty sound, the slip-on racing silencer can be ²tted in seconds.

It is suitable for use with either the titanium racing exhaust manifold

or the standard version. (When ²tted with the titanium racing

silencer and/or the titanium racing exhaust manifold, the G 450 X

is not homologated for on-road use.)

CHAIN GUARD

The drive chain of the G 450 X is highly durable anyway, but

the chain guard extends its service life still further. It resembles

a rubber tube in form and covers the chain in its entirety,

protecting it against dirt and reducing wear and tear.

WATERPROOF RACE POCKET

(TIME CARD POCKET)

The race pocket is ideal for storing time cards during enduro

events, but can also be used for small items such as mobile

phones or cash. Its transparent front means the contents are

visible at all times.

Relevant ²gure s refer to the DIN st andard de²nit ion of an unladen b ike. 1) Unladen we ight without op erating ³uids a nd battery. 2) As de²ned in E U directive 92 /93/EEC, ²lle d with all oper ating ³uids, fu elled to at least 9 0% of usable ta nk capacit y.

At this tim e, 49-state road -legal only ; California r oad-legal mo del will be intro duced at a later d ate.

ENGINE

Type Water-cooled four-stroke, single-cylinder engine, four valves,

twin overhead camshaft, dry sump lubrication

Bore x stroke 3.9 inches x 2.3 inches (98 mm x 59.6 mm)

Capacity 449.5 cm3

Max. output

(homologated for road use)

41 hp at 7,000 rpm

unrestricted (with sport silencer, no

catalytic converter) (off-road use only)

52 hp at 9,000 rpm

Max. torque

(homologated for road use)

31 lb/ft at 6,500 rpm

unrestricted (with sport silencer, no

catalytic converter) (off-road use only)

32.5 lb/ft at 7,800 rpm

Compression ratio 12:1

Fuel/engine management Electronic intake pipe injection/Keihin digital engine

management with overrun cut-off

Emission control Regulated 2-way catalytic converter

Fuel type Premium Unleaded

ELECTRICS

Alternator 280-W three-phase generator

Battery 12 V/7 Ah, maintenance-free

TRANSMISSION

Clutch Wet multidisc clutch, mechanically operated, primary clutch

mounted directly on crankshaft

Gears Synchromesh 5-speed gearbox, built into engine housing

Primary drive ratio

Final drive ratio

2:62

15:48 (13:48, 14:48)

Spare parts: 48–49 – 50– 51 chain rings

CHASSIS/BRAKES

Frame Bridge-type tubular frame made of high-strength

stainless steel, aluminum rear frame

Handlebars Double-butted, aluminum,

diameter 1.1/0.9 inches (28/22 mm)

Suspension, front Marzocchi upside-down telescopic fork,

adjustable compression and rebound

Suspension, rear Die-cast aluminum double swing-arm, Öhlins strut, adjustable

compression and rebound, adjustable spring preload

Tr av e l, f r o nt / r ea r 11.8 inches/12.6 inches (300 mm/320 mm)

Wheelbase (in normal position) 58.1 inches (1,475 mm)

Castor (in normal position) 4.7 inches (118.8 mm)

Steering head angle

(in normal position)

61.8°

Rim dimensions, front 1.60 x 21"

Rim dimensions, rear 2.15 x 18"

Tire, front 90/90-21

Tire, rear 140 /80 -18

Brakes, front Single disc brake, diameter 10.2 inches (260 mm),

double-piston ³oating caliper

Brakes, rear Single disc brake, diameter 8.6 inches (220 mm),

single-piston ³oating caliper

DIMENSIONS/WEIGHT

Seat height 37.6 inches (955 mm), 36.8 inches (935 mm)

with optional low seat

Dry weight1244.7 lbs.

Wet weight2266.8 lbs.

Usable tank capacity US version approx. 1.8 U.S. gal.

Of which reserve 0.2 U.S. gal.

TECHNICAL DATA

RACING WHITE

www.bmwmotorcycles.com

This catalog shows the European speci²cation F 800 GS model, which may vary from the U.S. speci²cation model in some respects. Please note that some of the BMW apparel shown may not be available in the U.S., or at all BMW Motorrad USA dealers. BMW is not responsible for printing errors and reserves the right to change

options, pricing or standard features on this model as required. For up-to-date information on this model and all BMW motorcycles, please visit your BMW Motorrad USA dealer or ride the web at www.bmwmotorcycles.com. Subject to change and error. © BMW Motorrad, UX-VM-2, Munich, Germany. Not to be reproduced,
