OWNER’S MANUAL
How to employ your intelligent floor cleaner
bObi Pet
Model NW604001
3
Congratulations!
Congratulations on your new intelligent floor cleaner! bObi is now at your service. To
see bObi at her best, please read the Quick Start Guide and this manual thoroughly.
Welcome to the bObsweep family and happy cleaning!
If you have any questions or concerns, feel free to contact our helpful team at:
Our business hours are Monday – Friday 9 am – 5 pm, PST.
Charging Station Warranty Information
& FAQs
End User
License Agreement
Get bObi
Ready to Clean
Troubleshooting
& Checkup Test
Important Safety
Instructions
Remote Control
Installing Battery 16
First Charge 17
First Cleaning 19
Touchscreen Buttons 20
Placement 24
Auto Charging 25
Syncing Station 25
Manual Charging 27
Defining Boundaries 31
Syncing blOck™ 33
blOck™ Placement 35
Controls 38
Syncing Remote 40
Error Codes 75
Home Checkup Test 80
Cleaning Behavior 91
Remote Screen 44
Set Current Time 46
Set Cleaning Schedule 48
Auto-Resume 51
Mini Mop 56
Dustbin 58
Main Brushes 62
Side Brush 66
UV Light 67
Front Wheel 68
Sensors 69
Blindfold Stickers 70
Storage 71
blOck™
Box Contents Setting bObi’s
Cleaning Schedule
Anatomy Parts &
Maintenance
14 72
6 36
28
10 54
22 92 98
8 42
Basic safety precautions should always be followed, including the following:
•To protect against electrical shock, do not immerse any part of bObi — with the exception
of her mopping cloth — into water or other liquids. bObi’s dustbin may be washed with water
only once her motor has been removed.
• Turn bObi OFF and unplug her from outlet when she is not in use and before conducting
maintenance.
• If bObi, her remote control, charging station, or blOck has been damaged, do not operate
•Do not handle bObi, her remote control, blOck (not included), or her charging station with wet
hands; use only on dry surfaces.
•Do not use bObi outdoors.
• bObi is not intended for use by persons (including children) with reduced physical or mental
capabilities, or lack of experience and knowledge, unless under the close supervision of a
person responsible for their safety.
• Do not pull or carry the charging station by the cord, use the cord as a handle, close a door
on the cord, or pull the cord around sharp edges or corners. Keep the cord away from heated
surfaces. To unplug the cord grasp the plug, not the cord.
• Do not mutilate or incinerate the battery, as it will explode at high temperatures.
•Leaks from battery cells can occur under extreme usage or temperature conditions. If the liquid
gets on skin, wash quickly with water. If the liquid gets into the eyes, flush them immediately
with clean water for a minimum of 10 minutes, and seek medical attention.
•Do not dispose of your battery in fire. Old batteries should be recycled safely (check with your
local recycler).
•Do not attempt to open the charging station. Repairs on the station should only be carried out
by our qualified customer care center.
•Do not expose bObi, her remote control, or charging station to temperatures higher than 113° F
(45° C), moisture, or humidity.
•Do not let bObi pick up toxic materials (chlorine bleach, ammonia, drain cleaner, etc.).
• Do not let bObi pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes. Do not use bObi to pick up flammable or combustible liquids such as gasoline, nor
use her in areas where they may be present.
• Do not use bObi in an enclosed space filled with vapors given off by oil-based paint, paint
thinner, moth-proofing substances, flammable dust, or other explosive or toxic vapors.
•bObi is composed of electronic components that in rare and unintended cases can cause
hazards of heating, fire, and other malfunctions. Furthermore, because bObi is capable of and
intended for autonomous movement and cleaning, her use poses the risk of collision with
property, pets, and persons and unintended removal of articles, such as small valuables, jewelry,
or hair of persons or pets lying on the floor, among others.
• Do not look directly into the UV light.
• Do not use bObi for other than intended usage.
Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modi-
fications or change to this equipment. Such modifications or change could void the user’s authority
to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Important Safety Instructions
8
Box Contents
1 bObi, Your Intelligent Floor Cleaner
2 Charging Station
3 Spare Main Brush
4 Charging Adapter
5 Remote Control
6 bObi blOck™
7 Spare Side Brush
8 Cleaning Tool
9 Pack of Screws
10 Blindfold Stickers
11 Mini-Mop Attachment
12 Mopping Cloths
13 Spare HEPA Filter
14 Owners’ Manual, Quick Start Guide, Warranty Card
15 Syncing Tool
16 Screwdriver
17 2 Spare Main Brush Holders
1
2
3
4
56
7
9
10
11
8
12
13
14
17
15 16
10 11
Top View
Anatomy
Top View
1Cover
2Touchscreen Buttons
3Transmitter
4 Charging Indicator
5Touch Sensors
6Wall Sensors
7Charging Inlet
8Power Switch
Bottom View
1Main Brush
2Rubber Brush
3Dustbin
4Right Wheel
5Left Wheel
6Side Brush
7Edge Sensors
8Front Wheel
9UV Light
10 Battery
Anatomy
RL
1
2
5
4
6
5
4
3
2
1
6
7
8
7 78
9
10
3
12 13
1Charging Station
2Remote Control
3blOck™
Touchscreen Buttons
1GO!
bObi will clean on her default cleaning mode
2JUICE
bObi will search for her charging station to refuel
3WAFFLE
bObi will clean localized mess
1
2
3
2 31
Get bObi
Ready to Clean
16 17
Before bObi’s first clean, you must install her battery. Make sure bObi’s power
switch is turned OFF.
After installing bObi’s battery, charge bObi for 8 hours before first use.
bObi will chirp, her lights will flash, and the center light will blink to indicate that
she is charging. The other lights will disappear.
Install bObi’s Battery Charge bObi
Remove the battery cover
using a Phillips head
screwdriver.
Plug the battery in at the
circuit junction. Tuck the
wire into the side of the
compartment and slide
the battery in.
Replace the cover and re-
tighten the screws.
1 2 3
Plug the charging adapter into the side
of the charging station. The station’s red
power light will turn on.
Place bObi on her charging station with
the metal nodes on her front resting
against the plates on her station.
1 2
The center light on bObi
will remain solid when
she is fully charged and
ready to clean.
18 19
Alternatively, you may charge bObi by plugging the charging adapter into the
inlet above her power switch.
bObi is now ready to clean!
Flip her power switch ON, and press the GO! button on her cover or remote.
bObi will clean on her default setting.
If bObi is left idle with her power switch ON, her screen will go blank and she
will enter standby mode. To wake bObi, tap her touchscreen. To fully power off
bObi, flip her power switch OFF.
bObi’s First Clean
Clear the area of small
items and cords before
asking bObi to clean.
20 21
There are three touchscreen buttons on bObi: GO!, JUICE, and WAFFLE.
These buttons do not work while bObi is on her charging station. To use these
buttons, you must first remove bObi from her charging station.
Alternatively, you can use bObi’s remote to select her cleaning modes without
needing to remove her from her charging station.
Touchscreen Buttons
GO!
GO! is bObi’s default cleaning mode. bObi will clean a large area until her
battery reaches 15% capacity, and then she will return to her charging station.
JUICE
JUICE tells bObi to return to her charging station. bObi will not clean while
in JUICE mode.
WAFFLE
WAFFLE can be used to clean up small spills of dry substances. bObi will clean
an area of 10 square feet (1 square meter) for about 1 – 3 minutes before she
stops and enters standby mode.
Charging Station
25
• Position bObi’s charging station against a wall on a hard, flat surface.
•Make sure that there is at least 10 feet (3 m) of open space in front of the
charging station and 2 feet (0.5 m) on either side of the station.
Secure bObi’s charging adapter behind her station so the cord does not
get in her way while she is cleaning.
Charging Station Placement
2 ft (0.5 m)
2 ft (0.5 m)
10 ft (3 m)
bObi automatically searches for her charging station when her battery reaches
15% capacity. She will chirp, stop vacuuming, and display JUICE on her cover
while searching. When bObi detects her charging station, she will line herself
up, dock, and begin to charge.
If bObi has trouble finding her station, you likely need to sync the station.
To sync the charging station:
Auto Charging
Flip bObi’s power switch
OFF.
Plug the adapter into the
charging station.
Use the syncing tool that
came in bObi’s box to
press the sync button on
the back of the station.
1 2 3
27
While still pressing the sync button, flip
bObi’s power switch ON.
Direct bObi to her charging station at any
time by pressing the JUICE button on her
cover or remote.
bObi will chirp twice to let you know the
sync was successful.
4 5
To prolong bObi’s battery
life, ip her power switch
OFF when not in use.
Using the charging station:
•Place bObi on her charging station with the metal nodes on her front
resting against the plates on her station.
Using the adapter:
•Plug the charging adapter directly into the inlet above bObi’s power switch.
Manual Charging
blOck™
30
If you need to keep certain areas out of bObi’s reach, you can use blOck™to
create a digital barrier that bObi will not cross. blOck™ runs on 4 AA batteries
(not included).
A digital barrier is emitted from the front of blOck™. There are two buttons on
the back of blOck™:
1Power Button
2Sync Button
To set up digital barriers with blOck™:
Press the power button. The red power light on the front of blOck™ will turn on,
stay on for 10 seconds, and then slowly blink every 3 seconds.
When blOck™ is low on battery, the power light flashes more quickly than
usual to indicate that it needs new batteries. To conserve battery, switch
blOck™ OFF when not in use.
blOck™
blOck™ remains ON for 3
hours before automatically
turning OFF to conserve
battery.
1 2
32 33
To conserve battery,
it is recommended to
turn blOck™ OFF after
each use.
To turn blOck™ OFF:
Press the power button again. The red power light on the front of blOck™ will
disappear.
If bObi does not respond to her blOck™, blOck™ likely needs to be synced.
To sync blOck™:
Switch both bObi and blOck™ OFF.
The power light on the front of blOck™ will
turn on, stay still for 10 seconds, and then
slowly blink every 3 seconds.
Press the power button on the back of
block™.
1 2
34 35
While holding down blOck™’s sync
button, flip bObi’s power switch ON.
bObi will chirp twice to let you know the
sync was successful.
3 4
blOck™ emits its digital barrier from the front. The front of blOck™ is the side
where the red power light is.
Position blOck™ with its front facing the direction you would like to create
a barrier. For example, see the image below where blOck™ is placed at the
opening of a doorway.
blOck™ Placement
blOck™ creates a barrier measuring
about 10 ft. The barrier’s signal gradually
weakens at the far end.
You can sync multiple
blOcks™ with bObi.
Remote Control
38 39
The remote control is your most useful tool when communicating with bObi. It
allows you to set bObi’s cleaning schedule and activate her cleaning modes.
Each time you select an action on the remote, bObi will chirp once before per-
forming the selected action.
1CUR TIME (Current Time)
2SCH TIME (Schedule Time)
3ALL/NONE
4UV
5HI/BYE
6OK
7Navigational Arrows
8STOP
9SPEED
10 JUICE
11 WAFFLE
12 GO!
Remote Control
CUR TIME (Current Time)
•Sets the current time and weekday.
SCH TIME (Schedule Time)
• Sets bObi’s cleaning schedule.
ALL/NONE
•Selects/deselects all weekdays.
UV
•Turns bObi’s UV light ON and OFF.
HI/BYE
•Puts bObi in and out of standby mode.
OK
•Confirms selection.
Navigational Arrows
•Guide bObi forward, backward, left, and right.
STOP
•Pauses or resumes bObi’s movement.
SPEED
•Alternates between bObi’s two speeds.
JUICE
•Sends bObi to her charging station.
WAFFLE
•bObi will clean a localized mess.
GO!
• bObi will clean on her default cleaning mode.
5 6
2 12
111
310
49
7
8
Table of contents
Other bObi Vacuum Cleaner manuals
