BMW R nineT 2019 Installation and maintenance manual

Rider's manual
R nineT
BMW Motorrad

Vehicle data/dealership details
Vehicle data
Model
Vehicle Identification Number
Colour code
Date of first registration
Registration number
Dealership details
Person to contact in Service department
Ms/Mr
Phone number
Dealership address/phone number (com-
pany stamp)

Welcome to BMW
We congratulate you on
your choice of a vehicle from
BMW Motorrad and welcome
you to the community of BMW
riders. Familiarise yourself with
your new vehicle so that you can
ride it safely and confidently in all
traffic situations.
About these operating
instructions
Read these operating instructions
carefully before starting to use
your new BMW. They contain
important information on how to
operate the controls and how to
make the best possible use of all
your BMW's technical features.
In addition, they contain informa-
tion on maintenance and care to
help you maintain your vehicle's
reliability and safety, as well as its
value.
The record of the maintenance
work you have had performed on
your vehicle is a precondition for
generous treatment of goodwill
claims.
If the time comes to sell your
BMW, please remember to hand
over these operating instructions
to the new owner. They are an
important part of the vehicle.
Suggestions and criticism
If you have questions concern-
ing your vehicle, your authorised
BMW Motorrad dealer will gladly
provide advice and assistance.
We hope you will enjoy riding
your BMW and that all your jour-
neys will be pleasant and safe
BMW Motorrad.
01 40 1 614 971
*01401614971*
*01401614971*
*01401614971*

Table of Contents
1 General instructions ... . 5
Overview..................... 6
Abbreviations and
symbols...................... 6
Equipment ................... 7
Technical data . . . . . . . . . . . . . . . 7
Currency ..................... 7
Additional sources of informa-
tion........................... 8
Certificates and operating li-
cences ....................... 8
Data memory................. 8
2 General views .. .. .. .. .. . 13
General view, left side . . . . . . . 15
General view, right side . . . . . 17
Underneath the seat . . . . . . . . 18
Multifunction switch, left . . . . 19
Multifunction switch,
right......................... 20
Instrument panel . . . . . . . . . . . . 21
3 Status indicators . . . . . . . 23
Indicator and warning
lights ........................ 24
Multifunction displays . . . . . . . 25
Warnings.................... 26
Service-due indicator . . . . . . . . 35
Riding time.................. 35
4 Operation................ 37
Ignition switch/steering
lock ......................... 38
Emergency off switch (kill
switch) ...................... 40
Lights ....................... 40
Hazard warning lights sys-
tem ......................... 42
Turn indicators . . . . . . . . . . . . . . 42
Reading ..................... 44
Anti-theft alarm (DWA) . . . . . . 49
Clock........................ 50
Date......................... 51
Adjusting brightness . . . . . . . . 52
Antilock Brake System
(ABS)........................ 53
Automatic Stability Control
(ASC) ....................... 54
Heated handlebar grips . . . . . 55
Front and rear seats . . . . . . . . . 56
5 Adjustment . .. .. .. .. .. .. . 59
Mirrors ...................... 60
Headlight.................... 60
Clutch....................... 61
Brakes ...................... 62
Spring preload . . . . . . . . . . . . . . 63
Damping .................... 65
Adjustable footrest sys-
tem ......................... 67
6 Riding.................... 73
Safety information . . . . . . . . . . . 74
Comply with checklist . . . . . . . 76
Starting...................... 76
Runningin .................. 79
Brakes ...................... 80
Parking your motorcycle . . . . 81
Refuelling ................... 81
Securing motorcycle for
transportation . . . . . . . . . . . . . . . 83

7 Engineering details.. . . . 85
General instructions . . . . . . . . . 86
Anti-lock brake system
(ABS)........................ 86
Automatic Stability Control
(ASC) ....................... 88
8 Maintenance . . . . . . . . . . . . 91
General instructions . . . . . . . . . 92
Toolkit....................... 92
Front-wheel stand . . . . . . . . . . . 93
Rear-wheel stand . . . . . . . . . . . 94
Engine oil ................... 95
Brake system . . . . . . . . . . . . . . . 97
Clutch..................... 102
Tyres...................... 102
Rims and tyres . . . . . . . . . . . . 102
Wheels.................... 103
Headlight.................. 111
Light source . . . . . . . . . . . . . . . 112
Starting aid . . . . . . . . . . . . . . . . 116
Battery .................... 117
Fuses ..................... 119
Diagnostic connector . . . . . . 121
9 Accessories .. .. .. .. .. . 123
General instructions . . . . . . . 124
Power sockets . . . . . . . . . . . . 124
Luggage .................. 125
Passenger frame . . . . . . . . . . 125
Tail-hump cover . . . . . . . . . . . 131
Optional accessories . . . . . . 133
10 Care .................. 135
Care products . . . . . . . . . . . . . 136
Washing the vehicle . . . . . . . 136
Cleaning easily damaged
components . . . . . . . . . . . . . . . 137
Care of paintwork . . . . . . . . . 138
Paint preservation . . . . . . . . . 138
Laying up the motor-
cycle ...................... 138
Restoring motorcycle to
use........................ 138
11 Technical data . . . . . . 141
Troubleshooting chart . . . . . 142
Screw connections . . . . . . . . 143
Fuel....................... 146
Engine oil ................. 147
Engine .................... 147
Clutch..................... 148
Transmission . . . . . . . . . . . . . . 148
Final drive ................. 149
Frame..................... 150
Chassis and
suspension................ 150
Brakes .................... 152
Wheels and tyres. . . . . . . . . . 153
Electrical system . . . . . . . . . . 154
Dimensions . . . . . . . . . . . . . . . 155
Weights ................... 156
Performance figures . . . . . . . 156
12 Service ............... 157
BMW Motorrad Service . . . 158
BMW Motorrad Service
history..................... 158
BMW Motorrad mobility
services ................... 159
Maintenance work . . . . . . . . . 159
Maintenance schedule . . . . 163
Maintenance confirma-
tions....................... 164
Service confirmations . . . . . 178

13 Appendix. . . . . . . . . . . . . 181
Declaration of conform-
ity for electronic immobil-
iser........................ 182
Certificate for electronic
immobiliser . . . . . . . . . . . . . . . . 188
Certificate for anti-theft
alarm...................... 190
14 Index ................. 196

General instructions
Overview ............................ 6
Abbreviations and symbols . . . . . . . . . . 6
Equipment........................... 7
Technicaldata....................... 7
Currency............................. 7
Additional sources of information . . . . 8
Certificates and operating
licences.............................. 8
Datamemory ........................ 8
1
5
z General instructions

Overview
An important aspect of this
Rider's Manual is that it can
be used for quick and easy
reference. Consulting the
extensive index at the end of this
Rider's Manual is the fastest way
to find information on a particular
topic or item. Refer to Chapter
2 for an initial overview of your
motorcycle. All maintenance and
repair work on the motorcycle
is documented in Chapter 12.
This record of the maintenance
work you have had performed on
your vehicle is a precondition for
generous treatment of goodwill
claims.
When the time comes to sell
your BMW, please remember
to hand over this Rider's Manual;
it is an important part of the mo-
torcycle.
Abbreviations and
symbols
CAUTION Low-risk hazard.
Non-avoidance can lead to
slight or moderate injury.
WARNING Medium-risk
hazard. Non-avoidance can
lead to fatal or severe injury.
DANGER High-risk haz-
ard. Non-avoidance leads
to fatal or severe injury.
ATTENTION Special
notes and precautionary
measures. Non-compliance can
lead to damage to the vehicle or
accessory and, consequently, to
voiding of the warranty.
NOTICE Specific instruc-
tions on how to operate,
control, adjust or look after items
of equipment on the vehicle.
Indicates the end of an
item of information.
Instruction.
Result of an activity.
Reference to a page with
more detailed informa-
tion.
Indicates the end of a
passage relating to spe-
cific accessories or items
of equipment.
Tightening torque.
Technical data.
OE Optional equipment.
The vehicles are as-
sembled complete with
all the BMW Motorrad
optional equipment ori-
ginally ordered.
1
6
z General instructions

OA Optional accessories.
You can obtain
BMW Motorrad
optional accessories
through your authorised
BMW Motorrad dealer;
optional accessories
have to be retrofitted to
the vehicle.
NV National-market version.
EWS Electronic immobiliser.
DWA Anti-theft alarm.
ABS Anti-lock brake system.
Equipment
When you purchased your BMW
motorcycle, you chose a model
with individual equipment. These
operating instructions describe
the optional equipment (OE)
offered by BMW and selected
optional accessories (OA).
This explains why the manual
may also contain descriptions
of equipment that you might
not have selected. Please
note, too, that on account of
country-specific differences, your
motorcycle might not be exactly
as illustrated.
If your motorcycle contains
equipment that has not been
described, its description can be
found in a separate manual.
Technical data
All dimensions, weights and
power ratings stated in the
operating instructions are quoted
to the standards and comply with
the tolerance requirements of the
Deutsches Institut für Normung
e.V. (DIN).
Technical data and specifications
in this rider's manual serve as
reference points. The vehicle-
specific data may deviate from
these, for example as a result of
selected optional equipment,
the national-market version or
country-specific measuring
procedures. Detailed values
can be taken from the vehicle
registration documents and
signs on the vehicle, or can be
obtained from your authorised
BMW Motorrad Retailer or
another qualified service partner
or specialist workshop. The
specifications in the vehicle
documents always have priority
over the information provided in
this rider's manual.
Currency
The high safety and quality
standards of BMW motorcycles
are maintained by constant
development work on designs,
equipment and accessories.
Because of this, your motorcycle
may differ from the information
supplied in these instructions.
Nor can BMW Motorrad entirely
1
7
z General instructions

rule out errors and omissions.
We hope you will appreciate that
no claims can be entertained on
the basis of the data, illustrations
or descriptions in these operating
instructions.
Additional sources of
information
Authorised BMW Motorrad
dealer
Your BMW Motorrad Retailer will
be happy to answer any ques-
tions you may have.
Internet
The rider's manual for your
vehicle, operating and installation
instructions for any accessories
and general information on
BMW Motorrad, for example
relating to technology, are
available at www.bmw-
motorrad.com/service.
Certificates and
operating licences
The certificates for the vehicle
and the official operating licences
for any accessories are available
at www.bmw-motorrad.com/
certification.
Data memory
General
Control units are installed in the
vehicle. Control units process
data that they receive, for ex-
ample, from vehicle sensors, or
that they generate themselves or
exchange between each other.
Some control units are required
for the vehicle to function safely
or provide assistance during rid-
ing, for example assistance sys-
tems. In addition, control units
enable comfort or infotainment
functions.
Information on data that has
been stored or exchanged can
be obtained from the manufac-
turer of the vehicle, for example
via a separate booklet.
Personal reference
Each vehicle is identified with a
clear vehicle identification num-
ber. Depending on the country,
the vehicle identification num-
ber, the number plate and the
corresponding authorities can
be referenced to ascertain the
vehicle owner. There are also
other ways to use data obtained
from the vehicle to trace the rider
or vehicle owner, for example
using the ConnectedDrive user
account.
Data protection rights
In accordance with applicable
data protection laws, vehicle
users have certain rights in re-
lation to the manufacturer of the
vehicle or in relation to compan-
1
8
z General instructions

ies which collect or process per-
sonal data.
Vehicle users have the right to
obtain full information at no cost
from persons or entities storing
personal data of the vehicle user.
These entities may include:
Manufacturer of the vehicle
Qualified service partners
Specialist workshops
Service providers
Vehicle users have the right to
request information on what per-
sonal data has been stored, for
what purpose the data is used,
and where the data comes from.
To obtain this information, proof
of ownership or use is required.
The right to information also in-
cludes information about data
that has been shared with other
companies or entities.
The website of the vehicle man-
ufacturer contains the applicable
data protection information. This
data protection information in-
cludes information on the right to
have data deleted or corrected.
The manufacturer of the vehicle
also provides their contact details
and those of the data protection
officer on their website.
The vehicle owner can also re-
quest that a BMW Motorrad Re-
tailer or another qualified service
partner or specialist workshop
read out the data that is stored in
the vehicle for a charge.
The vehicle data is read out us-
ing the legally prescribed socket
for on-board diagnosis (OBD) in
the vehicle.
Legal requirements for the
disclosure of data
As part of its legal responsib-
ilities, the manufacturer of the
vehicle is obligated to make its
stored data available to the rel-
evant authorities. This data is
provided in the required scope in
individual cases, for example to
clarify a criminal offence.
In the context of applicable laws,
public agencies are entitled in
individual cases to read out data
from the vehicle themselves.
Operating data in the vehicle
Control units process data to op-
erate the vehicle.
This includes, for example:
Status reports of the vehicle
and its individual components,
for example wheel revolutions,
wheel speed, deceleration
Environmental conditions, for
example temperature
The data is only processed in
the vehicle itself and is gener-
ally non-permanent. The data is
not stored beyond the operating
period.
Electronic components, for ex-
ample control units, contain com-
ponents for storing technical in-
1
9
z General instructions

formation. Information can be
temporarily or permanently stored
on the vehicle condition, com-
ponent loads, incidents or errors.
This information is generally used
to document the condition of a
component, a module, a system
or the surrounding area, for ex-
ample:
Operating conditions of system
components, for example filling
levels, tyre pressure
Malfunctions and faults in im-
portant system components,
for example light and brakes
Response of the vehicle in
special riding situations, for
example engagement of the
driving dynamics systems
Information on incidents result-
ing in damage to the vehicle
The data is necessary for the
provision of control unit functions.
Furthermore, the data is used to
detect and rectify malfunctions
and to enable the vehicle manu-
facturer to optimise vehicle func-
tions.
The vast majority of this data is
non-permanent and is only pro-
cessed in the vehicle itself. Only
a small amount of the data is
stored in incident or fault memor-
ies as required by events.
If services are accessed, for ex-
ample repairs, service processes,
warranty cases and quality assur-
ance measures, this technical in-
formation can be read out of the
vehicle together with the vehicle
identification number.
The information can be read out
by a BMW Motorrad Retailer or
another qualified service part-
ner or specialist workshop. The
legally stipulated socket for on-
board diagnosis (OBD) in the
vehicle is used to read out the
data.
The data is obtained, processed
and used by the relevant parts of
the retailer network. The data is
used to document the technical
conditions of the vehicle, to help
with error localization, to comply
with warranty obligations and to
improve quality.
In addition, the manufacturer has
various product monitoring ob-
ligations arising from product li-
ability legislation. To meet these
obligations, the vehicle manu-
facturer requires technical data
from the vehicle. The data from
the vehicle can also be used to
check warranty claims from the
customer.
Error and incident memories in
the vehicle can be reset dur-
ing servicing or repair work by
a BMW Motorrad Retailer or an-
other qualified service partner or
specialist workshop.
1
10
z General instructions

Data input and data transfer
in the vehicle
General
Depending on the equipment,
comfort and customised settings
can be stored in the vehicle and
can be changed or reset at any
time.
This includes, for example:
Settings of the windscreen po-
sition
Chassis and suspension set-
tings
If required, data can be entered
in the entertainment and commu-
nication system of the vehicle, for
example using a smartphone.
Depending on the individual
equipment, this includes:
Multimedia data, such as music
for playback
Contacts data for use in con-
nection with a communication
system or an integrated naviga-
tion system
Entered destinations
Data on the use of internet
services. This data can be
stored locally in the vehicle
or is located on a device that
is connected to the vehicle,
for example smartphone, USB
stick, MP3 player. If this data is
stored in the vehicle, the data
can be deleted at any time.
This data is transferred to third
parties only if personally reques-
ted within the context of using
online services. This depends on
the selected settings when using
the services.
Incorporation of mobile end
devices
Depending on the equipment,
mobile end devices connected to
the vehicle, for example smart-
phones, can be controlled using
the operating elements of the
vehicle.
The image and sound of the mo-
bile end device can then be out-
put via the multimedia system.
At the same time, specific in-
formation is transferred to the
mobile end device. Depending
on the type of integration, this in-
cludes, for example, position data
and additional general vehicle in-
formation. This enables optimal
use of the selected apps, for ex-
ample navigation or music play-
back.
The type of additional data pro-
cessing is determined by the
provider of the respective app.
The scope of the possible set-
tings depends on the corres-
ponding app and the operating
system of the mobile end device.
Services
General
If the vehicle has a wireless con-
nection, this enables the ex-
change of data between the
1
11
z General instructions

vehicle and other systems. The
wireless connection is enabled by
the vehicle's own transmitter and
receiver unit or using personally
integrated mobile end devices,
for example smartphones. On-
line functions can be used using
this wireless connection. These
include online services and apps
that are provided by the vehicle
manufacturer or by other pro-
viders.
Services of the vehicle manu-
facturer
For online services of the vehicle
manufacturer, the individual
functions are described at
suitable points, for example
rider's manual, website of the
manufacturer. At the same time,
information is also provided on
the relevant data protection law.
Personal data may be used to
provide online services. Data
is exchanged using a secure
connection, for example with
the IT systems provided by the
vehicle manufacturer.
Obtaining, processing and us-
ing personal data outside of the
normal provision of services re-
quires legal permission, contrac-
tual agreement or consent. It is
also possible to have the entire
data connection activated or de-
activated. Statutory functions are
excluded from this.
Services from other providers
When using online services from
other providers, these services
are subject to the responsibil-
ity and the data protection and
operating conditions of the indi-
vidual provider. The vehicle man-
ufacturer has no influence on the
content that is exchanged in this
instance. Information on the type,
scope and purpose of the data
capture and use of personal data
as part of the services of third
parties can be ascertained from
the individual provider.
1
12
z General instructions

General views
General view, left side . . . . . . . . . . . . . . . 15
General view, right side . . . . . . . . . . . . . 17
Underneath the seat . . . . . . . . . . . . . . . . 18
Multifunction switch, left . . . . . . . . . . . . 19
Multifunction switch, right . . . . . . . . . . . 20
Instrumentpanel.................... 21
2
13
z General views

2
14
z General views

General view, left side
1Adjusting damping char-
acteristic for front wheel
( 65)
2Checking clutch function
( 102)
3Refuelling ( 82)
4Removing rear-seat frame
( 125)
5Adjusting the damping
characteristic for rear
wheel ( 67)
6Power sockets ( 124)
7Checking engine oil level
( 95)
8Type plate (on the left of
the steering-head bearing)
2
15
z General views

2
16
z General views

General view, right side
1Checking brake-fluid level,
front brakes ( 100)
2Topping up the engine oil
( 96)
3Vehicle identification num-
ber (front right at the bot-
tom on the rear frame)
4Checking the brake-fluid
level, rear brakes ( 101)
5Adjusting the spring pre-
load ( 64)
6Removing rear seat
( 56)
2
17
z General views

Underneath the seat
1Operating instructions
2Remote positive terminal
( 116)
3Fuse box
Replace fuses ( 119).
4Tyre pressures table
5Payload table
6Toolkit ( 92)
7Diagnostic connector
Disengaging diagnostic
connector ( 121).
2
18
z General views
